Texas Instruments TPA0232 User manual

TPA0232
Audio Power Amplifier
Evaluation Module
August 2001 Mixed Signal Products
User’s Guide
SLOU073A

IMPORTANT NOTICE
TexasInstruments andits subsidiaries(TI) reservethe rightto makechanges totheir productsor todiscontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those
pertaining to warranty, patent infringement, and limitation of liability.
TI warrants performance of its products to the specifications applicable at the time of sale in accordance with
TI’sstandardwarranty.TestingandotherqualitycontroltechniquesareutilizedtotheextentTIdeemsnecessary
to support this warranty. Specific testing of all parameters of each device is not necessarily performed, except
those mandated by government requirements.
Customers are responsible for their applications using TI components.
In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.
TIassumesnoliabilityforapplicationsassistance orcustomer productdesign. TIdoes notwarrantorrepresent
thatanylicense,eitherexpressorimplied,isgrantedunderanypatentright,copyright,maskworkright,orother
intellectual property right of TI covering or relating to any combination, machine, or process in which such
products or services might be or are used. TI’s publication of information regarding any third party’s products
or services does not constitute TI’s approval, license, warranty or endorsement thereof.
Reproduction of information in TI data books or data sheets is permissible only if reproduction is without
alterationand isaccompanied byall associatedwarranties,conditions,limitationsandnotices. Representation
or reproduction of this information with alteration voids all warranties provided for an associated TI product or
service, is an unfair and deceptive business practice, and TI is not responsible nor liable for any such use.
Resale of TI’s products or services with statements different from or beyond the parameters stated by TI for
that product or service voids all express and any implied warranties for the associated TI product or service,
is an unfair and deceptive business practice, and TI is not responsible nor liable for any such use.
Also see: Standard Terms and Conditions of Sale for Semiconductor Products. www.ti.com/sc/docs/stdterms.htm
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2001, Texas Instruments Incorporated

EVM IMPORTANT NOTICE
Texas Instruments (TI) provides the enclosed product(s) under the following conditions:
Thisevaluationkit being soldbyTI isintendedfor use forENGINEERING DEVELOPMENT OR EVALUATION
PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided
may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective
considerations, including product safety measures typically found in the end product incorporating the goods.
As a prototype, this product does not fall within the scope of the European Union directive on electromagnetic
compatibility and therefore may not meet the technical requirements of the directive.
ShouldthisevaluationkitnotmeetthespecificationsindicatedintheEVMUser’sGuide,thekitmaybereturned
within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE
WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,
IMPLIED,ORSTATUTORY,INCLUDINGANYWARRANTY OFMERCHANTABILITY ORFITNESS FORANY
PARTICULAR PURPOSE.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user
indemnifies TI from all claims arising from the handling or use of the goods. Please be aware that the products
receivedmaynotbe regulatorycompliant oragency certified (FCC,UL,CE,etc.).Duetotheopenconstruction
oftheproduct,itistheuser’sresponsibilitytotakeanyandallappropriateprecautionswithregardtoelectrostatic
discharge.
EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE
TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not
exclusive.
TI assumes no liability for applications assistance, customer product design, software performance, or
infringement of patents or services described herein.
Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice in the EVM
User’sGuidepriortohandlingtheproduct.Thisnoticecontainsimportantsafetyinformationabouttemperatures
and voltages. For further safety concerns, please contact the TI application engineer.
Persons handling the product must have electronics training and observe good laboratory practice standards.
No license is granted under any patent right or other intellectual property right of TI covering or relating to any
machine, process, or combination in which such TI products or services might be or are used.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2001, Texas Instruments Incorporated

EVM WARNINGS AND RESTRICTIONS
It is important to operate this EVM within the specified input and output ranges described in
the EVM User’s Guide.
Exceeding the specified input range may cause unexpected operation and/or irreversible
damage to the EVM. If there are questions concerning the input range, please contact a TI
field representative prior to connecting the input power.
Applyingloadsoutsideofthespecifiedoutputrangemayresultinunintendedoperationand/or
possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to
connecting any load to the EVM output. If there is uncertainty as to the load specification,
please contact a TI field representative.
Duringnormaloperation,somecircuitcomponentsmayhavecasetemperaturesgreaterthan
60°C.TheEVM isdesignedto operateproperlywith certaincomponents above 60°Cas long
astheinputandoutput rangesare maintained.These componentsinclude butarenotlimited
tolinearregulators,switchingtransistors,passtransistors,andcurrentsenseresistors.These
typesof devicescanbeidentifiedusing theEVMschematiclocatedintheEVM User’sGuide.
When placing measurement probes near these devices during operation, please be aware
that these devices may be very warm to the touch.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2001, Texas Instruments Incorporated

v
Chapter Title—Attribute Reference
Preface
Related Documentation From Texas Instruments
J TI Plug-N-Play Audio Amplifier Evaluation Platform (literature
number SLOU011) provides detailed information on the evaluation
platform and its use with TI audio evaluation modules.
J TPA0232 Stereo 2-W Audio Power Amplifier (literature number
SLOS286) This is the data sheet for the TPA0232 audio amplifier
integrated circuit.
FCC Warning
This equipment is intended for use in a laboratory test environment only. It
generates, uses, and can radiate radio frequency energy and has not been
testedforcompliancewiththelimitsofcomputingdevices pursuant to subpart
Jofpart 15ofFCCrules,whicharedesignedtoprovidereasonableprotection
against radio frequency interference. Operation of this equipment in other
environments may cause interference with radio communications, in which
case the user at his own expense will be required to take whatever measures
may be required to correct this interference.
Trademarks
TI is a trademark of Texas Instruments Incorporated.

vi

Running Title—Attribute Reference
vii
Chapter Title—Attribute Reference
Contents
1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Feature Highlights 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 TPA0232 EVM Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Quick Start 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Precautions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Details 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Precautions 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 The TPA0232 Audio Power Amplifier Evaluation Module 3-3. . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 TPA0232 Audio Amplifier IC 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.2 Inputs and Gain 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.3 Differential Input 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.4 Depop Circuitry 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.5 BTL Operation 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.6 Single-Ended Operation 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Using The TPA0232 EVM With the Plug-N-Play Evaluation Platform 3-8. . . . . . . . . . . . . . .
3.3.1 Installing and Removing EVM Boards 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 TPA0232 Module Jumper Settings and Switches 3-9. . . . . . . . . . . . . . . . . . . . . . . .
3.3.3 Signal Routing 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.4 Mute (Shutdown)/Mode 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.5 Power Requirements 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.6 Inputs and Outputs 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Using The TPA0232 EVM Stand-Alone 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1 TPA0232 EVM Connected for BTL Output 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.2 TPA0232 EVM Connected for Single-Ended Output 3-17. . . . . . . . . . . . . . . . . . . . .
3.5 TPA0232 Audio Power Amplifier Evaluation Module Parts List 3-18. . . . . . . . . . . . . . . . . . .

Running Title—Attribute Reference
viii
Figures
1–1 The TI TPA0232 Audio Amplifier Evaluation Module 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1 Quick Start Platform Map 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–2 Module Preparation 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–3 Quick Start Module Map 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1 The TI Plug-N-Play Audio Amplifier Evaluation Platform 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 TPA0232 EVM 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–3 TPA0232 EVM Schematic Diagram 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–4 TPA0232 Amplifier IC 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–5 TPA0232 EVM Jumpers and Switches 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–6 Platform Signal Routing and Outputs 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–7 Mute/Mode and Polarity Control 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–8 Typical Headphone Plug 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–9 TPA0232 EVM Connected for Stereo BTL Output 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–10 TPA0232 EVM Connected for Stereo Single-Ended Output 3-17. . . . . . . . . . . . . . . . . . . . . . . .
Tables
2–1 Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA0232 2-1. . . . . . . . .
2–2 Typical TPA0232 EVM Jumper Settings 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–3 Platform Jumper and Switch Settings for the TPA0232 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–4 Typical TPA0232 EVM Jumper Settings 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1 TPA0232 EVM BTL Volume Settings 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 Typical TPA0232 EVM Jumper Settings for BTL Stand-Alone 3-16. . . . . . . . . . . . . . . . . . . . . .
3–3 Typical TPA0232 EVM Jumper Settings for Single-Ended Stand-Alone 3-17. . . . . . . . . . . . . .
3–4 TPA0232 EVM Parts List 3-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1
Introduction
Introduction
This chapter provides an overview of the Texas Instruments (TI) TPA0232
audio amplifier evaluation module (SLOP274). It includes a list of EVM
features, a brief illustrated description of the module, and a list of EVM
specifications.
Topic Page
1.1 Feature Highlights 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 TPA0232 EVM Specifications 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Feature Highlights
1-2 Introduction
1.1 Feature Highlights
The TI TPA0232 audio amplifier evaluation module and the TI plug-n-play
audio amplifier evaluation platform include the following features:
- TPA0232 stereo 2-W audio power amplifier evaluation module
J Internal depop circuitry to minimize transients in outputs
J Dual channel, bridge-tied load (BTL) or single-ended operation
J 2 W per channel output power into 3 Ωat 5 V, BTL
J Low current consumption in shutdown mode (150 µA)
J Internal input MUX selects among two sets of stereo inputs
J DC voltage volume control from +20 dB to –40 dB, and –85 dB mute
J Differential stereo inputs
J PC Beep input
- Quick and easy configuration with the TI plug-n-play audio amplifier
evaluation platform
J Evaluation module is designed to simply plug into the platform,
automatically making all signal, control, and power connections
J Platform provides flexible power options
J Jumpers on the platform select power and module control options
J Switches on the platform route signals
J Platformprovides quick and easyaudio input and outputconnections
- Platform power options
J External 5-V –15-V DC VCC supply inputs
J External regulated VDD supply input
J Socket for on-board 5-V/3.3-V VDD voltage regulator EVM
J Onboard overvoltage and reverse polarity power protection
- Platform audio input and output connections
J Left and right RCA phono jack inputs
J Miniature stereo phone jack input
J Left and right RCA phono jack outputs
J Left and right compression speaker terminal outputs
J Miniature stereo headphone jack output

Description
1-3
Introduction
1.2 Description
The TPA0232 stereo 2-W audio power amplifier evaluation module is a
complete, 2-W per channel stereo audio power amplifier. It consists of the TI
TPA0232 stereo 2-W audio power amplifier IC along with a small number of
other parts mounted on a circuit board that measures approximately
2 1/4 inches by 1 1/2 inches (see Figure 1–1).
Figure 1–1.The TI TPA0232 Audio Amplifier Evaluation Module
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00232 EVM Board SLOP274
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE
Single in-line header pins extend from the underside of the module circuit
board to allow the EVM to be plugged into the TI plug-n-play audio amplifier
evaluationplatform,ortobewireddirectlyintoexistingcircuitsand equipment
when used stand-alone.
The platform has room for a single TPA0232 evaluation module and is a
convenient vehicle for demonstrating TI’s audio power amplifier and related
evaluation modules. The EVMs simply plug into the platform, which
automatically provides power to the modules, interconnects them correctly,
andconnectsthemtoaversatilearrayofstandardaudioinputandoutputjacks
and connectors. Easy-to-use configuration controls allow the platform and
EVMs to quickly model many possible end-equipment configurations.
There is nothing to build, nothing to solder, and nothing but the speakers
included with the platform to hook up.
1.3 TPA0232 EVM Specifications
Supply voltage range, VDD 4.5 V to 5.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supply current, IDD 2 A max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous output power per channel, PO: 3-ΩBTL, VDD=5 V 2 W. . . . . .
Audio input voltage, VI,: HP input 5 Vpp max. . . . . . . . . . . . . . . . . . . . . . . . . .
Line input 5 Vpp max. . . . . . . . . . . . . . . . . . . . . . . .
PC BEEP input 5 Vpp max. . . . . . . . . . . . . . . . . . . .
Minimum load impedance, RL3 Ω. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-4 Introduction

2-1
Quick Start
Quick Start
ThestepsinthischaptercanbefollowedtoquicklypreparetheTPA0232audio
amplifier EVM for use. Using the TPA0232 with the TI plug-n-play audio
amplifierevaluationplatform is a quick and easyway to connect power,signal
and control inputs, and signal outputs to the EVM using standard connectors.
However, the audio amplifier evaluation module can be used stand-alone by
making connections directly to the module pins, and can be wired directly into
existing circuits or equipment.
TheplatformswitchandjumpersettingsshowninTable 2–1 are typical for the
TPA0232 EVM and will cause the TPA0232 to switch to single-ended output
mode when a plug is inserted into platform headphone jack J10.
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA0232
EVM JP6 JP7 JP8 S2 S3
P-N-P Platform Mode X Hi Note 2 U2–U4
Notes: 1) X = Don’t care
2) SetS2 to ONwhen signalconditioning boardis installedinU1; set S2
to OFF when no signal conditioning board is installed.
Table 2–2. Typical TPA0232 EVM Jumper Settings
EVM S3
TPA0232 OFF
Note: ON = Shunt installed
OFF = Open
Topic Page
2.1 Precautions 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2

Precautions
2-2 Quick Start
2.1 Precautions
Power Supply Input Polarity and Maximum Voltage
Always ensure that the polarity and voltage of the external power
connected to VCC power input connector J1, J2, and/or VDD power
input connector J6 are correct. Overvoltage or reverse-polarity
power applied to these terminals can open onboard soldered-in
fuses and cause other damage to the platform, installed evaluation
modules, and/or the power source.
Inserting or Removing EVM Boards
Do not insert or remove EVM boards with power applied—damage
to the EVM board, the platform, or both may result.
Figure 2–1.Quick Start Platform Map
Signal Conditioning
****CAUTION****
Do not insert or remove
EVM boards with power
applied
ICC
JP4
F1
VR1
R1
JP3
JP2 JP1 AC/DC
(J2)
VCC(J1)
D1 D2 D3
D4 J2
J3 J4 J5
AC/DC
In
VCC
In
+
J1
DC
SOURCE
LED1 VCC
LED2 VDD
R2
JP5 IDD
B1
U6
POWER
SUPPLY
U3 U4
U5
U1
U2
Audio
Power
Amps
OnOff Conditioning
S2
J7 J8 Right
Out Left
Out
+–+–
JP6
Mode
Mute
Spk(U2-U4)
JP8
J9 Left
Out
JP7
S3 HP Source
U2-U4
U5
Polarity
Lo
Hi
HP(U5)
C3 C2
++
R3
R5
J10
Stereo
HP Out
TP1
GND
Plug-N-PlayAudio Amplifier
Evaluation Platform
SLOP097 Rev. C.1
Stereo
In
Right
In Left
In
J6 In/Out VDD
F2
VR2 +
DC
Power
In/Out
Speaker
Output
Headphone
Output
Audio
Input
Power
Input
Batt
C1+
Right
Out
On Off Pwr
S1
TEXAS INSTRUMENTS 1997
R4
7a
1
23 4
5
6
7b
7b
7b 7b
910
13

Quick Start List for Platform
2-3
Quick Start
2.2 Quick Start List for Platform
FollowthesestepswhenusingtheTPA0232EVMwiththeTIplug-n-playaudio
amplifier evaluation platform (see the platform user’s guide, SLOU011, for
additional details). Numbered callouts for selected steps are shown in
Figure 2–1 and Figure 2–2, and details appear in Chapter 3.
- Platform preparations
1) EnsurethatallexternalpowersourcesaresettoOFFandthattheplatform
power switch S1 is set to OFF.
2) Install a TPA0232 module in platform socket U2, taking care to align the
module pins correctly.
3) Use switch S2 to select or bypass the signal conditioning EVM (U1).
4) Set control signal Polarity jumper JP8 to Hi.
5) Set jumper JP6 to select the Mode control input (causes the TPA0232 to
switch to the single-ended output mode if a plug is inserted into platform
headphone jack J10).
6) If the headphone jack (J10) output will be used, set headphone source
switch S3 to U2–U4.
Table 2–3. Platform Jumper and Switch Settings for the TPA0232
EVM JP6 JP7 JP8 S2 S3
P-N-P Platform Mode X Hi Note 2 U2–U4
Notes: 1) X = Don’t care
2) SetS2 to ON whensignal conditioning boardis installedin U1; set S2
to OFF when no signal conditioning board is installed.
- Power supply
7) Selectandconnectthepowersupply(ensurepowersupplyissettoOFF ):
a) Connectanexternalregulatedpowersupplysetto5VtoplatformVDD
power input connector J6 taking care to observe marked polarity,
or
b) InstallavoltageregulatorEVM(SLVP097orequiv.)inplatformsocket
U6.Connecta7V –12VpowersourcetoaplatformVCC powerinput
J1 or J2 and jumper the appropriate power input (see platform user’s
guide).
- Inputs and outputs
8) Ensure that the audio signal source level is set to minimum.
9) Connect the audio source to left and right RCA phono jacks J3 and J5 or
stereo miniature phone jack J4.
10) ConnectspeakerstoleftandrightRCAjacksJ7 and J9 or to stripped wire
speaker connectors J8.

Quick Start List for Platform
2-4 Quick Start
- Evaluation module preparations
Figure 2–2.Module Preparation
11
12
13
14
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00232 EVM Board SLOP274
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE
Table 2–4. Typical TPA0232 EVM Jumper Settings
EVM S3
TPA0232 OFF
Note: ON = Shunt installed, OFF = Open
11) To allow the module SE/BTL control input to switch the amplifier IC
between single ended (SE) and bridge-tied load (BTL) output modes, set
output mode jumper S2 to OFF. To keep the module amplifier IC in the
single-endedoutputmoderegardlessofthecontrolinputstate,setjumper
S2 to ON.
12) To allow the module HP/LINE control input to switch the amplifier IC
between using the HP pins and the LINE pins as the signal inputs, set the
input mode jumper S3 to OFF. To keep the amplifier IC in the HP input
mode regardless of the control input state, set jumper S3 to ON.
- Power Up
13) To allow the amplifier IC to switch from the LINE inputs to the HP inputs
when the output switches from BTL output mode to SE output mode and
vice versa, set jumper S4 to ON. To allow the inputs and output modes to
switch independently, set jumper S4 to OFF.
PlatformLED2shouldlightindicatingthepresenceofVDD,andtheevaluation
modules installed on the platform should begin operation.
14) Adjust the signal source level as needed.

Quick Start List for Stand-Alone
2-5
Quick Start
2.3 Quick Start List for Stand-Alone
Follow these steps to use the TPA0232 EVM stand-alone or when connecting
it into existing circuits or equipment. Connections to the TPA0232 module
header pins can be made via individual sockets, wire-wrapping, or soldering
to the pins, either on the top or the bottom of the module circuit board.
Numbered callouts for selected steps are shown in Figure 2–3 and details
appear in Chapter 3.
Figure 2–3.Quick Start Module Map
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00232 EVM Board SLOP274
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE
6
7
8
9
- Power supply
1) Ensure that all external power sources are set to OFF.
2) Connectanexternalregulated powersupplysetto5VtothemoduleVDD
and GND pins taking care to observe marked polarity.
- Inputs and outputs
3) Ensure that audio signal source level adjustments are set to minimum.
4) Connect the right (left) positive lead of the audio source to the module
R LINE–(L LINE–) pins and the negative lead to the R IN+ (L IN+) pins.
If using the headphone inputs, connect the positive audio source to the
module R HP (L HP) and the negative lead to R IN+ (L IN+). The inputs
can be used with a differential or single-ended audio source, but the
headphone and line have common positive inputs.
5) Select output mode:
a) For BTL output, connect a speaker to the module OUT+ and OUT–
pins of each channel,
or
b) For single-ended output, connect a headphone or a speaker to the
module OUT+ and GND pins of each channel through a 33-µF to
1000-µF output-coupling capacitor (see Figure 3–10).

Quick Start List for Stand-Alone
2-6 Quick Start
- Evaluation module preparations
6) To allow the module SE/BTL control input to switch the amplifier IC
between single ended (SE) and bridge-tied load (BTL) output modes, set
output mode jumper S2 to OFF. To keep the module amplifier IC in the
single-endedoutputmoderegardlessofthecontrolinputstate,setjumper
S2 to ON.
7) To allow the module HP/LINE control input to switch the amplifier IC
between using the HP pins and the LINE pins as the signal inputs, set the
input mode jumper S3 to OFF. To keep the amplifier IC in the HP input
mode regardless of the control input state, set jumper S3 to ON.
- Control inputs
8) To allow the amplifier IC to switch from the LINE inputs to the HP inputs
when the output switches from BTL output mode to SE output mode and
vice versa, set jumper S4 to ON. To allow the inputs and output modes to
switch independently, set jumper S4 to OFF. Connect control lines to the
various module control input pins as needed:
a) SE/BTL: A high selects the single-ended (SE) output mode; a low or
float selects the bridge-tied load (BTL) output mode.
b) SHUTDOWN:AlowshutsdowntheamplifierIConthemodule;ahigh
or float allows normal operation.
- Power-up
9) Verify correct voltage andinput polarity and setthe external power supply
to ON.
The EVM should begin operation.
10) Adjust the signal source level as needed.

3-1
Details
Details
This chapter provides details on the TPA0232 IC, the evaluation module, and
thestepsintheQuick-StartList,additionalapplicationinformation,andaparts
list for the TPA0232 evaluation module.
Topic Page
3.1 Precautions 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 The TPA0232 Audio Power Amplifier Evaluation Module 3–3. . . . . . . . .
3.3 Using the TPA0232 EVM With the Plug-N-Play
Evaluation Platform 3–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Using The TPA0232 EVM Stand-Alone 3–16. . . . . . . . . . . . . . . . . . . . . . . .
3.5 TPA0232 Audio Power Amplifier Evaluation Module Parts List 3–18. .
Chapter 3

Precautions
3-2 Details
3.1 Precautions
Power Supply Input Polarity and Maximum Voltage
Always ensure that the polarity and voltage of the external power
connected to VCC power input connector J1, J2, and/or VDD power
input connector J6 are correct. Overvoltage or reverse-polarity
power applied to these terminals can open onboard soldered-in
fuses and cause other damage to the platform, installed evaluation
modules, and/or the power source.
Inserting or Removing EVM Boards
Do not insert or remove EVM boards with power applied—damage
to the EVM board, the platform, or both may result.
Figure 3–1.The TI Plug-N-Play Audio Amplifier Evaluation Platform
Signal Conditioning
****CAUTION****
Do not insert or remove
EVM boards with power
applied
ICC
JP4
F1
VR1
R1
JP3
JP2 JP1 AC/DC
(J2)
VCC(J1)
D1 D2 D3
D4 J2
J3 J4 J5
AC/DC
In
VCC
In
+
J1
DC
SOURCE
LED1 VCC
LED2 VDD
R2
JP5 IDD
B1
U6
POWER
SUPPLY
U3 U4
U5
U1
U2
Audio
Power
Amps
OnOff Conditioning
S2
J7 J8 Right
Out Left
Out
+–+–
JP6
Mode
Mute
Spk(U2-U4)
JP8
J9 Left
Out
JP7
S3 HP Source
U2-U4
U5
Polarity
Lo
Hi
HP(U5)
C3 C2
++
R3
R5
J10
Stereo
HP Out
TP1
GND
Plug-N-PlayAudio Amplifier
Evaluation Platform
SLOP097 Rev. C.1
Stereo
In
Right
In Left
In
J6 In/Out VDD
F2
VR2 +
DC
Power
In/Out
Speaker
Output
Headphone
Output
Audio
Input
Power
Input
Batt
C1+
Right
Out
On Off Pwr
S1
TEXAS INSTRUMENTS 1997
R4
