tiko Energy Solutions K-Box A7 User manual

K-Box A7 User's Manual English 2 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Safety Warnings and Working Instructions
Hazard Risk
Read the user manual before installing and operating this product!
Installation by person with electronical expertise and trained on this product
only!
Disconnect all power sources before carrying out any manipulation!
Always use appropriate protection equipment!
Danger! High voltage!
Never touch disconnected wires! Life hazard!
Only use for current/voltage as indicated on the device label! Doing otherwise
can cause device damage and may pose an electrical shock or fire hazard!
Not properly tightened screws can cause a high contact resistance, lead to
overheating and cause a fire hazard!
Not properly connecting the Neutral will damage the device and pose safety
risk!
Warnings
•Read the installation instructions before you connect the system to its power source.
•To prevent the system from overheating, do not operate it in an area that exceeds
the maximum admitted ambient temperature of 55°C.
•This product relies on the building’s installation for short-circuit (over current) pro-
tection. Ensure that a fuse or circuit breaker no larger than 230 VAC, 65 A is used
on all current-carrying conductors.
•The circuit breaker shall be in front, close to the device, easily reachable by the op-
erator, and it shall be marked as the disconnecting breaker for the device.

K-Box A7 User's Manual English 3 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
•Do not work on the system or connect or disconnect cables during periods of light-
ning activity.
•Device is intended for indoor use only.
•Ultimate disposal of this product should be handled according to all national laws
and regulations.
•Any usage of this device in a manner that does not conform to this manual specifi-
cation can impair the provided safety protection.
Safety Instructions
Read these safety instructions carefully.
•Follow common household electrical safety practices.
•Read all cautions and warnings on the equipment.
•Don’t put power to the electrical panel before putting back the cover of the home
distribution box. No live contact shall be accessible.
•Disconnect this equipment from the distribution box before cleaning it. Do not use
liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning.
•The openings on the enclosure are for air convection and protect the equipment
from overheating. Do not cover the openings.
•Do not pour any liquid into opening. This could cause fire or electrical shock.
•Do not open the enclosure of this product and/or alter this product in any way.
•Have the equipment checked by a service professional if one of the following situa-
tions arises:
oThe line is damaged.
oLiquid has entered the equipment.
oThe equipment has been exposed to moisture.
oThe equipment does not work properly, or you cannot get it to work ac-
cording to user’s manual.
oThe equipment has been dropped or damaged.
oThe equipment has obvious signs of breakage.
•Keep this equipment away from excessive or condensing humidity.
•Do not leave this equipment in an unconditioned environment. Temperatures above
55°C will damage the equipment.
•Keep this guide for later reference.
Feedback
You can also submit your comments via regular mail by writing to the following address:
tiko Energy Solutions AG
Alte Tiefenaustrasse 6
CH-4600 Bern
We appreciate your comments.

K-Box A7 User's Manual English 4 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Overview
Intended Use
K-Box is a custom energy meter with remote controlled opto-coupler to be only used in
tiko Energy Solutions AG authorized setups. The output of the opto-coupler shall be con-
nected to a receiving unit able to decode the K-Box-A7 signaling.
Any installation or usage which does not conform to tiko Energy Solutions AG setup is
strictly forbidden. tiko Energy Solutions AG is not responsible for any improper installa-
tion/usage of this device.
Features
K-Box features:
•meters instantaneous energy consumption on 3 phases in both directions (con-
suming and generating)
•remotely controlled opto-coupler to send signals to a connected device
•LEDs showing connection and opto-coupler status
Package Content
Open the package and check that you have all the following items:
•Instructions manual
•K-Box
If any of the parts are incorrect, missing or damaged, please contact the retailer where
you made your purchase. Keep the carton box, including the original packing materials, in
case you need to return the unit for repair.
Device
IMAGE 1 shows the device from the front. IMAGE 2 shows the device from the bottom
and indicates the phases and neutral terminals.
On the bottom side is a label indicating
•The manufacturer
•The device model number (REF) and the current rating
•The hardware (HW) and firmware (FW) version
•The unique serial/MAC address as text and as barcode code (SN/MAC)

K-Box A7 User's Manual English 5 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Installation
Installation by person with electronical expertise and trained on this
product only!
Do not install the device unless you have removed the main power supply
(main breaker or fuses)!
Installing the K-Box
Step 1
Remove power from the electrical panel.
Step 2
Remove the cover panel so you can access the wires.
Step 3
Verify that there is no tension on the wires you intend to manipulate.
Step 4
Ensure that there is a short-circuit protection for 3 phases (breaker or
fuse) before the K-Box not larger than 420 V 65 A.
Step 5
Put the K-Box on the DIN rail of the home distribution box and ensure
the hook is locked properly (IMAGE 3).
Remove the protection covers from the terminals (IMAGE 4).
Step 6
Prepare the cables. Refer to Specifications on page 8 for supported rat-
ings and cable diameters.
Step 7
Connect the wires to the K-Box (IMAGE 6):
•From left to right, connect Phase 1, Phase 2, Phase 3, Neutral
•Wires for top terminals are coming from source
•Wires for bottom terminals are going to load
Tighten all clamp screws with enough torque. Insufficient
clamping force can result in high contact resistance that
leads to device heating and can result in a fire hazard.
Step 8
Connect the opto-coupler terminals so the K-Box can send encoded in-
formation to the target device. Lift the cover of the opto-coupler termi-
nals (IMAGE 5). Connect the contacts as indicated in IMAGE 7:
•OUT –Emitter (to be connected to signal)
•(middle) –not used
•IN –Collector (to be connected to + 24V)

K-Box A7 User's Manual English 6 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Step 9
Close the opto-coupler cover. Put back the protection covers for the
phase and neutral terminals (IMAGE 8). Ensure the orientation of the
covers (IMAGE 9).
Step 10
Put back the cover panel of the home distribution box to cover the elec-
trical contacts. Be sure that no electrical contact can be touched.
Step 11
Power on the system by enabling power in the electrical panel.
Step 12
To finalize the installation, all tiko devices must be configured using the
installation app.
Operation
Device Operation
The operation of the K-Box is subject to the control of the full system and operated by
the Data Center through the Gateway (M-Box). No user interaction is required.
On the front, there are two buttons, offering the following functionalities:
•Link –not used anymore (no function assigned)
•Heating Powered
oLong press (10 s) –reset device
LED Explanation
On the front, there are two green LEDs indicating
•Link –on if connected via Gateway (M-Box) to backend
•Second LED –status of opto-coupler. Behavior is custom and subject to project
specifications.

K-Box A7 User's Manual English 7 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Uninstalling
Step 1
Remove power from the electrical panel.
Step 2
Verify that there is no tension on the K-Box clamps.
Step 3
Remove the cover panel. Unwire and remove the device.
Step 4
Put the cover panel back. Ensure that no electrical contact can be
touched.
Step 5
Power on the system.
Step 6
The device remains property of tiko Energy Solutions AG or its
authorized reseller. It must be returned. The ultimate dis-
posal of a broken device shall be handled according to na-
tional laws and regulations.

K-Box A7 User's Manual English 8 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Specifications
Device Characteristics
Product Number
01.9007
Input / Output Voltage
3 x 230/400 VAC
Input / Output Current
max. 65 A
Input / Output Wire Specification
2.5 mm² –25 mm2(AWG 4 ~ 14)
Opto-coupler max. Current
30 mA
Opto-coupler max. Voltage
30 V
Opto-coupler Wire Specifications
0.14 mm² –4.0 mm² (AWG 12 ~ 26)
Frequency
50 Hz
Voltage of breaker before K-Box
max. 420 V (3 phases)
Current of breaker before K-Box
max. 65 A
Min. Measurable Current
± 0.1 A
Max. Measurable Current
± 65 A
Measurement Tolerance
± 1% @ 1 A –65 A
Dimensions
106 x 92 x 70 mm
Weight
430 g
Max. Power Consumption
less than 1.5 W
Operating Conditions
Storage Conditions
Temperature (min.)
-10 °C
-20 °C
Temperature (max.)
+55 °C
+70 °C
Relative Humidity
10% - 85%
no condensation
5% - 95%
no condensation

K-Box A7 User's Manual English 9 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Declaration of Conformity
Intended Use
The K-Box is a custom three-phase energy meter with remotely controlled opto-coupler
to be only used in tiko Energy Solutions AG authorized setups. The output of the opto-
coupler shall be connected to a receiving unit able to decode the K-Box-A7 signaling.
Safety Information
tiko Energy Solutions AG
Solothurnerstrasse 19
4600 Olten (CH)
IM-0005-0004 Revision 3
Declaration of Conformity
Hereby tiko Energy Solutions AG declares that the product 01.9007 in the form as deliv-
ered conforms to the provisions of the following European directives: 2011/65/EU on
hazardous substances, 2014/35/EU on low voltage devices, 2014/30/EU on electromag-
netic compatibility, partially 2004/22/EU on measuring instruments.
Position: CEO Position: CQO
Name: Frederic Gastaldo Name: Benjamin Sawicki
Date: 2019-12-12 Date: 2019-12-12
The full declaration of conformity is available on http://um.tiko.energy/9007

K-Box A7 Benutzerhandbuch Deutsch 10 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Sicherheitshinweise und Arbeitsanweisungen
Gefahrenrisiko
Lesen Sie das Benutzerhandbuch, bevor Sie dieses Gerät installieren und bedie-
nen!
Installation ausschliesslich durch Person mit Sachkenntnis in Elektronik und auf
diesem Produkt geschult!
Trennen Sie alle Energiequellen vor der Bedienung dieses Geräts!
Benützen Sie immer angemessene Schutzkleidung!
Gefahr! Hochspannung!
Niemals lose Kabel berühren! Lebensgefahr!
Ausschliesslich für Gebrauch mit Strom/Spannung wie auf dem Geräteetikett an-
gegeben! Anderenfalls ist eine Beschädigung des Gerätes und damit ein Strom-
schlag oder eine Brandgefahr möglich!
Nicht genügend angezogene Schrauben von Klemmen verursachen einen hohen
Kontaktwiderstand, welcher zu Überhitzung und Brandgefahr führen kann!
Nicht richtig verbundener Neutralleiter beschädigt das Gerät und stellt ein Sicher-
heitsrisiko dar!
Warnungen
•Lesen Sie die Installationsanweisungen, bevor Sie dieses Gerät an eine Stromquelle
anschliessen.
•Um das System vor Überhitzung zu schützen, betreiben Sie es nicht in einer Umge-
bung, welche die Temperatur von 55°C übersteigt.
•Dieses Produkt ist auf das Vorhandensein eines Kurzschlussschutzes im Gebäude
angewiesen. Stellen Sie sicher, dass alle stromführenden Leiter durch eine Sicherung
oder einen Leistungsschalter nicht grösser als 230 VAC, 65 A geschützt sind.
•Der Leistungsschalter muss sich vor und nahe dem Gerät befinden, gut zugänglich
sein und markiert werden als Trennschalter für dieses Gerät.
•Führen Sie keinesfalls Arbeiten am System oder an den Kabeln durch während eines
Gewitters.
•Gerät nur für den Innengebrauch.
•Endgültige Entsorgung dieses Geräts muss gemäss nationalen Gesetzen und Vor-
schriften erfolgen.

K-Box A7 Benutzerhandbuch Deutsch 11 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
•Jedweder Gebrauch dieses Geräts, welcher nicht dem Benutzerhandbuch entspricht,
kann den vorhandenen Schutz beeinträchtigen.
Sicherheitshinweise
Lesen Sie diese Sicherheitshinweise sorgfältig durch.
•Befolgen Sie gängige Sicherheitsregeln im Haushalt.
•Lesen Sie alle Hinweise und Warnungen auf dem Gerät.
•Setzen Sie den Elektroverteilkasten keinesfalls unter Strom, bevor Sie nicht die Ab-
deckungen abgebracht haben, sodass kein stromführender Kontakt berührt werden
kann.
•Entfernen Sie das Gerät aus dem Verteilschrank, bevor Sie es reinigen. Benutzen Sie
kein flüssiges oder gespraytes Reinigungsmittel. Benützen Sie ein feuchtes Tuch oder
Stück Stoff zur Reinigung.
•Die Öffnungen im Gehäuse dienen der Luftzirkulation und schützen das Gerät vor
Überhitzung. Blockieren Sie nicht die Öffnungen.
•Leeren Sie keine Flüssigkeit in eine der Öffnungen. Dies kann zu einem Brand oder
Elektroschock führen.
•Öffnen Sie weder das Gehäuse dieses Gerätes noch modifizieren Sie es auf irgend-
eine Weise.
•Lassen Sie das Gerät bei einem professionellen Service-Techniker überprüfen, sollte
eine der folgenden Bedingungen auftreten:
oDie Leitung ist beschädigt.
oFlüssigkeit ist ins Gerät eingedrungen.
oDas Gerät wurde Feuchtigkeit ausgesetzt.
oDas Gerät funktioniert nicht einwandfrei, oder es lässt sich nicht wie im
Benutzerhandbuch beschrieben betreiben.
oDas Gerät wurde fallengelassen oder beschädigt.
oDas Gerät weist sichtbare Spuren von Beschädigung auf.
•Halten Sie dieses Gerät von übermässiger oder kondensierender Feuchtigkeit fern.
•Setzen Sie dieses Gerät nicht einer unkontrollierten Umgebung aus. Temperaturen
über 55°C werden das Gerät beschädigen.
•Bewahren Sie dieses Dokument für den späteren Gebrauch auf.
Rückmeldungen
Ebenfalls können Sie uns Bemerkungen auf dem regulären Postweg senden, indem Sie an
diese Anschrift schreiben:
tiko Energy Solutions AG
Alte Tiefenaustrasse 6
CH-4600 Bern
Wir freuen uns über Ihre Rückmeldung.

K-Box A7 Benutzerhandbuch Deutsch 12 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Übersicht
Verwendungszweck
Die K-Box ist ein Energiemesser mit ferngesteuertem Optokoppler zur ausschliesslichen
Verwendung in durch tiko Energy Solutions AG genehmigten Installationen. Der Ausgang
des Optokopplers ist mit einem Empfängergerät zu verbinden, welches die K-Box A7-
Signale entsprechend dekodiert.
Jegliche Installation oder Verwendung, welche nicht den Richtlinien von tiko Energy Solu-
tions AG entspricht, ist strikte verboten. tiko Energy Solutions AG ist nicht verantwortlich
für unsachgemässe(n) Installationen oder Gebrauch dieses Geräts.
Merkmale
Merkmale der K-Box:
•misst den momentanen Energieverbrauch auf 3 Phasen und mit Vorzeichen
(verbraucht oder generiert)
•Ferngesteuerter Optokoppler, um Steuersignale an ein angeschlossenes Gerät
zu senden
•LEDs zur Anzeige des Verbindungs- und des Optokoppler-Status
Packungsinhalt
Öffnen Sie die Verpackung und überprüfen Sie, ob folgende Artikel vorhanden sind:
•Gebrauchsanweisung
•K-Box
Sollten Artikel fehlen, falsch sein oder Beschädigungen aufweisen, kontaktieren Sie bitte
den Händler, bei dem Sie Ihren Kauf getätigt haben. Behalten Sie die Kartonschachtel
einschliesslich der Originalverpackung für den Fall, dass Sie das Gerät zur Reparatur ein-
senden müssen.
Gerät
BILD 1 zeigt das Gerät von der Vorderseite. BILD 2 zeigt das Gerät von unten und kenn-
zeichnet die Klemmen für die Phasenleiter sowie den Neutralleiter.
Auf der Unterseite befindet sich eine Etikette mit den folgenden Informationen:
•Hersteller
•Geräte-Modellnummer (REF) und Betriebsleistung
•Hardware- (HW) und Firmwareversion (FW)
•Eindeutige Seriennummer (MAC-Adresse) als Text und Strichcode (SN/MAC)

K-Box A7 Benutzerhandbuch Deutsch 13 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Installation
Installation ausschliesslich durch Person mit Sachkenntnis in Elektronik
und auf diesem Produkt geschult!
Gerät nicht installieren, solange nicht die Hauptstromversorgung ab-ge-
schaltet ist (Hauptschalter oder Sicherung)!
Installation der K-Box
Schritt 1
Schalten Sie im Verteilkasten den Strom ab.
Schritt 2
Entfernen Sie die Abdeckungen, um Zugang zu den Kabeln zu haben.
Schritt 3
Stellen Sie sicher, dass sich keine Spannung auf den zu manipulierenden
Kabeln befindet.
Schritt 4
Stellen Sie sicher, dass sich ein Kurzschlussschutz für 3 Phasen (Schal-
ter oder Sicherung) nicht grösser als 420 VAC 65 A vor der K-Box be-
findet.
Schritt 5
Klemmen Sie die K-Box auf die Hutschiene im Verteilkasten und stellen
Sie sicher, dass der Verschluss eingerastet ist (BILD 3).
Entfernen Sie die Schutzabdeckungen von den Schraubklemmen (BILD
4).
Schritt 6
Bereiten Sie die Kabel vor. Erlaubte Kabelquerschnitte sind unter Tech-
nische Daten auf Seite 17 aufgeführt.
Schritt 7
Schliessen Sie die Kabel in den Klemmen der K-Box an (BILD 6):
•Von links nach rechts: verbinden Sie Phase 1, Phase 2, Phase
3, Neutralleiter
•Kabel in die oberen Klemmen stammen aus der Stromquelle
•Kabel in den unteren Klemmen führen zur Last
Ziehen Sie nun nochmals alle Klemmen mit genügend Dreh-
moment an. Ungenügende Klemmkraft resultiert in hohem
Kontaktwiderstand, welcher zu Überhitzung und Entzün-
dung führen kann!

K-Box A7 Benutzerhandbuch Deutsch 14 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Schritt 8
Verbinden Sie die Klemmen des Optokopplers, damit die K-Box co-
dierte Signale an das Zielgerät senden kann. Heben Sie hierzu die Ab-
deckung der Klemmen an (BILD 5). Verbinden Sie die Kontakte wie in
BILD 7 dargestellt:
•OUT –Emitter (mit dem Signalempfänger zu verbinden)
•(Mitte) –nicht verwendet
•IN –Kollektor (mit +24 V zu verbinden)
Schritt 9
Schliessen Sie die Abdeckung des Optokopplers. Bringen Sie die Abde-
ckungen der Klemmen für die Phasen und den Neutralleiter wieder an
(BILD 8). Beachten Sie die Orientierung der Abdeckungen (BILD 9).
Schritt 10
Bringen Sie die Abdeckungen im Verteilkasten wieder an, um die Kon-
takte zu bedecken. Stellen Sie sicher, dass kein elektrischer Kontakt
berührt werden kann!
Schritt 11
Schalten Sie das System ein, indem Sie im Verteilkasten den Strom wie-
der einschalten.
Schritt 12
Um die Installation abzuschliessen, müssen alle tiko-Geräte mittels der
Installations-App konfiguriert werden.

K-Box A7 Benutzerhandbuch Deutsch 15 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Betrieb
Betrieb des Geräts
Der Betrieb der K-Box wird vom Gesamtsystem kontrolliert und via das Gateway (M-Box)
von Datacenter gesteuert. Es ist kein Eingriff des Benutzers nötig.
Auf der Vorderseite befinden sich zwei Tasten mit den folgenden Funktionen:
•Link –nicht mehr in Gebrauch (keine Funktion zugeordnet)
•Heating Powered
oLanges Drücken (10 s) –Gerät zurücksetzen
LED-Legende
Auf der Vorderseite zeigen zwei grüne LEDs folgende Informationen an:
•Link –mit Backend verbunden via Gateway (M-Box)
•Zweites LED –Optokoppler-Status. Verhalten ist benutzerdefiniert und von den
Projektspezifikationen abhängig.

K-Box A7 Benutzerhandbuch Deutsch 16 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Deinstallation
Schritt 1
Schalten Sie im Verteilkasten den Strom ab.
Schritt 2
Stellen Sie sicher, dass auf keiner Klemme der K-Box Spannung vorliegt.
Schritt 3
Entfernen Sie die Abdeckungen, um Zugang zu den Kabeln zu haben.
Lösen Sie die Kabel und entfernen Sie das Gerät.
Schritt 4
Bringen Sie die Abdeckungen im Verteilkasten wieder an, um die Kon-
takte zu bedecken. Stellen Sie sicher, dass kein elektrischer Kontakt be-
rührt werden kann!
Schritt 5
Schalten Sie das System ein.
Schritt 6
Das Gerät bleibt Eigentum der tiko Energy Solutions AG oder
des autorisierten Händlers und muss zurückgegeben wer-
den. Die Entsorgung eines defekten Gerätes muss in Über-
einstimmung mit den nationalen Gesetzen und Vorschriften
erfolgen.

K-Box A7 Benutzerhandbuch Deutsch 17 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Technische Daten
Gerätespezifikationen
Artikelnummer
01.9007
Eingangs- / Ausgangsspannung
3 x 230/400 VAC
Eingangs- / Ausgangsstrom
max. 65 A
Eingang / Ausgang Kabelquerschnitt
2.5 mm² –25 mm2(AWG 4 ~ 14)
Optokoppler max. Strom
30 mA
Optokoppler max. Spannung
30 V
Optokoppler Kabelquerschnitt
0.14 mm² –4.0 mm² (AWG 12 ~ 26)
Netzfrequenz
50 Hz
Spannung Schutzschalter vor K-Box
max. 420 V (3 Phasen)
Strom Schutzschalter vor K-Box
max. 65 A
Kleinster messbarer Strom
± 0.1 A
Grösster messbarer Strom
± 65 A
Messgenauigkeit
± 1% @ 1 A –65 A
Abmessungen
106 x 92 x 70 mm
Gewicht
430 g
Maximaler Eigenverbrauch
weniger als 1.5 W
Betriebsbedingungen
Lagerbedingungen
Temperatur (min.)
-10 °C
-20 °C
Temperatur (max.)
+55 °C
+70 °C
Relative Luftfeuchtigkeit
10% - 85%
kein Kondensieren
5% - 95%
kein Kondensieren

K-Box A7 Benutzerhandbuch Deutsch 18 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Konformitätserklärung
Verwendungszweck
Die K-Box ist ein Dreiphasen-Energiemeter mit ferngesteuertem Optokoppler zur aus-
schliesslichen Verwendung in durch tiko Energy Solutions AG genehmigten Installationen.
Der Ausgang des Optokopplers ist mit einem Empfängergerät zu verbinden, welches die
K-Box A7-Signale entsprechend dekodiert.
Sicherheitshinweise
tiko Energy Solutions AG
Solothurnerstrasse 19
4600 Olten (CH)
IM-0005-0004 Revision 3
Konformitätserklärung
Hiermit erklärt die tiko Energy Solutions AG, dass das Produkt 01.9007 im Lieferzustand
den Vorschriften der folgenden europäischen Richtlinien entspricht: 2011/65/EU zu ge-
fährlichen Substanzen, 2014/35/EU zu Niederspannungsgeräten, 2014/30/EU zu elekt-
romagnetischer Verträglichkeit, teilweise 2004/22/EU zu Messgeräten.
Position: CEO Position: CQO
Name: Frederic Gastaldo Name: Benjamin Sawicki
Datum: 2019-12-12 Datum: 2019-12-12
Eine detaillierte Konformitätserklärung steht zur Verfügung unter
http://um.tiko.energy/9007

K-Box A7 Mode d’emploi Français 19 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
Avertissements de sécurité et instructions d’utilisation
Catégories de risque
Lisez le manuel d’utilisation avant d’installer et d’utiliser ce produit !
Installation uniquement par une personne possédant une expertise en électro-
nique et formée à ce produit !
Débranchez toutes les sources d’alimentation avant d’effectuer toute manipu-
lation !
Utilisez toujours un équipement de protection approprié !
Danger ! Haute tension !
Ne touchez jamais les fils déconnectés ! Danger de mort !
Utilisez uniquement avec le courant ou la tension indiqué sur l’étiquette de
l’appareil ! Cela pourrait endommager l’appareil et présenter un risque de dé-
charge électrique ou d’incendie !
Des vis mal serrées peuvent provoquer une résistance de contact élevée, une
surchauffe et un risque d’incendie !
Si vous ne connectez pas correctement le neutre, vous risquez d’endommager
l’appareil et de poser des problèmes de sécurité !
Avertissements
•Lisez les instructions d’installation avant de connecter le système à sa source d’ali-
mentation.
•Pour éviter toute surchauffe du système, ne le faites pas fonctionner dans une zone
dépassant la température ambiante maximale autorisée de 55°C.
•Ce produit dépend de l’installation du bâtiment pour la protection contre les courts-
circuits (surtension). Assurez-vous qu’un fusible ou un disjoncteur ne dépassant pas
230 VCA, 65 A est utilisé sur tous les conducteurs de courant.
•Le disjoncteur doit être à l’avant, à proximité de l’appareil, facilement accessible par
l’opérateur, et doit être marqué comme disjoncteur de déconnexion de l’appareil.

K-Box A7 Mode d’emploi Français 20 / 44
tiko Energy Solutions AG IM-0005-0004 Rev. 3
•Ne travaillez pas sur le système et ne connectez pas ou ne débranchez pas les câbles
lorsqu'il y a de l’orage.
•L’appareil est destiné à être utilisé à l’intérieur uniquement.
•L’élimination finale de ce produit doit être effectuée conformément à toutes les lois
et réglementations nationales.
•Toute utilisation de cet appareil d’une manière non conforme aux instructions de ce
manuel peut compromettre la sécurité assurée.
Consignes de sécurité
Lisez attentivement ces instructions.
•Suivez les pratiques de sécurité courantes en matière d'électricité domestique.
•Lisez toutes les mises en garde et avertissements sur l’équipement.
•Ne mettez pas le panneau électrique sous tension avant de remettre le couvercle du
boîtier de distribution domestique. Aucun contact direct ne doit être accessible.
•Déconnectez cet équipement de la prise de courant avant de le nettoyer. N’utilisez
pas de détergent liquide ou pulvérisé pour le nettoyage. Utilisez un chiffon humide
pour le nettoyage.
•Les ouvertures sur le boîtier sont destinées à la convection de l’air et protègent l’équi-
pement contre la surchauffe. Ne couvrez pas les ouvertures.
•Ne versez pas de liquide dans l’ouverture. Cela pourrait provoquer un incendie ou
une décharge électrique.
•N’ouvrez pas le boîtier de ce produit et / ou n'apportez aucune modification à ce
produit.
•Faites vérifier l’équipement par un professionnel si l’une des situations suivantes se
présente :
oLa ligne est endommagée.
oDu liquide est entré dans l’équipement.
oL’équipement a été exposé à l’humidité.
oL’équipement ne fonctionne pas correctement ou vous ne pouvez pas le
faire fonctionner conformément au manuel d’utilisation.
oL’équipement est tombé ou a été endommagé.
oL’équipement présente des signes évidents de casse.
•Maintenez cet équipement à l’écart de l’humidité excessive ou de la condensation.
•Ne laissez pas cet équipement dans un environnement inapproprié. Des tempéra-
tures supérieures à 55 °C endommageront l’équipement.
•Conservez ce guide pour référence ultérieure.
Commentaires
ment envoyer vos commentaires par courrier postal en écrivant à l’adresse suivante :
tiko Energy Solutions AG
Alte Tiefenaustrasse 6
CH-4600 Bern
Nous apprécions vos commentaires.
Table of contents
Languages:
Other tiko Energy Solutions Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands

Integrated control
Integrated control CCP+ user guide

Jain Technology
Jain Technology XONIC-100P user manual

KROHNE
KROHNE OPTIFLUX 400 Series Supplementary instructions

Endress+Hauser
Endress+Hauser LT5 Brief operating instructions

Trotec
Trotec TA400 quick start guide

finder
finder 7M.38.8.400.0112 user manual
