Titanium TML-3DRS User manual

Product Code: 88660 REVISION 2020.1.0
Instruction Manual
TML-3DRS Standard Kit
RED MULTI-LINE LASER

2

3
INCHES CM
1
1
2
3
4
5
6
7
2
3
1 Titanium TML-3DRS
2 Magnetic mount
3 Laser glasses
4 Laser target
5 Carry case
6 Indoor charger
7 Charging adaptor
8 Li-ion battery pack
9 Adaptor head (UK)
10 Adaptor head (EU)
2
8
7
3
4
6
1
EN
SAFETY
ITEM CHECKLIST
Read the following safety instructions before
attempting to operate this tool.
Keep these instructions in a safe place or store
in the carry case for future reference.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE.
WARNING!
Read and understand all instructions.
• Use the tool only with the specifically
designated batteries.
• Store the tool out of reach of children and other
untrained persons. Laser tools are dangerous in
the hands of untrained users.
• Use only accessories that are recommended
for your model.
• Tool service must be performed only by qualified
repair personnel. Repairs, service or maintenance
performed by unqualified personnel will void the
warranty. Only approved and authorised service
technicians can carry out warranty repairs.
• Do not use optical tools such as a telescope or transit
to view the laser beam. Serious eye injury could result.
• Do not place the tool in a position which may cause
anyone to intentionally or unintentionally stare into
the laser beam. Serious eye injury could result.
• Do not position the tool near a reflective surface
which may reflect the laser beam toward anyone’s
eyes. Serious eye injury could result.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the laser
beam can cross any person at head height.
• Do not let children come in contact with the tool.
• Turn the tool off when it is not in use. Leaving the tool
on increases the risk of staring into the laser beam.
• Do not operate the tool around children or allow children
to operate the laser. Serious eye injury may result.
• Position the tool securely on a level surface. Damage
to the tool or serious injury could result if the tool falls.
• Do not remove or deface warning labels.
• If the text on the warning label is not in your native
language, cover it with the appropriate label supplied
before commencing operation of the laser.
WARNING!
Do Not Disassemble The Laser.
There are no user serviceable parts inside. Disassembling
the tool will void all warranties on the product. Do not
modify the product in any way. Modifying the tool may
result in hazardous laser radiation exposure.
CAUTION!
Class 2 Laser Product
• Never look into the laser beam directly and intentionally.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the laser beam
can cross any person at head height.
• Do not let children come in contact with the laser.
!
!
!
5
9
10

Fig. 1
Fig. 2
Fig. 3
4
1 Laser port
2Bubble vial
3Control panel
4 Power / locking switch
5Locked position (power off) /
Tilt lock function (manual levelling)
6Unlocked position
(power on / self levelling)
7Battery door cover
POWER SUPPLY
• The laser level is supplied with a li-ion battery
pack as its power source.
Charging the li-ion battery pack
• Attached the adaptor head into the charging adaptor and
plug into a power source.
• Insert the charger into the charging adaptor. Connect the
li-ion battery onto the charging adaptor (Fig.1 & Fig.2).
• Progress will be shown by the power indicator
display on the charging adaptor as below:
Red (flashing) = Charger and battery
are not connected.
Red (constant) = Battery is charging
Green (constant) = Battery is charged
• Charging time is approximately 3-4 hours
for a depleted battery.
Inserting & removing the li-ion battery pack
1
23
4
67
89
10
12 13
11
1
5
8 1/4” tripod thread
9 5/8” x 11 tripod thread
10 Line mode
11 Pulse mode
12 Power indicator
13 Pulse mode indicator
EN LASER OVERVIEW
USING THE LASER
• Open the battery cover door and insert the battery tray
(Fig.3).
• Insert the li-ion battery pack and close the battery door.

Fig. 4
Fig. 5
5
MAGNETIC MOUNT OVERVIEW
USING THE
MAGNETIC MOUNT
1 Magnets
2Screw fixing point
3 1/4” thread
4 1/4” thread thumb screw
5 5/8” x 11 tripod thread
Mounting onto a magnetic surface
• Attach the laser level to the mount using the thumb screw.
• Attach the mount to a metal surface, ensuring that the
mount has a strong hold before releasing your hands.
• To rotate the laser level on the mount, loosen the thumb
screw, position the laser level, and then
re-tighten the thumb screw.
Mounting via screw fixing points
• Attach the laser level to the mount using the
thumb screw (Fig. 5).
• Fix a screw into a secure surface and hook the mount
over the screw. Ensuring that the mount has a strong
hold before releasing your hands.
• To rotate the laser level on the mount, loosen the thumb
screw, position the laser level, and then re-tighten the
thumb screw.
1
2
3
EN
MAGNETIC MOUNT
54
i
i
SETUP
•
Select a place as close as practical to the
work site. Ensure the location is clear of traffic.
• Place the laser on a level surface such as
a bench or mount.
OPERATION
Powering on (self-levelling)
• To turn the laser level on, slide the power / locking
switch to the “unlocked” position. Self levelling will
commence and the horizontal beam will activate (Fig. 4).
• Press the line mode button on the control panel to cycle
through the active beams.
• If the laser level is outside the self levelling range the
laser level will not level causing the laser beam to flash on
and off repeatedly. If this occurs, reposition the laser level
onto a level surface until the laser level can level off.
In bright outdoor conditions, visible distance will
besignicantlyreduced.Foroutdooruse,itis
recommended to purchase the optional TML-D3H
hybrid detector.
Powering off (self-levelling)
• To turn the laser level off, slide the power / locking
switch to the “locked” position.
Tilt lock function (manual mode)
• Ensure the power / locking switch is in the
“locked” position.
• Press and hold the line mode button for 3 seconds.
The horizontal line will activate.
• The laser level can now be tilted to the desired angle.
• Press the line mode button on the control panel to cycle
through the active beams.
• To turn off the beams, press the line mode button until
all beams are off.
When in tilt lock function (manual mode) the
laser level will not self level and correct for
vibrations and/or disturbances.
USING THE LASER (continued)

Fig. 6
Fig. 7
5
4
2
63
8
7
1
1
6
EN
• Press the pulse mode button on the top of the laser level
to enter into pulse mode. The pulse mode indicator LED
will light up.
• Switch the detector on by pressing the power button.
The speaker will beep indicating the detector is
operating.
• Move the detector into the path of the laser beam.
• Hold the detector upright for horizontal beams (Fig. 6).
Rotate the detector 90° for vertical beams (Fig. 7).
• The LED direction indicators will indicate the position of
the laser beam. The centre LED will indicate alignment
with the beam.
USING THE DETECTOR
MOUNTING TO A TRIPOD
The Titanium TML-D3H (89110) detector
and clamp can be purchased from your
nearest Titanium dealer.
A tripod can be purchased from your nearest
measurement tool dealer. The below instructions are
generic only and set-up methods may vary between
models. Refer to the documentation from the tripod
manufacturer for details.
i
i
DETECTOR OVERVIEW
DETECTOR OPERATION
1 Bubble vial
2LED direction indicators
3Power button
4Power LED indicator
5 Sound on / off button
6 Sound LED indicator
7 Laser sensor
8Speaker
NOT INCLUDED
NOT INCLUDED
!
WARNING! Attaching the laser to a
tripod without the correct thread size
may cause damage.
• Extend the tripod legs to the required height and
ensure the legs are spread wide enough so that
the tripod platform is stable. Secure the legs in
place (refer to the documentation from the tripod
manufacturer for details).
• Place the laser level onto the tripod and mount via
the male thread (5/8” or 1/4”) into the base until firm.
Do not over tighten as this may cause damage to
the laser level or tripod.
NOTE: adjustment methods will vary on tripod models.
Always ensure that any locking levers are unlocked
before making adjustments and returned to the locked
position when the adjustment is complete.
• If using an elevating tripod with a measuring scale on the
centre column, the height can be adjusted as required.

7
WARRANTY
All Titanium measurement tools are carefully checked
and tested to our precise quality assurance standards.
We offer a warranty in accordance with
the following conditions:
1. Our warranty provides the correction of deficiencies
to the tool once verified by an authorised
service centre that the deficiencies were caused
by a manufacturing fault within the warranty period.
2. The standard warranty period is 3 years from
the date of purchase. The warranty period can be
extended to 7 years upon registration of the tool
within 30 days of purchase.
3. The warranty does not cover:
a) Calibrations and components that are subject
to wear and tear.
b) Defects in the tool caused by non-compliance with
the operation instructions, improper use, abnormal
environmental conditions, inappropriate operating
conditions or insufficient maintenance.
c) Defects caused by using accessories or spare
parts other than approved parts.
d) Services or repairs carried out by
non-authorised persons.
4. Defects recognised by an authorised service centre as
being covered by the warranty shall be corrected either
by repair or replacement of the tool.
5. The warranty claim must be lodged within the warranty
period. This requires the complete tool with the original
sales receipt containing the purchase date and place
of purchase. Partial or disassembled tools cannot be
submitted for a warranty claim.
6. Services provided under warranty do not
lengthen or renew the warranty of the tool.
The above guarantees apply to tools that are
purchased in the countries and regions specified
online at www.titaniumlaser.tools
3 YEAR STANDARD WARRANTY PERIOD
1. The warranty period for your tool is 3 years from the date
of purchase.
2. The warranty period for batteries, battery packs and
chargers is 1 year from the date of purchase.
3. Calibrations are not covered under warranty as they are
deemed wear and tear.
4. All products have a standard warranty period, you do
not have to register your products to obtain the standard
warranty period.
5. To claim under this warranty, the date of purchase of the
tool must be documented by an invoice/receipt.
CARE & MAINTENANCE
1. This is a precision measuring tool and should always be
handled with care and transported within the carry case
provided.
2. Always turn the laser level off when transporting
the laser level or moving around the job site.
3. Whenever possible, store the tool in a dry,
shady location.
4. When the tool is not in use or is being stored, it
is highly recommended to remove the batteries.
EN
5. Calibration of the tool is recommended: every
six months, if ongoing accurate levelling is required,
or an impact has occurred.
6. The operator should check the accuracy of the tool
before precision levelling is attempted. Failure to do
so may result in inaccurate measurements.
7. Clean the tool with a dry, soft cloth after
use in dusty, damp or wet conditions before storing.
8. Smudges and fingerprints may be removed
with a damp tissue or a soft, lint-free cloth.
7 YEAR EXTENDED WARRANTY PERIOD
1. The extended warranty is available on selected tools only.
2. You may extend the warranty period for your tool (laser
level, optical level or laser distance measurer) to 7 years
from the date of purchase. Accessories are excluded
from the warranty extension and remain at the 3 year
warranty period.
3. The warranty period for batteries, battery packs and
chargers is 1 year from the date of purchase.
4. Calibrations are not covered under warranty as they
are deemed wear and tear.
5. To obtain the extended warranty, the registration
process must be completed within 30 days from
the date of purchase.
6. Failure to register your product online and/or submission
of a valid invoice/receipt will void the warranty extension.
7. Please ensure ALL information submitted/uploaded
is correct.
Extended warranty is ONLY available via online
registration, offline (mailing in of warranty registration)
will not be accepted.
Visit www.titaniumlaser.tools to register.

8
EN
CUSTOMER SUPPORT
To assist you with any queries or technical
questions please contact customer support.
Australia: 1300 658 338
New Zealand: 0800 367 527
United Kingdom: 0808 189 1152
All other countries / regions:
Visit www.titaniumlaser.tools for more information
SPECIFICATIONS
Specications TML-3DRS
Product code 88560
Warranty 7 Years*
Accuracy ±1.5mm at 10m
(±1/10in / 0.06in at 30ft)
Operating range 60m / 190ft
(with included detector)
Levelling range ±4°
Laser class 2 Red
Battery life 10 hours+
Battery type Li-ion battery pack /
4x 1.5V AA
Vertical lines 2
Horizontal lines 1
IP rating 54
Weight (kg) 0.8
Dimensions (mm) 150 x 75 x 125
*With online registration (3 years without registration).
Please refer to page 7 for details.
TROUBLE SHOOTING
Error Cause & Solution
Laser does not turn on
• Check the batteries. They may be in the wrong way or need replacing.
• Check the battery compartment for signs of damage and ensure that the
compartment is clean and that the battery terminals are not bent.
Laser does not remain on
for long periods of use.
• Check the batteries. They may need replacing.
• Check the battery compartment for signs of damage and ensure that the
compartment is clean and that the battery terminals are not bent.
Laser does not level off
• Laser level may be outside its self levelling range and may require an adjustment
before self-levelling can commence.
• Laser level may have impact damage.
EU DIRECTIVES
AND DISPOSAL
This device complies with all necessary standards for the
free movement of goods within the EU. This product is an
electric device and must be collected separately for disposal
according to the European Directive on waste electrical and
electronic equipment.

9
EN
NOTES

10
NOTES
EN

11
EN
NOTES

© 2020. Titanium Laser Tools
