The Flying Culinary Circus FCC BBQ EXTREME 3.1 User manual

Sare  u  cookin!
MANUAL
Assembly, use, maintenance and safety
!OUTDOORUSEONLY
READTHEMANUAL, FOLLOWTHE
ASSEMBLYINSTRUCTIONSSTEPBY
STEP. GETTOKNOWYOURGRILLAND
THESAFETYINSTRUCTIONSBEFORE
USINGTHEAPPLIANCE!
FCC-G-20290-31 / BW-GK43100

Contents
3
4
5
6
8
22
23
24
25
26
28
29
30
Warnings
Technical data
Read before assembly
Parts list
Assembly
Regulator and hose
Check for leaks before using the barbecue
Last check
Lighting instructions
Maintenance
Advice, tips and safety
Troubleshooting
Consumer contact

WARNINGS!
●ACCESSIBLE PARTS OF THE GRILL BECOME VERY HOT
DURING USE. KEEP CHILDREN AND OTHERS WHO NEED
SUPERVISION AT A SAFE DISTANCE.
●THE GRILL IS INTENDED FOR OUTDOOR USE ONLY IN WELL-
VENTILATED AREAS.
●LEAK TESTS (SEE PAGE 23) MUST ALWAYS BE CARRIED
OUT BEFORE THE GRILL IS USED AND WHEN REPLACING
THE GAS CONTAINER. ALSO PERFORM A LEAK TEST IF THE
PRODUCT HAS NOT BEEN IN USE FOR A LONG TIME AND IN
ADVANCE OF A NEW BARBECUE SEASON. ALWAYS CHECK
THE GAS HOSE FOR DAMAGE AND CRACKS BEFORE USING
THE BARBECUE.
●NEVER BARBECUE IN CLOSED ROOMS OR UNDER ROOFS,
AS THIS MAY LEAD TO A LACK OF OXYGEN.
●FAILURE TO FOLLOW THE INSTRUCTIONS PROVIDED CAN
IMPLY A RISK OF SERIOUS INJURY TO PERSONNEL AND
FIXED INSTALLATIONS.
●REBUILDING / MODIFYING THE BARBECUE CAN CAUSE
DANGER AND WILL INVALIDATE THE WARRANTY.
●ALWAYS SUPERVISE THE BARBECUE DURING USE AND KEEP
SUITABLE EXTINGUISHING EQUIPMENT WITHIN REACH.
THE GRILL SHOULD NOT BE OPERATED BY INTOXICATED
PERSONS.
●THE BARBECUE MUST NOT BE USED IN PLACES THAT ARE
BELOW NORMAL GROUND LEVEL. GAS CAN ACCUMULATE
AND REPRESENT A DANGER OF EXPLOSION. GAS
ACCUMULATION CAN ALSO CAUSE OXYGEN DEFICIENCY.
●THE BARBECUE MUST BE CLEANED REGULARLY AND
THOROUGHLY TO PREVENT UNCONTROLLED GREASE FIRE.
READ MORE ABOUT GREASE FIRE ON PAGE 26
ALSO READ PAGE 28 FOR MORE ADVICE AND TIPS ON GRILLING AND SAFETY..
3fccbbq.com

Tekniske data
Technical Data
Total Heat input: 13.3 kW
Gas consumption: Butane 967 g/h / Propane 949 g/h
Gasbottle (not included): Use standard bottle approved for use in the Nordic Region.
Even though butane and propane gas can be used, we recommend propane for use in the
Nordic Region. Approved hoses and regulators are available from most outlets selling gas
equipment.
Regulator and hose are sold separately and are not part of this grill. Most dealers of gas-
powered products have regulators and gas hoses for sale.
Only use a regulator and gas hose that is approved for use in Norway and install this in
accordance with the instructions on page 22.
Perform the gas leak test as instructed on page 23 before using the product.
NB! Gas hoses used for this product must not exceed 120 cm in length.
BE, BG, GY, CZ, DK, EE,
FI, FR, GB, GR, HR, HU,
IT, LT, LU, LV, MT, NL, NO,
RO, SE, SI, SK, TR
ø0.90 mm main burner
ø0.91 mm side burner
G30(Butane)
G31(Propane)
and their mixtures
I3B/P(30)
0063-21
USE ONLY GAS TYPE AND GAS CATEGORY ENTERED IN THIS MANUAL.
!
DESTINATION OF
COUNTRIES TO USE GAS TYPEVALVE SIZE GAS CATEGORY
The product is manufactured in accordance with European Gas Appliances Regulation (EU) 2016/426
h: 117.6cm
w: 156cm
d: 62.4cm
4

Read before assembly
Make sure that all parts and screws are included and that they are
undamaged before assembling the product.
If the barbecue is damaged during transport, do not assemble the
barbecue before contacting your dealer or [e-mail].
Transport damage to parts, varnish or enamel must be reported to
the dealer or [e-mail] before the barbecue is installed
and used.
Please note that some parts may be located in the Styrofoam to
protect the part during transport. If parts are missing, first check
the packaging carefully.
Compare the parts list with the contents of the box. Do not
assemble this grill if there is damages or parts are missing, contact
your dealer or [email protected]om.
Remove all remnants of packaging material and any plastic wrap
from the barbecue.
●FOLLOW THE ORDER IN THIS MANUAL TO AVOID INCORRECT
ASSEMBLY. PARTS OF THE ASSEMBLY WILL REQUIRE HEAVY LIFTING
WHICH SHOULD BE PERFORMED BY TWO PEOPLE TOGETHER, TO
AVOID PERSONAL INJURY AND DAMAGE TO THE BARBECUE. SOME
METAL PARTS MAY BE SHARP, WEAR PROTECTIVE GLOVES.
●POWER TOOLS SHOULD NOT BE USED TO ASSEMBLE THE BARBECUE.
TOOLS WITH TOO MUCH FORCE CAN DAMAGE THE SURFACE
TREATMENT ON SCREWS, DAMAGE ENAMELLED / LACQUERED PARTS
OF THE BARBECUE, AS WELL AS LOOSEN PRE-ASSEMBLED NUTS.
●IF THE PRODUCT'S VARNISH OR ENAMEL IS DAMAGED DURING
ASSEMBLY, WE RECOMMEND THAT THE DAMAGE BE TREATED
IMMEDIATELY TO AVOID LATER RUST DAMAGE. SUITABLE HEAT-
RESISTANT VARNISH CAN BE ORDERED FROM [e-mail].
!
FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID
SERIOUS PERSON INJURY OR DAMAGE TO YOUR BARBECUE.
FIRST TIME USE – GRILL BURN-OFF
BEFORE USING THE BARBECUE FOR THE FIRST TIME, IT IS IMPORTANT TO
COMPLETE A BURN-OFF. FIRE UP THE BARBECUE AND OPERATE FOR A MINIMUM
OF 15 MINUTES ON MAX TEMPERATURE TO BURN-OFF THE UNIT. THIS WILL “HEAT
CLEAN” THE INTERNAL COMPONENTS, DISSIPATE ODORS AND RID IT OF ANY
FOREIGN MATTER.
THEBARBECUESHOULDBEASSEMBLEDONALEVELSURFACE.
5fccbbq.com

CODE DESCRIPTION QTY
GASGRILLASSEMBLY 
COOKINGGRATESUPPORT 
COOKINGGRATE 
WARMINGRACKSUPPORT 
WARMINGRACKGRID 
SIDEBURNER 
FMETAMER 3
LEFTSHELF 
RIGHTSHELF 
 SIDEBURNERCOVER 
 SIDEBURNERKNOB 
 ROUNDCOOKINGGRATE 
 GREASETRAY 
 RIGHTREARCORNERBRACE 
 RIGHTSIDEBRACE 
 RIGHTSIDEPANEL 
 REARCASTERSWITHOUTBRAKE 
 BATTERYHOLDERFOR xAA BATTERIES (NOT INCLUDED) 
 RIGHTFRONTCORNERBRACE 
 BIGCOOKINGGRATE (FORMGS) 
 FRONTCASTERSWITHBRAKE 
 RIGHTDOOR 
 GREASE CUP 
 LEFTREARCORNERBRACE 
 DOORSTOP 
 LEFTSIDEBRACE 
 LEFTSIDEPANEL 
 LEFT FRONT CORNER BRACE 
 REAR PANEL 
 BOTTOM SHELF 
 TOPSUPPORT 
 LOWERFRONTPTE 
 LEFTDOOR 
Parts list
6

Parts list
CODE DESCRIPTION QTY
ASCREWMx 
BWASHERØ 
DSCREWMx 
GSCREWMx 
HPHILIPSSCREWDRIVER 
I HEXWRENCH / 
J HEXWRENCH / 
A
H
B
I
D
J
G
1
2
4
7
8
18
10
6
9
11
15
14
16
19
17
21
26
30
24
27
28
31
33
25
32
22
34
5
23
13
3
12
20
21
17
7fccbbq.com

Assembly
AM6x15 x 8 pcs
2.
AM6x15 x 8 pcs
1. Fit the right rear corner brace (14) and the right front corner brace (19) to
the right side panel (16) with screw (A). Then mount the right side brace (15)
on the corner braces (14) and (19) with screw (A).
Fit the left rear corner brace (24) and the left front corner brace (28) to the
left side panel (27) with screw (A). Then mount the left side brace (26) on
the corner braces (24) and (28) with screw (A).
A
A
14 16
19
15
A
A
27
28
24
26
8

Assembly
AM6x 15 x 10 pcs.
3.
4.
Install the left and right side panels with corner brace to the bottom panel
(31) with screw (A).
AM6x15 x 5 pcs
Install rear panel (30) between the corner brace (14) and (24) with screw (A).
Note which way the panel is mounted.
A
A
28
31 19
14
24
A
30
31
24
14
28
19
9fccbbq.com

Assembly
AM6x15 x 12 pcs.
5. Install top support (32) and lower front plate (33) between corner brace
(19) and (28) with screw (A). Then secure plate (33) by tightening screw (A)
from the underside as shown in the lower drawing.
19
28
32
33
A
A
14
24
30
A
10

Assembly
6. Mount the wheels (17) on the base cabinet with the wrench.
The wheels with brakes (21) must be in front of the base cabinet.
14
24
28
17
17
21
19
21
J
11 fccbbq.com

Assembly
7. Install the door stop (25) by attaching it to the top support (32) and the
botom shelf (31) using screw (A).
AM6x15 x 4 pcs
A
A
25
32
31
28
24
14
19
12

Assembly
8.
34
22
32
33
Install the doors (22) and (34) in the base cabinet by inserting the lower
pin of the door into the hole in lower front plate (33). The upper pin is
spring-loaded and can be checked in the opening on the inside of the
door. Pull the pin in and adjust to the hole in the top support (32).
13 fccbbq.com

Assembly
9.
TWO PERSONS IS RECOMMENDED
WHEN LIFTING THE GRILL ASSEMBLY BODY.
!
A
B
M6x15 x 6 pcs
ø6 x 2 pcs
Mount the gas grill assembly (1) on top of the base cabinet. It is
recommended to have two people when the grillassembly is lifted into
place. Secure the grill assembly with screw (A) in the fasteners on the base
cabinet. Then screw screw (A) with washer (B) into the front corner posts
from inside the grill body as shown below.
A
B
A
1
14

Assembly
10.
AM6x15 x 4 pcs
Mount the side tables (8) and (9) by hooking the side table onto the pre-
assembled screws in the grill body (1). Insert screw (A) in the lower part
of the side table against the base cabinet. Tighten all the screws to the
table when it is seated correctly.
These M6 screw are
pre-assembled. Loosen
the screw and hang the
side table on the screws.
A
81
9
A
81
A
81
15 fccbbq.com

Assembly
11. Install the side burner (6) in the opening in the side table with a screw (G).
Use the wrench to hold the nut while tightening by hand. Use screw (D) to
attach the valve to the front of the side table. Then connect the cable to
the lighter as shown below.
Plug in the ignition wire
The wrench is stuck to
the hexagonal position
of the side burner valve,
and screw it by hand.
D
G
M4x12 x 2 pcs
M6x12 x 3 pcs.
D
I
6
G
16

Assembly
7
24
12.
13.
Place the side burner cover (10) on the side burner (39).
Slide on the side burner switch (11) on the valve as shown below.
Insert the cooking grate support (2) and flame tamers (7) above the
burners. Hook on holder for heating shelf (4).
10
11
9
6
17 fccbbq.com

Assembly
14. Insert cooking grate in order from left (20), (12), (3) and heating shelf (5).
5
12
20
3
18

Assembly
13
15. Push in the grease tray (13) from the back of the bbq..
16. Slide the grease cup (23) into the groove under the grease tray.
23
19 fccbbq.com

Assembly
18
+
+
-
-
THIS GRILL HAS LED LIGHTS AROUND
THE SWITCHES THAT ARE POWERED
BY 2xAA BATTERIES (NOT INCLUDED).
!
1 7. Insert batteries for LED lights around switches into the battery box (18).
Magnetic mount
