FormNo.3430-923RevA
StumpGrinder
CompactToolCarrier
ModelNo.22429—SerialNo.404320000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3430-923*A

ThisproductcomplieswithallrelevantEuropean
directives.Fordetails,pleaseseetheDeclarationof
Incorporation(DOI)atthebackofthispublication.
WARNING
CALIFORNIA
Proposition65Warning
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
ThismachineisdesignedforuseonT orocompact
toolcarrierstogrindandremovetreestumpsand
surfaceroots.Itisnotintendedtocutrockoranyother
materialotherthanwoodandthesoilaroundastump.
Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactT orodirectlyatwww.T oro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorT oroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.
g245347
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2019—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

Contents
Safety.......................................................................3
GeneralSafety...................................................3
SlopeSafety.......................................................3
StumpGrinderSafety.........................................4
MaintenanceandStorageSafety........................4
SafetyandInstructionalDecals..........................5
Setup........................................................................6
1PreparingtheTractionUnit..............................6
2InstallingtheShieldBrackets...........................6
3AssemblingtheOperatorShield.......................9
4InstallingtheChipGuard................................10
ProductOverview....................................................11
Specications...................................................11
Operation.................................................................11
InstallingandRemovingtheAttachment............11
GrindingStumps...............................................12
GrindingRoots.................................................13
TransportPosition............................................13
TransportingtheStumpGrinderona
Trailer............................................................13
OperatingTips.................................................13
Maintenance...........................................................14
RecommendedMaintenanceSchedule(s)...........14
GreasingtheMachine.......................................14
ReplacingtheTeeth..........................................15
Storage...................................................................16
Troubleshooting......................................................17
Safety
DANGER
Theremaybeburiedutilitylinesinthework
area.Diggingintothemmaycauseashock
oranexplosion.
Havethepropertyorworkareamarkedfor
buriedlinesanddonotdiginmarkedareas.
Contactyourlocalmarkingserviceorutility
companytohavethepropertymarked(for
example,intheUS,call811orinAustralia,
call1100forthenationwidemarkingservice).
GeneralSafety
Alwaysfollowallsafetyinstructionstoavoidserious
injuryordeath.
•Donottransportanattachmentwiththearms
raised.Alwaystransporttheattachmentcloseto
theground;refertoTransportPosition(page13).
•Havethepropertyorworkareamarkedforburied
linesandotherobjects,anddonotdiginmarked
areas.
•ReadandunderstandthecontentofthisOperator’s
Manualbeforestartingtheengine.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Neverallowchildrenoruntrainedpeopleto
operatethemachine.
•Keepyourhandsandfeetawayfromthemoving
componentsandattachments.
•Donotoperatethemachinewithouttheguards
andothersafetyprotectivedevicesinplaceand
workingonthemachine.
•Keepbystandersandpetsawayfromthemachine.
•Stopthemachine,shutofftheengine,andremove
thekeybeforeservicing,fueling,orunclogging
themachine.
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol,which
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
SlopeSafety
•Operatethemachineupanddownslopeswith
theheavyendofthemachineuphill.Weight
distributionchangeswithattachments.This
3

attachmentmakesthefrontofmachinetheheavy
end.
•Keeptheattachmentintheloweredposition
whenonslopes.Raisingtheattachmentona
slopeaffectsthestabilityofthemachine.
•Slopesareamajorfactorrelatedtolossofcontrol
andtip-overaccidents,whichcanresultinsevere
injuryordeath.Operatingthemachineonany
slopeoruneventerrainrequiresextracaution.
•Establishyourownproceduresandrulesfor
operatingonslopes.Theseproceduresmust
includesurveyingthesitetodeterminewhich
slopesaresafeformachineoperation.Always
usecommonsenseandgoodjudgmentwhen
performingthissurvey.
•Slowdownanduseextracareonhillsides.Ground
conditionscanaffectthestabilityofthemachine.
•Avoidstartingorstoppingonaslope.Ifthe
machinelosestraction,proceedslowly,straight
downtheslope.
•Avoidturningonslopes.Ifyoumustturn,turn
slowlyandkeeptheheavyendofthemachine
uphill.
•Keepallmovementsonslopesslowandgradual.
Donotmakesuddenchangesinspeedor
direction.
•Ifyoufeeluneasyoperatingthemachineona
slope,donotdoit.
•Watchforholes,ruts,orbumps,asuneventerrain
couldoverturnthemachine.Tallgrasscanhide
obstacles.
•Usecautionwhenoperatingonwetsurfaces.
Reducedtractioncouldcausesliding.
•Evaluatetheareatoensurethatthegroundis
stableenoughtosupportthemachine.
•Usecautionwhenoperatingthemachinenearthe
following:
–Drop-offs
–Ditches
–Embankments
–Bodiesofwater
Themachinecouldsuddenlyrolloverifatrack
goesovertheedgeortheedgecavesin.Maintain
asafedistancebetweenthemachineandany
hazard.
•Donotremoveoraddattachmentsonaslope.
•Donotparkthemachineonahillsideorslope.
StumpGrinderSafety
•Forwheeledmachines,donotusethe
counterweightonthetractionunitwhenusingthe
stumpgrinder.
•Neveroperatethestumpgrinderwithouttheshield
installedonthetractionunitandthechipguard
onthegrinder.
•Keepallbystandersatleast9m(30ft)awayfrom
theworkarea.
•Onlyusethestumpgrinderforgrindingstumps
lessthan91cm(36inch)tall.
MaintenanceandStorage
Safety
•Checkfastenersatfrequentintervalsforproper
tightnesstoensurethattheequipmentisinsafe
operatingcondition.
•RefertotheOperator’sManualforimportant
detailsifyoustoretheattachmentforanextended
periodoftime
•Maintainorreplacesafetyandinstructionlabels,
asnecessary.
4

SafetyandInstructional
Decals
Safetydecalsandinstructionsare
easilyvisibletotheoperatorandare
locatednearanyareaofpotential
danger.Replaceanydecalthatis
damagedormissing.
decal133-8061
133-8061
decal136-5814
136-5814
1.Warning—readthe
Operator'sManual.
3.Thrownobject
hazard—keepallguards
andshieldsinplace;keep
bystandersawayfromthe
machine.
2.Cutting/dismemberment
hazardofhands
andfeet,rotating
knives/blades—waitforall
movingpartstostop;keep
allguardsandshieldsin
place.
decal136-5817
136-5817
1.Cutting/dismembermenthazardoffoot,rotating
knives/blades—waitforallmovingpartstostop;keephands
andfeetawayfrommovingparts.
decal136-5818
136-5818
1.Thrownobjecthazard—keepallguardsandshieldsin
place;keepbystandersawayfromthemachine.
5

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethetractionunit.
Rightshieldbracket(3holes)—200/300
SeriesorTX400/500Seriesonly1
Leftshieldbracket(3holes)—200/300
SeriesorTX400/500Seriesonly1
Self-tappingscrew(5/16x3/4inch)4
Rightshieldbracket(2holes)—TX1000
only1
Leftshieldbracket(2holes)—TX1000
only1
Bolt(1/4x3/4inch)—TX1000only4
2
Locknut(1/4inch)—TX1000only4
Installtheshieldbrackets.
Shieldsupport(1bend)—200/300
SeriesorTX400/500Series2
Shieldsupport(2bends)—TX1000only2
Shield1
Bolt(1/4x1-1/2inch)8
Washer8
3
Locknut(1/4inch)8
Assembletheoperatorshield.
Chipguard1
Guardpin1
4Hairpincotter1
Installthechipguard.
1
PreparingtheTractionUnit
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Lowertheloaderarms.
3.Engagetheparkingbrake(ifapplicable).
4.Shutofftheengineandremovethekey.
6

2
InstallingtheShield
Brackets
Partsneededforthisprocedure:
1Rightshieldbracket(3holes)—200/300SeriesorTX
400/500Seriesonly
1Leftshieldbracket(3holes)—200/300SeriesorTX
400/500Seriesonly
4Self-tappingscrew(5/16x3/4inch)
1Rightshieldbracket(2holes)—TX1000only
1Leftshieldbracket(2holes)—TX1000only
4Bolt(1/4x3/4inch)—TX1000only
4Locknut(1/4inch)—TX1000only
200or300SeriesTractionUnit
Only
Important:Usetheshieldbracketswith3holes.
1.Insertthetabontheshieldbracketintothe
lift-pointholeonthetractionunit,withthehole
inthebracketaligningwiththesmallholeinthe
tractionunitframe(Figure3).
Note:Thereisarightandleftbracket.Ensure
thatyouinstallthecorrectbracketoneachside.
Thetabshouldbeinthelift-pointholeandthe
bracketshouldbeontheoutsideoftheframe
(Figure3).
g013653
Figure3
1.Shieldbracket3.Tab
2.Lift-pointhole4.Self-tappingscrew
2.Securethebrackettotheframewitha
self-tappingscrew(Figure3).
3.Repeatsteps1and2fortheothersideofthe
tractionunit.
TX400or500SeriesTractionUnit
Only
Important:Usetheshieldbracketswith3holes.
1.Measureinfromtheedgesoftheframeas
illustratedinFigure4andmarkthelocationsof
theholesformountingtheshieldbracket.
Note:Iftheholesexist,skiptostep3.
g203568
Figure4
1.4.6cm(1.8inch)3.4.6cm(1.8inch)
2.1.4cm(0.6inch)4.Mountingholes
2.Drillahole(5/16inch)throughtheframeateach
markedlocation.
3.Alignthetabontheshieldbracketwiththefront
edgeoftheframewiththebracketinsideofthe
loader-armpocket(Figure5).
Note:Thereisarightandleftbracket.Ensure
thatyouinstallthecorrectbracketoneachside.
Thetabshouldbeovertheframeedgeandthe
bracketshouldbeinsidetheloader-armpocket
withthe2smallerholesinthebracketlinedup
withtheholesyoudrilledintheframe(Figure5).
7

g013655
Figure5
1.Self-tappingscrew2.Shieldbracket
4.Securethebrackettotheframewith2
self-tappingscrewsasillustratedinFigure5.
5.Repeatsteps1through4fortheothersideof
thetractionunit.
TX1000TractionUnitOnly
Important:Usetheshieldbracketswith2holes.
1.Measureinfromtheedgesoftheframeas
illustratedinFigure6andmarkthelocationsof
theholesformountingtheshieldbracket.
Note:Iftheholesexist,skiptostep3.
g245655
Figure6
1.7.0cm(2-3/4inch)4.Hole
2.5.7cm(2-1/4inch)5.Referencebar
3.1.3cm(1/2inch)
2.Drillahole(9/32inch)throughtheframeateach
markedlocation.
3.Installtheleftshieldbracketontheleftframe
using2bolts(1/4x3/4inch)and2Locknuts(1/4
inch)asshowninFigure7.
g202825
Figure7
1.Bolts(1/4x3/4inch)3.Locknut(1/4inch)
2.Leftshieldbracket
4.Installtherightshieldbracketontherightframe
2bolts(1/4x3/4inch)and2locknuts(1/4inch),
similartoFigure7.
8

3
AssemblingtheOperator
Shield
Partsneededforthisprocedure:
2Shieldsupport(1bend)—200/300SeriesorTX
400/500Series
2Shieldsupport(2bends)—TX1000only
1Shield
8Bolt(1/4x1-1/2inch)
8Washer
8Locknut(1/4inch)
AssemblingtheShield
Note:Usetheshieldsupportswith1bendfor
200/300seriesorTX400/500seriestractionunits.
Usetheshieldsupportswith2bendsforTX1000
tractionunits.
1.Slidetheshieldsupportsintothepocketsinthe
shieldbracketsonthetractionunit(Figure8or
Figure9).
g202610
Figure8
200/300SeriesorTX400/500SeriesTractionUnits
1.Locknut(8)5.Skirt
2.Washer(8)6.Shieldsupport(2)
3.Shield7.Shieldbracket(2)
4.Bolt(8)
9

g202842
Figure9
TX1000TractionUnitsOnly
1.Locknut(8)5.Skirt
2.Washer(8)6.Shieldsupport(2)
3.Shield7.Shieldbracket(2)
4.Bolt(8)
2.Assembletheshieldandexibleskirttothe
shieldsupportsasillustratedinFigure8or
Figure9,using8bolts(1/4x1-1/2inch),8
washers,and8locknuts(1/4inch).
Note:Theskirtshoulddrapeovertheengine
orhood.
4
InstallingtheChipGuard
Partsneededforthisprocedure:
1Chipguard
1Guardpin
1Hairpincotter
Procedure
Thestumpgrinderhas4setsofmountingholesfor
positioningthechipguard(Figure10).Movethe
guardup(upperholes)whenyouaregrindingclose
tothegroundanddown(lowerholes)whenyouare
chippingtallstumps.Installthechipguardasfollows:
1.Positionthemountingtubeontheguard
between2holesonthegrinder(Figure10).
g202609
Figure10
1.Guardpin4.Mountingtube
2.Mountingholes5.Hairpincotter
3.Chipguard
2.Slidetheguardpinthroughtheholesinthe
grinderandthemountingtube(Figure10).
3.Securethepinwithahairpincotter(Figure10).
10

ProductOverview
g013651
Figure11
1.Chipguard4.Stumpgrindinghead
2.Mountingplate5.Teeth
3.Pivotbolt
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Width(withchipguard)112cm(44inches)
Width(withoutchipguard)66cm(26inches)
Length51cm(20inches)
Height79cm(31inches)
Weight120kg(265lb)
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
Operation
InstallingandRemoving
theAttachment
RefertotheOperator’sManualforthetractionunitfor
theinstallationandremovalprocedure.
Important:Beforeinstallingtheattachment,
positionthemachineonalevelsurface,ensure
thatthemountplatesarefreeofanydirtordebris,
andensurethatthepinsrotatefreely.Ifthepins
donotrotatefreely,greasethem.
Note:Alwaysusethetractionunittoliftandmove
theattachment.
WARNING
Ifyoudonotfullyseatthequick-attach
pinsthroughtheattachmentmountplate,
theattachmentcouldfalloffthemachine,
crushingyouorbystanders.
Ensurethatthequick-attachpinsarefully
seatedintheattachmentmountplate.
WARNING
Hydraulicuidescapingunderpressurecan
penetrateskinandcauseinjury.Fluidinjected
intotheskinmustbesurgicallyremoved
withinafewhoursbyadoctorfamiliarwith
thisformofinjury;otherwise,gangrenemay
result.
•Ensurethatallhydraulic-uidhoses
andlinesareingoodconditionandall
hydraulicconnectionsandttingsaretight
beforeapplyingpressuretothehydraulic
system.
•Keepyourbodyandhandsawayfrom
pinholeleaksornozzlesthateject
high-pressurehydraulicuid.
•Usecardboardorpapertondhydraulic
leaks;neveruseyourhands.
11

CAUTION
Hydrauliccouplers,hydrauliclines/valves,
andhydraulicuidmaybehot.Ifyoucontact
hotcomponents,youmaybeburned.
•Weargloveswhenoperatingthehydraulic
couplers.
•Allowthemachinetocoolbeforetouching
hydrauliccomponents.
•Donottouchhydraulicuidspills.
GrindingStumps
WARNING
Duringoperation,debrisyinalldirections
andcancauseinjurytoeyesandother
exposedbodyparts.
•Neveroperatethestumpgrinderwithout
theshieldinstalledonthetractionunitand
thechipguardonthegrinder.
•Duringoperation,weareyeprotection,
hearingprotection,substantial,
slip-resistantfootwear,andlong
pants.
•Keepallbystandersatleast9m(30ft)
awayfromtheworkarea.
1.Ifyourtractionunithasaspeedselector,move
ittotheSLOWposition.
2.Starttheengine.
3.Pulltheauxiliaryhydraulicslevertotheoperator
griptoengagethestumpgrinder.
4.Positionthegrinderontheleftsideandbehind
thestump(Figure12).
g013658
Figure12
5.Swingthegrindertowardyouusingthe
attachment-tiltlever,grindingatadepthof0.5
to5cm(1/4to2inches),dependingonthe
hardnessofthewood(Figure12).
Note:Ifyoucuttoodeep,thegrinderstalls.Ifit
stalls,raiseitslightlyandtryagain.
6.Swingthegrinderbackout(Figure12),lowerit
0.5to5cm(1/4to2inches),andrepeatsteps
4through6untilyouhavegrounddownafew
inches.
7.Raisetheloaderarmstotheoriginalheight.
8.Movethegrindertotheright(Figure12).
9.Repeatsteps4through8untilyoureachthe
rightsideofthestump.
10.Returnthegrindertotheleftsideofthestump,
lowerit,andrepeatsteps3through10untilyou
havegroundthestumpintotheground.
Note:Tocontainthechips,youmayneedto
stopthegrinderandmovethechipguardupas
youmovethegrinderdown.
11.Whennished,stopthegrinderbymoving
theauxiliaryhydraulicslevertotheNEUTRAL
position.
12

GrindingRoots
1.Stopthegrinderandhangitverticallyfromthe
loaderarmsafewcentimeters(inches)offthe
ground.
2.Shutofftheengineandremovethekey.
3.Loosenthelargeboltonthetopofthegrinder
(Figure13).
g013659
Figure13
1.Largebolt—loosen2.Frontbolt—remove
4.Removethefrontboltandnutsecuringthe
grinder(Figure13).
5.Swingthegrinder30degreesclockwise(Figure
13).
6.Torquethelargeboltontopofthegrinderto406
N∙m(300ft-lb)asshowninFigure13.
7.Installtheboltandnutinthefrontholeand
torquethemto101N∙m(75ft-lb)asshownin
Figure13.
8.Startthetractionunitandstartthegrinder.
9.Lowerthegrinderintotheroot.
10.Movethegrinderalongthelengthoftherootby
movingthetractionunitovertheroot.
11.Whennished,stopthegrinderbymoving
theauxiliaryhydraulicslevertotheNEUTRAL
position.
12.Shutofftheengineandremovethekey.
13.Loosenthelargeboltonthetopofthegrinder
(Figure13).
14.Removethefrontboltandnutsecuringthe
grinder(Figure13).
15.Swingthegrinder30degreescounter-clockwise
(Figure13).
16.Torquethelargeboltontopofthegrinderto406
N∙m(300ft-lb)asshowninFigure13.
17.Installtheboltandnutinthefrontholeand
torquethemto101N∙m(75ft-lb)asshownin
Figure13.
TransportPosition
Whentransportingtheattachment,keepitasclose
tothegroundaspossible,nomorethan15cm(6
inches)abovetheground.Tiltitrearward.
g245446
Figure14
1.Nomorethan15cm(6
inches)abovetheground
2.Tilttheattachment
rearward.
TransportingtheStump
GrinderonaTrailer
Placetheattachmentonatrailerortruckcapableof
carryingit.Securelytieittothetrailerortruckusing
tiestrapsappropriatefortheweightoftheattachment
andforhighwayuse.
Important:Removetheoperator'sshieldbefore
transportingthetractionunittoavoiddamageto
theshieldofthetractionunit.
OperatingTips
•Alwaysusefullthrottle(maximumenginespeed).
•Nevertransporttheattachmentwiththeloader
armsraised.Keepthearmsloweredandthe
attachmenttiltedup.
•Ifyourtractionunithasaspeedselector(present
onsomewheeledtractionunits),setittotheSLOW
(turtle)position.
•Ifyourtractionunithasaowdivider(present
onsomewheeledtractionunits),adjustitto
approximatelythe10o’clockposition.
13

Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Beforeeachuseordaily•Greasethemachine.
•Checktheconditionoftheteethandrotateorreplaceanythatarewornordamaged.
Beforestorage•Greasethemachine.
•Paintchippedsurfaces.
GreasingtheMachine
ServiceInterval:Beforeeachuseordaily
Beforestorage
GreasethettinginFigure15.
g203602
Figure15
GreaseType:General-purposegrease
1.Parkthemachineonalevelsurface,lowerthe
loaderarms,andengagetheparkingbrake(if
applicable).
2.Shutofftheengineandremovethekey.
3.Cleanthegreasettingwitharag.
4.Connectagreaseguntothetting.
5.Pumpgreaseintothettinguntilgreasebegins
tooozeoutofthebearings.
6.Wipeupanyexcessgrease.
14

ReplacingtheTeeth
ServiceInterval:Beforeeachuseordaily—Check
theconditionoftheteethandrotate
orreplaceanythatarewornor
damaged.
Duetothehighamountofwearplacedontheteeth,
youwillneedtorotateandreplacethemperiodically.
Eachtoothisindexedwith3positionssothatyoucan
rotateittwice,exposinganewsharpedgebefore
replacingthetooth.
g034325
Figure16
1.Sharptooth2.Worntooth
Torotateatooth,loosenthenutsecuringthetooth
(Figure17).Pushthetoothforwardandrotateitone
thirdofaturn,bringinganunusededgetotheoutside.
Torquethenutsecuringthetoothto37to45N∙m(27
to33ft-lb).
g246708
Figure17
(Yourgrinder'sappearancemayvaryfromthatshownin
theillustration)
1.Nut3.Toothholder
2.Spacer4.Tooth
Toreplaceatooth,removethenutsecuringthetooth
toremoveit,theninstallanewtoothandnutinthe
sameposition(Figure17).Torquethenutsecuring
thetoothto37to45N∙m(27to33ft-lb).
15

Storage
1.Beforelong-termstorage,washtheattachment
withmilddetergentandwatertoremovedirtand
grime.
2.Checktheconditionoftheteeth.Turnorreplace
anywornordamagedteeth.
3.Checkandtightenallbolts,nuts,andscrews.
Repairorreplaceanydamagedorwornpart.
4.Ensurethatallhydrauliccouplersareconnected
togethertopreventcontaminationofthe
hydraulicsystem.
5.Paintallscratchedorbaremetalsurfaces.Paint
isavailablefromyourAuthorizedServiceDealer.
6.Storetheattachmentinaclean,drygarageor
storagearea.Coverittoprotectitandkeepit
clean.
16

Troubleshooting
ProblemPossibleCauseCorrectiveAction
1.Youarecuttingtoodeep.1.Raisetheloaderarms13mm(1/2
inch).
Thecuttingdiskstopsduringcutting.
2.Teethareworn,damaged,orbroken.2.Rotateorreplaceanyworn,damaged,
orbrokenteeth.
1.Ahydrauliccouplerisnotcompletely
connected.
1.Checkandtightenallcouplers.
2.Ahydrauliccouplerisdamaged.2.Check/replacecouplers.
3.Thereisanobstructioninahydraulic
hose.
3.Findandremovetheobstruction.
4.Anauxiliaryvalveonthetractionunit
isnotopening.
4.Repairthevalve.
5.Thehydraulicmotorordrivehasfailed.5.ContactyourAuthorizedService
Dealer.
Thecuttingdiskdoesnotturnorturns
slowly.
6.Thecheckvalvebrakeisreversed.6.Reversethecheckvalvedirection;
contactyourAuthorizedService
Dealer.
1.Teethareworn.1.Rotateorreplaceanywornteeth.
2.Thesettingiswrongontheowdivider
andspeedlever(applicablewheeled
unitsonly).
2.Settheowdividertothe10o’clock
positionandthespeedlevertothe
turtleposition.
3.Thereisarestrictioninaquickcoupler
orhose.
3.Checkthehosesandcouplersand
repairanyproblemsfound.
4.Thehydraulicsystemistoohot.4.Shutthesystemdownandallowitto
cool.
Thegrinderdoesnotcutfastenough.
5.Thereliefvalveissetbelow
specications.
5.ContactyourAuthorizedService
Dealer.
1.Theauxiliary-valveleverisinthe
wrongposition.
1.Movetheauxiliary-valvelevertothe
rearwardposition.
Thecuttingdiskturnsinthewrong
direction.
2.Thehydraulichosesarereversed.2.Disconnectthehosesandswitch
positions.
17

DeclarationofIncorporation
TheToroCompany,8111LyndaleAvenueSouth,Bloomington,MN,USAdeclaresthatthefollowingunit(s)
conform(s)tothedirectiveslisted,wheninstalledinaccordancewiththeaccompanyinginstructionsontocertain
ToromodelsasindicatedontherelevantDeclarationsofConformity.
ModelNo.SerialNo.ProductDescriptionInvoiceDescriptionGeneralDescriptionDirective
22429404320000andUpStumpGrinderSTUMPGRINDER
ATTACHMENTCEStumpGrinder2006/42/EC
RelevanttechnicaldocumentationhasbeencompiledasrequiredperPartBofAnnexVIIof2006/42/EC.
Wewillundertaketotransmit,inresponsetorequestsbynationalauthorities,relevantinformationonthispartly
completedmachinery.Themethodoftransmissionshallbeelectronictransmittal.
ThismachineryshallnotbeputintoserviceuntilincorporatedintoapprovedToromodelsasindicatedonthe
associatedDeclarationofConformityandinaccordancewithallinstructions,wherebyitcanbedeclaredin
conformitywithallrelevantDirectives.
Certied:AuthorizedRepresentative:
MarcelDutrieux
ManagerEuropeanProductIntegrity
ToroEuropeNV
Nijverheidsstraat5
2260Oevel
Belgium
JoeHager
Sr.EngineeringManager
8111LyndaleAve.South
Bloomington,MN55420,USA
February18,2019

EuropeanPrivacyNotice
TheInformationT oroCollects
ToroWarrantyCompany(Toro)respectsyourprivacy.Inordertoprocessyourwarrantyclaimandcontactyouintheeventofaproductrecall,weaskyou
tosharecertainpersonalinformationwithus,eitherdirectlyorthroughyourlocalT orocompanyordealer.
TheT orowarrantysystemishostedonserverslocatedwithintheUnitedStateswhereprivacylawmaynotprovidethesameprotectionasapplies
inyourcountry.
BYSHARINGYOURPERSONALINFORMATIONWITHUS,YOUARECONSENTINGTOTHEPROCESSINGOFYOURPERSONALINFORMATION
ASDESCRIBEDINTHISPRIVACYNOTICE.
TheWayT oroUsesInformation
Toromayuseyourpersonalinformationtoprocesswarrantyclaims,tocontactyouintheeventofaproductrecallandforanyotherpurposewhichwetell
youabout.T oromayshareyourinformationwithToro'safliates,dealersorotherbusinesspartnersinconnectionwithanyoftheseactivities.Wewillnot
sellyourpersonalinformationtoanyothercompany.Wereservetherighttodisclosepersonalinformationinordertocomplywithapplicablelawsand
withrequestsbytheappropriateauthorities,tooperateoursystemsproperlyorforourownprotectionorthatofotherusers.
RetentionofyourPersonalInformation
Wewillkeepyourpersonalinformationaslongasweneeditforthepurposesforwhichitwasoriginallycollectedorforotherlegitimatepurposes
(suchasregulatorycompliance),orasrequiredbyapplicablelaw.
Toro'sCommitmenttoSecurityofY ourPersonalInformation
Wetakereasonableprecautionsinordertoprotectthesecurityofyourpersonalinformation.Wealsotakestepstomaintaintheaccuracyandcurrent
statusofpersonalinformation.
AccessandCorrectionofyourPersonalInformation
Ifyouwouldliketorevieworcorrectyourpersonalinformation,pleasecontactusbyemailat[email protected].
AustralianConsumerLaw
AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oroDealer.
374-0282RevC

CaliforniaProposition65WarningInformation
Whatisthiswarning?
Youmayseeaproductforsalethathasawarninglabellikethefollowing:
WARNING:CancerandReproductiveHarm—www.p65Warnings.ca.gov.
WhatisProp65?
Prop65appliestoanycompanyoperatinginCalifornia,sellingproductsinCalifornia,ormanufacturingproductsthatmaybesoldinorbroughtinto
California.ItmandatesthattheGovernorofCaliforniamaintainandpublishalistofchemicalsknowntocausecancer,birthdefects,and/orother
reproductiveharm.Thelist,whichisupdatedannually,includeshundredsofchemicalsfoundinmanyeverydayitems.ThepurposeofProp65isto
informthepublicaboutexposuretothesechemicals.
Prop65doesnotbanthesaleofproductscontainingthesechemicalsbutinsteadrequireswarningsonanyproduct,productpackaging,orliteraturewith
theproduct.Moreover,aProp65warningdoesnotmeanthataproductisinviolationofanyproductsafetystandardsorrequirements.Infact,the
CaliforniagovernmenthasclariedthataProp65warning“isnotthesameasaregulatorydecisionthataproductis‘safe’or‘unsafe.’”Manyofthese
chemicalshavebeenusedineverydayproductsforyearswithoutdocumentedharm.Formoreinformation,gotohttps://oag.ca.gov/prop65/faqs-view-all.
AProp65warningmeansthatacompanyhaseither(1)evaluatedtheexposureandhasconcludedthatitexceedsthe“nosignicantrisklevel”;or(2)
haschosentoprovideawarningbasedonitsunderstandingaboutthepresenceofalistedchemicalwithoutattemptingtoevaluatetheexposure.
Doesthislawapplyeverywhere?
Prop65warningsarerequiredunderCalifornialawonly.ThesewarningsareseenthroughoutCaliforniainawiderangeofsettings,includingbutnot
limitedtorestaurants,grocerystores,hotels,schools,andhospitals,andonawidevarietyofproducts.Additionally,someonlineandmailorder
retailersprovideProp65warningsontheirwebsitesorincatalogs.
HowdotheCaliforniawarningscomparetofederallimits?
Prop65standardsareoftenmorestringentthanfederalandinternationalstandards.TherearevarioussubstancesthatrequireaProp65warning
atlevelsthatarefarlowerthanfederalactionlimits.Forexample,theProp65standardforwarningsforleadis0.5μg/day,whichiswellbelow
thefederalandinternationalstandards.
Whydon’tallsimilarproductscarrythewarning?
•ProductssoldinCaliforniarequireProp65labellingwhilesimilarproductssoldelsewheredonot.
•AcompanyinvolvedinaProp65lawsuitreachingasettlementmayberequiredtouseProp65warningsforitsproducts,butothercompanies
makingsimilarproductsmayhavenosuchrequirement.
•TheenforcementofProp65isinconsistent.
•CompaniesmayelectnottoprovidewarningsbecausetheyconcludethattheyarenotrequiredtodosounderProp65;alackofwarningsfora
productdoesnotmeanthattheproductisfreeoflistedchemicalsatsimilarlevels.
WhydoesToroincludethiswarning?
Torohaschosentoprovideconsumerswithasmuchinformationaspossiblesothattheycanmakeinformeddecisionsabouttheproductstheybuyand
use.T oroprovideswarningsincertaincasesbasedonitsknowledgeofthepresenceofoneormorelistedchemicalswithoutevaluatingthelevelof
exposure,asnotallthelistedchemicalsprovideexposurelimitrequirements.WhiletheexposurefromT oroproductsmaybenegligibleorwellwithinthe
“nosignicantrisk”range,outofanabundanceofcaution,TorohaselectedtoprovidetheProp65warnings.Moreover,ifT orodoesnotprovidethese
warnings,itcouldbesuedbytheStateofCaliforniaorbyprivatepartiesseekingtoenforceProp65andsubjecttosubstantialpenalties.
RevA
