THIEYE Safeel Zero+ User manual

Dash Cam Safeel Zero+
USER MANUAL
PSFZP - V1.0
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

USER MANUAL
Deutsche Anleitung
Guide de démarrage rapide
01
33
17
Guida di Operazione Rapida
49
取り扱い説明書
65
ThiEYE Social Media
Facebook YouTubeOfficial Website
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

Part 01 - Get Started
1. Packing List
Suction Cup Mount Adhesive Mount
Static Stickers
Dash Cam 32GB Micro SD Card
Micro USB Cable User ManualCar Charger with
Additional USB
English
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

2. Product Overview
Speaker
Micro SD Slot
Power / Mode Button
Up / WiFi Button
OK Button
Down Button
1.5” LCD Screen
Micro USB Port
Threaded Insert
Reset
170° Wide Angle Lens
Microphone
Status Indicator
1
2
3
4
6
7
8
9
11
12
13
5 10
1
2
3
4
5
6
11
10
7
13
9
12
8
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

3. LCD Screen
1080P 30FPS
000258 2019/02/03 045606
Video Resolution
Microphone Icon Date/Time
File Lock Icon
Motion Detection Icon
TF Card Icon
WiFi
Battery Status
Recording Status: When Not Recording
Recording Status: When Recording
000000 2019/02/03 045606
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP
1080P 30FPS
000258 2019/02/03 045606

Part 02 - Basic Operation
4. LED Indicators
Status
When Recording
When Not Recording
Blue Indicator Light
Continuous Flash
Constant ON
1. Insert TF Card
We recommend to use up to 32G Class 10 or UHS-1 Micro SD Card.
Please format the Micro SD Card in the camera before first use.
To keep your Micro SD card in good condition, please reformat it regularly. As reformatting
erases all of your content, be sure to back up your photos and videos first.
· Micro SD Card File
There are two folders on the SD card, one is named “1”, which contains UNLOCK files, the other
one is called “Lock” and it’s the LOCK files.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

2. Power On/Off
Auto Power On/Off with Ignition - When powered by the car charger, the dash camera will
automatically turn on when you start your car engine. When turning off your car, the camera will
automatically turn off after approximately 10 seconds.
Manual Power On/Off - To manually turn the camera on/off, press and hold the power button
for at least 3 seconds.
· Switching the camera OFF manually and pulling off the car charger is required for vehicles
where the vehicle’s power socket provides continuous power after the engine is turned OFF.
3. Mode Switching
When the dash cam is Powered ON, it’ll automatically start recording.
Press OK Button to stop recording.
Repeatedly press Power/Mode Button to switch to switch mode, there will be modes:
Video, Photo, Playback, Settings.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

5. Photo Mode
Button Function
DOWN
Up / WiFi
Up / WiFi
POWER / MODE
OK
When not recording:
Switch to Photo/Playback/Settings Mode
When recording: Manually Lock File
Display the WiFi SSID and Password
Start / Stop Video Recording
Turn ON/OFF the LCD display
Button Function
DOWN
POWER / MODE
OK
Switch to Playback/Settings Mode
×
Take a Photo
Turn ON/OFF the LCD display
1080P 30FPS
000258 2019/02/03 035606
12M
2019/02/03 040658
4. Video Mode
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP
1080P 30FPS
000258 2019/02/03 035606
12M
2019/02/03 040658

6. Playback Mode
7. Settings Mode
Up / WiFi
Button Function
DOWN
POWER / MODE
OK
Switch to Settings Mode
Navigate UP to choose video/photo file
Long Press to preview the LOCK files
Play/Pause
Navigate DOWN to choose video/photo file
When you preview the recorded files, the default is to preview Unlocked files, if you need to
preview the Locked files, please LONG PRESS Up Button.
Button Function
POWER / MODE
OK
Switch to Video Recording Mode, and
automatically start recording.
Enter Menu Settings
VID_002MOV
1080P 30FPS
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP
00:00:34 VID_002MOV
1080P 30FPS

Part 03 - Menu Settings Instruction
MUST Press OK Button
Menu Switching
When the dash cam is Powered ON, it’ll automatically start recording.
Short press OK Button to stop recording.
Repeatedly press Power / Mode Button to switch to Settings.
Press OK Button to enter menu settings, there will be:
Video Settings, Photo Settings, System Settings, Exit Settings.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP
1080P
3 Min
Resolution
Cyclic Record
Motion Detection
Voice Recording
Date Stamp

1. Video Settings
Loop Recording
In the case of recording and saving at interval of 3 / 5 / 10 minutes, the dash cam will
automatically overwrite the earliest file in the memory card once the card is full.
If you turn off the loop recording function, the dash cam will record every five-minute segment of
video when recording.
Motion Detection
When the camera is turned ON and the motion detection is ON, the dash camera will
automatically activate and record any movement that is detected in front of the camera, and it
stops recording when no dynamic motion appears.
· If you turn on the motion detection function, it only works when the dash camera is Powered
ON, the camera will record when it detects motion, which will cause discontinuous recording.
· If you need record continuously, we suggest you to turn off the motion detection function.
Tips
Tips
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

G-sensor
G-sensor will lock the file when detecting a collision during the recording, please check the “Lock”
file in the card and back up your important files regularly in case of overwritten by loop recording
once the card is full.
Parking Monitor
When the car is parked and the Parking Monitor has been turned on, the dash cam will activate
and start recording automatically once it detects collision. And it will turn off after continuously
recording about 20 seconds.
Only turn on the Parking Monitor while parking, the dash cam will record when detecting a
collision. It means that you do not need to turn on G-sensor and Motion Detection.
WDR ( Wide Dynamic Range)
Wide Dynamic Range (WDR) retains a greater level of detail and color in an image. This setting
is especially useful for scenes that include shadows or bright areas.
Tips
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

2. Photo Settings
Capture Mode
Single shot - the camera will take one photo every time.
Delayed shot - the camera will wait for 2/5/10s depending on setting before taking the shot.
Sequence
Once set in photo burst mode, the camera will take 3 shots in a row every time. Otherwise, the
camera only takes one photo every time. (Default: OFF)
3. System Menu Settings
Screen Saver
If you turn on Screen Saver Mode, the screen display will be turned off after a period of inactivity,
but the camera is still recording. You can see the Blue Indicator Light is flash during recording.
Auto Power Off
If you set to 3-minute auto power off, the camera will automatically power off if it is not recording
and without any operation in 3 minutes.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

Upgrade Firmware
· Please download the latest firmware from ThiEYE website (thieye.com/support.html) and
upgrade the camera according to the instruction in the file.
· Two ways to upgrade the firmware: Advanced Update (by PC) and Quick Update(by the
camera). We suggest Advanced Update, which is much more convenient.
· Please keep upgrading the firmware in time to maintain the best user experience.
· Do not disconnect your device from power while it is being updated. This will result in damage to
the dash cam.
Part 04 - APP Connection
1. Download ThiEYE DVR App
Please scan the QR Code or visit
our official website www.thieye.com
to download ThiEYE DVR App.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

2. WiFi is defaulted “ON”, the LCD will show a “ ” icon. Press Up/WiFi Button “ ” can
display the interface of WiFi SSID and Password, and press again that the interface will be
closed.
3. Connect your smartphone to the WiFi of the dash cam (WiFi Account: ThiEYE_CAM,
Password:12345678), then open the App to view and control your camera.
Note: WiFi is defaulted “ON” when you using this camera for the first time, if you want to turn on/off
the WiFi manually, the method as follows:
There is a “WiFi” in the System Settings, the option value is Off / On, and the default is On.
· If you need to TURN OFF WiFi, please setting the “WiFi” is Off, the WiFi is OFF.
· When the WiFi is off, if you want to TURN ON WiFi, please setting the “WiFi” is On, the WiFi is ON.
About Turing ON/OFF WiFi
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

Part 05 - Installation
1. Connect the Dash Cam and the Mount
2. Install the Dash Cam
Clean the area on the windshield where the dash cam will be installed.
You can attach the suction cup mount or adhesive mount to the windshield
where it will not obstruct the driver’s view.
(Note: If you use adhesive mount, please attach static stickers to prevent the adhesive from
sticking to dirty up the clean windshield of your car.)
Hide the power cable by placing it in the space between the windshield and headliner.
Recommended locations for the adhesive wire clips to arrange the power cable.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

Part 06 - Connect to Computer
With TF card inserted, when connected to computer, three options will be available:
Mass Storage, PC Camera, REC-mode.
Mass Storage allows the TF card to be accessed via computer as an
external storage.
PC Camera can act as a camera for your computer.
REC_mode allows the dash cam to function normally while charging
via computer.
Mass Storage
PC Camera
REC_mode
3. Connect to Power
Connect the power cable to Micro USB port of the
dash cam.
Plug the car charger adapter end of the power cable
into a vehicle power socket.
The car charger with additional USB, you can keep the dash cam charging on the go, and at
the same time charge your smartphone or pad with the same charger. Convenient!
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

Part 07 - Frequently Asked Questions
This is caused by the Motion Detection.
If you need record continuously, we suggest you to
turn off the motion detection function.
Why won’t the camera
record continuously?
FAQ Solutions
Only need to turn on the Parking Monitor.
(Don't need to turn on the G-sensor or motion detection).
How to monitor while parking?
Due to the huge HD video data, please use up to
Class 10 Micro SD Card and format the card on the
camera before first use.
When recording,
It will stop automatically.
This is caused by setting the wrong “Frequency”.
Please set it to “50Hz” or “60Hz” according to the local
power supply frequency.
There are horizontal stripes
in the image.
Please use the reset key to restore manufacturer defaults.When any abnormality occurs.
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP

Partie 01 – Guide de démarrage
1. Liste d’emballage
Support à ventouse Support adhésif
Autocollants statiques
Caméra de voiture
Câble Miro USB Mode d’emploiChargeur de voiture avec
USB additionnel
Français
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP
Carte Micro SD 32GO

2. Vue d'ensemble du produit
Haut-parleur
Fente pour carte Micro SD
Bouton d’alimentation/de mode
Bouton Haut / Bouton wifi
Bouton OK
Bouton Bas
Écran LCD 1,5”
Port Micro USB
Insert fileté
Réinitialisation
Objectif à grand angle de 170°
Microphone
Voyant d'état
1
2
3
4
6
7
8
9
11
12
13
5 10
1
2
3
4
5
6
11
10
7
13
9
12
8
01 02 03 04
05 06 07 08 09 10 11 12 13
14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58
59 60 61 62 63 64 65 66 67
68 69 70 71 72 73 74 75 76
77 78 79 80
EN EN EN EN
EN EN EN EN EN EN EN EN EN
EN EN EN FR FR FR FR FR FR
FR FR FR FR FR FR FR FR FR
FR DE DE DE DE DE DE DE DE
DE DE DE DE DE DE DE DE IT
IT IT IT IT IT IT IT IT IT
IT IT IT IT IT IT JP JP JP
JP JP JP JP JP JP JP JP JP
JP JP JP JP
