EZ-SERV® Table-Top Multi-System Dispenser (DS108)
1. Carefully remove all parts from packaging and poly bags. Before
assembling, make sure you have all the parts listed below. If any piece
is missing, please call [phone]. Hand wash parts (a) to (d).
SETTING UP YOUR PRODUCT
ITEM # DSL003
ITEM # DSP001
ITEM # DSM001
a
b
e
Lid
Portion Wheel
False Chamber
Container
Label Holder
Handle
h ITEM # DSM010
c
d ITEM # DSC001
ITEM # DSM002
k ITEM # DSB012
a.
b.
c.
d.
e.
f.
h.
i.
If the false chamber (c) is installed in the container, gently pull it out
and set aside.
3. Refer to Figure A. Drop the portion wheel (b) into the alloted space
at the front of the container (d). Align all the holes (on container and
wheel).
5. At the tip of the handle is a hole for the R clip. Insert the straight side
of the R clip (i) through this hole. See Figure B. A portion of the metal
handle will rest under the middle ridge.
7. Refer to Figure C. Match the bottom of the container into the
allotted slot on the leg base. Push down to lock in place.
j.
Funnel
R Clip
Bamboo Catch Tray
Leg Base
k.
i ITEM # DSM007
6. Slide the false chamber smoothly back into the container.
Figure B
Push the handle (f) through the front, all the way to the back hole.
4.
2.
Figure A
f ITEM # DSH001
Figure C
12
j ITEM # DST006
STRAIGHT SIDE
MIDDLE RIDGE
HANDLE HOLE
Filler Funnel*
l. *Please make sure to
store the filler funnel
at an accessible
location after the full
product is assembled.
l
ITEM # DSM008
NEED ASSISTANCE? Please contact our customer support at 1300 81 30 40 and we’ll be
happy to assist with any assembly questions, comments or concerns.
Visit our website at: www.TOPSHELFCONCEPTS.COM
Top Shelf Concepts 50 Morley st, Coorparoo. QLD. 4151

PRODUCT SPECIFICATIONS
•Print your label on regular paper and cut to size (3.1" x 5.25" / 78.75mm x 133.35mm).
Place it under the curved label holder (e), with the printed side directly on the plastic
piece.
Snap the label holder onto the assembled unit using the allotted ridges. The side
edges should latch snugly onto the front of the container, right above the handle.
Your dispenser unit is now ready for use! Enjoy!
CARE INSTRUCTIONS
1. To maintain the quality of your EZ-SERV® Multi-System dispenser, wash all parts regularly in warm soapy water.
Use a non-abrasive sponge.
2. DO NOT put any part of the unit through any dishwasher or dryer machines.
3. When disassembling the container, handle all parts gently. Please refrain from using too much force.
4. To keep the handle polished, you may use a commercial metal cleaner - however, remember to only use this
on the outer portion and NOT on the shaft.
5. Reassemble the unit only after all parts are completely dry.
* Also available with shelf-
mounting base (DS101) and
bamboo table-top base
(DS102)
8. If you wish, you may pour in the contents into the container at this
time. Fill the false chamber first using the filler funnel (m), then fill the
body. Securely place the lid (a) on top.
9. Hook the funnel (h) onto the container by connecting the inner nubs
to the notches on the container's spout.
10. Place the catch tray (j) on the allotted space at the front of the leg, right
under the funnel.
11. Label placement...
Assembled Product Dimensions: 9.2" x 13.6" x 24.8" H / 233.7mm x 345.4mm x 630mm H
Container Capacity: 3.5 gallons per unit - Assembled Product Weight: 9 lbs
CARE INSTRUCTIONS FOR BAMBOO CATCH TRAY
1. Do not place your bamboo catch tray in the dish washer.
2. Avoid using alcohol, ammonia, or any chemical-based cleaners.
3. Do not use abrasive materials such as scrapers or metal-based brushes.
4. Use a damp wash cloth to clean the bamboo catch tray. A simple microfiber cloth is recommended.
5. Keep away from open flame and direct sunlight.
NEED ASSISTANCE? Please contact our customer support at 1300 81 30 40 and we’ll be
happy to assist with any assembly questions, comments or concerns.
Visit our website at: www.TOPSHELFCONCEPTS.COM
Top Shelf Concepts 50 Morley st, Coorparoo. QLD. 4151
