Toa EverAlert DYNAMIC View User manual

QUICKSTART GUIDE
in partnership with

QUICKSTART INSTRUCTIONS
2
PRE-INSTALLATION
1. Verify with your IT Staff:
• Dynamic Host Conguration Protocol (DHCP) is enabled.
Note: Currently, EverAlert Dynamic View does not support static IP address conguration on the Portal.
This would need to be manually done though the OS or using DHCP reservations.
• Firewall port 123 is open for UDP (User Datagram Protocol) transfer.
• Internet Connection is available with Wi-Fi or Ethernet 10/100Base-T
i. Additional information for Wi-Fi; SSID, Password & Security Type
2.Choose a location that is near an AC power receptacle.
3. Additional Components Required (not sold by TOA Canada)
•It is recommends using a Commercial Display with the following specifications.
i. 16x9 aspect ratio
ii. Recommended Display sizes - 43”, 55” & 65”. These sizes are optimized for the graphic
layouts that are provided.
iii. HDMI 2.0
• TV Mount
• High Quality HDMI Cable

QUICKSTART INSTRUCTIONS
3
UNPACKAGING
1. Remove the components from the box.
• Save the packing materials in case you need them later.
2. Check the contents
• EverAlert Dynamic View Box
i. EverAlert Dynamic View
ii. 12vdc Power Supply Brick with North American AC power cord
iii. Wi-Fi Antenna
ii.
iii.
i.

QUICKSTART INSTRUCTIONS
4
MOUNTING
1. Attach the Wi-Fi antenna and hand tighten to desired angle before mounting.

QUICKSTART INSTRUCTIONS
5
Locate the Dynamic View near the TV that will be used to display the content. Most installation
applications will mount the Dynamic View directly to the wall, hidden behind the TV.
The Dynamic View can also be placed on a shelf or stand if desired.
MOUNTING

QUICKSTART INSTRUCTIONS
6
2. If wall mounting, use a minimum of 2 screws to
securely mount the Dynamic View to the wall.
Note: Make sure that the HDMI & USB ports are in a position
that can be easily accessible for conguration later.
3. Connect HDMI cable to the TV and Dynamic View.
• Optional: If using wired ethernet instead of Wi-Fi,
connect CAT5 or better cable to ethernet port.
Note: There is not a power switch on Dynamic View. If the device is plugged in, it is on.
MOUNTING

QUICKSTART INSTRUCTIONS
7
PROVISIONING
Assigning an EverAlert Dynamic View to the TOAlert Management Portal
• There are two simple ways to provision Dynamic View to connect to the TOAlert management
portal.
i. Option 1 uses a wired LAN cable on a DHCP enabled network with internet access.
ii. Option 2 uses a USB key that is created from the management portal and contains the
encrypted credentials for connecting the device to your network and Site.
Note: Before continuing installation, it is assumed that the user has already received the welcome email
from TOA Canada and has login credentials to the portal.
1. If network settings have not been entered, login to www.toalert.ca
Note: If network settings have been entered, go to step 6, Conguration.

QUICKSTART INSTRUCTIONS
8
2. If you have more than one Site established, select the Site where you would like to install
the Dynamic View by clicking on its name in the list.
PROVISIONING

QUICKSTART INSTRUCTIONS
9
PROVISIONING
3. Click on Default Cong under Admin > EverAlert Congs.

QUICKSTART INSTRUCTIONS
10
4. Under Network Conguration select the CONNECTION TYPE (Wi-Fi or Ethernet) and make
sure the correct wireless credentials have been entered. If they have not been entered yet
and the intention is to use Wi-Fi network, enter them now.
PROVISIONING

QUICKSTART INSTRUCTIONS
11
5. Scroll down, and click “Save Only”.
Note: If Wi-Fi is preferred, it is OK to use a wired LAN option for initial conguration. A wired LAN will
override Wi-Fi if connected to a Dynamic View.
PROVISIONING

QUICKSTART INSTRUCTIONS
12
6. Conguration
OPTION 1 - Conguration using wired LAN on a DHCP Network
All Dynamic Views have been precongured to a specic Site using their MAC address.
i. Make sure the Ethernet cable is plugged into the Dynamic View.
ii. Go to Step 7
OPTION 2 - Conguration using USB Key
• Click “Create Key”on bottom left of the screen.
The encrypted le is now made and stored in the
downloads directory on your PC.
•Go to the downloads directory on your PC and copy the
SecurityKey.txt le to a USB ash drive.
Note: If this process has been done before on your PC, there
may be more than one security le in this directory with a
number sufx like SecurityKey2.txt. Be sure to identify the
correct le and rename it to SecurityKey.txt if it is numbered.
PROVISIONING

QUICKSTART INSTRUCTIONS
13
7. Power up the Dynamic View by plugging into an AC wall receptacle.
8. Apply power to the TV and ensure that the correct HDMI port (input/source) is congured in
the TV menu settings.
9. While the device is loading, the Dynamic View software will check its version and
automatically download a new version if required.
PROVISIONING

QUICKSTART INSTRUCTIONS
14
10. Once the software update has been loaded, the Dynamic View will ash to a provisioning
screen that says “Plug in your Security Key” or device address on the portal.
11. If using wired ethernet, skip to Step 13.
12. Insert USB ash drive into one of
the two USB ports on the side of the
Dynamic View. Once the key is read, the
screen will show “Security Key Found”
and update the Wi-Fi credentials on the
EverAlert Dynamic View and connect to
the Portal.
PROVISIONING

QUICKSTART INSTRUCTIONS
15
PROVISIONING
13. After the device has established a connection, “Setup Complete”, “Your clock app will
restart in a moment.” will appear on screen.
14. The Dynamic View will now load its predened default Clock Layout and is ready for use.
NOTE: If any image or text appears to be cutoff, the picture size or aspect ratio settings on the tv should be
set to auto.
This completes the QuickStart. If you have questions, call
800-263-7639 or visit www.toalert.net. Thank You.
