Togo POWER TSP-60F User manual

60W SOLAR PANEL
Empower Your Life, Empower Your World
USER MANUAL
TSP-60F

HOW IT WORKS
60W SOLAR PANEL
Power Station Cell Phone
Power Bank Flashlight
Tablet

60W SOLAR PANEL
ACCESSORIES
1 X User Manual 1 X 3m Anderson to MC4 adapter
1X 0.65m Anderson to DC7909
+DC5525+DC5521+Aviation
1 X 1.5m Anderson Cable
(Equipped with Solar Panel)
1 X USB-A ,1 X USB-C
(Equipped with Solar Panel)
65
43
21

IMPORTANT SAFETY INFORMATION
To ensure safe operation and service of the meter, read and understand all instructions.
Failure to follow all instructions may result in severe injury or property damage.
TECHNICAL SPECIFICATIONS
Peak Power: 60W
DC Output: 18V/3.3A Max
USB-A Output: 5V3.4A/9V2.5A/12V2A Max
USB-C Output: 5V4.5A/9V3A/12V3A/15V3A Max
Cell Type: Monocrystalline * 3pcs
Dimensions (Unfolded): 1290*406*25mm
Dimensions (Folded): 406*370*50mm
Weight: 6.5lbs (2.95kg) Excluding Accessories
CAUTIONS
Avoid extreme temperature.
Do not immerse in water. Do not destroy it in any way.
Do not disassemble.
USING TIPS
Please make sure that the connecting cables match Solar Panel and charging equipment.
In theory, Solar Panel can charge all kinds of batteries.
It depends on the charging circuit of the batteries.
Please make sure that the charging voltage of the Solar Panel matches the input voltage
of your batteries.
Note that the red part of the Anderson plug is positive, and the black part is negative.
Please connect positive to positive and negative to negative to ensure using correctly.
60W SOLAR PANELTSP-60F

USINGTIPS
USING TIPS
The output power of Solar Panel is related to the intensity and angle of sunlight.
Solar Panel form a 90-degree angle with sunlight has the best charging efficiency.
To ensure your user experience, please use Solar Panel in a place with sufficient sunlight.
SOLAR PANEL
SOLAR PANEL
Using Example
BEST OKAY BAD
WARNINGS
The warnings in this manual cannot cover all possible conditions or situations that could occur.
Using this product with common sense and caution. Always be aware of the environment and
ensure that the product is used in a safe and responsible manner.
BEST OKAY BAD
Do NOT operate or assemble the Solar Panel until reading this manual and understanding
how it works.
When using the solar panel, place it upward in direct sunlight to ensure the best charging effect.
Use the Solar Panel to charge proper equipment.
Do NOT attempt to force it to do the work of larger industrial equipment.
Do NOT break, dismantle, or drop the Solar Panel.
Do NOT use nails or sharp objects to scratch the Solar Panel surface.
Do NOT place heavy objects or step on it.
Do NOT immerse the Solar Panel in water. Try to avoid exposure in the rain and moist
environments. Scrub the Solar Panel with a damp cloth when clean it.
Keep the Solar Panel away from excessive-high temperatures, such as fire or heater.
Do NOT put the Solar Panel into a fire or apply direct heat to it.
Do NOT contact the Solar Panel with strong corrosive objects.
Do NOT modify this product in any way. Unauthorized modification may impair function and
safety. Also, it could affect the life span of the product.
SOLAR PANEL

FREQUENTLY ASKED QUESTIONS
Q: Is the Solar Panel waterproof?
A: Both sides of the Solar Panel are protected well from splashing water.
However, the connectors which on the bag are not waterproof.
Do not immerse the Solar Panel in water, and we don’t recommend using the
Solar Panel in the rain and moist environments.
Q: Is this chainable with other Solar Panels?
A: Yes. You can chain other Solar Panels that have the same nominal output voltage power in
parallel. You should note that the superimposed current cannot exceed the current that the
connecting cables and plugs can bear. Our warranty does not cover any property loss
caused by misoperation when chaining Solar Panels.
Q: What if the foldable USB port solar charger is not charging my devices?
A:1. Check the manual of your device to ensure the input voltage fits 5V or support QC3.0&PD.
2. Cloudy weather and indirect sunlight may cause fluctuations in the current.
This in turn may hinder or prevent charging. Place the Solar Panel in direct sunlight or
wait for the weather to clear.
3. Wipe the panels clean with a damp cloth between usage to prevent scratching.
4. Avoid exposure to fire, water and chemical liquid.
Q: If it is partially cloudy or shady will the solar charger still work?
A: Yes, although the charging efficiency will be low causing prolonged charging time.
Q: Will this panel charge a power station?
A: Yes. The Solar Panel can charge BALDR/TogoPOWER series power station,
and also the products of other brands with appropriate power.
Note that charging power station which has excessive power will lead to longer charging time.

WARRANTY
STATEMENT
TogoPOWER provides a limited warranty for the original consumer purchaser,
which covers the TogoPOWER products from defects in workmanship and material under
consumer for 12 months from the date of purchase. In order to establish the start date of
the warranty period, the sales receipt from the first consumer purchase, or other reasonable
documentary proof is required.
TogoPOWER’s warranty does not apply to (i) any product that is misused, abused, modified,
damaged by accident, or used for anything other than normal consumer use as
authorized in TogoPOWER’s current product literature, or (ii) any product purchased
through an online auction house.
To know more and obtain warranty service, contact our customer service team at
[e-mail]
© Copyright TogoPOWER. All rights reserved.
All trademarks cited herein are the property of their respective owners.
The information contained herein is subject to change without notice.
The only warranties for TogoPOWER products and services are outlined in the warranty
statements accompanying such products and services.
TogoPOWER shall not be liable for technical or editorial errors or omissions contained herein.

322 Paseo Tesoro, Walnut, CA 91789
1-855-801-0798
[e-mail]
www.togopower.com
CONTACT US
