thomann Harley Benton DNAfx GiT User manual

DNAfx GiT Mobile
multi eects unit
user manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
21.03.2022, ID: 532855

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 9
2 Safety instructions.................................................................................................................................. 11
3 Features....................................................................................................................................................... 13
4 Starting up.................................................................................................................................................. 14
4.1 Dealing with lithium batteries..................................................................................................... 14
4.2 Charging the unit............................................................................................................................. 16
5 Connections and operating elements........................................................................................... 17
6 Operating.................................................................................................................................................... 19
6.1 Selecting the amp modeling model......................................................................................... 19
6.2 Selecting timbre............................................................................................................................... 20
6.3 Selecting digital eects.................................................................................................................. 21
6.4 USB audio............................................................................................................................................ 22
Table of contents
DNAfx GiT Mobile
3

6.5 Bluetooth® audio.............................................................................................................................. 22
7 Amps and eects list.............................................................................................................................. 23
8 Technical specications....................................................................................................................... 28
9 Plug and pin assignments................................................................................................................... 30
10 Protecting the environment.............................................................................................................. 32
Table of contents
multi eects unit
4

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
DNAfx GiT Mobile
5

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
multi eects unit
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
Letterings
Displays
General information
DNAfx GiT Mobile
7

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
References to other locations in this manual are identied by an arrow and the specied page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specied location.
Example: See Ä ‘Cross-references’ on page 8.
Instructions
Cross-references
General information
multi eects unit
8

1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
General information
DNAfx GiT Mobile
9

Warning signs Type of danger
Warning – danger zone.
General information
multi eects unit
10

2 Safety instructions
This device is intended to be used for sound processing of signals from musical instruments
with electromagnetic pickups. Any other use or use under other operating conditions is con‐
sidered to be improper and may result in personal injury or property damage. No liability will
be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking
hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke! Never let children unattended use electrical devices.
Intended use
Safety instructions
DNAfx GiT Mobile
11

WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Follow the advice on
the correct handling of lithium batteries in the present section.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid
direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctuations and do not switch the device on immediately
after it was exposed to temperature uctuations (for example after transport at low outside temperatures). Dust and dirt inside can
damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other malfunction.
NOTICE!
Possible damage to lithium-ion batteries through incorrect storage
By deep discharge, lithium-ion batteries can be permanently damaged or lose some of their capacity. Before long breaks, charge the
batteries to around 50 % of their capacity and then switch o the device. Store the device at room temperature or cooler in an envi‐
ronment as dry as possible. If the batteries are stored for a longer period, recharge them to 50 % every three months. Fully charge
the batteries only shortly before use at room temperature.
Safety instructions
multi eects unit
12

3 Features
Special features of the device:
nDirect connection to the electric guitar with a 1/4" rotatable jack plug
n14 amp modelings
n14 dierent high-quality digital eects
nFive Tone/EQ Settings
nUSB-C port for audio recordings and charging the unit
nHeadphones output, designed as 1/4" jack socket
nBluetooth® 5.0 connectivity for audio playback
nLithium-ion rechargeable battery operation
nUSB-C cable included
Features
DNAfx GiT Mobile
13

4 Starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
4.1 Dealing with lithium batteries
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
When handled correctly and appropriately lithium batteries pose no risk.
Store lithium batteries in a cool, dry place, ideally in the original packaging.
Starting up
multi eects unit
14

Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batteries are
hermetically sealed. Never attempt to open a lithium battery.
If the battery housing is damaged small amounts of the electrolyte may leak out. If this should
happen, seal the lithium battery in airtight packaging and wipe up the traces of electrolyte
using absorbent paper towels. You must wear protective rubber gloves when doing so. Clean
your hands and the aected surface thoroughly with cold water.
Never attempt to recharge non-rechargeable lithium batteries. When charging lithium bat‐
teries you must use a suitable charging device intended for the purpose.
Before disposing of the device remove the lithium batteries. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape.
Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning
lithium battery.
Starting up
DNAfx GiT Mobile
15

4.2 Charging the unit
If the status LED of the main switch ashes blue when the unit is switched on, only a maximum
of 30 minutes of battery life remains.
Switch o the unit and connect the unit via the USB-C cable to the AC outlet. During charging,
the status LED of the main switch lights up red. Once charging is completed, the status LED
lights up green.
Starting up
multi eects unit
16

5 Connections and operating elements
AMP TONE EFX
DNAfx GiT Mobile
ON OFF
ö
#
$
%'
)
(
&
* +
Connections and operating elements
DNAfx GiT Mobile
17

1[AMP] Button to call up the amp modeling models
2[TONE] Button to call up the timbre of the amp modeling models
3[EFX] Button to call up the digital eects of the amp modeling models
4 Button to toggle between the menu items and to decrease a value
5 Button to toggle between the menu items and to increase a value
6 1/4" jack plug for connection to the instrument
7 Control to adjust the instrument signal volume.
8/ [ON] / [OFF] Main switch
Set the switch to [ON] to switch on the unit. The status LED lights up.
Set the switch to to enable the Bluetooth® function for the audio playback.
Set the switch to [OFF] to switch o the unit.
9 Headphones output, designed as 3.5 mm phone socket
10 Port for the included USB-C cable for audio recordings and charging the unit
Connections and operating elements
multi eects unit
18

6 Operating
Turn the volume control counter-clockwise to set the volume to minimum.
Switch on the unit and adjust the volume as required.
6.1 Selecting the amp modeling model
1. Press [AMP] to call up the amp modeling models.
2. Press or to toggle between the 14 dierent the amp modeling models.
ðThe LED [AMP] lights up in the corresponding colour (see
Ä ‘AMP’ on page 23).
3. Press and hold [AMP] to conrm the selection.
Operating
DNAfx GiT Mobile
19

6.2 Selecting timbre
1. Press [TONE] to enable the timbre of the selected amp modeling model.
2. Press or to toggle between the ve dierent timbres.
ðThe LED [TONE] lights up in the corresponding colour (see
Ä ‘TONE’ on page 25).
3. Press and hold [AMP] to conrm the selection.
Operating
