TOPTEK TOPVERT L1 Series User manual

ISO 9001:2008
TOPTEK ELECTRONICS CORPORATION
QUICK START
快速安裝手冊
簡易迷你型 無感電流向量控制 變頻器
General purpose micro drive
Sensorless Vector Control

TOPVERT L1Series
E-
1
PREFACE
Thank you for choosing TOPTEK’S TOPVERT L1 Series Drive. TOPVERT L1 Series are Sensorless
current vector control high-performance drive. They were manufactured by adopting high-quality
components, material and incorporating the latest microprocessor technology available.
Copyright statement
All information in this Quick start manual is Toptek’s intellectual property. Even we had done our best
to make this manual but are unable to guarantee 100% correct.
Based on " Never Stop for better but perfect accomplished " quality policy, our product permanently
in the journey which perfectly strives for perfection to the pursue,
Therefore we reserve the right to change the information in this manual without prior notice.
But we will continue the latest edition document in our website, for free download.
http://www.toptek.biz
Getting Started
This manual will be helpful in the installation, parameter setting, troubleshooting, and daily
maintenance of the drives. To guarantee safe operation of the equipment, read the following safety
guidelines before connecting power to the Drives. Keep this operating manual handy and distribute to
all users for reference.
Always read this manual thoroughly before using TOPVERT L1 Series Drives.
DANGER! AC input power must be disconnected before any maintenance.
Do not connect or disconnect wires and connectors while power is applied to the
circuit. Maintenance must be performed by qualified technicians.
CAUTION! There are highly sensitive MOS components on the printed circuit boards. These
components are especially sensitive to static electricity.
To avoid damage to these components, do not touch these components or the circuit
boards with metal objects or your bare hands.
DANGER! A charge may still remain in the DC-link capacitor with voltages even if the power has
been turned off.
To avoid personal injury, please ensure that power has turned off before operating
Drive and wait ten minutes for capacitors to discharge to safe voltage levels.
CAUTION! Ground the TOPVERT L1 using the ground terminal.
The grounding method must comply with the laws of the country where the Drive is to
be installed. Refer to Basic Wiring Diagram.
DANGER! The Drive may be destroyed beyond repair if incorrect cables are connected to the
input/output terminals. Never connect the Drive output terminals U/T1, V/T2, and
W/T3 directly to the AC main circuit power supply.
CAUTION! The final enclosures of the Drive must comply with EN50178. (Live parts shall be
arranged in enclosures or located behind barriers that meet at least the requirements
of the Protective Type IP20.
The top surface of the enclosures or barrier that is easily accessible shall meet at
least the requirements of the Protective Type IP40).
WA RNING

TOPVERT L1Series
E-
2
(TOPVERT L1 Series corresponds with this regulation.)
CAUTION! Heat sink may heat up over 70℃(158℉), during the operation. Do not touch the
heat sink.
CAUTION! The rated voltage for the drive must be ≤240V (≤480V for 460V models, ≤600V
For 575V models) and the mains supply current capacity must be ≤5000A RMS
(≤10000A RMS for the ≥40hp (30kW) models).
CAUTION! The leakage current between chassis and earth could be up to 22mA.
CAUTION! The load motor should meet IEC:60034-1 standard.
Nameplate Information
Example for 3HP/2.2kW 230V 1&3-Phase , Kneading board operation,RS-485 Serial port , dynamic
braking resistor.
Model Explanation
Explanation of Production control data
● Please contact the dealers immediately should any discrepancy occurred.
Applicable M otor C apacity
0P1= 0.1kW 0P2= 0.2kW
0P4= 0.4kW 0P7= 0.75kW
1P5= 1.5kW 2P2= 2.2kW
Input Voltage
11= 115V 1 Phase
2M = 230V 1& 3 Phase
43= 480V 3 Phase
Toptek´s A C drive Fam ily
L1 S eries
Code for Kneading board operation
Blank or N : no selection
1 : REV -STO P-FW D Switch & S peed VR
Code for dynam ic braking resistor
Blank or N : no selection
D: selected dynam ic braking resistor
O the r: custom ization
TOPVERT L1-2M 2P2 x - x x x x - xxx
Hardware version
Blank: original version
A: version A
B: version B
Z: version Z
C ode for V /F C urve & O utput frequ ency U pper lim it
Blank or N : 60H z
050 : 50Hz, 200 :200Hz
O the r: custom ization
Code for Extension, Interface cards
Blank or N : no selection
1 : AI/DI Extension cards
Code for R S-485 serial port
Blank or N : no selection
S: selected R S-485 serial port
O the r: custom ization
P ro du ctio n F a ctory: T = T a iw a n fa ctory
F = F u z h ou fa c to ry
X = X im a n fa c to ry
P ro d u ctio n N u m b e r
P ro d u ctio n M o n th :
1 ~ 9 = J a n . T o S e p . O = O c t. N = N o v. D = D e c .
P ro d u ctio n Y e a r: 0 ~ 9 = 2 01 0 ~ 20 1 9
O p tio n C o d e o r cu sto m -m a d e co d e
M o d e l: L 1 s e rie s 2 3 0 V 1 & 3 P h a se 2 .2k W / 3 H p
M o to r V /F s e le c tin g P re se t (P r0 -0 2 )
L 1 -2 M 2P 2 -xxx -0 8 T 2 5 09 0 01
L1-2M2P2-1SD-08 T2509001
Model:TOPVERT L1-2M2P2-1SD
(FRN :3.009)
Input Specifications
Production control data
Output Frequency Range
Model number
Output Specifications
Barcode (Firmware code:3.009)
CE certification
1F 3F 300~240V 50/60Hz 12A1 3 300~240V 50/60Hz 12A

TOPVERT L1Series
E-
3
STANDARD SPECIFICATIONS
Series TOPVERT L1 series Simple Mini micro drive
Control Characteristics
Output frequency range 0.1 - 600Hz, Programmable
Overload endurance 150% of rated current for 1 minute/10 minutes, Ta <=40, 200% of rated current for 2 seconds
Maximum output voltage Proportional to Input Voltage, 3-Phase output
Power factor/Efficiency Power factor no lower than 0.95. Efficiency no lower than 95% at full load
Control system SPWM (Sinusoidal Pulse Width Modulation) vector control, 2 control modes :V/F, SVC
Speed control range V/F mode 20:1; SVC mode 120:1
Output frequency resolution Analog input: 10Bit(1/1024), Digital input: 0.01Hz, Fly-Shuttle dial input: 0.01Hz
Output frequency accuracy Analog input: Within ±0.2% of max. output frequency (25℃±10℃).
Digital input: Within 0.01% of set output frequency
PWM carrier Frequency 0.7 -18kHz,Adjustable (Some models are limited)
Torque characteristics auto-torque boost, auto-slip compensation; starting torque can be 150% at 1.0Hz
Skip frequency Setting range 0.00 -600Hz, Max. 6 points, skip width are adjustable
Accel/Decel time 0.1-60000 seconds ( 2 Independent settings for Accel/Decel Time)
Stall prevention 0 to 250% of Rated Current, independent adjustable both in acceleration and constant speed operation.
DC Braking DC Braking both when start up and stop , Braking Current Level: 0 to 125% of rated output current. Braking time: 0
to 60 seconds. Braking Start-Point when stop: 0.1-600Hz
Dynamic braking Braking torque Approx. 20%(10%E.D.)
V/F Pattern 2 of adjustable Random V/F curve. Constant Torque curve & Reduced Torque curve are available.
O
PERATING
Characteristics
Frequency Setting
Keypad By an Encoder style Fly-Shuttle dial. (setting resolution 0.01Hz/0.1Hz/1Hz/10Hz adjustable)
External
Signal 0 ~ +10VDC((Input impedance 20kΩ), 4 ~20mA DC ((Input impedance 250Ω),Multi-Function Inputs 1 ~2 (15 Steps up/down), PLC run, RS-485 port MODBUS protocol
Operation Setting
Keypad Set by RUN and STOP. Switch-able between Keypad and External signal
External
Signal 2 wire control(FWD/STOP、REV/STOP、RUN/STOP、FWD/REV), 3 wire control, FWD, REV, MI1 to MI3 can be
combined to offer various modes of operation, RS-485 serial interface MODBUS protocol
Multi-Function Digital Input
(DI)
(2 terminals)
Multi-step selection 0 to 15, first to second accel/decel switches, accel/decel inhibit, Input the counter, Pause Stop,
EF Input, Emergency Stop, auxiliary motor control is invalid, ACI/AVI speed command selection, Reset, PLC Run,
Up/Down command, Parameter team selection…etc, up to 43 functions.
Multi-Function Output Indication
(DO)
(1 indication )
Include a form C relay contact, a form A relay contact and 2 Open collector output. They can be programmed to
below indications: Drive Operating, FrequencyAttained, zero speed, Base Block, Over torque,
Fault Indication, Local/Remote indication, PLC Operation indication, andAuxiliary Motor Output, Drive ready for
use, IGBT over-heat indication …etc, up to 63 functions.
Multi-Function Analog Input
(AI1) AI1: 0 ~ +10VDC((Input impedance 20kΩ) /4 ~20mA DC ((Input impedance 250Ω). AI1 Input terminals can be programmed to 15 functions
Fault Indication The output will be activated when faults occur (User may get 1 or up to 4 indications from below terminals:1 Relay
contact point RA, RB, RC. or 2 Open-collector
Communication function RS-485 serial port, MODBUS protocol, ASCII & RTU. (Baud rate up to 125 k bps)
Other Functions
PID feedback control, Flying start, Automatic voltage regulation (AVR), 2 accel./decel time selection , Auto-
optimum
accel./decel. Time, S-curves, External fault interlock, External fault reset, Auto Restart after fault, 16 Fault records,
Automatic energy–saving, Upper/Lower limit, Programmable pulse output, Password protection, Pump and Fan
process control, Sleep/Wakeup function , Auto-Tuning, By-Pass, Y-Delta control,. Bi-Directional Speed search,
Reverse inhibit, Automatic torque boost & slip compensation, 16-
step PLC run, 16 step preset speed, Coast or ramp
to stop, Random V/F curve, Mechanical brake release control, IGBT/ Heatsink temperature display & Pre-warning,
Quiet operation mode (No noise), User define Multi-function display, Over torque detection, Over current/voltage t
stall prevention, Electronic Thermal Relay, Internal Counter, DC injection brake both in start and stop, Dynamic
brake, Controlled cooling Fan, Removable keypad operator, Programmable Multi-Function DI,AI and Ry terminals.
Intelligent Protection Functions
Self-testing,AC source Over Voltage, Phase loss, Over Voltage, Over Current, Under Voltage, Over Torque,
External Fault, Motor over-load, IGBT Over-temperature, Heat-sink Over-temperature, Electronic thermal, Ground
Fault, Output short circuit, Stall Prevention, Fuse protection, IGBT short circuit , Drive Over Load ,
DC bus capacitor
life monitoring, Auto carrier frequency adjust according temperature, 16 Trip records, Run information of
latest Fault
such like DC-BUS voltage, Output voltage/Frequency/Current, Command frequency, IGBT temperature, Heat-sink
temperature….etc.
Digital Keypad(OPTION)
Eight Function keys: Access Run, Stop, Reset/ Digit Shift, Display mode, Keypad Enable, Programming data
and…etc.
One Encoder style Fly-Shuttle dial: Sets the parameter number and changes the numerical data
One 6 digits 7 segment display: Display the Setting frequency/actual operation frequency, Output
current/Voltage, motor speed, Fault trip User defined unit(up to 88 type)…etc.
Six LED Display for status indication: Display the Drive run/stop status, Forward/Reverse run status, Keypad
enable, and Frequency command source.
One RJ
-45 connector: Removable Keypad, remote control distance up to 150 meters.
Environment
Certificate Complies with CE (EN61800-3) standard
Temperature Ambient: -10 ~ +40 /(℃ ℃ -10 ~ + 50 ) (℃ ℃ Non-Condensing and not frozen). Storage: -20 ~ +60℃ ℃
Humidity Below 98％R.H. (Non-Condensing)
Vibration Below 20Hz: 1G, above 20Hz: 0.6G
Installation Location Altitude 1,000 m or lower, keep away from corrosive gasses, liquid and dust
*TOPVERT all series are designed and manufactured base on CNS and IEC, IEEE, CE & UL standard.

TOPVERT L1Series
E-
4
1
-
Phase
, 100 ~ 120VAC, 50/60 Hz
(
Tolerance Range
: 90 ~ 132V, 47 ~ 63Hz)
Output Voltage
:200~240VAC
Model Applicable Motor
(230V 4 P) Rated Output Source
Enclosure Construction
TOPVERT
L1-xxxxx
Power
(kW)
Horse
Power
(Hp)
Capacity
(kVA) Current (A) Voltage (V) Frequency (Hz) Current (A) Cooling Methods
Protection
Methods
(IP/NEMA)
Net
Weight
(kg)
Frame Code
110P1 3-
Phase,
0-240
(Max)
0.1- 600
Fan-
cooled IP 20
NEMA 1
L1-A
11OP2 0.2 0.25 0.6 1.5 2.9
L1-B
110P4 0.4 0.5 1.2 3 5.7
110P7 0.75 1 2 5 9.5 L1-C
1
&3
-
Phase
, 200 ~ 240VAC, 50/60 Hz
(
Tolerance Range
: 180 ~ 264V,47 ~ 63Hz)
Model Applicable Motor
(230V 4 P) Rated Output Source
Enclosure Construction
TOPVERT
L1-xxxxx
Power
(kW)
Horse
Power
(Hp)
Capacity
(kVA) Current (A) Voltage (V) Frequency (Hz) Current (A) Cooling Methods
Protection
Methods
(IP/NEMA)
Net
Weight
(kg)
Frame Code
2M0P2 0.2 0.25 0.6 1.5
3-
Phase,
0-240
(Max)
0.1-600
2.9
Fan-
cooled IP 20 NEMA 1
0.92
L1-B
2M0P4 0.4 0.5 1.2 3 5.7 0.92
2M0P7 0.75 1 2 5 9.5 0.92
2M1P5 1.5 2 3 7.5 14 1.10
2M2P2 2.2 3 4.4 11 21 L1-C
3
-
Phase,
380 ~ 4
8
0VAC, 50/60 Hz
(
Tolerance Range:
342 ~ 528V,47 ~
63Hz)
Model Applicable Motor
(460V 4 P) Rated Output Source
Enclosure Construction
TOPVERT
L1-xxxxx
Power
(kW)
Horse
Power
(Hp)
Capacity
(kVA) Current (A) Voltage (V) Frequency (Hz) Current (A) Cooling Methods
Protection
Methods
(IP/NEMA)
Net
Weight
(kg)
Frame Code
430P4 0.4 0.5 1.3 1.6
3-
Phase,
0-460
(Max)
0.1-600
1.8
Fan-
cooled IP 20 NEMA 1
0.89
L1-B430P7 0.75 1 2.4 3 3.3 0.89
431P5 1.5 2 3.3 4.2 4.6 0.89
432P2 2.2 3 4.8 6 6.6 L1-C

TOPVERT L1Series
E-
5
Basic Wiring Diagram
Input/Output pin assignment
Remark: ◎
◎◎
◎→
→→
→Main circuit ○
○○
○→
→→
→Control circuit →
→→
→Shielded leads & Cable ( ) →
→→
→Factory default →
→→
→option
3-Phase
powersource
None Fuse Breaker
Motor
[ Use R(L1), S(L2) for 1-phase models ]
Digital Signal Common
FWD / STOP
(Multi-Step2)
(Multi-Step1)
REV / STOP
FactoryDefault
NFB
M
3~
U(T1)
W(T3)
V(T2)
R(L1)
M.C.
T(L3)
S(L2)
E
MI1
FWD
REV
TOPVERT L1
87654321
R1A
R1B
R1C
COM
SG+
SG-
RS-485 Serial port
option kit
(Modbus)
MI2
Main circuit
Control circuit
Multi-
function
Digital
input
(DI)
Contact output 1
(indicates malfunction)
240VAC/2.5A, 120VAC/5A, 24VDC/5A
Multi-
function
Relay
output
(Ry)
Serial
port
PU port
(Frequency Command)
Braking Resistor
B2
B1
+
TDBR
(Option)
(Option)
+10V 20mA
0～10V (20KΩ)
AI1
(AVI)
ACI
+10V
12
3
ACM
VR :
5～10 KΩ
AI/DI Extension card (Option)
MI3
(Multi-Step3)
RS-485 Serial port terminals (option)
( B1,B2) For Braking Resistor (option)
Port for keypad connection
Main circuit output terminals to motor
Kneading board operation
(option)
Main circuit input terminals from AC source Ground terminals
Control circuit terminals
R1A R1B R1C FWD REV MI1 MI2 COM E
AI/DI Extension card Control circuit terminals
(option)
SG+ SG-
MI3 +10V AI1 ACM

TOPVERT L1Series
E-
6
Main Circuit Terminal Explanations
Terminal Symbol Content Explanation
R(L1),S(L2),T(L3) AC source input terminals, to be connected to commercial power. Ensuring the power voltage and the maximum current possible supp
lied
is meet the driver nameplate.
U(T1),V(T2),W(T3) Drive output terminals for motor connections
⊕/B1, B2 Connections for Brake Resistor (optional) .
Ground terminals, please have these terminals grounded following the
third-type grounding of 230V series and the special grounding of 460V
series within the electrician regulations
Control Terminal Explanations (Available when an I/O card is installed)
Terminal
Symbols
Explanation on the Terminal Function Factory Default
Digital inputs
(Use the shielded twisted-pair cables to prevent operating faults)
MI1 Multi-function digital input MI1
(3-wire STOP-designated terminal) Pr2-01/ (multi-step speed command 1)
MI2 Multi-function digital input MI2 Pr2-02/
(multi-step speed command 2)
[MI3] Multi-function digital input MI3 Pr2-03/
(multi-step speed command 3)
FWD FWD RUN/STOP command Pr2-00/( FWD RUN/STOP)
REV REV RUN/STOP command Pr2-00/( REV RUN/STOP)
Relay contact outputs
Separate these control circuit wiring from wiring for other control terminals
R1A Multi-Function digital output 1
Relay 1 (Relay dry contact output)
R1A-R1C :Relay 1 Normal open (a contact)
R1B-R1C :Relay 1 Normal close (b contact)
Pr2-20
Resistive Load
5A(N.O.)/3A(N.C.) 240VAC
5A(N.O.)/3A(N.C.) 24VDC
Inductive Load
1.5A(N.O.)/0.5A(N.C.) 240VAC
1.5A(N.O.)/0.5A(N.C.) 24VDC
R1B
R1C
Voltage source for digital signal and Frame Ground
(Use the shielded twisted-pair cables to prevent operating faults)
E Connect to the shield net of shielded twisted-pair cables
(Frame Ground)
COM Digital/Analog control signal - the common end
Analog Inputs and outputs
Analog input signals are easily affected by external noise. Use shielded twisted-pair cables for wiring
and keep it as short as possible (<20m) with proper grounding. Basically the shield sheath should
connect to the E terminal, but If the noise is inductive, connecting
the shield to terminal ACM can bring
improvement.
[+10V] +10V reference voltage source.
Reference point is ACM. Max.20mA/(+10V)
[AI1] Multi-
Function analog input 1 (voltage command or
current command selectable)
(When
AI1 analog input selector switch to “V” can accept
Pr3-02/
(DC 0~10V / DC 4(0)~20mA
corresponding to the maximum

TOPVERT L1Series
E-
7
DC 0~10V voltage signal. when switch to “I” can accept
DC 4(0)~20mA current signal. operation frequency)
[ACM] The reference point of analog inputs and outputs signal. The reference of reference voltage source.
These terminals are isolated from DCM terminals
serial port
(Use the shielded twisted-pair cables to prevent operating faults)
[SG+] RS-485 serial port +
[SG-] RS-485 serial port -
[ ]:Option
Description of the Digital Keypad
Multi-Function Operating Explanations
ITEM Function
Multi-Function input (MI1、MI2) Multi-Function setting:
1. Factory default 2.Customer assign
Running command (FWD、REV) Forward/Stop、Reverse/Stop
Relay I/O(R1A、R1B、R1C) Multi-Function setting:
1. Factory default 2.Customer assign
PU port(Key pad input) Connecting with key pad (PU-01 AND PU-05)
POWER
Power indicator
RUN
Running indicator
FAULT
Fault indicator

TOPVERT L1Series
E-
8
Optional parts 1:
REV-STOP-FWD switch & speed ajustment
Multi-Function Operating Explanations
ITEM Function
Multi-Function input (MI1、MI2) Multi-Function setting:
1.Factory default 2.Customer assign
Running command (FWD、REV) Forward/Stop、Reverse/Stop
Relay I/O(R1A、R1B、R1C) Multi-Function setting:
1.Factory default 2.Customer assign
PU port(Key pad input) Connecting with key pad (PU-01 AND PU-05)
REV-STOP-FWD switch ON-OFF-ON 3 sections switch，
REV-STOP-FWD 3 states for setting
Speed adjustment Ajustment speed from 0%~100%.
POWER
Power indicator
RUN
Running indicator
FAULT
Fault indicator
Speed ajustment
Turn right to high:
0%~100%
Turn lift to low:
100%~0%
REV-STOP-FWD
3 sections switch
REV: Reverse
STOP: Stop
FWD: Forward

TOPVERT L1Series
E-
9
Option parts 2:
AI/DI Expansion Card
Multi-Function Operating Explanations
ITEM Function
Multi-Function input (MI1、MI2、MI3)
Multi-Function setting:
1.Factory default 2.Customer assign
Running command (FWD、REV) Forward/Stop、Reverse/Stop
Relay I/O(R1A、R1B、R1C) Multi-Function setting:
1.Factory default 2.Customer assign
PU port(Key pad input) Connecting with key pad (PU-01 AND PU-05)
External Analog Input(AI)
AI1 Multi-Function terminal Multi-Function setting: 1.Factory default 2.Customer assign
AI/DI Expansion Card
Selected circuit control or voltage control with DIP
switch
Set at ”AVI”,Input DC 0~10V to speed up/low。
Set at ”ACI”,Input DC 4(0)~20mA speed up & low。
Option parts 3:
RS-485 Serial port
Multi-Function Operating Explanations
ITEM Function
Multi-Function input (MI1、MI2) Multi-Function setting:
1.Factory default 2.Customer assign
Running command (FWD、REV) Forward/Stop、Reverse/Stop
Relay I/O(R1A、R1B、R1C) Multi-Function setting:
1.Factory default 2.Customer assign
PU port(Key pad input) Connecting with key pad (PU-01 AND PU-05)
RS-485 Serial port terminal (SG+、SG-)
RS-485 serial port,It is used Modbus networks
protocol, 2 pin easy plug in/out terminal. Also you
can buy the TB/RJ45 adaptor from us when you
need

TOPVERT L1Series
E-
10
Option parts 4 :
Digital Keypad PU-01
Digital Keypad PU-01 function descriptions
Digital Keypad PU-05
Digital Keypad PU-05 function descriptions
Multi-Function Operating Explanations
ITEM Function
Multi-Function input (MI1、MI2) Multi-Function setting:
1.Factory default 2.Customer assign
Running command (FWD、REV) Forward/Stop、Reverse/Stop
Relay I/O(R1A、R1B、R1C) Multi-Function setting:
1.Factory default 2.Customer assign
PU port(Key pad input) Connecting with key pad (PU-01 AND PU-05)
Key pad-- PU-01/PU-05
Advence used 360 degree encoder switch. Easy
and fast to adjustment the parameters. Our
resolution minimum is 0.01Hz. resolved the
resolution problem of VR.
FWD REV EXT PU
Part number
Status Display……
…………
…… Display the driver's current status
When "PU" lights, RUN/STOP is controlled by PU-01.
When "PU" is dark, RUN/STOP is set byPr0-19.
When "EXT" lights, frequency command is set by Pr0-18.
When "EXT" is dark,frequency command is controlled by PU-01
When "REV" lights, Drive is in reverse operation.
When "FWD" lights, Drive is in forward operation.
Left /Reset key
Moves cursor to the left.
Reset errors.
FWD/REV Direction key
Display Selection key
Changes between differentdisplay mode.
STOP key
Programming Unit key
Enable the keypad.
It can determine the source of RUNSTOP
RUN key
PU-01
PU
JOG
DISP
F/R
RUN STOP
RUN indication STOP indication
RESET
Main Display
Display the drive status such as frequency,
current, voltage, parameter setting valueand
alarm contents.
Data modification/Program Dial
Rotate to modification for settings, parameters
and output frequency adjustment.
Press to Read or Enter datas
Jog Operation key
Press this key to execute JOG frequency opeation
Left /Reset key
Moves cursor to the left.
Reset errors.
FWD/REV Direction key
STOP key
Programming Unit key
Enable the keypad.
It can determine the source of RUN/STOP
Jog Operation key
Press this key to execute
JOG frequency opeation
RUN key
RUN indicationSTOP indication
Data modification/Program Dial
Rotate to modification for settings, parameters
and output frequency adjustment.
Press to Read or Enter datas
Part number
Status Display……
…………
…… Display the driver's current status
When "FWD" lights, Drive is in forward operation.
When "REV" lights, Drive is in reverse operation.
When "EXT" lights, frequency command is set by Pr0-18.
When "EXT" is dark,frequency command is controlled by PU-05
When "PU" lights, RUN/STOP is controlled by PU-05.
When "PU" is dark, RUN/STOP is set by Pr0-19.
Main Display
Display t he drive status such as frequency,
current, voltage, Parameter setting value and
alarm contents.
Display Selection key
Changes between different display mode.

TOPVERT L1Series
E-
11
Explanations of Display Messages
Operation Steps
Selecting display mode
Messages Displayed Descriptions
Display master frequency command of the drive
(Press the DISP key to read)
Display actual operation frequency output to the motor from the drive
(Press the DISP key to read)
Display output current to motor
(Press the DISP key to read)
Display User-selected content on Pr0-07
(Press the DISP key to read)
The specified parameter item
(Rotate and press the dial to modification, read and Enter)
(Press to display those parameters which data are different from
factory default)
Value of the parameter content
(Rotate the dial to modify for setting parameters)
If the “End” message is displayed , for about 1 second, it is an
indication that the data has been accepted and saved to the internal
memory.
F W D R E V E X T P U
F W D R E V E X T P U
F W D R E V E X T P U
F W D R E V E X T P U
RESET
FW D REV EXT PU
FW D RE V EXT PU
FW D REV EXT PUFW D REV EXT PU
To scrolling between F page, H page, A page and U page by pressing the DISP key
User defined Multi-
Function Display
DISP
Output current to motor
Press
DISP
Actual operation
frequency output to the
motor from the drive
Press
DISP
Master frequency
command of the drive
Press
FWD REV EXT PU FWD REV EXT PU FWD REV EXT PU
DISPPress
FWD REV EXT PU

TOPVERT L1Series
E-
12
Setting parameters
(For example, to set Pr0-07 = 2)
To run
(For example, to run 50 Hz from PU)
To run setted 50.00Hz
Set master frequency
to 50.00Hz
(Use left key for quick
data entry)
RUN
Press
FWD REV EXT PU
FWD REV EXT PU
RESET
To shift data
Rotate
To setting direction,
FWD/REV
F/R
Press
FWD REV EXT PU
To enable PU
PU
Press
FWD REV EXT PU
To display actualoutput frequency
to the motor
DISP
Press
FWD REV EXT PU
To setting parameter
Power-up Display
Press then
rotate
FWD REV EXT PU
Modify data to 2
Press then
rotate
FWD REV EXT PU
Success to set parameter.
FWD REV EXT PU
Press
Press 0.5sec
FWD REV EXT PU
To setting parameter
FWD REV EXT PU
DISP
Press twice
Press
FWD REV EXT PU
Select Pr 0-07
to be modified

TOPVERT L1Series
E-
13
FUNCTIONS and PARAMETER SUMMARY
★=This parameter cannot be set
during operation. ◎: Available in Firmware Version 2.xx and after only. ☉: Available in Firmware Version 3.xx and after only.
{ }Parameter no. in
Firmware Version 1.xx [ ] :optional
Group 0: System parameters
Parame
ters Functions Settings Factory
Setting User
★
Pr0-00
Model display Display according to the model number Read Only
★
Pr0-01 Rated output current to
motor Display according to the model number Read Only
★
Pr0-02 Parameter Reset (Motor
V/F selecting)
10: Parameter reset for 60Hz - 230/460V motor
application
8
9: Parameter reset for 50Hz - 220/380V motor
application
8: Parameter reset for 60Hz - 220/380V motor
application
7: Parameter reset for 50Hz - 230/460V motor
application
6: Parameter reset for 60Hz - 240/415V motor
application ◎
5: Parameter reset for 50Hz - 240/415V motor
application ◎
Pr0-03 Password Input (The Key)
0～9999 0
Pr0-04 Password set (The Lock) 0～9999 0
Pr0-05
Parameter Locking Level
Bit 0
(bxxxx0)
0: All parameters are readable,
b00000
1: Parameters after Pr0-05 cannot read
”Err” message will displayed when try
to read.
Bit 1
(bxxx0x) 0: Enable Frequency Command.
1: Disable frequency command
Bit 2
(bxx0xx) 0: Enable run command from PU
1: Disable run command from PU
Pr0-06
Power on display
selection
0: Frequency command value (F)
0
1: Actual output frequency (H）
2: Output current (A)
3: User defined contents on Pr0-07 (U)
Pr0-07
Versatile display
0: Motor speed (RPM)
0
1: DC-Bus Voltage (Vdc)
2: Actual output voltage (Vac)
3: Output voltage command value (Vac)
4: PID feedback frequency value (Hz)
5: Running step no. of MSS run
6: Sleep time (Pr8-07)
7: Auto-Restart after Fault (Pr6-10)
8: PID frequency command value (Hz)
9: (Factory Reserved)
10: Output power factor angle ( º )
11: Counter value
12: Over-Torque detection time 1 (Pr5-17)
13: (Factory Reserved)
14: Dwell Time at Accel. (Pr6-14)
15: Dwell Time at Decel. (Pr6-16)
16: DC Braking time in Start-up (Pr6-01)
17: DC Braking Time during stop (Pr6-02)
18: Remain time of the executing MSS Run

TOPVERT L1Series
E-
14
19: (Factory Reserved)
20: (Factory Reserved)
21: Accumulated power-up Day (day)
22: Accumulated power-up time (hh:mm)
23: (Factory Reserved)
24: (Factory Reserved)
25: (Factory Reserved)
26: The signal of AI1 analog input
27: (Factory Reserved)
28: (Factory Reserved)
29: (Factory Reserved)
30～33: (Factory Reserved)
34: Over-Torque detection level 1 (Pr5-16)
35: Motor 1 Auto torque boost (Pr5-01)
36~37: (Factory Reserved)
38: Stall level while run in constant torque area
(Pr5-12)
39〜52: (Factory Reserved)
53: Output power (kW)
54: Output capacity (kVA)
55：(Factory Reserved)
56: The temperature of IGBT module--TH1 ( °C)
57: The temperature of environment or fin (TH2)
(°C)
58: (Factory Reserved)
59: (Factory Reserved)
60: Drive overload accumulated time (OL)
61~63：(Factory Reserved)
64: DC Bus voltage upon a fault (Vdc)
65: Output voltage upon a fault (Vac)
66: Output frequency upon a fault (Hz)
67: IGBT module temperature upon a fault
( °C) ◎
68: Output current value upon a fault (Aac)
69︰Temperature of Fin or environment
upon a fault ( °C) ◎
70~86︰(Factory Reserved)
87: DC Bus ripple voltage (Vdc) ◎
88: (Factory Reserved) ◎
Pr0-08
User-Defined coefficient
K
0～39 (no use) 0
40～60000 (the corresponding value for Pr1-00-- the
max. frequency).
Pr0-09
The decimal places 0~3 (0=Without d.p., 1= 1 digit d.p., 2=2 digit d.p.,
3=3 digit d.p.) 0
Pr0-10
Firmware version Read-only x.xx
Pr0-11 EPROM store set
Bit 0
(bxxxx0)
0: FWD/REV direction command will be
store
b00000
1: FWD/REV direction command not
store
Bit 1
(bxxx0x)
0: Frequency command from PU will be
store
1: Frequency command from PU not
store
Bit 2
(bxx0xx)
0: RS-485 frequency command will be
store
1: RS-485 frequency command not store
Bit 3
(bx0xxx)
0: Up/Down frequency command will be
store
1: Up/Down frequency command not
store

TOPVERT L1Series
E-
15
Bit 4
(b0xxxx)
0: Changed parameter will be store
1: Changed parameter not store
Pr0-12
Auto Accelerate/
Decelerate
0: Linear Acc, linear Dec.
0
1: Auto Acc, linear Dec.
2: Linear Acc, auto Dec.
3: Auto Acc, auto Dec.
4: Linear Acc,/Dec., auto to prevent stall.
★
Pr0-13
Accelerate/ Decelerate
time unit
0: 0.01 Second 01: 0.1 Second
2: 1 Second
Pr0-14
PWM Carrier frequency
upper bound 0=0.7kHz 10
1～18kHz
Pr0-15
PWM Carrier frequency
lower bound 0=0.7kHz 10
1～18kHz
Pr0-16
Automatic Voltage
Regulation (AVR)
0: Enable Automatic Voltage Regulation
0
1: Disable Automatic Voltage Regulation
2: Disable Automatic Voltage Regulation while in
cancel
Pr0-17
Automatic Energy-Saving
Operation (AESO)
and others
Bit 0
(bxxxx0)
0: Disable Automatic Energy-Saving
Operate
b00000
1: Enable Automatic Energy-Saving
Operate
Bit 1
(bxxx0x)
0: Allow output voltage over source
voltage
1: Maximum output voltage equals to
source voltage
Bit 2
(bxx0xx)
0: For constant torque load application.
1: For variable torque load application.
Bit 3
(bx0xxx)
0: Regen-torque no slip compensation
1: Regen-torque with slip compensation
Bit 4
(b0xxxx)
0: Low noise mode operation
1: Quiet mode operation
Pr0-18
Source of the frequency
command
0: From PU
0
1: From RS485 communication port
2: From external analog signal
3: From external Up/Down terminals
4: (Factory Reserved) ◎
Pr0-19
Source of the operation
command
0: From RS485 communication port or PU
0
1: From external terminals or PU
2: From PU
3: From external terminals
Pr0-20
Stop/ Run/safety lockout
Bit 0
(bxxxx0)
0: Ramp to stop
b00000
1: Coast to stop
Bit 1
(bxxx0x)
0: Terminal command not run after reset
1: Terminal command restart after reset
Bit 2
(bxx0xx)
0: Line start Lockout is enabled
1: Line start Lockout is disabled
Bit 3
(bx0xxx)
0: FWD/REV go through zero point
1: FWD/REV go not through zero point
Bit 4
(b0xxxx)
0: Linear Accel/Decel at high speed
zone
1: S-curve Accel/Decel at high speed
zone
Pr0-21
Direction limit 0: Enable Forward/Reverse operation 0
1: Disable Reverse operation
2: Disabled Forward operation

TOPVERT L1Series
E-
16
Pr0-22
Waiting time to restart
after stop 0.00~60.00sec 0.00
Pr0-23
Cooling fan control & PID
direction
Bit 0
(bxxxx0)
0: Fan on while power on
b00000
1: Fan on while run command effect
Bit 1
(bxxx0x)
(Factory Reserved)
Bit 2
(bxx0xx)
(Factory Reserved)
Bit 3
(bx0xxx)
0: PID reverse operation allow
1: PID reverse operation not allow
Bit 4
(b0xxxx)
(Factory Reserved)
Pr0-24 Resolution of dial
0=0.01 Hz
1
1=0.10Hz
2=1.00Hz
3=10.00 Hz
★
◎
Pr0-25 Parameter select 0: Team A 0 1: Team B
2: (Factory Reserved)
Group 1: Basic parameters
Paramet
ers Functions Settings Factory Setting User
★
Pr1-00 Maximum operation frequency 3.00～600.00Hz 60.00/50.00
★
Pr1-01 1st Frequency 1 (Fbase 1)
(Base frequency 1 ) 0.00～600.00 Hz 60.00/50.00
Pr1-02 1st Voltage 1 (Vbase 1)
(Motor rated voltage 1) 230V models:
0.0～255.0V 460V models: 0.0～510.0V 230V:230.0 460V:460.0
★
Pr1-03 2nd Frequency 1 (Fmid 1)
(Middle frequency 1) 0.00～600.00 Hz 0.50
Pr1-04 2nd Voltage 1 (Vmid 1)
(Middle voltage 1) 230V models:
0.0～255.0V 460V models: 0.0～510.0V 230V:5.0 460V:10.0
★
Pr1-05 3rd Frequency 1 (Flow 1)
(Low-point frequency 1) 0.00～600.00 Hz 0.50
Pr1-06 3rd Voltage 1 (Vlow 1)
(Low-point voltage 1) 230V models:
0.0～255.0 460V models: 0.0～510.0V 230V:5.0 460V:10.0
Pr1-07 0Hz Voltage 1 (V0Hz 1)
(Output voltage at 0Hz) 230V models: 0.0～25.5 460V models: 0.0～51.0V 0.0
Pr1-08 Start-up frequency 0.00～600.00 Hz 0.50
Pr1-09 Output frequency Upper limit 0.0～150.0% of Maximum operation
frequency (Pr1-00) 110.0
Pr1-10 Output Frequency Lowerl limit 0.0～100.0% of Maximum operation
frequency (Pr1-00) 0.0
Pr1-11 1
st
Acceleration time 0.00～60000 Sec 10.00/60.00
Pr1-12 1
st
Deceleration time 0.00～60000 Sec 10.00/60.00
Pr1-13 2
nd
Acceleration time 0.00～60000 Sec 10.00/60.00
Pr1-14 2
nd
Deceleration time 0.00～60000 Sec 10.00/60.00
Pr1-15 (Factory Reserved) (Factory Reserved)
Pr1-16 (Factory Reserved) (Factory Reserved)
Pr1-17 (Factory Reserved) (Factory Reserved)

TOPVERT L1Series
E-
17
Pr1-18 1st/2nd Acceleration/Deceleration
Switching frequency 0.00～600.00 Hz 0.000
Pr1-19 S-Acc. departure time when
accelerate 0.00～12000 Sec 0.00
Pr1-20 S-Acc. arrival time when
accelerate 0.00～12000 Sec 0.00
Pr1-21 S-Dec. departure time when
decelerate 0.00～12000 Sec 0.00
Pr1-22 S-Dec. arrival time when
decelerate 0.00～12000 Sec 0.00
Pr1-23
{Pr1-29}
Offset voltage while decelerate 230V models:
-50.0~50.0 V 460V models: -100.0~100.0 V 0.00
★
Pr1-24
{Pr1-23}
Skip Frequency 1 upper limit 0.00~600.00Hz 0.00
★
Pr1-25
{Pr1-24}
Skip Frequency 1 lower limit 0.00~600.00Hz 0.00
★
Pr1-26
{Pr1-25}
Skip Frequency 2 upper limit 0.00~600.00Hz 0.00
★
Pr1-27
{Pr1-26}
Skip Frequency 2 lower limit 0.00~600.00Hz 0.00
★
Pr1-28
{Pr1-27}
Skip Frequency 3 upper limit 0.00~600.00Hz 0.00
★
Pr1-29
{Pr1-28}
Skip Frequency 3 lower limit 0.00~600.00Hz 0.00
★
◎
◎◎
◎
Pr1-30 Skip Frequency 4 upper limit 0.00～600.00 Hz) 0.00
★
◎
◎◎
◎
Pr1-31 Skip Frequency 4 lower limit 0.00～600.00 Hz 0.00
★
◎
◎◎
◎
Pr1-32 Skip Frequency 5 upper limit 0.00～600.00 Hz 0.00
★
◎
◎◎
◎
Pr1-33 Skip Frequency 5 lower limit 0.00～600.00 Hz 0.00
★
◎
◎◎
◎
Pr1-34 Skip Frequency 6 upper limit 0.00～600.00 Hz 0.00
★
◎
◎◎
◎
Pr1-35 Skip Frequency 6 lower limit 0.00～600.00 Hz 0.00
★
◎
◎◎
◎
Pr1-36 1st Frequency 2 (Fbase 2)
(Base frequency 2 ) 0.00～600.00 Hz 60.00/50.00
◎
◎◎
◎
Pr1-37 1st Voltage 2 (Vbase 2)
(Motor rated voltage 2) 230V models:
0.0～255.0V 460V models: 0.0～510.0V 230V:230
460V:460
★
◎
◎◎
◎
Pr1-38 2nd Frequency 2 (Fmid 2)
(Middle frequency 2) 0.00～600.00 Hz 0.50
★
◎
◎◎
◎
Pr1-39 2nd Voltage 2 (Vmid 2)
(Middle voltage 2) 230V models:
0.0～255.0V 460V models: 0.0～510.0V 230V:5.0
460V:10.0
★
◎
◎◎
◎
Pr1-40 3rd Frequency 2 (Flow 2)
(Low-point frequency 2) 0.00～600.00 Hz 0.50
★
◎
◎◎
◎
Pr1-41 3rd Voltage 2 (Vlow 2)
(Low-point voltage 2) 230V model:
0.0～255.0V 460V model: 0.0～510.0V 230V:5.0
460V:10.0
★
◎
◎◎
◎
Pr1-42 0Hz Voltage 2 (V0Hz 2)
(Output voltage at 0Hz) 230V models:
0.0～25.5 460V models: 0.0～51.0V 0.0

TOPVERT L1Series
E-
18
Group 2: Digital Input/Output parameters
Parame
ters Functions Settings Factory Setting User
★ Pr2-00 External operation 0: 2-wire mode 1- FWD/STOP, REV/STOP 0
1: 2-wire mode 2- RUN/STOP, REV/FWD
2: 3-wire mode -RUN,STOP, FWD/REV
★
Pr2-01
Multi-Function Digital input
MI1 0: No definition 1
★
Pr2-02
Multi-Function Digital input
MI2 1: Multi-step speed command 1 2
★
Pr2-03
(Factory Reserved) 2: Multi-step speed command 2 3
★
Pr2-04
(Factory Reserved) 3: Multi-step speed command 3 4
★
Pr2-05 (Factory Reserved) 4: Multi-step speed command 4 5
★ Pr2-06 (Factory Reserved)
5: External Reset
14
6: Clear counter
7: 1st and 2nd acceleration/ deceleration time
select
8: Acceleration/deceleration inhibit
9: Force the frequency command from AI1
10: (Factory Reserved)
11: (Factory Reserved)
12: Emergency Ramp to stop
13: Disable PID function
14: External fault input (EF)
15: B.B. traces from the bottom upward
16: B.B. traces from the top downward
17: Force operation command to external
18: Cancel the auto acceleration/ deceleration
function
19: (Factory Reserved)
20: (Factory Reserved)
21: (Factory Reserved)
22: Cancel PLC Run
23: Pause PLC Run
24: Up command
25: Down command
26: Zero speed is replaced by DC braking
27: Pause
28: Disable dwell function
29: Disable traverse function
30: Disable Speed search during start-up
31: Disable EEPROM write function
32: Counter Trigger input (MI2 only)
33~41: (Factory Reserved)
42: Motor Select ◎
43: Confirm signal of Motor selection ◎
44: Disable reverse operation ◎
45: Disabled forward operation ◎
Pr2-07 UP/DOWN command mode
Bit 0
(bxxxx0)
0: Up command-Accel by the Acc. time
b00000
1: Up command-Accel by Pr2-08
setting
Bit 1
(bxxx0x)
0: Down Command-Decel by the Dec.
time
1: Down Command-Decel by Pr2-08
setting
Bit 2
(bxx0xx)
(Factory Reserved)
Bit 3
(bx0xxx)
0: FWD/REV terminals act by edge
trigger

TOPVERT L1Series
E-
19
1: FWD/REV terminals act by level
trigger
Bit 4
(b0xxxx)
(Factory Reserved)
Pr2-08
UP/DOWN command rate 0.01
Pr2-09
Digital Input terminal
debounce time 0.001～30.000 Sec 0.005
Pr2-10
Polarity of Digital Input
terminals 00000~007FF h00000
(0=Close circuit enable 1=Open circuit enable)
Pr2-11 Target count value 0～65500 0
Pr2-12
Pre warn count value 0～65500 0
Pr2-13 Digital pulse output gain 1~20 1
Pr2-14
Pre-set arrival frequency 1 0.00～600.00 Hz 60.00/
50.00
Pr2-15
Pre-set arrival frequency 1
bandwidth 0.00～600.00 Hz 2.00
Pr2-16
Pre-set arrival frequency 2 0.00～600.00 Hz 60.00/
50.00
Pr2-17
Pre-set arrival frequency 2
bandwidth 0.00～600.00 Hz 2.00
Pr2-18
Polarity of Digital output
terminals 00000~0003F h00000
◎
Pr2-19
Delay time of Digital output
terminals 0.000~60.000 Sec 0.003
Pr2-20
{Pr2-19}
Multi-Function Digital output
1- Relay 1 0: No definition 11
Pr2-21
{Pr2-20}
(Factory Reserved) 1: Drive in run 1
Pr2-22
{Pr2-21}
(Factory Reserved) 2: Master frequency attained 1
(Both Forward and Reverse) 5
Pr2-23
{Pr2-22}
(Factory Reserved) 3: Master frequency attained 2
(Both Forward and Reverse)
◎
◎◎
◎
Pr2-24 (Factory Reserved) 4: Pre-set speed attained 1
(Both Forward and Reverse) 9
◎
◎◎
◎
Pr2-25 (Factory Reserved) 5: Pre-set speed attained 1
(Forward only) 0
6: Pre-set speed attained 2
(Both Forward and Reverse) 0
7 : Pre-set speed attained 2
(Forward only)
8: Drive in decel
9: Drive ready for operate
10: Low voltage alarm (LU, LUr)
11: Fault Indication
12: Base block (B.B.) Indication
13: Zero Speed (including shutdown)
14: Zero speed (while in run)
15: Terminal count value attained
16: Pre warn count value attained
17: PLC Run running
18: PLC Run paused
19: A step of PLC Run completed
20: PLC Run completed
21: OH1 pre–warning indication
22: Dwell Accel/Decel in execution
23: External operation mode indication
24: Over-torque 1 (ot1)
25: (Factory Reserved)
26: Software brake output (MO1 only)
27: Auxiliary Motor no. 1
