thomann MicroMix 2 USB User manual

MicroMix 2 USB
mixer
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
12.07.2018, ID: 424898

Table of contents
1 General information................................................................................................................................. 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 6
1.3 Symbols and signal words............................................................................................................... 6
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 11
4 Installation and starting up................................................................................................................ 12
5 Connections and controls................................................................................................................... 13
6 Technical specifications....................................................................................................................... 18
7 Plug and connection assignment.................................................................................................... 20
8 Protecting the environment.............................................................................................................. 24
Table of contents
MicroMix 2 USB
3

1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
mixer
4

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
MicroMix 2 USB
5

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
mixer
6

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
MicroMix 2 USB
7

2 Safety instructions
This device is intended to be used for amplification, mixing and playback of signals from
musical instruments and microphones. Use the device only as described in this user manual.
Any other use or use under other operating conditions is considered to be improper and may
result in personal injury or property damage. No liability will be assumed for damages resulting
from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
mixer
8

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce volume
levels that may cause temporary or permanent hearing impairment.
Do not operate the device permanently at a high volume level. Decrease the
volume level immediately if you experience ringing in your ears or hearing
impairment.
Safety
Safety instructions
MicroMix 2 USB
9

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
Short-circuit hazard
The phantom power leads to damage to the device if unbalanced XLR cables are
connected.
Use only balanced XLR cables.
Safety instructions
mixer
10

3 Features
n5-channel mixer
n1 × mono channel with XLR / 1/4" combo socket (MIC / Line), gain adjustment, 2-band EQ
and pan control
n1 × stereo channel with RCA sockets (line), 2-band EQ and balance control
n1 × stereo channel with RCA sockets (line)
n18 V phantom power permanently present on the XLR input
nHeadset with headphone and microphone connectable (3.5 mm jack)
n1 × stereo RCA output
nUSB port for use as an audio interface
nBuilt-in Bluetooth module for wireless sources
nPower supply via USB port
Features
MicroMix 2 USB
11

4 Installation and starting up
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
Installation and starting up
mixer
12

5 Connections and controls
Connections and controls
MicroMix 2 USB
13

1[USB TO COMPUTER]
USB port for connection to a computer for use as an audio interface as well as for power supply.
2[MONITOR - MIC]
To connect the microphone when using a headset, signal processing via channel 1.
3[POWER]
This LED lights when the device is turned on.
4[ON / OFF]
On / off switch.
5[MONITOR - HEADSET]
To connect the headphone when using a headset.
6[2-TK / BT TO]
When the switch is pressed, the Bluetooth and 2-TK input signals are assigned to the ‘Monitor’ output, otherwise to the
‘MAIN MIX’ output and the USB port.
Connections and controls
mixer
14

7[PAIR]
This switch must be pressed to allow the device to pair with Bluetooth sources. The blue LED above the switch indicates
the Bluetooth status: 1 × blink per second: Ready to make the connection. 1 × blink per 5 seconds: Connected. 2 × blinks
per 5 seconds: Connection interrupted.
8[MONITOR]
Volume control for the Monitor output.
9[L - CLIP - R]
The ‘L’ or ‘R’ LED lights up green when a signal is present in the respective bus side. It lights up red when overload occurs
in the respective bus side. Then lower the input levels that possibly cause the overload or turn the ‘MAIN MIX’ control
counterclockwise.
10 [MAIN MIX]
Volume control for the ‘MAIN MIX’ output and the USB port.
11 [CH 2/3]
Level control for the signals at input ‘CH2/3’ and at the USB port.
12 [CH1]
Level control for the signals at input ‘CH1’.
Connections and controls
MicroMix 2 USB
15

13 [PEAK]
This LED lights up on overload in channel 1. If this happens, turn the [GAIN] control counterclockwise until the LED goes
out.
14 [HIGH - LOW - PAN]
Tone and pan control for channel ‘CH1’. Slide the ‘HIGH’ control up or down to raise or lower the treble. Slide the ‘LOW’
control up or down to raise or lower the bass. Slide the ‘PAN’ control up or down to move the signal source further to the
left or right in the stereo panorama.
15 [HIGH - LOW - BAL]
Tone and pan control for channel ‘CH2/3’. Slide the ‘HIGH’ control up or down to raise or lower the treble. Slide the ‘LOW’
control up or down to raise or lower the bass. Slide the ‘BAL’ control up or down to increase the loudness of the left or
right channel of the signal source.
16 [GAIN]
Control to adjust the sensitivity of the input ‘CH1’.
17 [LINE / USB - FROM]
When this switch is pressed, the signals present at the USB port will be played, otherwise those at the ‘LINE IN’ input.
Connections and controls
mixer
16

18 [LINE / USB - TO]
When the switch is pressed, the channel signal is present at the ‘MONITOR’ output, otherwise at the ‘MAIN MIX’ output.
19 [CH1 INPUT]
Balanced XLR / 1/4" phone jack input for connecting a microphone (XLR) or a line level signal source (1/4" phone jack).
The XLR socket provides permanently 18 V phantom power for connecting condenser microphones. Never connect
unbalanced cables to this socket, otherwise the unit will be damaged.
20 [INPUT - LINE IN]
Stereo RCA input for line level signals, such as CD or MP3 players.
21 [INPUT - 2-TK]
Additional stereo RCA input for line level signals.
22 [MAIN MIX]
Stereo RCA output for the final signal mix of the device. Here you can connect a power amp, powered speakers or a
recording device.
Connections and controls
MicroMix 2 USB
17

6 Technical specifications
Sensitivity / impedance Channel 1, XLR 2 mV / 1.8 kΩ (gain @ max.)
Channel 1, 1/4" phone
jack 10 mV / 12 kΩ (line)
Channel 2 30 mV / 20 kΩ
Output level Main & monitor 5.8 V (max.)
Frequency response 20 Hz ~ 22 kHz
THD ≤ 0.05 %
Signal-to-noise ratio 80 dB (A-weighted)
EQ Bass ± 15 dB / 80 Hz
Treble ± 15 dB / 12 kHz
Impedance headphones output ≥ 16 Ω
Technical specifications
mixer
18

USB interface USB 1.1 compatible, 16 bit Delta-Sigma
Sampling rates: 44.1 kHz, 48 kHz
Phantom voltage +18 V
Voltage supply via computer (USB port) or USB mains adaptor 5 V / 500 mA
(not supplied)
Dimensions (W × H × D) 100 × 40 × 135 mm
Weight 430 g
Technical specifications
MicroMix 2 USB
19

7 Plug and connection assignment
This chapter will help you select the right cables and plugs to connect your valuable equip-
ment in such a way that a perfect sound experience is ensured.
Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a
plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short
circuit or ‘just’ in poor transmission quality!
Unbalanced transmission is mainly used in semi-professional environment and in hifi use.
Instrument cables with two conductors (one core plus shielding) are typical representatives of
the unbalanced transmission. One conductor is ground and shielding while the signal is trans-
mitted through the core.
Unbalanced transmission is susceptible to electromagnetic interference, especially at low
levels, such as microphone signals and when using long cables.
In a professional environment, therefore, the balanced transmission is preferred, because this
enables an undisturbed transmission of signals over long distances. In addition to the conduc-
tors ‘Ground’ and ‘Signal’, in a balanced transmission a second core is added. This also transfers
the signal, but phase-shifted by 180°.
Introduction
Balanced and unbalanced trans-
mission
Plug and connection assignment
mixer
