The Flying Culinary Circus FCC BBQ APOLLO FCC-EG-202020 Guide

!
INSTRUCTION MANUAL & MAINTENANCE
Sare  u  cookin!
OUTDOORUSEONLY
READTHEOPERATINGINSTRUCTIONS
BEFOREUSINGTHEAPPLIANCE.
ENGLISHFCC-EG-202020 / RO906-F
POWERGRILLAPOLLO

POWER GRILL APOLLO
Contents
Description ....................................................................................................3
Instructions .....................................................................................................4
Warning ..........................................................................................................6
Before use .....................................................................................................7
Safety regulations........................................................................................8
Technical data..............................................................................................9
Cooking guidance ................................................................................10
Tips / Cleaning ..........................................................................................11
Consumer Contact .................................................................................12
2

1. Grill Lid handle
2. Grill Lid
3. Detachable temperature,
regulator with power cord
4. Temperature indicator lamp
5. Power inlet socket
6. Grill plate
7. Oil collecting tray
8. Grill holder
9. Grill holder handle
10.Grill bracket
11. Support tube
12. Food tray holder
13. Food tray
Description
1－Grill Lid handle
2－Grill Lid
3－Detachable temperature
regulator with power cord
4－Temperature indicator lamp
5－Power inlet socket
6－Grill plate
7－Oil collecting tray
8－Grill holder
9－Grill holder handle
10－Grill bracket
11－Support tube
12－Food tray holder
13－Food tray
Note: when the electric baking tray is on a slope or slightly windy, there is a risk that
the grill lid will close automatically.
1
2
3
4
5
6
7
8
9
10
11
12
13
3
Description

A
Installation instructions
1.the four supporting tube assembly (11) into the grill bracket (10) four column hole assembly move pin
hole gap alignment
2.The food tray (13) are respectively buckled on the food tray holder (12) of the support pipe assembly (11)
3. Set the BBQ grill holder(8) with the oil collecting tray(7) into the grill bracket(10) assembly
Installation instructions
1.the four supporting tube assembly (11) into the grill bracket (10) four column hole assembly move pin
hole gap alignment
2.The food tray (13) are respectively buckled on the food tray holder (12) of the support pipe assembly (11)
3. Set the BBQ grill holder(8) with the oil collecting tray(7) into the grill bracket(10) assembly
POWER GRILL APOLLO
Instructions
1. Place the grill bracket(10) and the
food tray(12)
Upside down on top of each other,
the four supporting tube (11) through
into Food tray (12) four column hole
assembly move pin(A) hole gap
alignment,The positioning pin of the
four support tubes should be
clamped into the positioning groove
of the food tray and the grill bracket,
and rotating the four supporting
tube (11) until they get stuck.
2.
3. Set the BBQ grill holder(8) with the oil collecting
tray(7) into the grill bracket(10) assembly
The food tray (13) are respectively buckledon
the food tray holder (12) of the support pipe
assembly (11)
4

Instructions
ATTENTION: THEBBQELECTRICGRILLWITHTHEGRILL
PTE ANDGRILLHOLDER. ASSEMBLYCANBETOGETHER
FROMTHEGRILL. BRACKETASSEMBLYMOVETOTHEKITCHEN
ASINDOORUSE.
RECOMMENDATION: NOGRILLLIDFORINDOORUSE
REMIND: THEGRILLPTE MUSTONLYBEUSEDTOGETH
ERWITHBBQOFTHEGRILLHOLDER !
ATTENTION!
THEGRILLPTE MUSTONLYBE
USEDTOGETHERWITHBBQ
OFTHEGRILLHOLDER !
4. Place the grill plate (6) in the grill holder BBQ (8)
Insert the inlet socket (5) of the grill plate into the
grill holder of the socket hole , then lower the grill
plate onto grill holder. Make sure it is cool and
disconnected from the power.
5.
6. the temperature regulator and the cable (3)
The electrical plug is inserted into the power socket.
When inserting or removing power cord shall be
remained the grill holder(8) stable on the appliance
4. Place the grill plate (6) in the grill holder BBQ (8) Insert the inlet
socket (5) of the grill plate into the grill holder of the socket hole ,
Then lower the grill plate onto grill holder. Make sure it is cool and
disconnected from the power.
Attention: The grill plate(6) must only
be used Together with BBQ of the grill holder(8) !
5. Use two m4x14 screws respectively through a stainless steel flat washer and grill lid (2) into the handle (1) Then
screw clockwise.
Note: the m4x14 screws and the handles(1) are pre assembled.
6. The grill lid(2) is inserted into the grill holder(8)as
shown in the figure
7. the temperature regulator and the cable(3) The electrical plug is inserted into the power socket.When inserting
or removing power cord shall be remained the grill holder(8) stable on the appliance.
4. Place the grill plate (6) in the grill holder BBQ (8) Insert the inlet
socket (5) of the grill plate into the grill holder of the socket hole ,
Then lower the grill plate onto grill holder. Make sure it is cool and
disconnected from the power.
Attention: The grill plate(6) must only
be used Together with BBQ of the grill holder(8) !
5. Use two m4x14 screws respectively through a stainless steel flat washer and grill lid (2) into the handle (1) Then
screw clockwise.
Note: the m4x14 screws and the handles(1) are pre assembled.
6. The grill lid(2) is inserted into the grill holder(8)as
shown in the figure
7. the temperature regulator and the cable(3) The electrical plug is inserted into the power socket.When inserting
or removing power cord shall be remained the grill holder(8) stable on the appliance.
4. Place the grill plate (6) in the grill holder BBQ (8) Insert the inlet
socket (5) of the grill plate into the grill holder of the socket hole ,
Then lower the grill plate onto grill holder. Make sure it is cool and
disconnected from the power.
Attention: The grill plate(6) must only
be used Together with BBQ of the grill holder(8) !
5. Use two m4x14 screws respectively through a stainless steel flat washer and grill lid (2) into the handle (1) Then
screw clockwise.
Note: the m4x14 screws and the handles(1) are pre assembled.
6. The grill lid(2) is inserted into the grill holder(8)as
shown in the figure
7. the temperature regulator and the cable(3) The electrical plug is inserted into the power socket.When inserting
or removing power cord shall be remained the grill holder(8) stable on the appliance.
4. Place the grill plate (6) in the grill holder BBQ (8) Insert the inlet
socket (5) of the grill plate into the grill holder of the socket hole ,
Then lower the grill plate onto grill holder. Make sure it is cool and
disconnected from the power.
Attention: The grill plate(6) must only
be used Together with BBQ of the grill holder(8) !
5. Use two m4x14 screws respectively through a stainless steel flat washer and grill lid (2) into the handle (1) Then
screw clockwise.
Note: the m4x14 screws and the handles(1) are pre assembled.
6. The grill lid(2) is inserted into the grill holder(8)as
shown in the figure
7. the temperature regulator and the cable(3) The electrical plug is inserted into the power socket.When inserting
or removing power cord shall be remained the grill holder(8) stable on the appliance.
Use two m4x14 screws respectively through a
plain washer and grill lid (2) into the handle (1).
Then screw clockwise.
Note: the m4x14 screws and the handle (1) are
preassembled.
The grill lid(2) is inserted into the grillholder(8)
as shown in the figure
5

POWER GRILL APOLLO
WARNING
Read Carefully
●IF THE ELECTRIC GRILL IS USED AS A TABLE GRILL, IT MUST
ONLY BE USED WITH THE GRILL PLATE AND THE GRILL HOLDER.
●KEEP THE GRILL AT LEAST 30 CM FROM ANY WALLS WHEN
OPERATING. DO NOT SCREW DOWN THE PLASTIC FEET UNDER
THE GRILL PLATE. THIS WOULD REDUCE THE REASONABLE GAP
BETWEEN THE GRILL PLATE AND THE GRILL HOLDER, WHICH
WOULD LEAD TO MELTING OF THE PLASTIC PARTS. THIS COULD
LEAD TO SERIOUS INJURIES AND DAMAGE TO THE APPLIANCE.
●ATTENTION PLEASE TAKE CARE. AVOID TRIPPING OVER BY THE
POWER CORD WHEN OPERATING THE APPLIANCE,ARRANGE
THE POWER CORD SO ITS OUT OF YOUR WAY.REMEMBER TO
REMOVE THE PLUG AFTER USE.
6

Indoor usage
The appliance can be used indoors as a table grill.
Hold the grill plate 4 and the grill holder 5 at the
heat-insulated grill holder handles 11 and lift it
from the mounting bracket 6.
Carry the table grill inside to use it indoors.
Make sure to not trip over the power cord.
Recommendation: It is recommended to not
use the grill lid (2) indoors.
Outdoor usage
Please read these instructions carefully. They will give you important advice for the use, security and
maintenance of this appliance. Keep these instructions and, should the situation arise, pass them on to
other users. The appliance must only be used for the intended purpose according to these
instructions.
●Observe any local regulations.
●Dispose of the packaging thoughtfully.
Before using the appliance for the first time:
●Remove all the packaging materials and wash the grill plate (6). Oil collecting tray (7) and grill lid (2)
thoroughly.
Important:
Dry all the different parts thoroughly. This applies especially to the power inlet socket(3). Never
immerse the power cord with regulator() in water. Heat the grill to its maximum setting for about
3-5minutes,with the roasting hood in place and without any food. Residues left from manufacturing
may cause some smell and smoke when the appliance is used for the first time.
Before use
7

POWER GRILL APOLLO 8
Safety regulations
●This appliance is not meant for commercial use but exclusively for private use
●This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved shall not be done by with the appliance.Cleaning and user maintenance shall not
be done by children without constant supervision.Keep the appliance and its cord out of reach of
children less than 8 years.
●Plug the appliance only in on outlet as mentioned on the rating plate and only plus it into an eart-
hed, three-pin socket.
●Use only one appliance per socket and use only earthed extension cables in safe condition,with
earth wire cross section of at least 1.0mm²(capacity at least 10A).
●It is strongly recommend that power for any domestic appliance must only be supplied through a
residual current devive(RCD) having a rated residual operating current not exceeding 30mA.
●Consult your electrician for details.
●Only the appropriate power cord as supplied with this unit must be used.
●The power cord should be regularly examined for signs of damage,and if the cord is damaged, the
appliance must not be used.
●The appliance must not be operated(disconnect the mains plug immediately) when:
• The appliance, casing or power cord is damaged.
• The appliance shows visible signs of damage.
• A fault is suspected after the appliance has been dropped or similar.
●Switch off at the power point and disconnect the main plug.
• In case of faults during use.
• Before cleaning or moving the appliance from place to place.
• After use
●Please check the device and the power cord regularly,and stop using immediately by disconnecting
the power cord from the power if you have any problems with the device.
●If the power line is damaged, it must be replaced by the manufacturer, its after sales department or
similar professionals to avoid the risk
●Do not use this appliance within reach of water contained in bath-tubs,washbasins or other recepta-
cles.Never expose it to rain,snow or other moisture.
●Position the power cord and cable so that unintentional touching or catching is impossible.
●Never allow the extension lead or power cord to be in touch with the hot grill plate.
●Don't pull the power cord over sharp edges, don't wedge (eg under doors etc.)
●Don't not stand the BBQ over the edge or corner of a table and avoid all contact with the BBQ hot
surfaces.
●Don't not use the appliance without the oil collecting tray and the BBQ base all fitted properly
together.
●Never cover the hotplate with aluminum foil for trays(this might damage the non-stick coating).
●Make sure without fail that this appliance is assembled correctly before use.
●Keep the electric grill at least 30cm from any walls when in operation.
●The temperature of accessible surfaces may be dangerously high when the appliance is operating.
take care when the appliance is in use. Keep it away from combustible materials.
●Take care! The hotplate will get very hot, and it stays hot for a long time after it has been switched
off. Beware of burns! Do not touch any hot surfaces and take care when handling the appliance
after use.
Safety

●Beware of fat oil or moisture spitting while grilling.
●Do not leave the appliance unattended when switched on or still hot.
●Do not touch the appliance(lid or grill plate) when cooking in order to prevent any risk of burning.
●Charcoal or similar combustible fuels must not be used with this appliance.
●This appliance is intended to be used in household and similar applications such as:
• Staff kitchen areas in shops,offices and other working environments.
• Farm houses.
• By clients in hotels, motels other residential type environments.
• Bed and breakfast type environments.
●Use this appliance only as described in this manual.Any other use not recommended by the manu-
facturer may cause fire, electric shock or injury to persons possibly resulting in depth or permanent
disablement.
●This appliance is only to be used or cooking.
●Never pull the plug out of the socket by the power cord or with wet hands.
●For safety reasons do not use attachments that were not recommended or supplied by the manu-
facture.
●Always switch off the appliance before removing the mains plug.
●Before removing attachments or cleaning the appliance,allow it to cool completely.
●The power cord must be removed before the appliance is cleaned and the appliance inlet must
thoroughly dried before the appliance is used again.
●Never immerse the power cord or the thermostat plug in water or any other liquid.
●Never immerse the appliance with heating element,the appliance should be switched off at mains
when not in use.
●Only professional trained personnel should repair electrical appliances.
●Unskilled repairs cause considerable danger to the user.
●No warranty for any possible damage can be accepted if the appliance is used for improper
purpose, wrongly operated or unprofessionally. In such a case,any warranty claim is void.
DISPOSAL
●Disable unserviceable appliance immediately.Remove the mains plug and cut up the mains
connection cable.If possible,bring unserviceable appliances to an official waste collection point.
Many local authorities provide removal services for bulky refuse at least once a year.
●Please see separate sheet for warranty details.
●For service and warranty repairs please contact your place of purchase.
MODEL VO LTAG E POWER IP-Code
FCCEG- /
RO-F
230V,
50/60Hz, W IPX
9
Safety / Technical data

POWER GRILL APOLLO 10
●
●Connect the appliance to the mains electricity supply.
●Set the temperature regulator (3) to the required temperature level(it usually takes about 3 minutes
to preheat).Preheating is faster with the roasting hood in place.
●The temperature indicator lamp (4) will go out as soon as the required temperature has been
reached.
●Place the food to be grilled on the grill plate (6).
Cooking timers
●The following are recommended cooking times.Different times will be required for weights and
sizes of foods to be grilled,and depending on whether you are grilling with or without the grill lid.
weather conditions can also affect cooking times.
1. It will take approximately 3-5 minutes to heat up before barbecuing.Turn the temperature control
switch 1-MAX (5) to MAX position. The Temperature indicator lamp will illuminate,at the same
time the heating element will start to heat up.
2. Now the food can be placed on the grill plate.Deep frozen food should be defrosted completely
before barbecuing.
3. You can adjust the temperature with the temperature control switch.Once the required
temperature has reached,the pilot lamp will go out
4. To switch off the barbecue,turn the temperature switch to "MIN" position and unplug the power
cord from outlet
5. Burn hazard! if for any reason/ the barbecue base must be moved when the appliance is still hot,
always hold only by its heat-insulated handles and move it slowly.
6. This table shows som guiding values for the cook the cook time of different barbecue food. The
barbecue time can vary according to personal taste and the thickness of the meat.
Tips
FOOD TEMPERATURE
SETTING
APPROXIMATECOOKING
TIME (MINS)
Steak/beef 515-25
Lamb 515-25
Chicken drumsticks 515-20
Chops 520-25
Chicken wings 515-20
Fillet of pork 4~5 10-15
Whole fish 510-15
Kebabs 3~4 10-20
Various sausages 3~4 10-15
Green pepper 3~4 5-10
Onion 3~4 10-15
Mushroom 3~4 5-10
Potato Slices 3~4 10-15

CLEANING
●Your meat will be more if you marinade in the refrigerator it over night before cooking(you can
make your own marinade from oil (to aid moistness),vinegar,fruit juice or wine (to tenderize) and a
mixture of seasonings for flavor).
●Always use tongs to turn grilled food (using a fork to turn the food will dry it out and damage the
●non-stick coating). Take care with tongs not to damage the non-stick coating.
●Only turn meat and fish once during grilling.You do not need to turn it more than once and too
much turning dries food out.
●Never cook meat for too long. Even pork is better if it is served when it is still a little pink and juicy.
●If cooked food sticks to the grill plate,rub the plate with a piece of kitchen paper soaked in oil from
time to time.
●Cleaning and looking after the appliance
●Disconnect the appliance from the mains electricity supply.
●Allow the grill to cool completely.
●Take the temperature Regulator with power cord (3) out of the appliance
socket (5).
●Clean the grill plate(6) and Oil collecting tray (7) with warm washing-up wa-
ter and a damp cloth.Do not use steel wool pads,brush or abrasives to avoid
any damages to the coating of grill plate.
●Wipe the holder (8) of the appliance with a damp cloth. Fat splashes can be
removed with a mild cleaning agent.
Note:
●The grill plate has a non-stick coating.Do not scratch this coating during
either the cooking or the cleaning stages.
TIP:
●Protect the appliance from dust and dirt if it is not to be used for a pro-
longed length of time (dry thoroughly then wrap it in a plastic bag).
●Store it in a cool dry place.
11
Tips / Cleaning

Always attach your receipt and product serial number when making a warranty claim.
Serial number is located on the side of the BBQ.
Produced in China for FCCProducts
This product is covered by a warranty in accordance with consumer legislation. It has
undergone strict quality controls and testing at the factory.
If there are any parts missing or the product has been damaged, please contact your
dealer or the consumer contact below for help.
Faults due to misuse, lack of maintenance or modification of the product will
invalidate the warranty. Damaged parts not due to a fault with the product will be
invoiced according to our price list + carriage and administration fee.
If new parts are needed or in the event of a warranty claim, please contact your
dealer or consumer contact:
FCCPRODUCTS
KJELLERVEST   KJELLER NORWAY
[phone]
[e-mail]
www.fccbbq.com
Support opening hours: 10-14
We are always looking for ways we can improve our products. Therefore, we reserve the right to change
technical specifications at any time. You will always find the latest manual on www.fccbbq.com
POWER GRILL APOLLO
Consumer contact
