Texas Instruments CC430F6137 User manual

ECCN 5E002 TSPA - Technology / Software Publicly Available
CC430F6137, CC430F6135, CC430F6127, CC430F6126, CC430F6125
CC430F5137, CC430F5135, CC430F5133
www.ti.com SLAS554H –MAY 2009–REVISED SEPTEMBER 2013
MSP430™ SoC With RF Core
Check for Samples: CC430F6137,CC430F6135,CC430F6127,CC430F6126,CC430F6125,CC430F5137,CC430F5135,CC430F5133
1FEATURES
23• True System-on-Chip (SoC) for Low-Power – Embedded Emulation Module (EEM)
Wireless Communication Applications • High-Performance Sub-1-GHz RF Transceiver
• Wide Supply Voltage Range: Core
3.6 V Down to 1.8 V – Same as in CC1101
• Ultralow-Power Consumption: – Wide Supply Voltage Range: 2.0 V to 3.6 V
– CPU Active Mode (AM): 160 µA/MHz – Frequency Bands: 300 MHz to 348 MHz,
– Standby Mode (LPM3 RTC Mode): 2.0 µA 389 MHz to 464 MHz, and 779 MHz to
928 MHz
– Off Mode (LPM4 RAM Retention): 1.0 µA – Programmable Data Rate From 0.6 kBaud
– Radio in RX: 15 mA, 250 kbps, 915 MHz to 500 kBaud
• MSP430 System and Peripherals – High Sensitivity (–117 dBm at 0.6 kBaud,
– 16-Bit RISC Architecture, Extended –111 dBm at 1.2 kBaud, 315 MHz,
Memory, up to 20-MHz System Clock 1% Packet Error Rate)
– Wake Up From Standby Mode in Less – Excellent Receiver Selectivity and Blocking
Than 6 µs Performance
– Flexible Power-Management System With – Programmable Output Power Up to
SVS and Brownout +12 dBm for All Supported Frequencies
– Unified Clock System With FLL – 2-FSK, 2-GFSK, and MSK Supported as
– 16-Bit Timer TA0, Timer_A With Five Well as OOK and Flexible ASK Shaping
Capture/Compare Registers – Flexible Support for Packet-Oriented
– 16-Bit Timer TA1, Timer_A With Three Systems: On-Chip Support for Sync Word
Capture/Compare Registers Detection, Address Check, Flexible Packet
– Hardware Real-Time Clock (RTC) Length, and Automatic CRC Handling
– Two Universal Serial Communication – Support for Automatic Clear Channel
Interfaces Assessment (CCA) Before Transmitting (for
– USCI_A0 Supports UART, IrDA, SPI Listen-Before-Talk Systems)
– USCI_B0 Supports I2C, SPI – Digital RSSI Output
– 12-Bit Analog-to-Digital Converter (ADC) – Suited for Systems Targeting Compliance
With Internal Reference, Sample-and-Hold, With EN 300 220 (Europe) and
and Autoscan Features (CC430F613x and FCC CFR Part 15 (US)
CC430F513x Only) – Suited for Systems Targeting Compliance
– Comparator With Wireless M-Bus Standard EN
13757‑‑4:2005
– Integrated LCD Driver With Contrast
Control for up to 96 Segments – Support for Asynchronous and
(CC430F61xx Only) Synchronous Serial Receive or Transmit
Mode for Backward Compatibility With
– 128-Bit AES Security Encryption and Existing Radio Communication Protocols
Decryption Coprocessor •Table 1 Summarizes Family Members
– 32-Bit Hardware Multiplier • For Complete Module Descriptions, See the
– Three-Channel Internal DMA CC430 Family User's Guide (SLAU259)
– Serial Onboard Programming, No External
Programming Voltage Needed
1Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2MSP430 is a trademark of Texas Instruments.
3All other trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date. Copyright © 2009–2013, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.

ECCN 5E002 TSPA - Technology / Software Publicly Available
CC430F6137, CC430F6135, CC430F6127, CC430F6126, CC430F6125
CC430F5137, CC430F5135, CC430F5133
SLAS554H –MAY 2009–REVISED SEPTEMBER 2013 www.ti.com
APPLICATIONS
• Wireless Analog and Digital Sensor Systems
• Heat Cost Allocators
• Thermostats
• AMR or AMI Metering
• Smart Grid Wireless Networks
DESCRIPTION
The Texas Instruments CC430 family of ultralow-power microcontroller system-on-chip (SoC) with integrated RF
transceiver cores consists of several devices featuring different sets of peripherals targeted for a wide range of
applications. The architecture, combined with five low-power modes, is optimized to achieve extended battery life
in portable measurement applications. The device features the powerful MSP430 16-bit RISC CPU, 16-bit
registers, and constant generators that contribute to maximum code efficiency.
The CC430 family provides a tight integration between the microcontroller core, its peripherals, software, and the
RF transceiver, making these true SoC solutions easy to use as well as improving performance.
The CC430F61xx series are microcontroller SoC configurations that combine the excellent performance of the
state-of-the-art CC1101 sub-1-GHz RF transceiver with the MSP430 CPUXV2, up to 32KB of in-system
programmable flash memory, up to 4KB of RAM, two 16-bit timers, a high-performance 12-bit analog-to-digital
converter (ADC) with eight external inputs plus internal temperature and battery sensors on CC430F613x
devices, a comparator, universal serial communication interfaces (USCIs), a 128-bit AES security accelerator, a
hardware multiplier, a DMA, a real-time clock (RTC) module with alarm capabilities, an LCD driver, and up to
44 I/O pins.
The CC430F513x series are microcontroller SoC configurations that combine the excellent performance of the
state-of-the-art CC1101 sub-1-GHz RF transceiver with the MSP430 CPUXV2, up to 32KB of in-system
programmable flash memory, up to 4KB of RAM, two 16-bit timers, a high performance 12-bit ADC with six
external inputs plus internal temperature and battery sensors, a comparator, universal serial communication
interfaces (USCIs), a 128-bit AES security accelerator, a hardware multiplier, a DMA, an RTC module with alarm
capabilities, and up to 30 I/O pins.
Typical applications for these devices include wireless analog and digital sensor systems, heat cost allocators,
thermostats, metering (AMR or AMI), and smart grid wireless networks.
Table 1 summarizes the available family members.
For complete module descriptions, see the CC430 Family User's Guide (SLAU259).
2Submit Documentation Feedback Copyright © 2009–2013, Texas Instruments Incorporated
Product Folder Links: CC430F6137 CC430F6135 CC430F6127 CC430F6126 CC430F6125 CC430F5137
CC430F5135 CC430F5133

ECCN 5E002 TSPA - Technology / Software Publicly Available
CC430F6137, CC430F6135, CC430F6127, CC430F6126, CC430F6125
CC430F5137, CC430F5135, CC430F5133
www.ti.com SLAS554H –MAY 2009–REVISED SEPTEMBER 2013
Table 1. Family Members(1)(2)
USCI
Program Package
Channel A: Channel B:
Device SRAM (KB) Timer_A(3) LCD_B(4) ADC12_A(4) Comp_B I/O
(KB) Type
UART, LIN, SPI, I2C
IrDA, SPI
8 ext,
CC430F6137 32 4 5, 3 96 seg 1 1 8 ch. 44 64 RGC
4 int ch.
8 ext,
CC430F6135 16 2 5, 3 96 seg 1 1 8 ch. 44 64 RGC
4 int ch.
CC430F6127 32 4 5, 3 96 seg 1 1 n/a 8 ch. 44 64 RGC
CC430F6126 32 2 5, 3 96 seg 1 1 n/a 8 ch. 44 64 RGC
CC430F6125 16 2 5, 3 96 seg 1 1 n/a 8 ch. 44 64 RGC
6 ext,
CC430F5137 32 4 5, 3 n/a 1 1 6 ch. 30 48 RGZ
4 int ch.
6 ext,
CC430F5135 16 2 5, 3 n/a 1 1 6 ch. 30 48 RGZ
4 int ch.
6 ext,
CC430F5133 8 2 5, 3 n/a 1 1 6 ch. 30 48 RGZ
4 int ch.
(1) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
web site at www.ti.com.
(2) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging.
(3) Each number in the sequence represents an instantiation of Timer_A with its associated number of capture compare registers and PWM
output generators available. For example, a number sequence of 5, 3 would represent two instantiations of Timer_A, the first
instantiation having 5 and the second instantiation having 3 capture compare registers and PWM output generators, respectively.
(4) n/a = not available
Copyright © 2009–2013, Texas Instruments Incorporated Submit Documentation Feedback 3
Product Folder Links: CC430F6137 CC430F6135 CC430F6127 CC430F6126 CC430F6125 CC430F5137
CC430F5135 CC430F5133

RAM
4kB
2kB
Power
Mgmt
LDO
SVM/SVS
Brownout
SYS
TA0
5 CC
Registers
EEM
(S: 3+1)
RTC_A
Comp_B
Flash
32kB
16kB
SMCLK
ACLK
MDB
MAB
XOUTXIN
Spy-Bi-
Wire
CRC16
Bus
Cntrl
Logic
MAB
MDB
MAB
MDB
MCLK
USCI_A0
(UART,
IrDA, SPI)
USCI_B0
(SPI, I2C)
LCD_B
96
Segments
1,2,3,4
Mux
I/O Ports
P1/P2
2x8 I/Os
PA
1x16 I/Os
P1.x/P2.x
2x8
I/O Ports
P3/P4
2x8 I/Os
PB
1x16 I/Os
P3.x/P4.x
2x8
I/O Ports
P5
1x8 I/Os
P5.x
1x8
AES128
Security
En-/De-
cryption
RF_XOUTRF_XIN
RF_NRF_P
TA1
3 CC
Registers
MODEM
RF/ANALOG
TX & RX
Frequency
Synthesizer
CPU Interface
Packet
Handler
Digital RSSI
Carrier Sense
PQI / LQI
CCA
Sub-1GHz
Radio
(CC1101)
MPY32
ADC12
(32kHz) (26MHz)
Unified
Clock
System
CPUXV2
incl. 16
Registers
JTAG
Interface
DMA
Controller
3 Channel
Port
Mapping
Controller
Watch-
dog
REF
Voltage
Reference
ECCN 5E002 TSPA - Technology / Software Publicly Available
CC430F6137, CC430F6135, CC430F6127, CC430F6126, CC430F6125
CC430F5137, CC430F5135, CC430F5133
SLAS554H –MAY 2009–REVISED SEPTEMBER 2013 www.ti.com
CC430F613x Functional Block Diagram
4Submit Documentation Feedback Copyright © 2009–2013, Texas Instruments Incorporated
Product Folder Links: CC430F6137 CC430F6135 CC430F6127 CC430F6126 CC430F6125 CC430F5137
CC430F5135 CC430F5133
