Toastmaster T230/T230B User manual

OWNER S MANUAL
Model No. T230/T230B
2 SLICE TOASTER
Toastmaster®
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 1

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs,
or appliance in water or other liquid.
4. Close supervision is necessary when any appliance is used by
or near children.
5. Unplug from outlet when not in use and before cleaning. Allow
to cool before putting on or taking off parts.
6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in any
manner. Contact Consumer Service for examination, repair or
adjustment.
7. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a
heated oven.
11.To disconnect, press the CANCEL Button, then remove plug
from wall outlet.
12. Do not use appliance for other than intended use.
13. Oversize foods, metal foil packages, or utensils must not be
inserted in a Toaster as they may involve a risk of fire or
electric shock.
14. A fire may occur if toasters are covered or touching flammable
material, including curtains, draperies, walls, and the like,
when in operation.
15. Do not attempt to dislodge food when toaster is plugged in.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 2

3
ADDITIONAL IMPORTANT SAFEGUARDS
CAUTION HOT SURFACES: This appliance generates heat and
escaping steam during use. Proper precautions must be taken
to prevent the risk of burns, fires, or other injury to persons or
damage to property.
1. A person who has not read and understood all operating and
safety instructions is not qualified to operate this appliance. All
users of this appliance must read and understand this Owner’s
Manual before operating or cleaning this appliance.
2. If this appliance falls or accidentally becomes immersed in
water, unplug it from the wall outlet immediately. Do not reach
into the water!
3. When using this appliance, provide adequate air space above
and on all sides for air circulation. Do not operate this
appliance while it is touching or near curtains, wall coverings,
clothing, dishtowels or other flammable materials.
4. To reduce the risk of fire, do not leave this appliance
unattended during use.
5. If this appliance begins to malfunction during use, immediately
press the CANCEL Button and unplug the cord. Do not use or
attempt to repair a malfunctioning appliance!
6. The cord to this appliance should only be plugged into a
120V AC electrical wall outlet.
7. Do not use this appliance in an unstable position.
8. Use the Toaster on a hard, flat surface. Do not place it near
a flame or heat or on a soft surface (such as carpet). Avoid
placing it where it may tip over during use. Dropping the
Toaster could cause it to malfunction.
WARNING: ELECTRICAL SHOCK HAZARD. Never attempt to
dislodge food inside the Toaster while the Toaster is plugged
in. Doing so could cause an electrical shock hazard or a risk
of fire.
CAUTION: This appliance is hot during operation and retains heat
for some time after turning off. Always use oven mitts when
handling hot materials and allow metal parts to cool before
cleaning. Do not place anything on top of the Toaster while
it is operating or while it is hot.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 3

4
CAUTION:
DO NOT toast pastries with runny fillings or frosting.
DO NOT toast torn slices of bread.
DO NOT place buttered bread or wrapped food into the Toaster.
DO NOT toast small-size breads, mini-baguettes, breadsticks, etc.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to
fit into a polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
Ashort power-supply cord is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
Do not use an extension cord with this product.
PLASTICIZER WARNING
CAUTION: To prevent Plasticizers from migrating to the finish
of the counter top or table top or other furniture, place
NON-PLASTIC coasters or place mats between the appliance
and the finish of the counter top or table top.
Failure to do so may cause the finish to darken, permanent
blemishes may occur or stains can appear.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on
a separate electrical circuit from other appliances.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 4

5
GETTING TO KNOW YOUR
TOASTMASTER®2 SLICE TOASTER
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATIONS
CANCEL
OST BAGEL
1. Toasting Slots
2. Toasting Lever
3. BAGEL Button
4. DEFROST Button
5. Adjustable Browning Control
6. CANCEL Button
7. Cord Storage Wrap
(not shown)
8. Crumb Tray (not shown)
(P/N 22813W-White)
(P/N 22813B-Black)
8.
7.
Lightest
Setting
Darkest
Setting
1.
2.
3.
6.
4.
5.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 5

6
BEFORE USING FOR THE FIRST TIME
1. Remove all packaging materials including those which may be
inside the Toasting Slots or Toasting Lever slot.
2. Wipe the exterior with a damp cloth. Dry thoroughly. Do not
use abrasive cleaners.
3. Do not put the Toaster, cord or plug in water.
4. Be sure the Crumb Tray is pushed all the way into the Toaster
and the Toasting Lever is in the UP position.
5. Unwrap power cord from Cord Storage Area on underside of
Toaster and plug into a 120V AC outlet.
6. Turn the Adjustable Browning Control to the lightest setting (see
Page 5 for reference).
7. Lower the Toasting Lever until it locks in place. Operate with-
out bread once or twice to burn off any manufacturing residue.
You may notice a slight amount of smoke; this is normal and
will stop as the heating elements continue to heat.
OPERATING INSTRUCTIONS
TOASTING BREAD
1. Be sure no bread or other objects are inside the Toasting Slot.
Place Toaster on a flat, level, heat resistant surface and plug the
power cord into a 120V AC electrical outlet.
2. Position the Adjustable Browning Control to desired setting. The
first time you toast, it is best to use both Toasting Slots; position
the Adjustable Browning Control to Medium (mid-way between
the lightest and darkest setting); then adjust each subsequent
toasting to your preference.
3Remove all protective wrappings from food before placing into
the Toasting Slots. Avoid toasting torn bread slices that may get
lodged in Toasting Slot.
4. Insert the bread into the Toasting Slots. Lower the Toasting
Lever until it locks into place. The Centering Guides will auto-
matically center the bread for even toasting. When the bread
is lowered into position, it will automatically begin to toast.
NOTE: The Toasting Lever will not lock into position unless the
Toaster is plugged in!
NOTE: When toasting a single slice, the bread may be placed in
either Toasting Slot.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 6

7
NOTE: To prevent a fire hazard, never place bread over the
opening of the Toaster, but always place it into the Slots.
NOTE: DO NOT change the Adjustable Browning Control
selection during the toasting cycle. First press the CANCEL
Button; then turn the Browning Control to adjust the browning
level. Replace bread and toast until the desired toast color is
achieved.
5. When the toast reaches the selected browning level, it will pop
up automatically.
6. Remove bread from Toasting Slots. Use care when removing
bread as the bread and Toaster will still be hot.
7. Unplug cord from wall outlet when not in use.
IMPORTANT: Never use a fork or sharp-edged utensil to remove
toast, because that may damage the heating element or cause
injury.
CANCEL BUTTON
To stop or interrupt any Toasting cycle, press the CANCEL Button,
located on the side of the Toaster. The bread will automatically rise
and the Toaster will turn off.
TOASTING BAGELS AND ENGLISH MUFFINS
1. Plug power cord into a 120V AC electrical outlet.
2. Position the Adjustable Browning Control to the color desired.
For the first use, position the Adjustable Browning Control to
Medium (mid-way between the lightest and darkest setting).
3. Slice bagel or English muffin in half; place one half in each
Toasting Slot with the cut sides facing the center of the Toaster.
NOTE: Use either Toasting Slot when toasting only half a bagel or
English muffin. Use slices that fit freely into Toasting Slots. The
Automatic Centering Guides hold food upright for uniform
side-to-side toasting.
4. Push down to lower the Toasting Lever.
5. As soon as the Toasting Lever is lowered and locked into
position, press the BAGEL Button. This changes the Toaster
to gently heat the outside of each bagel while toasting the cut
side of the bagel. The BAGEL setting works great for English
muffins, too!
6. When the bagel or muffin is done, the Toasting Lever will pop
up. The Toaster will shut off automatically.
7. To interrupt toasting, press the CANCEL Button.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 7

8
DEFROST BUTTON
Take the guesswork out of toasting frozen bread and other toaster
foods. The DEFROST Button is designed to first defrost and then
toast the bread, which extends the toasting cycle slightly.
1. Insert slices of bread into the Toasting Slots.
2. Turn the Adjustable Browning Control onto the desired posi-
tion.
3. Press the Toasting Lever down until it locks into position.
4. When the cycle is completed the bread carriage will raise the
toast up. To terminate the cycle before it is completed, simply
press the CANCEL button.
CONVENIENCE FOOD TOASTING
Extra wide Toasting Slots accommodate many varieties of packaged
convenience food available today, both frozen and non-frozen
(shelf pastry). Since toaster foods and individual tastes vary, it is
difficult to recommend exact Browning Control settings. However,
after a little experimentation you will discover the best setting for
your needs. You may also wish to refer to the heating instructions
on food packaging.
PASTRY
For best results, follow the instructions printed on the pastry
package. If the package does not have instructions, position
the Adjustable Browning Control to Medium (mid-way between the
lightest and darkest setting). Some pastries may require a second
toasting cycle.
NOTE: Do not use this Toaster for toasting pastry items with
runny-type frosting or open fillings.
NON-FROZEN SHELF PASTRY
Move the Adjustable Browning Control to a lighter setting.
For thicker convenience foods, it may be necessary to turn
the Adjustable Browning Control clockwise for a longer toasting
cycle.
AUTOMATIC CENTERING GUIDES
Lowering the Toasting Lever closes the Centering Guides, and holds
the bread or toaster food centrally in the Toasting Slots.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 8

9
NOTE: The Toasting Lever will not lock down unless the Toaster is
plugged into an electrical outlet.
REMOVING LODGED FOODS
If a piece of bread or any other toaster food becomes lodged in
either of the Toasting Slots, unplug the Toaster and allow it to cool.
Hold the Toasting Lever down. Turn the Toaster upside down and
shake the food loose.
IMPORTANT: Never use a fork or sharp-edged utensil to remove
toast, because that may damage the heating element or
cause injury.
IMPORTANT POINTS
•Remove all protective wrappings from food before placing in
the Toasting Slot.
•For best results, clean the Crumb Tray frequently.
•Different breads require different color settings. Raise Toasting
Lever manually or press the CANCEL Button at any time to
check toast color.
•Do not block top opening. Do not place any object over the
top opening.
•Do not toast buttered bread or buttered pita bread. Melted
butter will cause fire.
•When toasting more than one slice of bread, use slices of
similar size, thickness and freshness.
•Stale bread, thin bread or sweet bread products, such as tea
cakes and fruit loaf, brown much more quickly than ordinary
bread, so they should be toasted on the lighter settings.
•Never immerse Toaster, cord or plug in water or other liquid.
•Never use a fork or sharp-edged utensil to remove toast,
because that may damage the heating element or cause injury.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 9

10
USER MAINTENANCE INSTRUCTIONS
This appliance requires little maintenance. It contains no user
serviceable parts. Do not try to repair it yourself. Any servicing that
requires disassembly must be performed by a qualified appliance
repair technician.
CLEANING
CAUTION: Do not immerse Toaster, cord, or plug in water or any
other liquid.
CAUTION: Be sure the Toaster is unplugged before cleaning.
CRUMB TRAY: Remove the Crumb Tray at bottom of the Toaster.
Pull the Crumb Tray away from the bottom of the Toaster, and allow
the crumbs to fall out.
We suggest that you do this over a sink or over a garbage can.
Wipe the Crumb Tray with a clean, damp cloth. Replace the Crumb
Tray, making sure to push firmly so that it is fully inserted in the
bottom of the Toaster.
EXTERIOR: Wipe the Toaster exterior with a clean, damp cloth.
Do not use abrasive cleaners. Do not put cord, or plug in water
or liquid.
STORAGE
Unplug unit, allow to cool, and clean before storing.
Store Toaster in its box in a clean, dry place.
Never store Toaster while it is hot or still plugged in.
Never wrap cord tightly around the appliance, use the Cord Storage
area on the bottom of the Toaster.
Do not put any stress on the cord where it enters the unit, as it
could cause the cord to fray and break.
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 10

LIMITED ONE-YEAR WARRANTY
Warranty Coverage: This product is warranted to be free from defects in materials or workman-
ship for a period of one (1) year from the original purchase date. This product warranty is
extended only to the original consumer purchaser of the product and is not transferable. For a
period of one (1) year from the date of original purchase of the product, our Repair Center will,
at its option, either (1) repair the product or (2) replace the product with a reconditioned com-
parable model. These remedies are the purchaser's exclusive remedies under this warranty.
Warranty Service: To obtain warranty service, you must call our warranty service number at
1-800-947-3744 for return instructions on how to deliver the product, in either the original pack-
aging or packaging affording an equal degree of protection to the Repair Center specified below.
You must enclose a copy of your sales receipt or other proof of purchase
to demonstrate eligibility for warranty coverage.
What Is Not Covered: This warranty does not cover damage resulting from misuse, accident,
commercial use, improper service or any other damage caused by anything other than defects
in material or workmanship during ordinary consumer use. This warranty is invalid if the serial
number has been altered or removed from the product. This warranty is valid only in the
United States and Canada.
LIMITATION ON DAMAGES: THERE SHALL BE NO LIABILITY FOR ANY INCIDENTAL OR CON-
SEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY OR CONDI-
TION ON THIS PRODUCT.
DURATION OF IMPLIED WARRANTIES: EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ALL IMPLIED WARRANTIES AND CONDITIONS, INCLUDING, WITHOUT LIMITATION,
IMPLIED WARRANTIES AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PAR-
TICULAR PURPOSE OR USE ON THIS PRODUCT ARE LIMITED IN DURATION TO THE DURA-
TION OF THIS WARRANTY.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential dam-
ages, or allow limitations on how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights and you
may have other rights under the laws of your jurisdiction.
For more information on our products, visit our website: www.maxim-toastmaster.com.
© 2006 Toastmaster Inc. Rev. 07/06
All Rights Reserved Printed in China
To return the appliance, ship to:
ATTN: Repair Center
708 South Missouri Street
Macon, MO 63552 USA
To contact us, please write to, call, or email:
Consumer Relations Department
PO Box 7366
Columbia, MO 65205-7366 USA
1-800-233-9054
E-mail: [e-mail]
TMR_T230/T230B_IB_28-7-06 7/29/06 1:37 AM Page 11
