EXPLORER®500
QUICK GUIDE
Start up
1. Connect the cable(s).
2. Press and hold the power button next to the display
until the green power indicator lights up.
3. Enter the SIM PIN if required.
4. Adjust the antenna position to obtain the maximum
signal strength, and accept.
NOTE: When the display shows READY, the terminal
automatically activates the LAN interface if the cable is
connected and the interface is enabled. If you are not
going to use the LAN connection, remove the cable or
disable the LAN interface to avoid being charged for
any transmission through this interface.
You can now make a call or run a data session.
If you need to repoint the antenna later, enter the
display menu system and select SETTINGS > POINT
NOW.
Voice call
If you are using a Bluetooth handset, the handset must
be paired and placed close to the EXPLORER 500.
To make a call from the EXPLORER 500, dial
00 <country code> <phone number> followed by # or
off-hook key.
Example: Thrane & Thrane A/S in Denmark:
00 45 39558800 #
NOTE: There are two audio qualities for voice: Standard
voice and 3.1 kHz Audio.
To force the call to use Standard voice, dial 1* before
the number.
To force the call to use 3.1 kHz Audio, dial 2* before
the number.
To make a call to the EXPLORER 500, dial
+870 <mobile number>
NOTE: There are two mobile numbers for voice, one for
3.1 kHz Audio and one for Standard voice.
Fax call
To send a fax from the EXPLORER 500, dial
00 <country code> <phone number> #
Example: Thrane & Thrane A/S in Denmark:
00 45 39558888 #
NOTE: For an analog fax, the audio quality must be set
to 3.1 kHz Audio.
To force 3.1 kHz Audio, dial 2* before the number.
To send a fax to the EXPLORER 500, dial
+870 <mobile number>
Local call
To make a local call from a Bluetooth phone to a
standard phone, dial 0301 followed by off-hook key.
To make a local call from a standard phone to a
Bluetooth phone, dial the number (e.g. 0201) of the
Bluetooth phone followed by #.
To look up the local Bluetooth numbers, enter the
display menu system and select
PROPERTIES > BLUETOOTH DEVICES.

TT-99-122189-C
Start/Stop Streaming on LAN
1. Enter the menu system and select CONNECT.
2. Select the Streaming Profile you want to activate on
the LAN interface.
3. Select START or STOP.
NOTE: When running a Streaming session you are
charged for the time you are connected. A started
Streaming session will stay active until you stop it.
The Streaming Profiles must first be defined and
activated in the LAN window of the web interface.
Refer to the User Manual.
Accessing the web interface
1. Connect a PC to the EXPLORER 500.
2. Start your Internet browser.
3. Enter the IP address of the web interface in the
address field.
The default IP address is 192.168.0.1.
The IP address is found in the menu system, by
selecting PROPERTIES>TERMINAL>IP ADDRESS.
Send SMS
1. In the web interface, select
MESSAGES > Write Message
2. Type the message.
3. Type in the phone number as follows:
00 <country code> <phone number>.
4. Select Delivery Notification Yes or No.
5. Click Send.
Shortcuts in the menu system
To turn pointing sound on/off press or .
To activate stealth mode, press C+ OK.
To exit the menu system, press and hold Cfor one
second.
