INSTRUCTIONMANUAL
SPEAKERSYSTEMS
F-1000WTWPEB-Q
F-1000BTWPEB-Q
F-1300WTWPEB-Q
F-1300BTWPEB-Q
F-2000WTWPEB-Q
F-2000BTWPEB-Q
ThankyouforpurchasingTOA'sSpeakerSystem.
Pleasecarefullyfollowtheinstructionsinthismanualtoensurelong,trouble-freeuseofyourequipment.
TraceabilityInformationforEurope(EMCdirective2004/108/EC)
Manufacturer:
TOACorporation
7-2-1,MinatojimaNakamachi,Chuo-ku,Kobe,Hyogo,
Japan
Authorizedrepresentative:
TOAElectronicsEuropeGmbH
Suederstrasse282,20537Hamburg,
Germany
EN54-24:2008
12
1438/CPD/0282
1438
1.SAFETYPRECAUTIONS ........................................ 2
2.GENERALDESCRIPTION
3.FEATURES
..............................................................3
4.IMPEDANCECHANGE ........................................ 3
5.WIRINGANDUSINGTERMINALCOVER
6.INSTALLATION
6.2.UsingtheSuppliedBrackets
6.2.1.Whenusingonly
.......................5
9.DIMENSIONALDIAGRAM
8.REPAINTINGTHESPEAKER
10.SPECIFICATIONS
TABLEOFCONTENTS
COVERANGEANGLE(F-2000seriesonly)
.............................. 11
thesuppliedbrackets
6.3.WallMounting
6.4.CeilingMounting
7.REDUCINGTHESPEAKER
...................................... 3
.........4
................................................ 5
............................................ 8
...... 10
.................................. 12
10.1.-10.3.Frequencyresponse
10.4.Specification
...................13
................................................ 14
6.1.Noteoninstallation ......................................4
6.2.2.Whenusingboththesuppliedand
..........5
optionalmountingbrackets

2
WhenInstallingtheUnit
•Installtheunitonlyinalocationthatcan
structurallysupporttheweightoftheunitandthe
mountingbracket.Doing otherwise mayresultin
theunitfallingdownandcausingpersonalinjury
and/orpropertydamage.
• Donotuseothermethodsthanspecifiedtomount
thebracket.Extremeforceisappliedtotheunit
andtheunitcouldfalloff,possiblyresultingin
personalinjuries.
•Usenutsandboltsthatareappropriateforthe
ceiling'sorwall'sstructureandcomposition.Failure
todosomaycausethespeakertofall,resultingin
materialdamageandpossiblepersonalinjury.
• Tighteneachnutandboltsecurely.Ensurethatthe
brackethasnoloosejointsafterinstallationto
prevent accidentsthatcouldresult inpersonal
injury.
•Donotmounttheunit inlocations exposed to
constantvibration.Themountingbracket can be
damagedbyexcessivevibration,potentially
causingtheunittofall,whichcouldresultin
personalinjury.
•Theunitiscertifiedforin-dooruse,donot
installitoutdoors.Ifinstalledoutdoors,theagingof
partscausestheunittofalloff,resultinginpersonal
injury.Also,whenitgetswetwithrain,thereisa
dangerofelectricshock.
• Donotuseanti-rustlubricant.Ifitcontactsresinor
rubberparts,theycoulddeteriorateandcausethe
unittofall,possiblyresultinginpersonalinjury.
•Donotinstalltheunitwhereitislikelytobe
corrodedin suchplaces as bath rooms,indoor
WhenInstallingtheUnit
•Neversettheimpedanceswitchtothe"330Ω"
Failure to follow this instruction could result in
damagetotheunitoramplifier.
•Avoidtouching theunit'ssharpmetaledge to
preventinjury.
• Toavoidelectricshocks,besuretoswitchoffthe
amplifier'spowerwhenconnectingspeakers.
WhentheUnitisinUse
• Donotplaceheavyobjectsontheunitasthismay
causeit to fallorbreakwhichmayresultin
personalinjuryand/orpropertydamage. In
addition,theobjectitselfmayfalloffandcause
injuryand/ordamage.
• Donotoperatetheunitforanextendedperiodof
timewiththesounddistorting.Thisisanindication
ofamalfunction,whichinturncancauseheatto
generateandresultinafire.
• Donotstandorsiton,norhangdownfromtheunit
asthismaycauseittofalldownordrop,resulting
inpersonalinjuryand/orpropertydamage.
•Havetheunitcheckedperiodicallybytheshop
fromwhereitwaspurchased.Failuretodosomay
resultincorrosionordamagetotheunitorits
mountingbracketthatcouldcausetheunittofall,
possiblycausingpersonalinjury.
1.SAFETYPRECAUTIONS
• Beforeinstallationor use,besureto carefullyreadallthe instructionsinthissection forcorrectandsafe
operation.
• Besuretofollowalltheprecautionaryinstructionsinthissection,whichcontainimportantwarningsand/or
cautionsregardingsafety.
• Afterreading,keepthismanualhandyforfuturereference.
SafetySymbolandMessageConventions
Safetysymbolsandmessagesdescribedbelowareusedinthismanualtopreventbodilyinjuryandproperty
damagewhichcouldresultfrommishandling.Beforeoperatingyourproduct,readthismanualfirstand
understandthesafetysymbolsandmessagessoyouarethoroughlyawareofthepotentialsafetyhazards.
100Vline.
pools,orseaside.Insuchlocationsthebracket
maybevulnerabletocorrosion,eventuallyallowing
thespeakertofallresultinginpersonalinjury.
Indicatesapotentiallyhazardoussituationwhich,
ifmishandled,couldresultindeathorserious
personalinjury.
WARNING
Indicatesapotentiallyhazardoussituationwhich,
ifmishandled,couldresultinmoderateorminor
personalinjury,and/orpropertydamage.
CAUTION
(F-1000series),"170Ω"(F-1300series)or"83Ω"
(F-2000series)positionwhenoperatingtheuniton

3
2.GENERALDESCRIPTION
Theswitchis
factory-presetto670Ω.
Theswitchis
factory-presetto330Ω.
Theswitchis
factory-presetto170Ω.
CAUTION
Neversetthisswitchtothe"330Ω"(F-1000series),"170Ω"(F-1300series)or"83Ω"(F-2000series)
positionwhenoperatingthespeakeron100Vline.
Failuretofollowthisinstructioncouldresultindamagetothespeakeroramplifier.
4.IMPEDANCECHANGE
Tochangetheimpedance,useastandardscrewdrivertorotatetherotaryswitchonthespeaker'srearto
selectthedesiredinputpower.
3.FEATURES
• Widedirectivityhigh-frequencyhorn.
• Suppliedbracketpermitsmountingtoawallandceiling.
• Combineduseofthesuppliedbracketandoptionalmountingbracketallowsthespeakerstobemountedin
clusters.
90ºhorizontalx90ºvertical(F-1000series)or110ºhorizontalx100ºvertical(F-1300andF-2000series).
•Impedancechangeavailablebyarotaryswitchlocatedinrearside.
•CertifiedtoEN54-24:2008.
Speakersarecompacttwo-wayspeakersystemsdesignedforhighefficiency,widerange,
andhighpowerinputhandlingcapability.Thesespeakersystemscanbeinstalledinamanneridealfor
thelocationandintendedapplication.ThespeakeriscertifiedtotheEuropeanStandardEN5424:2008.
[F-1000series] [F-1300series] [F-2000series]

Speakerunit
4
5.WIRINGANDUSINGTERMINALCOVER
Notes
• Forthespeakercable,useacablewithadiameterof6‒10mm,whichwillfitthecablebushing.
• Toensurewaterproofcapabilities,firmlymounttheterminalcovertothespeakerandtightenthebushingon
thecover.
Step1. Feedthespeakercablethroughthebushingandterminalcover,thenconnectthecabletotheinput
terminal.
Step2. Attachtheterminalcovertothespeaker.
Attachthecoverwhilepullingthecablesothatitisnotentangledinsidetheterminalcover.
Step3. Holdtheterminalcovertightlytothespeakerusingthesuppliedscrews.
Step4. Tightenthebushing.
Note
Aftertighteningthebushingbyhand,useatooltofurthertightenitanother90º(1/4-turn)orso.Note
thatpartscanbedamagedbyover-tightening.
[Imputterminalpolarity]
6.1.Noteoninstallation
• Besuretomountthespeakerinavertical(portrait-style)orientation.
• Adjustthespeaker'stiltanglewithintheshadedrangeshownbelow:
Terminalcover(accessory)
Bushing*
Speakercable
ø6‒ø10mm
Inputterminal
Tappingscrew4x12(accessory)
1
2
3
4
*ScrewedontotheTerminalcoveratthefactory.
30mm
10mm
[Strippedconductor]
Inputterminal
(‒)
BLACK
(+)
RED
6.INSTALLATION
[WallandCeiling:0ºhorizontalto45ºdownward]
Max.45°
Note
Mountthespeakersothatitsrear-mounted
terminalcoverispositionedontheupperside.
0º
(horizontal)
• Usethesuppliedterminalcoverwhenconnectingthespeakercable.
45º
0°
(horizontal)
Terminalcover

5
6.2.UsingtheSuppliedBrackets
Thespeakersystemissuppliedwiththefollowingbrackets.Usethese bracketsproperlydepending onthe
installationlocationandintendedapplication.
30º
[Wallbracket][Jointbracket][Speakerbracket]
6.2.1.Whenusingonlythesuppliedbrackets
Wall
Ceiling
Whenhorizontalandvertical
angleadjustabilityisdesired.
*Speakercoverageanglescanonlybeadjustedintheverticaldirection.
Whenclosewallsurface
mountingisdesired*.
Verticalspeakermounting*
P.5
P.7
P.8
Installation
Location tekcarbllaWnoitacilppA Jointbracket egaPtekcarbrekaepS
6.2.2.Whenusingboththesuppliedandoptionalmountingbrackets
Ceiling Suspendedspeaker P.9
Installation
Location tekcarbllaWnoitpOnoitacilppA Jointbracket egaPtekcarbrekaepS
clustermounting*3
1
*Speakercoverageanglescanonlybeadjustedintheverticaldirection.
*F-1000orF-1300series *F-2000series
3
2
HY-CL10B*or
1
HY-CL20B*2
Speakerangleofverticaldirection
F-1000series
ModelNo.
F-1300series
F-2000series
[Viewedfromtopofspeaker]
Max.45°
Note
Mountthespeakersothatitsrear-mounted
terminalcoverispositionedontheupperside.
0º
(horizontal)
6.3.WallMounting
Usethesuppliedwallbracket,jointbracket,andspeakerbrackettopermitadjustmentofthehorizontal
andverticalspeakercoverageangles.
Maximumrotationangleofhorizontaldirectioninverticalinstallation.
Whenadjustinghorizontalandverticalangles:
0º 7.5º 15º 22.5º 30º 37.5º 45º
±82º ±81º ±80º ±79º ±76º ±73º ±66º
±75º ±75º ±74º ±72º ±69º ±63º
±75º ±75º ±74º ±71º ±68º ±61º
±7º

30mm(F-1000orF-1300series)
45mm(F-2000series)
30mm(F-1000orF1300series)
45mm(F-2000series)
4-ø6mm
[Wallbracketmountingdimensions]
1
3
2
4
6
Speakerunit(rear)
Speakerbracket
[Verticalspeakerinstallation]
Speakerunit
Jointbracket
FixingboltM5x60(F-1000orF-1300series)orM6x85(F-2000series)
Wallbracket
HexagonboltM6x12
(withplainwasher
andspringwasher)
Verticalspeaker
mounting
[Installationexample]
UsethesuppliedmachinescrewM5x20(withplainwasherandspringwasher)
[F-1000series] [F-1300series] [F-2000series]
6

7
Step1. Mountthewallbrackettothewallsurface.
Matchtheorientationofthearrowlabelwiththehorizontaldirection(leftorright)thespeakerfaces.
Note: Hardwareusedformountingthewallbrackettothewallisnotsupplied.
Jointbracket
Wallbracket
•Arrowlabelorientation(Viewedfromtopofbrackets)
[Left-facingorientation] [Right-facingorientation]
Arrowlabel
Jointbracket
Wallbracket
Arrowlabel
Step2. Attachthejointbrackettothewallbracketusingthesuppliedscrews,adjustthehorizontalspeaker
angle,thentightenthescrews.
Note: Matchtheorientationofthearrowsonboththewallbracketandjointbracket.
Step3. Attachthespeakerbrackettothespeaker'srearusingthesuppliedscrews.
Note: Attachthespeakerbracketaccordingtothespeakermountingorientation.
Step4. Mountthespeaker tothejoint bracket by insertingthespeaker bracket intothejoint bracket and
looselysecuringthefixingboltfortemporaryspeakerinstallation.
Step5. Usethesuppliedterminalcoverwhenconnectingthespeakercabletotheinputterminal.
Step6. Adjustthespeaker'sverticalmountingangleandtightenthefixingbolt.
Thespeakerangleisadjustablein7.5ºsteps.
Note
Thematingsurfacesofthespeakerbracketandjointbracketaredesignedtointerlock.Ensurethat
bothpartsaresecurelyengagedwitheachotheraftermountingiscomplete.
[Changingtheorientationofthefrontpanellogo]
Thefrontpanellogoisaffixedtothemeshnetusingdouble-facedtape.Peeloffthelogocarefullyandreaffixit
intheproperorientation.
Useboththesuppliedjointbracketandspeakerbracket,andmountthejointbracketdirectlytoawall.After
mountingthejointbracket, follow theSteps 3 ‒ 6 above. In thisconfiguration,the speakercanonly be
adjustedintheverticaldirection*.
*Verticalinstallation:15º-37.5ºdownward(F-1000series),15º-30ºdownward(F-1300series),
0º-30ºdownward(F-2000series)
Note:Hardwareusedformountingthejointbrackettothewallisnotsupplied.
Mountingthespeakerclosetoawallsurface
6
Jointbracket
Fixingbolt
M5x60(F-1000orF-1300series)or
M6x85(F-2000series)
Speakerbracket
4-ø6mm
[Jointbracketmountingdimensions]
25mm(F-1000or
F-1300series)
45mm(F-2000series)
30mm(F-1000orF-1300series)
45mm(F-2000series)
[Installationexample]
Verticalspeaker
mounting
4
Speakerunit
Note:Refertop.4forwiringandusingterminalcover.

8
6.4.CeilingMounting
Usethesuppliedjointbracketandspeakerbracket.
Note
Speakercoverageanglescanonlybeadjustedintheverticaldirection(Max.45ºdownward).
Adjustthespeaker'stiltanglewithintheshadedrangeshownbelow:
Verticalorientation
[Installationexample]
a
45º
a0°
(horizontal)
4-ø6mm
[Jointbracketmountingdimensions]
ø10mm
25mm(F-1000or
F-1300series)
45mm(F-2000series)
30mm(F-1000orF-1300series)
45mm(F-2000series)
Step1. Mountthejointbrackettotheceilingsurface.
Note
Hardwareusedformountingthejointbracket
totheceilingisnotsupplied.
Step2. Attachthespeakerbrackettothespeaker'sbottom
usingthesuppliedscrews.
Machinescrew
M5x20(with
plainwasherand
springwasher)
1
35
2
Fixingbolt
M5x60(F-1000orF-2000series)or
M6x85(F-2000series)
Speakerunit
Frontpanellogo*
Jointbracket
Fixedmountingscrewhole
(4holes)
Anchorboltmountinghole
Speakerbracket
Ceilingboard
Anchorbolt
Jointbracket
Effectivelength
•Useanappropriateanchorboltforsupporting
thefullweightofthespeakerandforthesize
ofmountingholeinthejointbracket.
•Ensurethattheeffectivelengthoftheanchor
boltis20mmorless.
•Whenspeakerrotationcapabilityisnotdesired,
securewiththe4fixedmountingscrewholes.
Notes
Asholesealsar e
adheredovertheholes,
removethemusinga
pointe dtoolbefore
attachingthebracket.
*Changingtheorientationofthefrontpanellogo
Thefrontpanellogoisaffixedtothemeshnetusing
double-facedtape.Peeloffthelogocarefullyand
reaffixitintheproperorientation.
Terminalcover

9
Step3. Mountthespeaker tothejoint bracket by insertingthespeaker bracket intothejoint bracket and
looselysecuringthefixingboltfortemporaryspeakerinstallation.
Step4. Usethesuppliedterminalcoverwhenconnectingthespeakercabletotheinputterminal.
Step5. Adjustthespeaker'sverticalmountingangleandtightenthefixingbolt.
Thespeakerangleisadjustablein7.5ºsteps.
Note
Thematingsurfacesofthespeakerbracketandjointbracketaredesignedtointerlock.Ensurethat
bothpartsaresecurelyengagedwitheachotheraftermountingiscomplete.
Note:Refertop.4forwiringandusingterminalcover.
Usethesuppliedjointbracketsandspeakerbracketsincombination
withtheoptionalHY-CL10B(F-1000orF-1300series),
speakerstobesuspendedfromtheceilingasshowninthefigureat
right.
Refertotheinstructionmanualenclosedwiththeoptionalmounting
bracketforitsmountingdetails.
Clusterconfigurationassembly
HY-CL20B(F-2000series)ClusterBrackettopermitatotalof4
[Installationexample]

10
7.REDUCINGTHESPEAKERCOVERAGEANGLE(F-2000seriesonly)
Thespeaker'scoverageanglecanbereducedto80ºhorizontalx80ºverticalfromitsnormalrangeof110ºx
100ºbyattachingthesuppliedhornadaptertothespeaker'shornsection.
]retpadanrohhtiW[]retpadanrohtuohtiW[
latnozirohº08latnozirohº011
80°vertical
100°vertical
[Attachingthehornadapter]
Step1. Peeloffthelogocarefully,thenremovethescrewunderneathtodetachthemeshspeakergrill.
Step2. Attachthesuppliedhornadapterusingthesuppliedscrews.
Step3. Replacethemeshgrillandlogo.
Note
Becausethelogoisaffixedusingdouble-facedtape,peelitoffcarefully.
Note
Takecarenottotouchthe
speakerdiaphragmduring
attachment.
Logo
Meshspeakergrill
Countersunkhead
tappingscrew4x12
Tappingscrew4x12
Hornadapter
2
1,3

11
Step2. Wipecleanthemeshgrillandspeakercabinetwithasoftclothdampenedinadetergent.
Note
Donotusethinnerorothervolatileliquidstocleanthegrillandcabinet.
Step3. Usespraypainttoapplythincoatevenlyoverallthespeaker.
Notes
• Avoidpaintingwitharollerorbrush,asthegrillholescouldbecomecloggedwithpaint.
• Securelymasktheentirebafflesurfacebeforepainting.
• Useappropriatepaintsforthespeakergrillandcabinetmaterials.
Grill: Rolledsteelplate(acrylicpaint)
Cabinet: HIPSresin
Step4. Afterthepainthasdried,applyanotherlightcoat.
Note
RepeatingStep3,apply2ormorelightcoatsofpaint.
Applicationofonethickcoatofpaintallatoncemaycausedripsorunevennesstoshowupinthe
paintedfinish,orclogthemeshholes.
Step5. Afterthepainthasdried,replacethemeshgrillandlogo.
8.REPAINTINGTHESPEAKER
Followtheprocedurebelowwhenrepaintingthespeakergrillandcabinet.
Note:Takecarenottotouchthespeakerdiaphragmduringwork.
Step1. Peeloffthelogocarefully,thenremovethescrewunderneathtodetachthemeshspeakergrill.
[Detachingthemeshgrill]
Logo
Baffle(Maskingarea)
Countersunkhead
tappingscrew4x12
Meshspeakergrill
Note
Becausethelogoisaffixedusingdouble-facedtape,peelitoffcarefully.

12
9.DIMENSIONALDIAGRAM
Unit:mm
BA
30
30
15º
244(F-2000series)
162(F-1300series)
130(F-1000series)
373(F-2000series)
250(F-1300series)
202(F-1000series)
[Front]
[Top]
[Side]
2-M5mountingscrewhole
(Effectivescrewdepth:14mm)
2-M5mountingscrewhole
(Effectivescrewdepth:14mm)
[Bottom]
2-M5mountingscrewholes
Note
Holesealsareadheredovertheholes
atthefactory.
Beforeattachingthespeakermounting
[RearF-1000series]
235(F-2000series)
161(F-1300series)
131(F-1000series)
brackettothisside,removethem
usingapointedtool.
[RearF-1300series] [RearF-2000series]
4-M5mountingscrewhole
(Effectivescrewdepth:14mm)
6-M5mountingscrewhole
(Effectivescrewdepth:14mm)
B:30(F-1000orF-1300series)or
50(F-2000series)
A:28(F-1000series),38(F-1300series)or
48(F-2000series)
Note:Figuresareshownwithoutterminalcover.
30
30
76.2
50
76.2
50

13
10.SPECIFICATIONS
10.1.F-1000seriesFrequencyresponse
10.2.F-1300seriesFrequencyresponse
10.3.F-2000seriesFrequencyresponse
20 50 100 500 1k 5k 10k 20k
[Hz]
50
60
80
70
90
100
[dB]
FrequencyResponse(1W,4m)
20 50 100 500 1k 5k 10k 20k
[Hz]
50
60
80
70
90
100
[dB]
FrequencyResponse(1W,4m)
20 50 100 500 1k 5k 10k 20k
[Hz]
50
60
80
70
90
100
[dB]
FrequencyResponse(1W,4m)

14
10.4.SpecificationsforF-1000,F-1300andF-2000series
Standard
EnvironmentalType
Sensitivity
(at100Hzto10kHzpinknoise)
Max.SPL
FrequencyResponse
CoverageAngle(‒6dB)
OperatingTemperature
CableConnection
ApplicableCableSize
F-1000BTWPEB-Q
F-1000WTWPEB-Q
F-1300BTWPEB-Q
F-1300WTWPEB-Q
F-2000BTWPEB-Q
F-2000WTWPEB-Q
(100Vlineand70Vline)
30W 60W15W
TypeA(Indoorapplications)
RatedImpedance
92dB(1W,1m)90dB(1W,1m)87dB(1W,1m)
(at100Hzto10kHzpinknoise)
95dB(15W,1m),
83dB(15W,4m)
100dB(30W,1m),
88dB(30W,4m)
105dB(60W,1m),
93dB(60W,4m)
88dB(1W,1m),
76dB(1W,4m)
83dB(1W,1m),
71dB(1W,4m)
86dB(1W,1m),
74dB(1W,4m)
85Hz-20kHz 80Hz-20kHz 65Hz-20kHz
RatedNoisePower
andVoltage
Push-interminals
‒10ºCto+50ºC
ModelNo.
(atinstallationinasemianechoicfield)
CertifiedtotheEuropeanStandardEN54-24:2008
Loudspeakerforvoicealarmsystemsforfiredetectionandfirealarmsystems.
CertificationNo.1438/CPD/0282
Certifiedyear2012.
Conductor: 0.8‒2.5mm2(AWG18‒13)
Outerdiameter: ø6‒ø10mm
EnclosureType Bass-reflextype
SpeakerComponent Lowfrequency:
10cmcone-type
Highfrequency:
Balanceddome
tweeter
Lowfrequency:
13cmcone-type
Highfrequency:
25mmdome
tweeter
Lowfrequency:
20cmcone-type
Highfrequency:
25mmdome
tweeter
CrossoverFrequency 5kHz 2kHz 2.5kHz
100Vline:
2kΩ (5W),
3.3k (3W),Ω
670Ω (15W),
10k (1W)Ω
100Vline:
1kΩ (10W),
3.3k (3W),Ω
330Ω (30W),
10k (1W)Ω
100Vline:
330Ω (30W),
670 (15W),Ω
170Ω (60W),
3.3k (3W)Ω
70Vline:
670Ω (7.5W),
2k (2.5W),Ω
330Ω (15W),
3.3k (1.5W),Ω
10k (0.5W)Ω
70Vline:
330Ω (15W),
1k (5W),Ω
170Ω (30W),
3.3k (1.5W),Ω
10k (0.5W)Ω
70Vline:
170Ω (30W),
330 (15W),Ω
83 Ω (60W),
670 (7.5W),Ω
3.3k (1.5W)Ω
360° (500Hz),
199° (1kHz),
Horizontal:
138° (2kHz),
92° (4kHz)
360° (500Hz),
182° (1kHz),
Horizontal:
150° (2kHz),
81° (4kHz)
360° (500Hz),
134° (1kHz),
Horizontal:
116° (2kHz),
82° (4kHz)
360° (500Hz),
197° (1kHz),
Vertical:
132° (2kHz),
44° (4kHz)
360° (500Hz),
133° (1kHz),
Vertical:
87° (2kHz),
80° (4kHz)
360° (500Hz),
132° (1kHz),
Vertical:
111° (2kHz),
81° (4kHz)

15
Finish
Dimensions(mm)
Weight
Accessory
Notes
• Thedesignandspecificationsaresubjecttochangewithoutnoticeforimprovement.
• Thespecificationsdatawasmeasuredinananechoicchamber,accordingtoEN54-24.
• Referenceaxis: Axisisonthecenterofspeakergrillandperpendiculartothespeakergrill.
• Referenceplane:Planeisonthespeakergrillandperpendiculartothereferenceaxis.
• Horizontalplane:Planeiscontainingthereferenceaxisandperpendiculartothereferenceplane.
F-1000BTWPEB-Q
F-1000WTWPEB-Q
F-1300BTWPEB-Q
F-1300WTWPEB-Q
F-2000BTWPEB-Q
F-2000WTWPEB-Q
ModelNo.
Enclosure:HIPS,blackorwhite
Meshspeakergrill:Surface-treatedsteelplate,blackorwhite,paint
Speakerbracket:Aluminumdie-cast,blackorwhite,paint
Jointbracket,Wallbracket,screwsandbolts:Stainlesssteel
130(w)x202(h)x131(d) 162(w)x250(h)x161(d) 244(w)x373(h)x235(d)
2kg 3.6kg 7.4kg
(includingthesuppliedbrackets)
Terminalcover...1,Hornadapter...1(F-2000seriesonly),
Speakerbracket...1,Jointbracket...1,Wallbracket...1,
HexagonboltM6x12(withplainwasherandspringwasher)...2,
MachinescrewM5x20(withplainwasherandspringwasher):
F-1000orF-1300series...2,F-2000series...4,
Tappingscrew4x12:
F-1000orF-1300series...4,F-2000series...8,
Fixingbolt:M5x60(F-1000orF-1300series)...1,M6x85(F-2000series)...1

16

17

18

19

URL:http://www.toa.jp/
533-06-257-70
Other manuals for F-1000BTWP EB-Q
1
This manual suits for next models
5
Table of contents
Other Toa Speakers System manuals
Popular Speakers System manuals by other brands

Vizio
Vizio SB362AN-F6 quick start guide

Harman Kardon
Harman Kardon SB 16 Product information

Electro-Voice
Electro-Voice DML-2181A Series Specifications

Ibiza sound
Ibiza sound POWERLINE 2.2 user manual

Von Schweikert Audio
Von Schweikert Audio VR-4SR Mk2 instruction manual

Sound Town
Sound Town ZETHUS-112BPW product manual
