User's GuideSLAU258 – August 2008
TAS5602EVM2 Audio Power Amplifier Evaluation Module
Contents1 Introduction ................................................................................................................... 12 Operation ..................................................................................................................... 23 Reference ..................................................................................................................... 5
List of Figures
1 Suggested Process Flow for TAS5602EVM2 ............................................................................ 22 TAS3308EVM/ TAS5602EVM2 External Connections.................................................................. 33 TAS5602EVM2 Schematic ................................................................................................. 54 TAS5602EVM2 – Top Side Layout ........................................................................................ 65 TAS5602EVM2 – Bottom Side Layout .................................................................................... 6
List of Tables
1 Bill of Materials for TAS5602EVM2 – BDBTL ............................................................................ 7
The TAS5602EVM2 evaluation module consists of a single class-D stereo audio power amplifier completewith a small number of external components mounted on a circuit board that can be used to directly drivespeakers using a TAS3308 EVM as the input. The input connector for the TAS5602EVM2 is configured toconnect directly to the TAS3308 EVM PWM connector. The TAS5602EVM2 can be configured to drive 2stereo BTL channels up to 20W/ch or 4 SE (single-ended) channels up to 10/ch. It is also possible toconfigure the EVM to drive speakers in a 2.1 configuration with 2 channels of SE stereo and one channelof BTL subwoofer. The user can also connect to the TAS5602EVM2 input with a ribbon cable from atarget system if desired.
This document assumes that the user has obtained a TAS3308 EVM and has set up the PurePathStudio™ software on a test computer with USB interface. The Quick Setup Guide in the TAS3308 EVMUser's Guide (TI document SLEU093 ) describes a method to get the TAS3308 EVM up and runningefficiently.
The TAS3308 EVM outputs 6 PWM channels plus a VALID/SYNC signal. The six PWM channels aregrouped into three stereo channels named PWM1 L and R, PWM2 L and R, and PWM3 L and R. TheTAS5602EVM2 is configured to connect to PWM3, which consists of 4 output lines
VALUE UNIT
V
CC
Supply voltage range 10 to 26 VI
CC
Supply current 4 A rmsP
O
Continuous output power per channel: 8 ΩBTL, VCC = 18 V, THD+N = 10% 20 WR
L
Minimum load impedance, 4 Ω
PurePath Studio is a trademark of Texas Instruments.
SLAU258 – August 2008 TAS5602EVM2 Audio Power Amplifier Evaluation Module 1Submit Documentation Feedback

2 Operation
2.1 Quick Start Guide for use with TAS3308 Digital Audio Signal Processor
Operation www.ti.com
Follow these steps to use the TAS5602EVM2 along with the TAS3308 EVM. Power and speakerconnections to the EVM module can be made by inserting stripped wire or using banana plugs for thepower supply and output connections. The inputs can be connected directly to the TAS3308 EVM via the2×20 pin header. Set up the TAS3308 according to the instructions given in the TAS3308EVM User'sGuide (SLEU093 ). Download the TAS5602 configuration file from the TAS5602 product folder. This can beused to optimize the TAS3308 set-up for the TAS5602 power stage.
Some additional adjustments to the Pure Path Studio™ setup for TAS3308 may be necessary to run theTAS5602EVM2.
1. The input selection is performed by selecting the StereoMux and changing the Mux Select Property toStereoCh1 or StereoCh2 depending on the type of signal being used. Select StereoCh1(TAS3308ADCIn-1) if it is Analog input; select StereoCh2 (TAS3308SAPIn-1) if it is SPDIF formatdigital input.2. Build the process flow above and select Build/Generate Code3. Select Build/Download, and then Run.4. Press the Mute button on the TAS3308 EVM to turn it to the OFF state. The MUTE indicator LEDshould turn off. This is necessary since the TAS3308 EVM transitions to the run mode with the MUTEin the ON state.
Figure 1. Suggested Process Flow for TAS5602EVM2
TAS5602EVM2 Audio Power Amplifier Evaluation Module2 SLAU258 – August 2008Submit Documentation Feedback

2.2 Connect the TAS3308 EVM to TAS5602EVM2
USB
Input
Optical Input
9V Supply
Inputs
10-26V Supply
Inputs
TAS5602 Power
Stage
TAS3308 Audio
System
2.3 Power Supply
2.4 Evaluation Module Preparations
www.ti.com Operation
Place the TAS3308 EVM and TAS5602EVM2 at the same height and let the 40 pin connector on eachboard face each other. Push them together carefully until they make a solid connection
Figure 2. TAS3308EVM/ TAS5602EVM2 External Connections
1. Three power supplies are required: two 9V, 1.7A power supplies for the TAS3308 EVM and one 10V -26V, 4A supply for the TAS5602EVM2.2. Ensure that all external power sources are set to OFF.3. Connect the two 9V supplies to the TAS33088 EVM. Connect the power supply adjusted from10V–26V to the module TAS5602 PVCC and GND banana jacks taking care to observe markedpolarity.
Speaker Connections (BTL Configuration)1. Connect a speaker across OUTA ( J2) and OUTB ( J4). Connect another speaker across OUTC ( J6)and OUTD ( J8)2. Install Jumpers 1-5.
Speaker Connections (SE Configuration)1. Connect a speaker across the following pairs of jacks: OUTA ( J2) and GND ( J3), OUTB ( J4) and GND(J5) , OUTC ( J6) and GND ( J7), and OUTD ( J8) and GND ( J9).2. Remove Jumpers 1-5.
SLAU258 – August 2008 TAS5602EVM2 Audio Power Amplifier Evaluation Module 3Submit Documentation Feedback

2.5 Power Up
Operation www.ti.com
Control Inputs1. HIZ: This terminal is active LOW. This terminal can be used to ( < 1ms) disable the output switching inthe event of a power failure. If the HIZ is tied to RESET, the volume ramps up slowly at start-up, butthe output switching is stopped at power down. Place JP6 in the NORM position to bypass thefunction. This position ties HIZ to the 3.3 V supply. Place JP6 in the RESET position to tie HIZ toRESET. Place JP6 in the EXT position if manual test is desired. When JP6 is in the EXT position, theHIZ pin is accessible via the test point "EXT" and the HIZ function can be exercised by grounding thistest point to the board ground. The PGND at the power supply ground can be used for this test.2. RESET: This terminal is active LOW. This terminal can be used for pop-free start/stop.3. FAULT: This terminal is active LOW. This terminal is used to indicate short circuit faults. If this pin islow, a short circuit at the output has been detected. FAULT will be reset if the RESET pin is pulled low,or the PVCC supplies are turned off. Thermal fault is not reported on this pin.4. THERM_WARN: This terminal is a TTL compatible push-pull output. Thermal warning flag goes low ifthe die temperature has reached 125 °C. This pin is automatically reset if the temperature drops backbelow 105 °C. The THERMAL WARNING LED lights when this pin goes low.5. SE/ BTL: This pin controls the starting up timing based on the output configuration. If SE/ BTL isconnect to DVDD (SE), the start-up is slow to allow a pop-free start-up in single-ended configurations.If the SE/ BTL is connect to GND, the start-up is faster, as desired, for BTL configurations. Use thejumper, JP1, to set this function.
1. Verify correct voltage and input polarity for the ±9V supplies for the TAS3308 EVM and 10V - 26Vsupply for the TAS5602EVM2. Turn the TAS3308 power supplies ON.2. Prepare the TAS3308 EVM for audio play by using the Quick Setup Guide in the TAS3308EVM User'sGuide (TI document SLEU093). The user may want to turn down the volume on the audio source priorto enabling the audio outputs to the TAS5602 audio amplifier. Connect the audio source to theTAS3308 EVM and use the Pure Path Studio GDE to select the correct Mux to route the audio signalto the PWM3 output.3. Turn on the power supply for the TAS5602EVM2. LED2 next to the PVCC jack on the TAS5602EVM2should be lit. Audio power should be reaching the speakers (loads) at this time.4. Adjust the audio level using the Pure Path Studio GDE to produce the required audio signal.
TAS5602EVM2 Audio Power Amplifier Evaluation Module4 SLAU258 – August 2008Submit Documentation Feedback

3 Reference
3.1 TAS5602EVM2 Schematic
PCB
EDGE
IN
PCB
16-NC 6-3.3V
4-5V
BTL
14-NC 8-3.3V 2-5V
PGND
EDGE
PGND
PGND
PGND PGND
PGND PGND
PGND
PGND PGND
0.68ufd
0.01ufd
0.68ufd
C5-C8
IN
IN
OUT
JP2-5
BTL
SE SE SE
PGND PGND
PGND
SE
39-GND
40-PWM1LB
37-GND
36-PWM1RB
33-GND
34-PWM1RA
31-GND
30-PWM2LA
27-GND
28-PWM2RB
25-GND
24-PWM3LB
21-GND
22-PWM3LA
19-GND
18-PWM3RA
15-GND
13-GND
12-FAULT
9-GND
10-VALIDSYNC
7-GND 3-GND
1-GND
IN = BTL (DEFAULT)
OUT = SE
PGND
JP6
1-2
3-4
RESULT
HI-Z =RESET
35-GND
38-PWM1LA 29-GND
32-PWM2LB 23-GND
26-PWM2RA 17-GND
20-PWM3RB 11-GND 5-GND
THERMAL
PGND PGND
PGND
PGND PGND
PGND
PGND PGND
OUT OUT
AD MODE Singled Ended
AD MODE BTL
BD MODE BTL
C31/32
MODE
STUFF OPTION
PGND PGND
RECONSTRUCTION FILTER
PGND PGND
5-6 HI-Z = EXT TP
PINs TAS5602EVM2
PGND PGND
PGND
SE/BTL MODE
POWER SUPPLY
WARNING
PA1 = NORMAL OP
HI-Z CONTROL
CONTROLLER
HIGH VOLTAGE
TAS5602DCA
PA1
www.ti.com Reference
Figure 3. TAS5602EVM2 Schematic
SLAU258 – August 2008 TAS5602EVM2 Audio Power Amplifier Evaluation Module 5Submit Documentation Feedback

3.2 TAS5602EVM2 PCB Layers
Reference www.ti.com
Figure 4. TAS5602EVM2 – Top Side Layout
Figure 5. TAS5602EVM2 – Bottom Side Layout
TAS5602EVM2 Audio Power Amplifier Evaluation Module6 SLAU258 – August 2008Submit Documentation Feedback

3.3 Bill of Materials
www.ti.com Reference
Table 1. Bill of Materials for TAS5602EVM2 – BDBTLREFERENCE MANUFACTURERITEM DESCRIPTION QTY MANUFACTURERDESIGNATORS PART NUM
1 20W 4 CH POWER AMP, HTSSOP56-DCA PA1 1 TEXAS INSTRUMENTS TAS5602DCA
2 Transistor PNP 50V PreBiased/4.7K 100mA Q1 1 DIODES, INC. DDTA143TCA-7SOT23-DBV3
3 LED, GREEN 2.0V SMD0805 LED2 1 LUMEX OPTICAL SML-LXT0805GW-TR
4 LED, YELLOW 2.0V SMD0805 LED1 1 LUMEX OPTICAL SML-LXT0805YW-TR
5 CAP 1000PFD 50V CERM 0603 X7R C10, C27, C28, C33 4 PANASONIC ECU-V1H102KBV
6 CAP 0.1UFD 50V CERM 0603 X7R C12, C14, C19, C22 4 MURATA GRM188R71H104KA93D
7 CAP 1.0UFD 50V CERM 0603 X5S C1, C2, C3 3 TAIYO YUDEN UMK107C105KA-T
8 CAP 0.1UFD 50V CERM 1206 X7R C9, C24 2 PANASONIC ECJ-3VB1H104K
9 CAP 0.22UFD 50V CERM 1206 X7R C11, C16, C21, C26 4 TDK CORPORATION C3216X7R1H224K
10 CAP 0.68UFD 50V CERM 1206 X7R ROHS C5, C6, C7, C8 4 KEMET C1206C684K5RACTU
12 CAP 10UFD 16V ALUM ELEC SMD VSA C4 1 PANASONIC ECE-V1CS100SR
13 CAP 15UFD 50V RAD ALUM ELEC FC C23 1 PANASONIC EEU-FC1H150
14 CAP 220UFD 50V RAD ALUM ELEC FC C13, C15, C17, C25 4 PANASONIC EEU-FC1H221
15 CAP 470UFD 35V RAD ALUM ELEC HE C18, C20, C29, C30 4 NICHICON UHE1V471MPDROHS
16 RES 392 OHM 1/10W 1% SMD 0603 R1 1 PANASONIC ERJ-3EKF3920V
17 RES 2.49K OHM 1/16W 1% SMD 0603 R11 1 PANASONIC ERJ-3EKF2491V
18 RES 10K OHM 1/16W 5% SMD 0603 R2 1 PANASONIC 9C06031A1002JLHFT
19 RES 4.7K OHM 1/8W 1% SMD 0805 R3, R4, R5, R6 4 YAGEO 9C08052A4701FKHFT
20 RES 20 OHM 1/4W 1% SMD 1206 R7, R8, R9, R10 4 YAGEO 9C12063A20R0FKHFT
21 INDUCTOR, SERIES 11RHBP, 22UH L1, L2, L3, L4 4 TOKO AMERICA A7503AY-220M
22 HEADER, 2x20 PIN MALE PCB-RA GOLD J1, J1 2 SULLINS PBC20DBANROHS
23 HEADER, 2 PIN MALE, PCB, STRAIGHT JP1, JP2, JP3, JP4, 5 SULLINS PBC02SAANGOLD ROHS JP5
24 HEADER, 2X3 PIN MALE, PCB STRAIGHT JP6 1 SULLINS PBC03DAANGOLD ROHS
25 PC Testpoint, Orange EXT 1 KEYSTONE ELECTRONICS 5003
26 BINDING POST, BLUE, TIN PCB ROHS J4, J8 2 POMONA 3760-6
27 BINDING POST, GREEN, TIN PCB ROHS J3, J5, J7, J9 4 POMONA 3760-5
28 BINDING POST, RED, TIN PCB ROHS J2, J6 2 POMONA 3760-2
29 BINDING POST, BLACK, 15A ECONO GND 1 KEYSTONE ELECTRONICS 7007
30 BINDING POST, RED, 15A ECONO PVCC 1 KEYSTONE ELECTRONICS 7006
31 SHUNT, BLACK AU FLASH 0.100 JP1, JP2, JP3, JP4, 6 SULLINS SPC02SYANJP5, JP6(1-2)
32 Hex Nut, 4-40, Zinc/Steel HW1, HW2, HW3, 4 BUILDING FASTENERS HNZ440HW4
33 Standoff 4-40 Threaded M/F 1.50 in. HW1, HW2, HW3, 4 KEYSTONE ELECTRONICS 8409ALUM-HEX HW4
