330-340-345 Series
Hob
Installation Manual
for use in GB, FR, DE, ES,
IT, SI, SE, AT, CH, IE, LU
SINS2101 /0415-V01
©Thetford 2015

Declaration of Conformity SHB330XX Series, SHB340XX Series, SHB345XX Series “Continental Range” LPG Hobs, October 2014
DECLARATION OF CONFORMITY
We: THETFORD Ltd
Address: Unit 6 Brookfields Way, Manvers, Rotherham, S63 5DL
Telephone: (+44) (0) 844 997 1960. Fax: (+44) (0) 844 997 1961
Declare that
Product Types; Domestic build-in gas hobs
Model Number/Description; SHB330XX Series, SHB340XX Series, SHB345XX Series
“Continental Range” LPG Hobs
Satisfies the essential requirements of the Gas Appliances Directive 2009/142/EC and is
manufactured in accordance with the harmonised European standards:
Satisfies the essential requirements of the Electro Magnetic Compatibility Directive
2014/30/EU and is manufactured in accordance with the harmonised European standards:
EN 30-1-1: 1998+A2:2010
EN 30-2-1: 1998+A1:2003+A2:2005
We also declare that the production of each specific model will be in conformity with the
type as described in the EC type-examination certificate:
EC 704 Rev.4 Issued by Intertek
We also declare that the production of each specific model will be in conformity with the
type as described in Test Report(s):
06022215, 07024132 & 08032970/B, Issued by Intertek
Name : S.P. Cordeille
Title/Position : Chief Executive Officer
Place & Date of Issue : Rotherham, 24 October 2014
Signature :

2
EN
Original Installation Manual
Contents
1 Introduction............................................................................................................................................................ 2
2 Symbols...................................................................................................................................................................2
3 Regulations and standards................................................................................................................................3
4 Position and placement......................................................................................................................................4
5 Connecting gas......................................................................................................................................................8
6 Connecting electricity..........................................................................................................................................8
7 After installation....................................................................................................................................................8
8 Technical specifications..................................................................................................................................... 9
9 Servicing..................................................................................................................................................................9
10 Questions / customer service........................................................................................................................ 10
1. Introduction
This is the installation manual for the Thetford 330, 340 and 345 series hob. The manual is meant
for qualified installers who will install the hob in a caravan, camper, boat or holiday home. Read the
information and instructions carefully and follow them strictly to install the unit safely and correctly.
Also read the warnings in the User Manual before testing the appliance after installation.
If the appliance is not installed in accordance with national and European Regulations,
Rules and Standards this will void the warranty and may lead to criminal prosecution.
2. Symbols
Key to symbols:
Warning. Risk of injury and/or damage.
Attention. Important information.
Note. Additional information.

EN
3
3. Regulations and standards
Gas appliances should only be installed by qualified
and certified professionals;
Ensure that the type of gas and pressure match
the specification of the appliance. You can find the
specification on the data badge;
Pay close attention to current regulations on
ventilation of the country in use;
Do not modify this appliance, unless the
modification is authorised and carried out by the
manufacturer or their agent;
Use only genuine and approved parts and materials.
Wear the correct Personal Protective Equipment
during the installation. Also follow the applicable
safety regulations.
For more information about ventilation regulations
and requirements, see chapter Position and
placement on page 4.

4
4. Position and placement
■Install the SHB330 in a worktop cut-out prepared as shown, when using surface mount fixing;
452.9
453.0
R112.0
R112.0
R80.0
88.4
88.4
236.0
236.0
R690
7.0
SHB330
■Install the SHB340/SHB345 in a worktop cut-out prepared as shown, when using surface mount
fixing;
527.0
110.5 25.0 256.0
417.5 12.0
R73.5
R73.5
R73.5
R73.5
23.5
25.0
SHB340/SHB345

EN
5
■Install the SHB330 in a worktop cut-out prepared as shown, when using flush mount fixing;
453.0
453.0
R112.0
R112.0
R80.0 88.4 236.0
R690
7.0
R122.0
18.5
18.5
484.0
484.0
R122.0
R87.0
R702.0
SHB330
88.4
236.0
■Install the SHB340/SHB345 in a worktop cut-out prepared as shown, when using flush mount
fixing;
527.0
110.5 25.0 256.0
417.5 12.0
R73.5
R73.5
R73.5
R73.5
8.5
544.0
449.0
23.5
R82.0
R82.0 R82.0
R82.0
25.0
SHB340/SHB345

6
■Adjust the rebate depth (1 = 6mm).
1
The surrounding surfaces must be able to withstand the allowable temperature rise
of 65˚C above ambient temperature, as specified in the EN 30-1-1 standard and in
accordance with the design of this unit.
The temperature of the surrounding surfaces may rise if there are other additional
devices besides the hob. Check the allowable temperature of the materials used for the
surrounding surfaces to ensure that they meet the requirements of EN 30-1-1, EN1949,
EN1645-1, EN1646-1, EN1647 and EN721.
■Maintain the minimum distances between the burners and side, rear and overhanging parts.
12
3
1. Distance between edge of the burner and the side: min. 200mm
2. Distance between edge of the burner and the rear with glass lid fitted: min. 110mm
3. Distance between burners and overhanging parts: min. 500mm
If you are unable to maintain these minimum distances, install fire-resistant material for
protection.
All combustible materials such as curtains and blinds must be kept well clear of the
appliance.

EN
7
A
B
■Provide an air gap of at least 100mm (A) under the unit;
■Provide venting to the outside of at least Ø12mm and max Ø25mm (B);
Make sure the gas dispersal hole can never be blocked.
■Position the unit so it is centred and level in the cut-out. There must also be a gap of 2-3mm
between the appliance and sides of the cut-out;
■Attach the series 330 or 340/345 on the worktop as shown.
Using surface mount fixing:
4.5mm
1
6 5
4
78
3
2
1. Surface mounting bezel
2. Bump stop
3. Glass lid
4. Clamping bush
5. Pressing
6. Clamping screw
7. Clamping arm
8. Worktop

8
Using flush mount fixing:
6mm
1
6 5
4
78
3
2
1. Flush mounting bezel
2. Bump stop
3. Glass lid
4. Clamping bush
5. Pressing
6. Clamping srew
7. Clamping arm
8. Worktop
5. Connecting gas
■Connect the gas to the Ø8mm gas inlet;
■Use only metal gas pipes in accordance with the requirements of EN1949.
Never use rubber tubing.
The burners have a fixed air/fuel mixture. When using propane, the flames burn quietly
with a blue-green color and no yellow at the tip. With butane, the flames have yellow tips.
The yellow colour of the flames increases slightly as the burner heats up.
6. Connecting electricity
■Connect the spark ignition cables to a 12V DC battery using appropriate connectors.
7. After installation
■Fix a warning label next to the unit that meets the requirements of EN721, Annex A;
■Test all gas piping and connections and make sure they do not leak;
■Check the pressure of the gas when all connected gas appliances are in use simultaneously.
The gas pressure may not rise or fall by more than 2.5mbar relative to the nominal value;
■Ensure that all packaging materials have been removed.

EN
9
8. Technical specifications
Table 1: Burner specifications
SHB330 SHB340 SHB345
Gas input Injector Gas input Injector Gas input Injector
kW g/hr mm kW g/hr mm kW g/hr mm
Semi-Rapid Burner 1.5 107 0.61 1.5 107 0.61 1.5 107 0.61
Semi-Rapid Burner 1.5 107 0.61 1.5 107 0.61 1.5 107 0.61
Semi-Rapid Burner 1.5 107 0.61 1.5 107 0.61
Rapid Burner 2.5 179 0.77
Total 4.5 321 4.5 321 5.5 393
Table 2: Dimensions and weight
SHB330 SHB340 SHB345
Dimensions H W D H W D H W D
mm 100 480 480 100 540 445 100 540 445
Appliance Weight 4.0kg 5.6kg 5.6kg
Spark ignition 12V DC 12V DC 12V DC
Table 3: Gas category
Class 3 Appliance
CAT I3 + (28-30/37) CAT I3 B/P (30)
BUTANE (G30) 28 – 30mbar BUTANE (G30) 30mbar
PROPANE (G31) 37mbar PROPANE (G31) 30mbar
9. Servicing
All servicing must be carried out by an approved competent person. Before any service work is
started the appliance should have been left to cool and be disconnected from both the gas and
electrical supplies. After each service the appliance must be checked for gas soundness.

10
For service, please contact your authorised local Service Centre giving details of the model and
serial number on the data badge plus date of purchase.
10. Questions / customer service
■Look at www.thetford-europe.com
■Contact Customer Service Thetford in your country. See the addresses on the back.

© 2014 Thetford
90036/0314-V06
EUROPEAN HEADQUARTER
Thetford B.V.
Nijverheidsweg 29
P.O. Box 169
4870 AD Etten-Leur
The Netherlands
T [phone]
F [phone]
E [email protected]
UNITED KINGDOM
Thetford Ltd.
Unit 6
Brookfields Way
Manvers, Rotherham
S63 5DL, England
United Kingdom
T [phone]
F [phone]
E [email protected]
GERMANY
Thetford GmbH
Schallbruch 14
D-42781 Haan
Deutschland
T [phone]
F [phone]
E: [email protected]
FRANCE
Thetford S.A.R.L.
Bâtiment Le Californie
11, Rue Rosa Luxembourg
CS 40204 Eragny sur Oise
95614 Cergy Pontoise Cedex
France
T [phone]
F [phone]
E [email protected]
ITALY
Thetford Italy c/o Tecma s.r.l.
Via Flaminia
Loc. Castel delle Formiche
05030 Otricoli (TR)
Italia
T [phone]
F [phone]
E [email protected]
SPAIN AND PORTUGAL
Mercè Grau Solà
Agente para España y Portugal
c/ Castellet, 36 bxs 2ª
08800 Vilanova i la Geltrú
Barcelona
España
T [phone]
F not available
E [email protected]
SCANDINAVIA
Thetford B.V.
Representative Office
Scandinavia
Hönekullavägen 13
43544 Mölnlycke
Sverige
T [phone]
F [phone]
E [email protected]
AUSTRALIA
Thetford Australia Pty. Ltd.
41 Lara Way
Campbellfield VIC 3061
Australia
T [phone]
F [phone]
E [email protected]
www.thetford.com.au
CHINA
Thetford (Shenzhen) Trade Co., Ltd.
Rm. 1207, Coastal Building
(East Block) Hai De San Dao
Nanshan, Shenzhen 518059
China
T [phone]
F [phone]
E [email protected]
www.thetford.cn
EUROPEAN HEADQUARTERS
Thetford B.V.
Nijverheidsweg 29
P.O. Box 169
4870 AD Etten-Leur
The Netherlands
T [phone]
F [phone]
E [email protected]
UNITED KINGDOM
Thetford Ltd.
Unit 6
Brookfields Way
Manvers, Rotherham
S63 5DL, England
United Kingdom
T [phone]
F [phone]
E [email protected]
GERMANY
Thetford GmbH
Schallbruch 14
D-42781 Haan
Deutschland
T [phone]
F [phone]
E [email protected]
FRANCE
Thetford S.A.R.L.
Bâtiment Le Californie
11, Rue Rosa Luxembourg
CS 40204 Eragny sur Oise
95614 Cergy Pontoise Cedex
France
T [phone]
F [phone]
E [email protected]
ITALY
Thetford Italy c/o Tecma s.r.l.
Via Flaminia
Loc. Castel delle Formiche
05030 Otricoli (TR)
Italia
T [phone]
F [phone]
E [email protected]
SPAIN AND PORTUGAL
Mercè Grau Solà
Agente para España y Portugal
c/ Castellet, 36 bxs 2ª
08800 Vilanova i la Geltrú
Barcelona
España
T [phone]
F not available
E [email protected]
SCANDINAVIA
Thetford B.V.
Representative Office Scandinavia
Hantverkaregatan 32D
521 61 Stenstorp
Sverige
T [phone]
F [phone]
E [email protected]
AUSTRALIA
Thetford Australia Pty. Ltd.
41 Lara Way
Campbellfield VIC 3061
Australia
T [phone]
F [phone]
E [email protected]
www.thetford.com.au
CHINA
Thetford (Shenzhen) Trade Co., Ltd.
Rm. 1207, Coastal Building
(East Block)
Haide 3rd Road, Nanshan District
Shenzhen 518054
China
T [phone]
F [phone]
E [email protected]
www.thetford.cn
SINS2102/0415-V01
©Thetford 2015
353 Series
Hob
Installation Manual
for use in GB, FR, DE, ES,
IT, SI, SE, AT, CH, IE, LU
