Thunder power Tp820cd Installation instructions manual

DUAL PORT, HIGH-POWER MULTI-CHEMISTRY

CHARGER/DISCHARGER/CYCLER/BALANCER SYSTEM

INSTRUCTION/OPERATION MANUAL

www.ThunderPowerRC.com

TABLE OF CONTENTS

NOTICE,WARNINGANDCAUTION.....................................................................................................................4

NOTICE..........................................................................................................................................................4

WARNING......................................................................................................................................................4

CAUTION.......................................................................................................................................................4

BOX CONTENTS.................................................................................................................................................4

INTRODUCTION.................................................................................................................................................5

FEATURES..........................................................................................................................................................6

SPECIFICATIONS................................................................................................................................................7

INPUTPOWER SOURCEANDCONNECTION........................................................................................................7

Input CurrentMax.........................................................................................................................................7

Input Power Low Voltage Cutoff....................................................................................................................7

Input PowerSource Connection.....................................................................................................................8

INPUTANDOUTPUT POWER.............................................................................................................................8

BATTERY CONNECTIONS....................................................................................................................................9

BALANCER CONNECTIONS(forLiPo/LiIon/LiFe batteries)...................................................................................9

OPERATINGINFO.............................................................................................................................................11

ButtonFunctions.........................................................................................................................................11

+/–buttons .................................................................................................................................................11

PORTbutton................................................................................................................................................11

MODE button..............................................................................................................................................11

ENTERbutton..............................................................................................................................................11

CHARGEMODE................................................................................................................................................11

Memory Profiles..........................................................................................................................................12

Battery Chemistry Type...............................................................................................................................12

Battery Cell Count........................................................................................................................................12

Battery Capacity ..........................................................................................................................................13

ChargeCurrentRate....................................................................................................................................13

Balancing ON/OFF(forLiPo/LiIon/LiFe batteries).........................................................................................14

Delta Peak Sensitivity (for NiCd/NiMH batteries).........................................................................................15

Charging theBattery....................................................................................................................................15

Charging LiPo/LiIon/LiFe (A123) Batteries....................................................................................................15

Data Monitoring During Charging................................................................................................................16

Charging Complete/End...............................................................................................................................16

Charging LiPo Batteriesfor use inSerieson SeparatePorts..........................................................................17

Charging SplitLiPo Batteries up to 16S onSeparate Ports............................................................................17

DISCHARGEMODE...........................................................................................................................................19

DischargeCurrent Rate................................................................................................................................20

Discharge Voltage Cutoff.............................................................................................................................21

Discharging the Battery ...............................................................................................................................21

Data Monitoring During Discharging............................................................................................................21

Discharging Complete/End ..........................................................................................................................22

Cooling Fans During/After Discharge ...........................................................................................................22

CYCLEMODE...................................................................................................................................................22

CycleOrder..................................................................................................................................................23

CycleNumber..............................................................................................................................................23

Cycling the Battery ......................................................................................................................................23

Data Monitoring During Cycling...................................................................................................................23

Cycling Complete/End .................................................................................................................................23

STORAGEMODE..............................................................................................................................................24

Storage Charging/Discharging the Battery ...................................................................................................24

Data Monitoring During theStorage Process ...............................................................................................24

Storage Complete/End.................................................................................................................................25

SETTING DATA (SETTINGS)MODE....................................................................................................................25

ChargeEndVoltage.....................................................................................................................................25

PowerDistribution.......................................................................................................................................26

Input PowerLVC/InputCurrentMax............................................................................................................27

CyclePause Time.........................................................................................................................................27

Charge Capacity Limit..................................................................................................................................27

Safety Timer................................................................................................................................................27

TemperatureCutoff.....................................................................................................................................28

Key Beep.....................................................................................................................................................28

EndBeepDuration.......................................................................................................................................28

TemperatureUnit........................................................................................................................................28

DATA VIEW MODE...........................................................................................................................................28

Battery Internal Resistance..........................................................................................................................29

ToMeasure Battery Internal Resistance.......................................................................................................30

ToMeasure Individual Cell Internal Resistance............................................................................................31

Charge/DischargeModeData......................................................................................................................31

Cycle Charge/Discharge Capacity Data.........................................................................................................31

PeakVoltageand DischargeAverage VoltageData......................................................................................31

Individual Cell Voltage Data(forLiPo/LiIon/LiFe Batteries)...........................................................................31

Real-Time InputVoltage andOutput Voltage Data.......................................................................................32

Internal Temperature Data..........................................................................................................................32

ERRORMESSAGES ANDTROUBLESHOOTING...................................................................................................32

FIRMWAREUPDATES.......................................................................................................................................33

WARRANTY, SUPPORT ANDSERVICE ...............................................................................................................34

NOTICE, WARNING AND CAUTION

NOTICE

All instructions, warranties, and other collateral documents are subject to change at the sole discretion

of Advance Energy, Inc. dba Thunder Power RC. For up-to-date product literature, visit

www.ThunderPowerRC.com or call 702-228-8883.

WARNING

Read the ENTIRE instruction manual to become familiar with the features/functions of the

charger before operating. NEVER LEAVE THE CHARGER UNATTENDED DURING USE. Failure

to observe/operate the charger properly can cause damage to the charger, battery, personal

property and/or cause serious injury.

CAUTION

Attempting to charge batteries different that those specified in this manual can result in excessive heat

and other related product malfunctions, which can lead to property damage and/or injury. Please

contact Thunder Power RC (TPRC) or an authorized retailer with compatibility questions.

As TPRC has no control over use, setup, final assembly, modification or misuse, no liability shall be

assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly, the

user accepts all resulting liability.

If you as the Purchaser or user are not prepared to accept the liability associated with the use of this

Product, you are advised to return this Product immediately in new and unused condition to the place

of purchase.

BOX CONTENTS

INTRODUCTION

The TP820CD is a powerful and advanced dual port multi-chemistry charger, discharger, cycler and

balancer system. With up to 800 watts of total charging power the TP820CD is equipped with two

ports that function completely independently to charge, discharge and cycle a wide variety of

1-8S LiPo, LiIon and LiFe (A123) batteries, as well as 1-24 cell NiCd and NiMH along with 6-30V Pb

(lead-acid) batteries. The built-in 2-8S LiPo/LiIon/LiFe (A123) cell balancers, one for each port, and

included balance connector adapter boards are readily compatible with all Thunder Power balance

connectors and the JST-XH balance connectors found on many other batteries.

The dual port TP820CD offers the convenience and flexibility of two separate chargers in a single yet

incredibly compact case as a result of its advanced power conversion technology and

Thunder Power RC exclusive design. Each port is capable of charging at rates up to 20 amps, even

simultaneously depending on input power and charge settings, offering the ability to charge many of

the latest-generation LiPo batteries at ultra-fast rates up to 6C and beyond. This means the

TP820CD is well-equipped to quickly charge batteries up to 8S on each port, as well as ‘split’ batteries

equipped with interconnect leads up to 16S by using both ports simultaneously.

Popular examples of the powerful charging capabilities of the TP820CD are the ability to charge

two 5S 5000mAh batteries, one on each port simultaneously at rates up to 4C, or two 6S 5000mAh

batteries at rates more than 3.5C, to have a complete 10S or 12S 5000mAh battery setup charged in

as little as 15 minutes or less time. That’s even faster than single port chargers rated at higher

current and wattage output, without the need for cumbersome parallel charging and an even more

powerful power supply, and without giving up the added convenience and flexibility that independent

dual port charge, discharge and cycling functionality offers. And because each port functions

independently you can even mix and match charge, discharge or cycling duties of a LiPo motor power

battery and a NiMH transmitter battery, a NiCd receiver battery and a lead-acid field box battery or

just about any other combination you might have.

Additional features include built-in data logging and viewing on the large, class-leading and

easy-to-read 48-character blue backlit LCD screen, internal resistance (IR) measurement and an

advanced Storage Mode function to automatically charge or discharge LiPo/LiIon/LiFe (A123)

batteries as needed. Other great features also include dual computer-controlled cooling fans and

temperature protection, an attractive and extremely durable aluminum case, plus the ability to install

future firmware updates available for free download from www.ThunderPowerRC.com using a

standard mini USB cable. Best of all these incredible features are all available at a value that’s hard

to beat while being fully supported and backed by Thunder Power RC with industry-leading warranty

support and service.

FEATURES

Powerful all-in-one dual port charger, discharger and cycler system with built-in

LiPo/LiIon/LiFe (A123) cell balancers that offer maximum safety, performance and

easy-to-see individual cell voltages

The included balance connector adapter boards (2pcs) allow the built-in balancers to be

used with 2-8S Thunder Power-compatible balance connectors as well as the JST-XH

balance connectors found on many other brand batteries from Align, Dynamite®, E-flite®,

ParkZone® and more

Convenient and flexible dual (two) port design charges, discharges and cycles

1-8S LiPo/LiIon/LiFe (A123), 1-24 cell NiCd/NiMH and 6-30V Pb (lead-acid) batteries on

each port independently or simultaneously

More than double the charging power, up to 800 watts total (400 watts per port), of other

similar class chargers with selectable charge rates from 0.2 amps up to 20 amps for each

port

The perfect choice for safe and ultra-fast charging at rates of 3-6C and beyond for the

latest-generation LiPo batteries

Charge two 5S or 6S 5000mAh batteries at rates up to 4C for 10S or 12S battery setup

charge times of as little as 15 minutes or less* – even faster than single port chargers that

require cumbersome parallel charging and a more powerful power supply

Advanced Storage Mode function for LiPo/LiIon/LiFe (A123) batteries will automatically

charge or discharge as needed to achieve storage level voltage

24 user-programmable memories plus built-in data logging and viewing with

internal resistance measurement, battery voltage, input voltage, temperature and more

Fully-adjustable charge capacity limit, per cell end voltage and low voltage cutoff settings

for all chemistries to maximize safety, charge and discharge performance

Durable and compact aluminum case with dual computer-controlled cooling fans and a

large, class-leading and easy-to-read 48-character blue backlit LCD screen

Wide input voltage range from 10.5-28.0V for higher efficiency and power output when

using 24.0-28.0V power supplies

Adjustable output power distribution per port, input power current limiting and low voltage

cutoff settings to maximize performance while also protecting the charger and input power

supply

Future firmware updates can be downloaded for free from www.ThunderPowerRC.com

when new features, battery chemistry and other updates are made available and are easily

uploaded to the charger using a standard mini USB cable

Full industry-leading warranty and support from Thunder Power RC

*With 24.0-28.0V input and depending on state of charge before charging begins

SPECIFICATIONS

Type: Dual Port Multi-Chemistry DC Charger/Discharger/Cycler with Integrated Balancers

Battery Cell Counts/Types (Per Port): 1-8S LiPo/LiIon/LiFe (A123), 1-24 cell NiCd/NiMH and 6-30V

Pb (lead-acid)

Balancer (Per Port): Integrated for 2-8S LiPo/LiIon/LiFe (A123) with balance connector adapter

board for Thunder Power and JST-XH connectors

Input Power: 10.5-28.0V DC (40 amps max)

Charge Power: 800 watts max (400 watts max per port) w/24.0-28.0V input (see later in this manual

for additional information regarding input and output power)

Charge Current (Per Port): 0.2 to 20 amps in 0.01 amp increments

Charge Voltage: 50% storage and adjustable end voltage for LiPo/LiIon/LiFe (A123), adjustable delta

peak sensitivity and end voltage for NiCd/NiMH and end voltage for Pb (Lead Acid)

Discharge Power: 100 watts max (50 watts max per port)

Discharge Current (Per Port): 0.2 to 10 amps in 0.01 amp increments

Discharge Voltage: Adjustable low voltage cutoff for LiPo/LiIon/LiFe (A123), NiCd/NiMH and Pb

(lead-acid)

Cycles: 1 to 15 times with data stored for all cycles

Memories: 24 user-programmable

Firmware: User-updatable using USB

INPUT POWER SOURCE AND CONNECTION

The TP820CD (charger) is designed and built to be powered from a 10.5-28.0V DC power source.

This can include a single 12V Pb/lead-acid battery, two 12V Pb/lead-acid batteries connected in

series for 24V or a quality AC to DC power supply with stable 10.5-28.0V DC output.

Input Current Max

The maximum input current can be set from 10.0-40.0A in order to prevent damage to the power

source and/or charger. This means you can limit the maximum current the charger can pull from the

power source per the maximum capabilities of the source as needed. For example, if you are using a

power supply that is capable of outputting 25.0A max you should adjust the Input Current MAX setting

to 25.0A to ensure the charger is not able to pull more than 25.0A from the power supply. You can

adjust this setting in the charger by powering it on and pressing the MODE button once to scroll to the

Setting Data (Settings) menu, then press the + or – buttons to scroll to the appropriate menu and

adjust the setting accordingly. Or, in order to obtain maximum output power (per input voltage) for

charging, you must use a power supply capable of delivering up to 40.0A.

Input Power Low Voltage Cutoff

You can also set the Input Power LVC (Low Voltage Cutoff). This is the input voltage at which the

charger will stop charging/discharging in order to prevent overloading/over-discharging the input

power source. This is particularly beneficial when charging from a 12V Pb/lead-acid car battery as it

allows you to maintain enough voltage/power in the battery to still start the car after using the charger.

You can adjust this setting in the charger by pressing the MODE button once to scroll to the Setting

Data (Settings) menu, then press the + or – buttons to scroll to the appropriate menu and adjust the

setting accordingly. We recommend setting this value to between 10.5V and 11.0V for typical use, or

in the case that you will be loading the input power source considerably (so the voltage will drop more

significantly under load even though there is still sufficient capacity remaining in the 12V battery for

example) you can set this as low as 10.0V. However, keep in mind that dropping the voltage under

load to as a low as 10.0V (or even 10.5V under some loads) could result in discharging a 12V battery

input power source low enough that it will not start the car when needed.

Input Power Source Connection

The input power leads for the charger are equipped with 4mm bullet connectors compatible with most

typical female ‘banana plug’ receptacles. You can connect these directly to the outputs of many AC to

DC power supplies, or you can also connect them to the included alligator clips for more convenient

connection to Pb/lead-acid batteries. However, especially when charging at or near maximum

input/output power levels, you must ensure the bullet connectors/alligator clips are making excellent

contact with the power source in order to minimize resistance and prevent voltage/power

loss/damage.

After connecting the charger to the input power source with proper polarity the charger will power on

accordingly. At this point you will briefly see the ‘Welcome’ screen indicating the charger model and

the version of firmware currently installed in the charger.

Please also note that in some cases if the connection to the input power source is not ‘clean’

the welcome screen may not show and instead only part of the default Charge Mode screen

will show. This will typically happen when connecting the charger to a power source that is

already ‘on’ so we suggest powering down the source before connecting the charger. Also, if

this occurs simply disconnect the charger from the power source, then re-connect ensuring

that you achieve a solid/clean connection during the process.

INPUT AND OUTPUT POWER

The charger will automatically adjust the output power level available based on the input voltage,

current, output voltage, etc. and at no time can the input current exceed 40.0A max. As a result you

can obtain higher/maximum output power when using higher voltage power sources that provide 24.0-

28.0V. However, it is still possible to obtain relatively high levels of output power using more common

10.5-15.0V power sources.

Here also is a quick way to help determine the approximate amount of input power your chosen power

source can supply:

Input Voltage (under load) (V) x Input Current (A) = Input Power (W)

For example:

12V x 25A = 300W

12V x 40A = 480W 24V x 25A = 600W

27V x 40A = 1080W

The input power level will dictate the charger’s output power level capability in total based on charger

efficiency (typically ~85-93% depending on input/output voltage). And in turn the output power level

capability will dictate the maximum charge current/voltage capability accordingly.

Please see the chart provided separately for a quick reference of the maximum output power

levels/charge current for LiPo batteries based on the listed input voltage and current (and please note

that these values are approximate and may vary +/– slightly depending on input voltage of the power

source under load, ambient temperatures, state of charge/voltage level of the battery being charged,

etc.).

Also, for those interested in achieving maximum output power (800W total) we recommend using a

27.0-28.0V, 35-40A power supply for maximum efficiency (especially when charging multiple 6S

22.2V LiPo batteries for example). One such power supply we’ve used with excellent success is the

IOTA Engineering DLS-27-40. With a typical output voltage of 27.2V and the capability to deliver up

to 40A, this power supply can deliver upwards of 1100W to the charger allowing for maximum output

(800W) with some headroom to spare (also works well with two TP820CD chargers running at high

power levels up to ~500W each).

BATTERY CONNECTIONS

The charger is equipped with typical female ‘banana plug’ receptacles for each port that are

compatible with most male banana plugs and 4mm bullet connectors. We suggest using gold 4mm

bullet connectors, like those found on the included battery connection leads, especially when charging

at rates above 5 amps.

You can also install the connector(s) of your choice on the included battery connection leads and/or in

many cases you can purchase pre-made ‘charge leads’ equipped with banana or 4mm bullet

connectors, wire leads and connectors compatible with the connectors installed on the batteries you

will be charging/discharging. Also, wire leads that are too long and/or not large enough gauge

(AWG/GA) for the applicable charge/discharge current will become warm/hot which can damage the

charger and/or result in errors in battery charging/discharging (i.e. – ‘false peaks’ when charging

NiCd/NiMH batteries, etc.). These details in mind, we recommend keeping the length of the wire

leads as short as possible (preferably 12”/305mm long max). We also recommend using 10 to 14

AWG wire leads when charging at rates 10 amps and higher, minimum 16 AWG at rates up to 10

amps and minimum 18 AWG at rates up to 5 amps.

Please also be certain to connect all batteries with the proper polarity as marked on the faceplate

label and further identified by the colored rings around the banana plug receptacles (red is +/positive

and black is –/negative). And in the event that you do connect the battery with incorrect polarity the

error message ‘Battery Reverse Polarity’ (or ‘Battery Polarity Inversion’ in earlier version firmware) will

show on the screen. However, in order to prevent all possibility of damage to the charger and/or

battery you should always exercise care to ensure proper polarity when connecting batteries.

Also, DO NOT connect the battery to the charger when the charger is powered off. The

charger should always be powered on before connecting the battery.

BALANCER CONNECTIONS (for LiPo/LiIon/LiFe batteries)

The TP820CD is equipped with built-in balancers for LiPo/LiIon/LiFe (A123) cells/batteries. There is

an independent balancer for each port as marked on the faceplate label and you should ALWAYS

use the balancers when charging LiPo/LiIon/LiFe batteries for maximum safety and battery

performance/longevity. The balancers, working in conjunction with the charger, perform functions

similar to the safety circuits found in the LiPo/LiIon/LiFe cells/batteries for cell phones, laptop and

other electronic devices to prevent over-charging that can result in fire causing damage and/or

personal injury. They do this by ensuring the voltages of cells within LiPo/LiIon/LiFe batteries are

closely equalized/balanced by discharging the higher voltage cells to closely match the lower voltage

cell(s) in the battery. This prevents over-charging any cell(s) that may have a higher voltage during

the charge process, or, in the event that the balancer cannot balance the cell(s) in time to prevent

exceeding the ‘CHG End Voltage’ setting (for any cell), the charger will automatically reduce the

charge current rate and/or end the charge process entirely as needed.

Please also note that due to the high-power charging capabilities of the TP820CD it is not

designed to charge through the balance connectors/leads of LiPo/LiIon/LiFe batteries. These

connectors/leads are typically limited to maximum charge/discharge rates of only 2-4 amps

versus the up to 20 amp charge rate capability of the TP820CD. As a result you MUST connect

the main power AND balance connector leads to the charger in order to charge through the

main power and balance through the balance connector leads accordingly.

The 9-pin Thunder Power type connectors for each balancer are located on the sides of the charger.

When viewing each connector straight on (with the top/face of the charger pointed upwards) the main

ground/negative (–) connector (pin) is located on the far left while the positive (+) connector is located

on the far right. And while it is possible to connect Thunder Power 4-pin and 6-pin balance

connectors from batteries and extensions to these connectors directly (always aligning the main

ground/negative wire to the far left), to prevent any issues with connection location, polarity and

fatigue of the connection between the 9-pin connectors and the charger board internally, we

recommend always using the included balance connector adapter boards instead.

To use the included balance connector adapter boards simply insert the male 9-pin connector into the

female 9-pin connector for each balancer. The connectors are ‘keyed’ to prevent reverse polarity

connection, and each balance connector adapter board is equipped with balance connectors

compatible with all 2S 7.4V to 8S 29.6V LiPo/LiIon/LiFe batteries equipped with Thunder Power and

JST-XH balance connectors. And in the event that you must connect batteries that are not equipped

with TP or JST-XH balance connectors, there are additional balance connector adapter leads (i.e. –

TP to JST-EH, etc.) available from many sources. Please also note that the balance connector

adapter boards are also available separately if needed:

TP8SAB-TPJXH 2S to 8S Thunder Power/JST-XH Balance Connector Adapter Board

The following accessories for Thunder Power balance connectors are also available:

TP4P8 4-Pin Balance Connector w/8" 22GA Color Coded Wires

TP6P13 6-Pin Balance Connector w/13" 22GA Color Coded Wires

TP4P10E 4-Pin Balance Connector Extension w/10" Color Coded Wires

TP6P10E 6-Pin Balance Connector Extension w/10" Color Coded Wires

TP6P4E 6-Pin to 4-Pin Balance Connector Adapter

After connecting the balance connector adapter board to the charger/balancer you can connect the

balance connector from the battery to the appropriate mating connector, ensuring proper keying of the

connectors and polarity, on the board accordingly. And please note that unless you are using the

correct adapters/connections to charge multiple batteries in series and/or parallel (contact Thunder

Power RC directly for more information on series/parallel charging if needed) you must NOT connect

more than one battery to the balance connector adapter board. If you connect multiple batteries

incorrectly or connect one battery with incorrect polarity it is possible to damage the traces and/or the

pins/connectors on the balance connector adapter board (and such damage is not covered under

warranty).

OPERATING INFO

Button Functions

+/– buttons

The +/– buttons allow you to scroll up/down through menus before and during charging/discharging.

These buttons also allow you to change values/settings for options after they have been selected

(typically when flashing after pressing the ENTER button).

PORT button

The PORT button allows you to toggle/switch the port (1 or 2) you are currently viewing. You can

toggle/switch between each port any time before and during charging/discharging by pressing the

PORT button. Also, the port you are currently viewing is always indicated by a 1 or 2 as seen in the

upper right hand corner on all screens.

MODE button

The MODE button functions only before/when not charging/discharging. Pressing the MODE button

will allow you to scroll between the three available modes:

Charge/Discharge/Cycle/Storage Modes

Setting Data Mode

Data View Mode

ENTER button

The ENTER button allows you to select and validate values/settings for options that can be changed

(using the +/– buttons to change) before and during charging/discharging. Pressing and holding the

ENTER button also allows you to start and stop charging/discharging.

CHARGE MODE

After powering on the charger properly the first mode always shown by default is the ‘Charge Mode’.

This is the mode that allows you to set the memory profile number, battery chemistry type, number of

cells, battery capacity limit, charge current rate, balancing on/off for LiPo/LiIon/Life or the delta peak

value for NiCd/NiMH. It’s also important to note that all of these settings must be set in this

mode/screen before changing to the discharge, cycle or storage modes (these settings cannot

be changed/set in those modes).

Here is a quick reference of what the Charge Mode screen displays:

1) Memory profile number

2) Battery chemistry type

3) Mode (charge, discharge, cycle, storage)

4) Number of cells (in series)

5) Port currently being viewed

6) Battery capacity

7) Current rate

8) Balancing ON/OFF for LiPo/LiIon/LiFe or

Delta Peak Sensitivity value for NiCd/NiMH

Memory Profiles

You can set a total of 12 memory profiles per port (24 total). This is a convenient feature as it allows

you to set the typical charge, discharge, cycle and storage mode profiles for specific batteries to save

you time versus having to always change the settings when charging/discharging different

configurations and chemistries of batteries.

To scroll through the available memory profiles, while on the Charge Mode screen simply press the

ENTER button once. The memory profile number will begin to flash and you can use the +/– buttons

to scroll through the profiles accordingly. And again, you can set up to 12 profiles per port (24 profiles

in total), however, we do recommend setting the same profiles, in the same order, for both ports if you

have no more than 12 different configurations/chemistries of batteries as it will allow you to select the

profile for your batteries on either or both ports simultaneously with ease.

Battery Chemistry Type

The TP820CD is capable of charging/discharging LiPo, LiIon, LiFe (A123), NiCd, NiMH and Pb (lead-

acid) batteries. Each of these chemistries/types of batteries is charged in a different way and

you MUST select the correct chemistry/type in order for the charger to charge/discharge

safely. Failure to select the correct chemistry/type and settings per the battery being

charged/discharged can result in damage to the battery or fire causing damage and/or

personal injury. If you are unsure of the battery chemistry/type, and the correct settings that

must be used for safe and correct charging/discharging, DO NOT attempt to charge/discharge

the battery. Instead, please contact the manufacturer of the battery for more information first.

To select the correct battery chemistry/type, while on the Charge Mode screen simply press the

ENTER button twice. The battery chemistry/type will begin to flash and you can use the +/– buttons to

scroll through them accordingly. After selecting the correct chemistry/type you can press the ENTER

button to select the other adjustable values, or wait approximately 5 seconds until the chemistry/type

stops flashing to begin the charge process or to scroll through the other modes (discharge, cycle and

storage).

Battery Cell Count

The TP820CD is capable of charging/discharging 1S (3.7V) to 8S (29.6V) LiPo, LiIon and LiFe (A123)

batteries, as well as 1-24 cell NiCd and NiMH along with 1S (2V) to 15S (30V) Pb (lead-acid)

batteries. After selecting the correct battery chemistry/type you MUST select the correct cell

count for the battery you will be charging/discharging. Failure to select the correct cell count

per the battery being charged/discharged can result in damage to the battery or fire causing

damage and/or personal injury. If you are unsure of the battery cell count DO NOT attempt to

charge/discharge the battery. Instead, please contact the manufacturer of the battery for more

information first.

To select the correct battery cell count, while on the Charge Mode screen simply press the ENTER

button three times. The battery cell count will begin to flash and you can use the +/– buttons to

increase/decrease the cell count accordingly. After selecting the correct cell count you can press the

ENTER button to select the other adjustable values, or wait approximately 5 seconds until the cell

count stops flashing to begin the charge process or to scroll through the other modes.

Battery Capacity

For added safety and ease of use, the TP820CD features a function that allows you to set the battery

capacity. This function allows you to enter the capacity of the battery you’ll be charging so the

charger can automatically set a 1C (1 x Capacity) charge rate. In general most supported battery

chemistries/types can be charged safely and successfully at a 1C rate so this feature makes for the

easiest possible setting and use especially if you are not confident in taking advantage of and/or

aware of the max charge rate capability of the battery you’ll be charging.

This function also adds an additional level of safety as it helps to ensure, in conjunction with the CHG

(Charge) Capacity Limit function found in the Setting Data (Settings) menu, that even if the charger

does not terminate/end charging correctly per the battery chemistry/type, that it will still end the

charge when the set capacity has been reached.

These details in mind you should ALWAYS set the battery capacity correctly. To set the correct

battery capacity, while on the Charge Mode screen simply press the ENTER button four times. The

battery capacity will begin to flash and you can use the +/– buttons to increase/decrease the capacity

accordingly. After setting the correct capacity you can press the ENTER button to select the other

adjustable values, or wait approximately 5 seconds until the cell count stops flashing to begin the

charge process or to scroll through the other modes.

Charge Current Rate

After setting the battery capacity limit correctly, the charger will automatically set the charge current

rate to 1C. In the case of a 5000mAh battery, it will set the charge current to 5.00A. And again, in

general most supported battery chemistries/types can be charged safely and successfully at a 1C rate

so we suggest charging at the 1C rate especially if you are not confident in taking advantage of and/or

aware of the max charge rate capability of the battery you’ll be charging.

Or, if you are interested in charging at a rate higher (or lower) than 1C you can adjust the charge

current rate accordingly. However, it is important to note that if you charge at a current rate that

is too high it can result in damage to the battery or even fire causing damage and/or personal

injury. If you are unsure of the maximum safe charge rate of the battery DO NOT charge at a

rate higher than 1C or please contact the manufacturer of the battery for more information.

And to set the charge current rate, while on the Charge Mode screen simply press the ENTER button

five times. The charge current rate will begin to flash and you can use the +/– buttons to

increase/decrease the current rate accordingly. After setting the charge current rate per your

preference you can press the ENTER button to select the other adjustable values, or wait

approximately 5 seconds until the current rate stops flashing to begin the charge process or to scroll

through the other modes.

Also, before starting the charge process the maximum charge current that can be set (if it is

less than 20.0A, which is the max charge current rate for each port) is automatically calculated

by the charger based on the voltage of the input power source and the estimated voltage of

the battery being charged based on the cell count you have selected. This is calculated using

the discharged voltage of the battery (i.e. ~3.3V per cell for LiPo batteries) so it is possible to set the

charge current rate to the maximum rate possible.

And if you have set the charge current rate to the maximum rate possible, after starting the

charge process the charger will automatically adjust the current rate, per the actual voltage of

the battery at any given time, to maintain (and not exceed) the maximum output power level

(wattage). For example, in the case of charging a 6S 22.2V 5000mAh LiPo battery and when using a

27.0-28.0V/35-40A power supply for maximum input/output power, before the charge process has

started you will be able to set the charge current rate to 20.0A max. However, if the battery is

currently at more than 20.0V the charger will then adjust the current rate automatically between 20.0A

and approximately 15.8A as needed to ensure it does not exceed the 400W maximum output power

level of each port. And when the battery nears/reaches the end of the Constant Current (CC) phase

of the charge around 25.2V (4.2V per cell) the current rate will reduce accordingly throughout the

Constant Voltage (CV) phase of the charge process and until the charge is complete.

Also, after the charge process has started (and if you have not already set the charge current

rate to the maximum rate possible) you can actually increase the charge current rate by up to

25% (i.e. – from 10.0A to 12.5A) or to the maximum charge current rate possible based on the

actual voltage of the battery and power level of each port; whichever comes first . To do this,

simply press the ENTER button once immediately (or any time) after the charge process has been

started (and the ‘Battery Check Please Wait…’ check is complete) and the current rate will begin to

flash. You can then use the + button to increase (or the – button to decrease) the current rate

accordingly.

These details in mind, please also see the chart provided separately for a quick reference of the

maximum output power levels/charge current rate settings for LiPo batteries based on the listed input

voltage and current (and please note that these values are approximate and may vary +/- slightly

depending on the input voltage, output current, power level of the power source under load, ambient

temperatures, state of charge/voltage level of the battery being charged, etc.).

Balancing ON/OFF (for LiPo/LiIon/LiFe batteries)

As noted in further detail in the BALANCER CONNECTIONS section of this manual, the TP820CD is

equipped with built-in balancers for LiPo/LiIon/LiFe (A123) cells/batteries and you should ALWAYS
