thomann Harley Benton HBW-150 User manual

HBW-150
bass combo
user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
email: [email protected]
Internet: www.thomann.de
21.03.2012

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 7
3 Features....................................................................................................................................................... 12
4 Installation and starting up................................................................................................................ 13
4.1 Pin assignment.................................................................................................................................. 15
5 Components and functions................................................................................................................ 17
6 Technical specifications....................................................................................................................... 23
7 Protecting the environment.............................................................................................................. 25
Table of contents
HBW-150
3

1 General notes
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section gives an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
bass combo
4

Signal word Meaning
DANGER! This combination of symbol and signal word
indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.
CAUTION! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in minor injury if it is not avoided.
NOTICE! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
General notes
HBW-150
5

Warning signs Type of danger
Warning – danger zone.
General notes
bass combo
6

2 Safety instructions
This device is intended to be used for amplification and playback of signals from musical
instruments with electromagnetic pickups. Any other use or use under other operating condi‐
tions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
HBW-150
7

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
Safety instructions
bass combo
8

CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.
CAUTION!
Risk of injury due to heavy weight
Due to the heavy weight of the device, at least two persons are required for trans‐
port and installation.
Safety instructions
HBW-150
9

NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
bass combo
10

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
HBW-150
11

3 Features
Special features of the device:
nInputs: 1/4" phone sockets for instrument, RETURN and AMP IN, RCA sockets for AUX IN
nOutputs: 1/4" phone sockets for headphones, SEND and PRE OUT
nSelectable input sensitivity for active and passive bass guitars
n15" woofer, tweeter
nControls for input gain, bass, mids, treble and master volume
nSwitchable 7-band equalizer
nBuilt-in compressor
nBRIGHT and BOOST switch
nHousing with felt cover, plastic corners, rubber foots and metal front grill
nWedge cabinet for monitor use
Features
bass combo
12

4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the device against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
CAUTION!
Risk of injury due to heavy weight
Due to the heavy weight of the device, at least two persons are required for trans‐
port and installation.
Installation and starting up
HBW-150
13

NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
Installation and starting up
bass combo
14

4.1 Pin assignment
Drawing and table indicate the pin assignment of a 1/4" TS phone jack to be used.
1 Signal
2 Ground, shielding
1/4" sockets for signal in and
outputs
Installation and starting up
HBW-150
15

Drawing and table indicate the pin assignment of an RCA jack to be used.
1 Signal
2 Ground, shielding
RCA sockets for signal inputs
Installation and starting up
bass combo
16

5 Components and functions
Front panel
Components and functions
HBW-150
17

1INPUT
1/4" TS phone socket for the input signal coming from your bass guitar.
2ACTIVE/PASSIVE
To select the sensitivity. Press this button if you connect an instrument with active electronic. Release the button if
you connect an instrument with passive electronic.
3GAIN
This control adjusts the input gain.
4BRIGHT
This switch increases the high frequencies.
5BOOST
This switch increases the low frequencies.
6HIGH, MIDDLE, LOW
These controls let you decrease or increase the high, mid and low frequencies by ±12 dB.
Components and functions
bass combo
18

7EQ
This switch activates the 7-band equalizer.
8 7-band graphic equalizer for sound shaping. The adjustable frequencies are 50 Hz, 120 Hz, 400 Hz, 500 Hz, 800 Hz,
4.5 kHz and 10 kHz. Use the sliders to increase or decrease the respective frequency by ±15 dB.
9MASTER
This is the overall volume control.
10 COMP
This indicator is lit when the built-in compressor responds.
11 AUX IN
Auxiliary signal input, electronically located behind the equalizer, directly feeding the power stage for connecting a
CD player or the like. Control the volume on the connected audio device.
12 PHONES
1/4" phone socket for headphones. If you connect headphones, the internal speakers are disconnected.
To avoid annoying sounds turn the ‘MASTER’ (9) control down before plugging headphones in or out.
Components and functions
HBW-150
19

13 POWER
This indicator is lit when the device is switched on and operational.
14 POWER
Use the mains switch to turn the unit on or off.
Components and functions
bass combo
20
