Thermo Scientific Orion Versa Star User manual

Thermo Scientific Orion VERSA STAR™
Conductivity/Temperature Module
Reference Guide

Ross and the COIL trade dress are trademarks of Thermo Fisher Scientific, Inc. and
its subsidiaries.
AQUAfast, AQUASensors, BOD AutoEZ, ionplus, KNIpHE, LogR, No Cal, ORION, perpHect,
PerpHecT, pHISA, pHuture, Pure Water, Sage, ROSS, ROSS Ultra, Sure-Flow, Titrator PLUS, and
TURBO2 are registered trademarks of Thermo Fisher Scientific, Inc. and its subsidiaries.
A+, All in One, Aplus, AUTO-BAR, AUTO-CAL, Auto-ID, AUTO-READ, AUTO-STIR,
Auto-Test, AutoTration, CISA, digital LogR, DuraProbe, EZ Startup, ISEasy,
Low Maintenance Triode, Minimum Stir Requirement, MSR, NISS, Optimum Results, Orion Dual
Star, Orion Star, SAOB, SMART AVERAGING, SMART STABILITY, Star LogR, Star Navigator 21,
Stat Face, Triode are trademarks of Thermo Fisher Scientific, Inc. and its subsidiaries.
Guaranteed Success and The Technical Edge are service marks of Thermo Fisher Scientific, Inc.
and its subsidiaries.
© 2011 Thermo Fisher Scientific Inc. All rights reserved. All trademarks are the property of
Thermo Fisher Scientific, Inc. and its subsidiaries.
The specifications, descriptions, drawings, ordering information and part numbers within this
document are subject to change without notice.
This publication supersedes all previous publications on this subject.

Thermo Scientific Orion VERSA STAR™ Conductivity/Temperature Module
Table of Contents
Chapter 1 Introduction ..........................................................1
Chapter 2 Module Overview .....................................................3
Module Connections and Inputs ........................................ 3
Module Maintenance.................................................. 4
Display Information From Module ....................................... 4
Chapter 3 Setup Menus .........................................................5
Setup Menus for Primary Measurements ................................ 5
Read Type Information..............................6
Temperature Compensation Options ...................6
Setup Menu for Temperature ........................................... 7
Chapter 4 Conductivity Calibration ...............................................9
Chapter 5 Temperature Calibration ..............................................11
Chapter 6 Measurement........................................................13
Chapter 7 Methods ............................................................15
Chapter 8 Data Storage and Review .............................................17
Data Storage Settings ................................................ 17
Measurement Read Type...........................17
Datalog, Computer and Printer Export Settings ..........17
Datalog Review ...................................................... 17
Calibration Review................................................... 18
Chapter 9 Customer Services ...................................................19
Troubleshooting Guide................................................ 19
Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Warranty and Registration ............................................ 19
WEEE Compliance ................................................... 19
Declaration of Conformity ............................................. 20
Conductivity/Temperature Module Specifications ....................... 21
Ordering Information ................................................. 22
Appendix Advanced Features...................................................27
Conductivity Temperature Compensation and Reference Temperature ..... 27
Conductivity and Total Dissolved Solids (TDS)........................... 27
Conductivity Automatic Calibration .................................... 27
Table of Conductivity Standards Values Vs. Temperature ................. 28

This page intentionally left blank.

1
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 1 Introduction
Thank you for your purchase of the Thermo Scientific Orion VERSA STAR™ Conductivity/Temperature Module.
This module is for use with the Thermo Scientific Orion VERSA STAR Advanced Electrochemistry Benchtop Meter.
Some key features of this module include:
• Conductivity,TDS,salinityandresistivitycapabilities
• Selectablereadingreferencetemperaturesof5,10,15,20or25°C
• Compatibilitywith2-or4-cellconductivitycells
• Linear,non-linear,nLFuorEPcurveoptionsforconductivity
• Choiceofpracticalsalinityornaturalseawatercurvesforsalinityreadings
• Automaticandmanualdataloggingoptions
Pleasereadthisreferenceguidethoroughly.Anyuseoutsideoftheseinstructionsmayinvalidateyourwarrantyand
causepermanentdamagetothemeter.

This page intentionally left blank.

3
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 2 Module Overview
Toconnectthemodulestothemeterandforspecicinformationregardingthemeteroutputs,pleaseseethe
OrionVERSASTARReferenceGuide.TheReferenceGuideisontheCDincludedwiththemeterandalsoavailable
at www.thermoscientific.com/water.
Module Connections and Inputs
1. Selectaconductivitycellbasedonsamplerangeandreportingrequirements.
2. Placeconductivitycellinthemeter’selectrodearm.
3. Attachthe8pinmini-DINconnectionintotheconductivitymodule.
4. AttachtheOrionStarstirrerprobe(cat.no.096019,soldseparately)tothesideofthemeterandinto
themeter'selectrodearm,ifneededforyourtestmethod.
5. Setupareawithstandards,rinsewater,sample&othersupplies.
6. Connectthemeterfordatacollection(Hyperterminal,LIMS,StarPrinter,etc),ifdesired.
7. PowertheOrionVERSASTARmeter,stirrer,anddatacollectiondevice(s).
Conductivity Module
8pinmini-DINconnectorfor
conductivityprobe

4Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Module Maintenance
Forroutinemaintenance,dustandwipethemodulewithadampcloth.Ifnecessary,warmwaterormildwater-based
detergentcanbeused.Maintenancecanbeperformedonadaily,weeklyormonthlybasis,asrequiredbyoperating
environment.Immediatelyremoveanyspilledsubstanceusingthepropercleaningprocedureforthatspilltype.
Display Information from Module
ExampleConductivityMeasurementScreen–SingleChannel
Dateandtime
Sample
temperature
Primaryreading
Informationon
lastcalibration
Theinformationonthedisplaycanbecustomized.
Enterthesetupmenutomakechanges.
1.PressSetup.
2.UsethearrowkeystohighlightInst.Settings,
press (f3/select) key.
3.UsethearrowkeytohighlightDisplayView.
 Press(f3/select) key.
4.Followtheonscreenpromptstochoosewhatyou
would like to see on the measurement screen.

5
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 3 Setup Menus
Setup Menus for Primary Measurements
1. SelecttheConductivitychannelbypressingthechannelkey,thenpressf3 (Setup).
2. Arrowovertohighlighttheappropriateconductivitymoduleforsetup,pressf3 (Select).
3. ArrowthecursortoMode,pressf3 (Select),arrowtoConductivity,pressf3 (Select).
4. Selecttheoptionsforyourtesting.
TDS, Salinity and Resistivity Setup Menus
Conductivity Setup Menu
(Default values are in bold in the table below)
ProbeSerialNumber Input
SampleID Off,Manual,AutoIncrement
Stability Smart,Fast,Medium,Slow
Averaging Off,Automatic Smart
Read Type AutoRead,Timed,Continuous
CellK(Constant) Inputcellconstant
Reference Temperature 5,10,15,20,or25 ºC
Temp Compensation Linear,nLFn,nLFu,EP
Temperature Coefficient 2.1
Alarm** Limit,CalDue,SetPoint
**Limitandsetpointalarmdefaultsetto‘off’.
Calduealarmsetto12hours.
TDS Setup Menu (Default values in bold)
Read Type AutoRead,Timed,Continuous
CellK(Constant) Inputcellconstant
TDSFactor 0.50
Reference Temperature 5,10,15,20,or25 ºC
Temp Compensation Linear,nLFn,nLFu,EP,Off
ProbeSerialNumber Input
Stability Smart,Fast,Medium,Slow
Averaging Off,Automatic Smart
Alarm Limit,SetPoint
Cell Type Standard,USP
Resistivity Setup Menu (Default values in bold)
Read Type AutoRead,Timed,Continuous
CellK(Constant) Inputcellconstant
Reference Temperature 5,10,15,20,or25ºC
Temp Compensation Linear,nLFn,nLFu,EP,Off
Stability Smart,Fast,Medium,Slow
Averaging Off,Automatic Smart
Alarm Limit,SetPoint
Cell Type Standard,USP
Salinity Setup Menu (Default values in bold)
Read Type AutoRead,Timed,Continuous
CellK(Constant) Inputcellconstant
Salinity Type Practical Salinity,SeaWater
Stability Smart,Fast,Medium,Slow
Averaging Off,Automatic Smart
Alarm Limit,SetPoint
Cell Type Standard,USP

6Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Read Type Information
Therearethreemainreadtypesavailableasshowninthesetupmenus.
• Auto-Read – Themeterwilldisplaythemeasurementasitstabilizesandlockandholdthe
measurementwhenitisstable.(TheARiconwilllockonthescreen.)Oncethemeasurementislocked,
themeterwillautomaticallyexportthemeasurementtothedatalog,ifthedatalogisenabledin
thesetupmenu,andtoaprinterorcomputer,ifaprinterorcomputerisconnectedtothemeterand
enabledinthesetupmenu.Totakeanewmeasurement,pressmeasure (esc)/1.
• Timed – Themeterwillreadanddisplayameasurementatthesettimeintervalthatisprogrammed
bytheoperator.Therearetwooptions:
 1. Bychecking/selectingthe"Interval"box,atthesettimeinterval,themeterwillautomatically
 exportthemeasurementtothedatalog,ifthedatalogisenabledinthesetupmenu,andtoa
 printerorcomputer,ifaprinterorcomputerisconnectedtothemeterandenabledinthesetup
 menu.Ifselected,enterthetimeintervalvalueinahours:minutes:secondsformatusingthe
numeric keypad and press f3 (select) key.
 2. Ifthe"Interval"boxisunchecked/notselected,asingletimedmeasurementwillbetaken.
 Themeterwillapplythesamesavingandexportingdataconditionsaswiththesettime
 intervaltorecordandexportdata,butlockafteronetimedintervalhasexpired.Press
measure (esc)/1toresetthecountdownclockandtakeanewreading.
• Continuous – The meter will continuously measure and update the display. This read type is useful
whenperforminganexperimentthatrequirescontinuousmeasurementstobetaken.Pressthe
log/print/0keytoexportthemeasurementtothedatalog,ifthedatalogisenabledinthesetup
menu,andtoaprinterorcomputer,ifaprinterorcomputerisconnectedtothemeterandenabledin
the setup.
Temperature Compensation Options
Theseoptionscanvaryaccordingtothemeasurementmode.
• Linear –Mostbenecialforusewithsampleswithknownandlineartemperaturecoefcients.
• nLFn –Thisabbreviationisfornon-linearnaturalpurewater.Itworksbestforlowconductivitywater
suchaspurewatersandnaturalwaters(ground,wellorsurfacewaters).
• nLFu –Thisabbreviationisfornon-linearultrapurewaterthatcontainsnoairorcarbondioxide.
• EP –Temperature-compensationisturnedoffwhenthisisselected.Usingthisfeatureresultsin
warninglimitsbeingdisplayedwhenthepurewatersampleisovertheacceptablereadingforthat
temperatureperEPorUSPrequirements.

7
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Setup Menu for Temperature
AllofthetemperaturemeasurementsettingsarefoundinTemperatureSetupmenuforeachmeasurement.
*Thisnumberwillchangetomatchthesetupmenuchannel.
Temperatureprobescanbesetupinthemeasurementmodeofthesampleyouaremeasuring.Ch-1ATCallowsthe
temperatureprobetobeusedinmorethanonechannelfortemperature-compensatedmeasurements,suchaswhen
apHelectrodeanda2-cellconductivitycellareinthesamemeasurementsample.TemperatureisacriticalpHand
conductivitymeasurementasthemeasurementvaluesrequireatemperaturecorrectiontodeterminethereference
value,often25ºCintheAmericaand20ºCinEurope.
Temperature Unit ºCorºFselection
Temperature Input and Type Ch-1ATC,Ch-2ATC,Ch-3ATC,Ch-4ATC,MTC
Temperature Cal Ch-1*ATConlyorAllATCallowsallATCstobe
calibratedatonce

8Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
This page intentionally left blank.

9
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 4 Conductivity Calibration
Theconductivitymeasurementmodesaredesignedforapplicationstodeterminethequalityofwaterinprocesses
wheredissolvedions(Salinityinpsu,practicalsalinityunits),purity(ResistanceinlowmicroSiemens/cm)anddissolved
saltsandothercompounds(TotalDissolvedSolids,TDSinppt/ppm).Eachmeasurementhasitsownunits.
Conductivityspansawidemeasurementrange,soautoranginginthelivereadingsmakesgatheringsampledata
easier.Asthereadingschange,theunitsdisplaybasedonthevaluechange.TheConductivitymeasurementsare
reportedbacktotheReferenceTemperatureselectedinsetup.
Uptosixconductivitystandardscanbeusedforcalibration.Alwaysusefreshstandardsandselectstandardsthat
arenearthesampleconductivity.Preparetheconductivitycellaccordingtotheinstructionsintheconductivitycell
userguide.
Note:Forautomaticcalibration,thenominalcellconstantoftheconductivitycellmustbeenteredinthesetup
menubeforethecalibrationisperformed.UsefreshThermoScienticOrionConductivityStandardswithvaluesof
100μS/cm,1413μS/cmand12.9mS/cmtouseautomaticcalibration.
1. PressCal (f1) tobeginConductivitycalibration,bracketingexpectedsamplerange.
Calibrationmaybe1to6points.
a.Usefreshstandards,rinsecellwithdeionizerwaterbeforeeachreading,blotdry.
b.MeasuretheConductivitystandardsfromtheleastconcentratedstandardtothemost
concentratedstandardforgreatestaccuracyandtopreventcarryover.
c.Followtheonscreenprompts.
d.Duringcalibration,pointscanbeeditedorretestedpriortoacceptance.Ifthereading
doesnotstabilize,youmaypressOverride (f3)totakethereading.
e.Acceptthecalibrationwhenitiscompleted.
2. Thecalibrationinformationisnowdisplayedbystandardbeakersandconcentrationsusedinthe
calibrationwhenthemainmeasurementscreenreturns.Pressthelog view (9)keytoviewcalibration
details.Fromlogview,printingorsendingdataisanoption.

10 Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
This page intentionally left blank.

11
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 5 Temperature Calibration
TheATCtemperaturedisplayhasarelativeaccuracyof±0.1°C.Temperaturesensorsbuiltintotheconductivity
cellshavevaryingtemperatureaccuracies,usually±0.5°Cto±2°C.Use this function only if necessary. Since the
temperatureoffsetcalculatedduringthecalibrationisappliedtoallfuturetemperaturemeasurements,recalibrate
ifadifferentconductivitycellisused.Fortemperaturecalibration,theprobeneedstobeconnectedtothemeter
andthecalibrationsolutionshouldhaveaknown,stabletemperature.ItisrecommendedthattwoNIST-traceable
thermometersbeusedtomeasureandverifysolutiontemperature.
1. Pressf3 (setup) key.
2. Usethearrowkeystohighlightthechannelthatthetemperatureprobeisconnectedto.
Pressf3 (select).
3. UsethearrowkeystohighlightTemperatureandpressf3 (select).
4. UsethearrowkeystohighlighttheappropriateTemperatureCaloptionandpressf3 (select).
5. Followtheonscreenprompts.

12 Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
This page intentionally left blank.

13
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 6 Measurement
Aftersuccessfulcalibration,thesamplescanbetested.
1. Rinsetheconductivitycellwithdeionizedwater,blotdrywithlint-freetissue.
2. Placeconductivitycellandstirrerinrstsample.
3. IfthemeterisinAutoReadmode(meterdefault)pressmeasure (esc) (1)key.Ifthemeterisin
continuousortimedreadmode,themeterwillimmediatelystarttakingreadings.
4. IfinAutoReadmodeanddatalogisenabled(default),thereadingwillautomaticallybestoredwhen
the“AR”appears.Ifincontinuousreadmodeanddatalogisenabled,presslog/print (0) key to store
intothemeter’smemory.
Note:Toenableordisabledatalogging,presssetupandselectInst.Settings.

14 Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
This page intentionally left blank.

15
Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
Chapter 7 Methods
Themeterstoresuptotenmethodsperchannelwiththelastcalibrationdatastoredforeachmethod.
Usethechannelsetuptoaccessandmodifymethods.
1. Pressf3 (setup) key.
2. Usethearrowkeystohighlighttheappropriatechannel.Pressf3 (select).
3. UsethearrowkeystohighlightMethodandpressf3 (select).
4. Themethodscanbeloaded,copied,savedandeditedbyfollowingtheonscreenprompts.

16 Thermo Scientific Orion VERSA STAR Conductivity/Temperature Module
This page intentionally left blank.
