Toro 88515 User manual

FormNo.3379-377RevA
48VBatteryPack/Charger
ModelNo.88515
ModelNo.88516
ModelNo.88517
ModelNo.88519
Operator'sManual
Safety
Importantsafetyinstructions—Savetheseinstructions.
DANGER
Usingthewrongplugforapoweroutletcancause
reorelectricshock.
Useapowercordwiththepropercongurationfor
yourpoweroutlet.
CAUTION
Thebatteryusedinthisdevicemaypresentarisk
ofreorchemicalburnifmistreated.
Donotdisassemble,heatabove50°C(122°F),
orincinerate.ReplacebatterywithTorogenuine
batteriesonly.Useofanotherbatterymaypresenta
riskofreorexplosion.
CAUTION
Disposeofausedbatterypromptly.Keepaway
fromchildren.Donotdisassembleanddonot
disposeofinre.
CAUTION
Overheatingbatteriescancausereandsevere
burns.
Donotopen,crush,heatabove50°C(122°F),or
incinerate.Followthemanufacturer’sinstructions.
•Thisapplianceisnotintendedforusebypersons
(includingchildren)withreducedphysical,sensoryor
mentalcapabilities,orlackofexperienceandknowledge,
unlesstheyhavebeengivensupervisionorinstruction
concerninguseoftheappliancebyapersonresponsible
fortheirsafety.
•Childrenshouldbesupervisedtoensurethattheydonot
playwiththeappliance.
•Donotdismantle,openorshredsecondarycellsor
batterypack.
•Donotexposecellsorbatterypacktoheatorre.Avoid
storageindirectsunlight.
•Donotshort-circuitacellorabatterypack.Donotstore
cellsorbatterypackhaphazardlyinaboxordrawerwhere
theymayshort-circuiteachotherorbeshort-circuitedby
othermetalobjects.
•Donotremoveacellorbatteryfromitsoriginalbattery
packenclosurerequiredforuse.
•Donotsubjectcellsorbatterypacktomechanicalshock.
•Intheeventofacellleaking,donotallowtheliquidto
comeincontactwiththeskinoreyes.Ifcontacthasbeen
made,washtheaffectedareawithcopiousamountsof
waterandseekmedicaladvice.
•Donotuseanychargerotherthanthatspecically
providedforusewiththeequipment.
•Observetheplus(+)andminus(–)marksonthecell,
batteryandequipmentandensurecorrectuse.
•Donotuseanycellorbatterypackwhichisnotdesigned
forusewiththeequipment.
•Donotmixcellsofdifferentmanufacture,capacity,size
ortypewithinadevice.
•Keepcellsandbatterypackoutofthereachofchildren.
•Seekmedicaladviceimmediatelyifacellorabatterypack
hasbeenswallowed.
•Alwayspurchasethecorrectcellorbatteryforthe
equipment.
•Keepcellsandbatterypackcleananddry.
•Wipethecellorbatterypackterminalswithacleandry
clothiftheybecomedirty.
•Secondarycellsandbatterypackneedtobecharged
beforeuse.Alwaysusethecorrectchargerandreferto
themanufacturer’sinstructionsorequipmentmanualfor
propercharginginstructions.
•Donotleaveabatterypackonprolongedchargewhen
notinuse.
•Afterextendedperiodsofstorage,itmaybenecessary
tochargeanddischargethecellsorbatterypackseveral
timestoobtainmaximumperformance.
•Secondarycellsandbatterypackgivetheirbest
performancewhentheyareoperatedatnormalroom
temperature(20°C±5°C).
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedinChina
AllRightsReserved*3379-377*A

•Retaintheoriginalproductliteratureforfuturereference.
•Useonlythecellorbatterypackintheapplicationfor
whichitwasintended.
•Whenpossible,removethebatterypackfromthe
equipmentwhennotinuse.
•Disposeofproperly.
Thispowerunitisintendedtobecorrectlyorientatedina
verticaloroormountedposition.
SafetyandInstructional
Decals
Important:Safetyandinstructiondecalsarelocated
nearareasofpotentialdanger.Replacedamageddecals.
121–7679
1.ReadtheOperator’s
Manual.
3.DonotthrowLithium-Ion
batteriesinthetrash.
2.Donotdisposeofthe
batteryinre.
121–7680
1.ReadtheOperator’s
Manual.
3.DonotthrowLithium-Ion
batteriesinthetrash.
2.Donotdisposeofthe
batteryinre.
121–7676
1.Productismadefor
householduseonly.
3.Donotthrowthecharger
inthetrash.
2.ReadtheOperator’s
Manual.
4.Doubleinsulated
121–7677
1.Productismadefor
householduseonly.
3.Donotthrowthecharger
inthetrash.
2.ReadtheOperator’s
Manual.
4.Doubleinsulated
2

121–7654
ChargingtheBatteryPack
Important:Forbestresults,yourbatterytoolshould
bechargedinalocationwherethetemperatureismore
than5°C(41°F)butlessthan40°C(104°F).Toreduce
theriskofseriouspersonalinjury,donotstoreoutside
orinvehicles.Chargingtimewillbeincreasedifnot
chargedwithinthisrange.
1.Plugthepowercordthatmatchesyourpoweroutlets
intothebatterycharger(Figure1).
2.Turnthebatteryupsidedownandlineupthebattery
terminalwiththeslotinthecharger(Figure1and
Figure2).
Figure1
1.Insertbatteryhere3.Charge/storagemode
switch
2.LEDindicators4.Powercordplug-in
location
3

Figure2
1.LEDindicators(levelof
charge)
3.Batteryterminal
2.Releasebutton4.Testbutton
3.Slidethebatteryintothechargeruntilitclicksinto
place.
4.Toremovethebattery,pressdownontherelease
buttonandslidethebatterybackwardsoutofthe
charger.
5.RefertoFigure3tointerprettheLEDindicatorson
thebatterycharger.
0
0
0
0
Figure3
1.Redlighton;green
lightashing—batteryis
charging.
5.Redlightoff;green
lightashing—batteryis
preparingforstorage.
2.Redlighton;green
lighton—batteryisfully
charged.
6.Redlightoff;greenlight
on—batteryisprepared
forstorage.
3.Redlightashing;green
lightoff—abnormalbattery
temperature(greaterthan
50C(122F)orlessthan0
C(32F).
7.Redlighton;greenlight
off—nobatteryinserted.
4.Charge/storagemode
switch
8.Redlightashing;green
lightashing—batteryis
defective.
Storingalithium-ionbatteryat40%ofitscapacitymaximizes
batterylife.
Usestoragemode(Figure3)whenthebatterywillnotbe
usedfor1monthorlonger.
1.Insertthebatteryintothecharger.
2.Turnstoragemodeon.
3.Thebatterywillchargeordischargeasnecessaryto
approximately40%charge.
4.Whenthebatteryisreadyforstorage(Figure3),
removethebatteryfromthecharger.
4

InsertingtheBatteryIntothe
Trimmer
1.Alignthetongueofthebatterypackwiththecavityin
thehandlehousing(Figure4).
Figure4
1.Triggerhandle3.Latch
2.Tongue
2.Graspthetriggerhandle(Figure4).
3.Pushthebatterypackintothehandleuntilthelatch
locksintoplace.
Important:Thebatterypackisnotfullychargedwhen
itispurchased.Beforeusingthetrimmerfortherst
time,placethebatterypackinthechargerandchargeit
untiltheLEDdisplayindicatesthebatteryischarged.
Makesuretoreadallsafetyprecautions.Withregular
use,itwillneedshorterchargingtime.Ifstoringfor1
monthorlonger,removethebatteryandusestorage
mode((page)).Whenreadytouseagain,chargethe
batterypackuntiltheLEDdisplayindicatesthebattery
ischarged.
BatteryPackPreparationFor
Recycling
WARNING
Uponremoval,coverthebatterypack'sterminals
withheavy-dutyadhesivetape.Donotattemptto
destroyordisassemblethebatterypackorremove
anyofitscomponents.Lithium-ionbatteriesmust
berecycledordisposedofproperlyatthenearest
batteryrecyclingfacility.
Troubleshooting
Usingthebatterywhenitishotcanreducetheoperating
time.Thebatterywillautomaticallystopworkingwhenit
isoverheatedtopreventdamagetoit.Removethebattery
fromthechargerandallowittocoolbeforeplacingitback
intothetrimmer.
Usingthebatterywhenthereismoistureontheleadscan
causethetrimmertomalfunction.Allowthebatterytodryor
wipeitdrybeforeplacingitbackintothetrimmer.
5
