Tidal InSee User manual

1
InSee Device User Manual

2
Table of Content
• Specifications and Performance page 3
• Instructions for Use page 4
• Attaching Spirometer
• Use by Respiratory Therapist
• Use by Patient
• Charging and Cleaning
• Warnings page 8
• Medical Info page 9
• Contact Info page 10

3
Specifications and performance
• Measures spirometer tidal volume from 500 mL to
4000 mL in 250 mL increments
• Audible and visual alarms
• User interface
• 0.96 x 0.53 in OLED screen
• Manual buttons
• Rechargeable lithium battery (1200 mAh)
• Recharged using USB-C
• 20 hour battery life
• 2.5 hour charge time
• Weight: 4.2 oz

4
Instructions for Use:
Attaching spirometer
Step 1 – Press down on tab
Step 2 – Slide spirometer into lip
Step 3 – Release tab
* To remove the spirometer, do these steps in reverse

5
Instructions for Use:
Use by respiratory therapist
• “+” Button
• Increase the target tidal volume in 250 mL increments
• “A” Button (Alarm)
• Turn alarm on or off
• “P” Button (Power)
• Turns device on and off with 3 second press
• “R” Button (Reset)
• Resets and recalibrates the device
• Must be done with spirometer attached
• Must be done every time device is turned on
• Wake from sleep mode with any button press

6
Instructions for Use:
Use by patient
• Follow directions for normal spirometer use
• Alarm to use spirometer occurs every 10 minutes
• Alarm will sound
• LED will flash red
• When plunger reaches target volume, LED will flash
green
• Keeps track of attempts, successes, and maximum
volume

7
Instructions for Use:
Charging
• Charge using the USB-C cable
• LED will be solid green while charging
• LED will turn off when finished charging
• Average charge time: 2-2.5 hours
Cleaning
• Wipe down with alcohol/disinfectant wipe
• Do not immerse in liquid
• Do not autoclave
Charging Port

8
Warnings
Improper attachment
Staff should be instructed on proper attachment
techniques. Attach the InSee to the spirometer
per the diagram on page 4. The InSee should be
tightly attached to the spirometer and not easily
shifted so to ensure proper readings can be
measured.
Calibration values and incorrect reads
Prior to use of the InSee device, it is carefully
calibrated as part of quality control. During
initial training, the healthcare provider should
monitor readings to ensure proper calibration. If
the healthcare provider notices improper
readings, then the InSee should be recalibrated
using the USB-C connection and firmware.
Overall, an incorrect reading should have no risk
to the patient treatment as incentive spirometers
are used as preventative tools and not diagnostic
tools.

9
Medical info
Indications for Use
InSee is compatible with the Vyaire Medical AirLife
Incentive Spirometer. It is intended for use as a
reusable accessory, in a hospital setting, for
quantitatively tracking patient usage of the incentive
spirometer as an aid in treatment of respiratory
conditions by patients with COVID-19.
Contraindications
-Recent eye surgery
-Pneumothorax
-Aneurysm in brain, chest, or abdomen
Contact Info

10
Tidal Medical Technologies
2024 W 15th Street Suite F336
Plano, TX 75075
https://tidalmed.tech
Manufacturer:
VPI Technology Group
11814 S. Election Rd, Ste 200
Draper, UT 84020
www.vpitechnology.com
For immediate assistance 24/7: please contact
Tidal Medical Technologies at 1-508-479-6116 or
1-214-864-5629
