Smiths Medical CADD-Legacy Reference guide

CADD™Medication Cassette
Reservoirs with Flow Stop
Quick Reference Card
Flow stop free-flow protection is an integral
set-based free-flow protection device that has
been added to medication cassette reservoirs.
CADD-Legacy®Pumps
IN19859EN-032013.indd 1IN19859EN-032013.indd 1 27/08/2020 13:3527/08/2020 13:35

1. Fill the medication cassette reservior and remove all air
from the medication cassette reservoir according to the
Instructions for Use supplied with the product.
2. Close the tubing clamp.
3. Using aseptic technique, connect the medication
cassette reservoir luer to the luer lock (blue cap)
of the extension set.
NOTE: Connect the medication cassette reservoir luer
to the luer lock of the extension set. If the anti-siphon
valve end of the extension set is connected to the
medication cassette luer, a high pressure alarm will
sound when you try to start the pump.
Step 1- Connect the Extension Set
WARNING: Leave the blue clip on the cassette in place
until ready to attach the cassette to the pump. Storing
the cassette with the blue clip removed may affect
delivery accuracy.
Step 2- Prime the Tubing
1. Remove the blue clip from the cassette.
IN19859EN-032013.indd 2IN19859EN-032013.indd 2 27/08/2020 13:3527/08/2020 13:35

2. Insert the cassette hooks into the pump’s hinge pins.
3. Place pump with cassette on firm surface and push
down on top of pump so cassette fits tightly against
the pump.
4. Insert a CADD®pump key or coin into the lock, push in
and turn counter clockwise until the line on the lock
lines up with the arrow on the side of the pump, and
you feel the lock click into place.
5. Gently twist and pull on cassette to make sure
it is attached properly.
Step 3- Start the Infusion
IN19859EN-032013.indd 3IN19859EN-032013.indd 3 27/08/2020 13:3527/08/2020 13:35

Step 3- Start the Infusion
1. Using aseptic technique, connect the tubing to the
patient’s access site.
2. Open all tubing clamps and begin the infusion.
WARNING: Ensure fluid path below filter is free of air
before connection to patient. Please refer to the detailed
Instructions for Use supplied with the medication cassette
reservoir for additional information, cautions, and warnings.
For pump priming, refer to the Operator’s Manual supplied
with the pump.
6. Open all clamps.
7. Prime the tubing using the pump’s priming feature
according to the pump Instructions for Use. Ensure that
the entire fluid path is free of all air.
8. If the extension set contains a filter, prime
the filter according to the extension set’s Instructions
for Use.
9. Close all tubing clamps.
IN19859EN-032013.indd 4IN19859EN-032013.indd 4 27/08/2020 13:3527/08/2020 13:35

Filling
The medication cassette
reservoir is designed to be
easily filled with the blue
flow stop clip in place.
Closing the fluid path
Remove the blue clip
to close the fluid path.
Opening the fluid path
Press the green button to
open the fluid path.
Smiths Medical is part of the global technology business Smiths Group plc. MPAUCA-1001
Product(s) described may not be licensed or available for sale in all countries. Please
see the Instructions for Use/Operator’s Manual for a complete listing of the indications,
contraindications, warnings and precautions. CADD, the Medication Cassette Reservoir design
and the Smiths Medical and CADD design marks are trademarks of Smiths Medical. The
symbol ® indicates the trademark is registered in the U.S. Patent and Trademark Office and
certain other countries. ©2013 Smiths Medical. All rights reserved. IN19859EN-032013
Smiths Medical ASD, Inc.
St. Paul, MN 55112, USA
Phone: [phone]
Toll-Free USA: 1-800-258-5361
www.smiths-medical.com
Find your local contact information at www.smiths-medical.com/customer-support
Australian Representative
Smiths Medical Australasia Pty. Ltd.
Brisbane, QLD 4113, Australia
Phone: [phone]
IN19859EN-032013.indd 5IN19859EN-032013.indd 5 27/08/2020 13:3527/08/2020 13:35

Filling
The medication cassette
reservoir is designed to be
easily filled with the blue
flow stop clip in place.
Closing the fluid path
Remove the blue clip
to close the fluid path.
Opening the fluid path
Press the green button to
open the fluid path.
