Thermo Scientific Orion VERSA STAR VSTAR-RD User manual

Thermo Scientific Orion VERSA STAR™
RDO/DO/Temperature Module
Reference Guide

Ross and the COIL trade dress are trademarks of Thermo Fisher Scientific, Inc. and
its subsidiaries.
AQUAfast, AQUASensors, BOD AutoEZ, ionplus, KNIpHE, LogR, No Cal, ORION, perpHect,
PerpHecT, pHISA, pHuture, Pure Water, Sage, ROSS, ROSS Ultra, Sure-Flow, Titrator PLUS, and
TURBO2 are registered trademarks of Thermo Fisher Scientific, Inc. and its subsidiaries.
A+, All in One, Aplus, AUTO-BAR, AUTO-CAL, Auto-ID, AUTO-READ, AUTO-STIR,
Auto-Test, AutoTration, CISA, digital LogR, DuraProbe, EZ Startup, ISEasy,
Low Maintenance Triode, Minimum Stir Requirement, MSR, NISS, Optimum Results, Orion Dual
Star, Orion Star, SAOB, SMART AVERAGING, SMART STABILITY, Star LogR, Star Navigator 21,
Stat Face, Triode are trademarks of Thermo Fisher Scientific, Inc. and its subsidiaries.
Guaranteed Success and The Technical Edge are service marks of Thermo Fisher Scientific, Inc.
and its subsidiaries.
© 2011 Thermo Fisher Scientific Inc. All rights reserved. All trademarks are the property of
Thermo Fisher Scientific, Inc. and its subsidiaries.
The specifications, descriptions, drawings, ordering information and part numbers within this
document are subject to change without notice.
This publication supersedes all previous publications on this subject.

Thermo Scientific Orion VERSA STAR™ RDO/DO/Temperature Module
Table of Contents
Chapter 1 Introduction ..........................................................1
Chapter 2 Module Overview .....................................................3
Module Connections and Inputs ........................................ 3
Module Maintenance.................................................. 4
Display Information From Module ....................................... 4
Chapter 3 Setup Menus .........................................................5
Setup Menus for Primary Measurements ................................ 5
Read Type Information..............................6
RDO Probe Information .............................6
Setup Menu for Temperature ........................................... 7
Chapter 4 RDO/DO Calibration ...................................................9
Calibration Methods................................................... 9
Calibration Procedure ................................................. 9
Chapter 5 Temperature Calibration ..............................................11
Chapter 6 Measurement........................................................13
Chapter 7 Methods ............................................................15
Chapter 8 Data Storage and Review .............................................17
Data Storage Settings ................................................ 17
Measurement Read Type...........................17
Datalog, Computer and Printer Export Settings ..........17
Datalog Review ...................................................... 17
Calibration Review................................................... 18
Chapter 9 Customer Services ...................................................19
Troubleshooting Guide................................................ 19
Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Warranty and Registration ............................................ 19
WEEE Compliance ................................................... 19
Declaration of Conformity ............................................. 20
RDO/DO/Temperature Module Specifications ........................... 21
Ordering Information ................................................. 22
Appendix Advanced Features...................................................27
Dissolved Oxygen Barometric Pressure Compensation .................. 27
Dissolved Oxygen Salinity Correction .................................. 27

This page intentionally left blank.

1
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 1 Introduction
Thank you for your purchase of the Thermo Scientific Orion VERSA STAR™ RDO/DO/Temperature Module.
This module is for use with the Thermo Scientific Orion VERSA STAR Advanced Electrochemistry Benchtop Meter.
Some key features of this module include:
• WorkswithandautomaticallyrecognizesOrionpolarographicDOandRDOoptical/
luminescence-base probes
• PolarographicDOprobemeasurementrangeof0to90mg/Land0to600%saturation
• RDOprobemeasurementrangeof0to50mg/Land0to500%saturation
• Readingscompensatefortemperature,salinityandbarometricpressure
• Automaticandmanualdataloggingoptions
• Quickcalibrationusingwater-saturatedair,air-saturatedwater,Winklertitrationorzeropoint
Pleasereadthisreferenceguidethoroughly.Anyuseoutsideoftheseinstructionsmayinvalidateyourwarrantyand
causepermanentdamagetothemeter.

This page intentionally left blank.

3
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 2 Module Overview
Toconnectthemodulestothemeterandforspecicinformationregardingthemeteroutputs,pleaseseethe
Orion VERSA STAR Reference Guide. The Reference Guide is on the CD included with the meter and also available
at www.thermoscientific.com/water.
Module Connections and Inputs
1. SelecteithertheRDOorPolarographicDOprobebasedonsamplerangeandtestingrequirements.
2. Placeselectedprobeinthemeter’selectrodearm.IfusingtheRDOprobe,attachtheincludedadapter.
3. Attachthe9pinmini-DINconnectionintotheRDO/DOmodule.
4. Attachthestirrertothesideofthemeterandintothemeter'selectrodearm,ifneededforyour
test method.
5. Setupareawithdeionizedrinsewater,sampleandothersupplies.
6. Connectthemeterfordatacollection(Hyperterminal,LIMS,StarPrinter,etc),ifdesired.
7. PowertheOrionVERSASTARmeter,stirrer,anddatacollectiondevice(s).
RDO/DO Module
9pinmini-DINconnectorfor
RDOorpolarographicDOprobe

4Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Module Maintenance
Forroutinemaintenance,dustandwipethemodulewithadampcloth.Ifnecessary,warmwaterormildwater-based
detergentcanbeused.Maintenancecanbeperformedonadaily,weeklyormonthlybasis,asrequiredbyoperating
environment.Immediatelyremoveanyspilledsubstanceusingthepropercleaningprocedureforthatspilltype.
Display Information from Module
ExampleRDOMeasurementScreen–SingleChannel
Date and time
Primaryreading
Barometric
pressure
Sample
Temperature
Calibration
information
RDO cap life
information
(changestored
colorat30days)
Theinformationonthedisplaycanbecustomized.
Enterthesetupmenutomakechanges.
1.PressSetup.
2.UsethearrowkeystohighlightInst.Settings,
press (f3/select) key.
3.UsethearrowkeytohighlightDisplayView.
 Press(f3/select) key.
4. Follow the onscreen prompts to choose what you
would like to see on the measurement screen.

5
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 3 Setup Menus
Setup Menus for Primary Measurements
1. SelecttheRDO/DOchannelbypressingthechannelkey,thenpressf3 (Setup).
The meter detects the RDO or DO probe type automatically and selects mode menu.
2. Selecttheoptionsforyourtesting.
3. Pressthef1 (Back) button to step back to the main screen.
RDO/DO Setup Menu
(Default values are in bold in the table below)
ProbeSerialNumber Input
SampleID Off,Manual,AutoIncrement
Resolution
Dependent on measurement unit:
0.1 (default),1for%sat
0.01(default),0.1formg/L
Stability Smart,Fast,Medium,Slow
Averaging Off,Automatic Smart
Read Type AutoRead,Timed,Continuous
Measurement Unit mg/L,%
PressureCompensation Auto,Manual
Salinity Correction Auto*,Manual
Alarm** Limit,CalDue,SetPoint
*ForautomaticsalinitycorrectionofRDO/DOreading,
ensureoxygenprobeandconductivitycellareinthesamesample.
**Limitandsetpointalarmdefaultsetto‘off’.
Cal due alarm set to 12 hours.

6Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Read Type Information
There are three main read types available as shown in the setup menus.
• Auto-Read – Themeterwilldisplaythemeasurementasitstabilizesandlockandholdthe
measurementwhenitisstable.(TheARiconwilllockonthescreen.)Oncethemeasurementislocked,
themeterwillautomaticallyexportthemeasurementtothedatalog,ifthedatalogisenabledin
thesetupmenu,andtoaprinterorcomputer,ifaprinterorcomputerisconnectedtothemeterand
enabledinthesetupmenu.Totakeanewmeasurement,pressmeasure (esc)/1.
• Timed – Themeterwillreadanddisplayameasurementatthesettimeintervalthatisprogrammed
by the operator. There are two options:
 1. Bychecking/selectingthe"Interval"box,atthesettimeinterval,themeterwillautomatically
 exportthemeasurementtothedatalog,ifthedatalogisenabledinthesetupmenu,andtoa
 printerorcomputer,ifaprinterorcomputerisconnectedtothemeterandenabledinthesetup
 menu.Ifselected,enterthetimeintervalvalueinahours:minutes:secondsformatusingthe
numeric keypad and press f3 (select) key.
 2. Ifthe"Interval"boxisunchecked/notselected,asingletimedmeasurementwillbetaken.
 Themeterwillapplythesamesavingandexportingdataconditionsaswiththesettimeinterval
 torecordandexportdata,butlockafteronetimedintervalhasexpired.Pressmeasure (esc)/1
 toresetthecountdownclockandtakeanewreading.
• Continuous – The meter will continuously measure and update the display. This read type is useful
whenperforminganexperimentthatrequirescontinuousmeasurementstobetaken.Pressthe
log/print/0keytoexportthemeasurementtothedatalog,ifthedatalogisenabledinthesetup
menu,andtoaprinterorcomputer,ifaprinterorcomputerisconnectedtothemeterandenabledin
the setup.
RDO Probe Information
TheRDOprobeworkswithauniqueopticalcap.Informationexclusivetothiscap,suchas:
• Serialnumber
• Remainingcaplife
• Dateofmanufacture
canbefoundinthesetupmenuwhentheRDOprobeisconnectedandrecognizedasthemeasurementmode.
1. Verify RDO probe is connected.
2. Press setup/3.
3. UsethearrowstohighlightthechannelwithRDOifneeded.Pressf3 (Select) key.
4. UsetherightarrowtohighlightRDOElectrodeInfotoreviewinformation.

7
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Setup Menu for Temperature
AllofthetemperaturemeasurementsettingsarefoundinTemperatureSetupmenuforeachmeasurement.
*Thisnumberwillchangetomatchthesetupmenuchannel.
Temperatureprobescanbesetupinthemeasurementmodeofthesampleyouaremeasuring.Ch-1ATCallowsthe
temperatureprobetobeusedinmorethanonechannelfortemperature-compensatedmeasurements,suchaswhen
apHelectrodeanda2-cellconductivitycellareinthesamemeasurementsample.TemperatureisacriticalpHand
conductivitymeasurementasthemeasurementvaluesrequireatemperaturecorrectiontodeterminethereference
value,often25ºCintheAmericaand20ºCinEurope.
Temperature Unit ºCorºFselection
Temperature Input and Type Ch-1ATC,Ch-2ATC,Ch-3ATC,Ch-4ATC,MTC
Temperature Cal Ch-1* ATC only or All ATC allows all ATCs to be
calibrated at once

8Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
This page intentionally left blank.

9
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 4 RDO/DO Calibration
PolarographicDOprobesonly–Theseprobesneedtobepolarizedpriortouse.Itiscontinuouslypolarizedwhen
connectedtothemeter.Iftheprobeisneworhasnotbeenconnectedtothemeter:connecttheprobetothemodule
connectedtothemeter,connectthemetertoapowersourceandwait30minutesforpolarization.
Calibration Methods
• Water-Saturated Air (Air) – Thesimplestandmostaccuratemethod,thismethodusesthe
calibration sleeve included with the DO probe. Due to the inherent differences between water
saturatedairandair-saturatedwater,102.3%saturationwillbedisplayedwhenthecalibration
readingisstableusingapolarographicDOprobe.Forbestaccuracy,thecalibrationtemperature
shouldmatchthemeasuringtemperature.Moistenthespongeorabsorbentclothinthecalibration
sleevewithdistilledwaterandinserttheprobeintothesleevewithouttouchingthe
water-saturated material.
• Air-Saturated Water (Water) – Usewaterthatis100%saturatedwithair.Bubbleairintoawater
sampleforanextendedperiodoftime,preferablyovernight.
• Winkler Titration (Manual) – This method uses a water sample with a known concentration
ofdissolvedoxygenandcanbeusedtocalibratetheDOprobetothevalueachievedbyaWinkler
titration.AmanualcalibrationinvolvesperformingaWinklertitrationandusingthatsampleasa
calibrationstandard.Theoxygenlevelresultingfromthetitrationisentered.Thiscorrelatesthe
meterinputtotheWinklertitration.Duetothepossibilityoftitrationerrors,thismethodisinherently
less accurate.
• Set Zero – Azeropointcalibrationrequiresoxygen-freesolution.Thismethodneedstoberepeated
eachtimetheprobeisreplacedormodied(capchangewithRDOprobes;membranechangeor
freshelectrolytewithpolarographicDOprobes).Thiscalibrationisgenerallynotrequiredunless
measurementswillbetakenbelow10%saturationor1mg/L.Anairorwatercalibrationneedstobe
performedpriortoazeropointcalibration.
Calibration Procedure
1. Presscal/. to enter calibration mode.
2. Follow the screen prompts for calibration.
3. The calibration can be saved or printed when complete.
4. Informationforthelastcalibrationcanbedisplayedonthemainmeasurementscreen.Refertothis
referenceguide,Chapter2ModuleOverview,DisplayInformationsectionformoreinformation.

10 Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
This page intentionally left blank.

11
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 5 Temperature Calibration
TheATCtemperaturedisplayhasarelativeaccuracyof±0.1°C.TemperaturesensorsbuiltintoRDO/polarographic
DOprobeshavevaryingtemperatureaccuracies,usually±0.5°Cto±2°C.Use this function only if necessary. Since the
temperatureoffsetcalculatedduringthecalibrationisappliedtoallfuturetemperaturemeasurements,recalibrateifa
differentprobeisused.Fortemperaturecalibration,theprobeneedstobeconnectedtothemeterandthecalibration
solutionshouldhaveaknown,stabletemperature.ItisrecommendedthattwoNIST-traceablethermometersbeused
to measure and verify solution temperature.
1. Pressf3 (setup) key.
2. Usethearrowkeystohighlightthechannelthatthetemperatureprobeisconnectedto.
Pressf3 (select).
3. UsethearrowkeystohighlightTemperatureandpressf3 (select).
4. UsethearrowkeystohighlighttheappropriateTemperatureCaloptionandpressf3 (select).
5. Followtheonscreenprompts.

12 Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
This page intentionally left blank.

13
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 6 Measurement
Aftersuccessfulcalibration,thesamplescanbetested.
1. RinsetheRDOorDOprobewithdeionizedwater,blotdrywithlint-freetissue.
2. PlaceRDO/DOprobe,conductivitycellifrequired,andoptionalstirrerinrstsample.
3. IfthemeterisinAutoReadmode(meterdefault)pressmeasure (esc) (1)key.Ifthemeterisin
continuousortimedreadmode,themeterwillimmediatelystarttakingreadings.
4. IfinAutoReadmodeanddatalogisenabled(default),thereadingwillautomaticallybestoredwhen
the“AR”appears.Ifincontinuousreadmodeanddatalogisenabled,presslog/print (0) key to store
intothemeter’smemory.
Note:Toenableordisabledatalogging,presssetupandselectInst.Settings.

14 Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
This page intentionally left blank.

15
Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
Chapter 7 Methods
The meter stores up to ten methods per channel with the last calibration data stored for each method.
Use the channel setup to access and modify methods.
1. Pressf3 (setup) key.
2. Usethearrowkeystohighlighttheappropriatechannel.Pressf3 (select).
3. UsethearrowkeystohighlightMethodandpressf3 (select).
4. Themethodscanbeloaded,copied,savedandeditedbyfollowingtheonscreenprompts.

16 Thermo Scientific Orion VERSA STAR RDO/DO/Temperature Module
This page intentionally left blank.
