FormNo.3398-468RevA
HighVolumeBucket
TX1000CompactUtilityLoaders
ModelNo.22342—SerialNo.315000001andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3398-468*A

WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Useofthisproductmaycauseexposureto
chemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orother
reproductiveharm.
WARNING
Power,gas,and/ortelephonelinesmaybeburied
intheworkarea.Ashockorexplosionmayoccurif
youdigintothem.
Markthepropertyorworkareaforburiedlines
anddonotdiginmarkedareas.Contactyourlocal
markingserviceorutilitycompanytomarkthe
property(forexample,intheUnitedStates,call811
forthenationwidemarkingservice).
Introduction
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
safetyandoperationtrainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Themodelandserialnumbersarelocated
onaplateonthebackofthebucket.Writethenumbersin
thespaceprovided
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafety-alertsymbol(Figure1),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure1
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Contents
Safety...........................................................................3
GeneralSafety.........................................................3
ToroSafety.............................................................4
StabilityRatings.......................................................5
SafetyandInstructionalDecals.................................5
Operation.....................................................................6
OperationalSpecications........................................6
MaximumMaterialDensityatCapacity.......................6
Storage...................................................................7
©2015—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

Safety
Improperuseormaintenancebytheoperatororowner
canresultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandthoseinthe
tractionunit Operator's Man ual .Alwayspayattentionto
thesafety-alertsymbol,whichmeans Caution , W ar ning ,
or Danger —personalsafetyinstruction.Failureto
complywiththeinstructionmayresultinpersonalinjury
ordeath.
WARNING
Power,gas,and/ortelephonelinesmaybeburied
intheworkarea.Ashockorexplosionmayoccurif
youdigintothem.
Markthepropertyorworkareaforburiedlines
anddonotdiginmarkedareas.Contactyourlocal
markingserviceorutilitycompanytomarkthe
property(forexample,intheUnitedStates,call811
forthenationwidemarkingservice).
WARNING
Whentheengineisoff,attachmentsintheraised
positioncangraduallylower.Someonenearbymay
bepinnedorinjuredbytheattachmentasitlowers.
Alwayslowertheattachmentlifteachtimeyoushut
offthemachine.
WARNING
Ifyoustepofftheplatformwiththeloadraised,the
machinecouldtipforward.Someonenearbymay
bepinnedorinjured.
Lowertheloadbeforesteppingofftheplatform.
WARNING
Whengoingupordownhill,themachinecould
overturniftheheavyendistowardthedownhill
side.Someonemaybepinnedorseriouslyinjured
bythemachineifitoverturns.
Operateupanddownslopeswiththeheavyendof
themachineuphill.Thisattachmentwillmakethe
frontendheavy.
WARNING
Ifthebucketisnotkeptlevelwhilelifting,theload
couldbeinadvertentlydumpedonyou,causing
injury.
Whenliftingthebucket,tiltitforwardtokeepit
levelandpreventitfromspillingbackward.
WARNING
Ifyoudonotfullyseattheattachment-lockingpins
intheholesoftheattachment-mountplate,the
attachmentcouldfalloffthetractionunit,severely
injuringyouorbystanders.
•Ensurethatyoufullyseattheattachment-locking
pinsthroughtheholesintheattachment-mount
platebeforeliftingtheattachment.
•Ensurethattheattachment-mountplateis
freeofanydirtordebristhatmayhinderthe
connectionofthetractionunittotheattachment.
•Refertothe
Operator's Man ual ofyour
tractionunitfordetailedinformationonsafely
connectinganattachmenttoyourtractionunit.
GeneralSafety
Thefollowinginstructionshavebeenadaptedfromthe
ANSI/OPEIandISOstandards.
Preparation
•Neverattempttomakeanyadjustmentswhiletheengine
isrunning,exceptwhenspecicallyrecommendedby
Toro.
•Theoperationofanypoweredmachinecanresultin
foreignobjectsbeingthrownintotheeyes.Alwayswear
eyeprotectionduringoperationorwhileperformingan
adjustmentorrepair.
Operation
•Donotputhandsorfeetnearorunderrotatingparts.
•Exerciseextremecautionwhenoperatingonorcrossing
graveldrives,walks,orroads.Stayalertforhidden
hazardsortrafc.Donotcarrypassengers.
•Afterstrikingaforeignobject,stoptheengine,thoroughly
inspecttheattachmentforanydamage,andrepairthe
damagebeforestartingandoperatingtheattachment.
•Iftheunitshouldstarttovibrateabnormally,stopthe
engineandcheckimmediatelyforthecause.Vibrationis
generallyawarningoftrouble.
•Stoptheenginewheneveryouleavetheoperatingposition
andwhenmakinganyrepairs,adjustments,orinspections.
•Whencleaning,repairing,orinspecting,stoptheengine
andensurethatallmovingpartshavestopped.
3

•Keepchildrenandpetsaway.
•Donotoverloadthemachinecapacitybyattemptingto
backllattoofastarate.
•Neveroperatethemachineathigh-transportspeedson
slipperysurfaces.Lookbehindthemachineandusecare
whenmovinginreverse.
•Neverallowanyoneinfrontoftheunit.
•Neveroperatetheattachmentwithoutgoodvisibilityor
light.
•Lightningcancausesevereinjuryordeath.Iflightning
isseenorthunderisheardinthearea,donotoperate
themachine;seekshelter.
MaintenanceandStorage
•Checkfastenersatfrequentintervalsforpropertightness
toensurethattheequipmentisinsafeworkingcondition.
•AlwaysrefertotheOperator’sManualforimportantdetails
ifyoustoretheattachmentforanextendedperiodoftime.
•Maintainorreplacesafetyandinstructionlabels,as
necessary.
ToroSafety
ThefollowinglistcontainssafetyinformationspecictoToro
productsorothersafetyinformationthatyoumustknowthat
isnotincludedintheANSIorISOstandards.
•Stayintheoperator’spositionwhileoperatingthe
attachment.Keepyourfacehands,feet,andanyother
partofyourbodyorclothingawayfrommovingor
rotatingparts.
•Beforeadjusting,cleaning,repairing,andinspectingthe
attachment,lowertheattachment,stoptheengine,
removethekey,andwaitforallmovingpartstostop.
•Beforeleavingtheoperator’sposition,lowerthe
attachment,stoptheengine,removethekey,andwait
forallmovingpartstostop.
•Donotwearloosettingclothingthatcouldgetcaught
inmovingparts.
•Ifashield,safelydevice,ordecalisdamaged,illegible,or
lost,repairorreplaceitbeforebeginningoperation.Also,
tightenanyloosefasteners.
•Performonlythosemaintenanceinstructionsdescribed
inthismanual.Beforeperforminganymaintenance,
service,oradjustment,stoptheengine,removethekey,
andensurethatallmovingpartshavestopped.Ifmajor
repairsareeverneeded,contactyourAuthorizedToro
ServiceDealer.
•Toensurethebestperformanceandsafety,purchaseonly
genuineTororeplacementpartsandaccessories.
•Alwaystransporttheattachmentinaloweredposition.
4

StabilityRatings
Todeterminethedegreeofslopeyoucantraversewiththe
bucketinstalledonatractionunit,ndthestabilityratingfor
thehillpositionthatyouwanttotravelintheappropriate
tablebelow ,thenndthedegreeofslopeforthesamerating
andhillpositionintheStabilityDatasectionoftheOperator’s
Manualforthetractionunit.
WARNING
Exceedingthemaximumrecommendedslope
cancausethetractionunittotip,crushingyouor
bystanders.
Donotdrivethetractionunitonaslopesteeper
thanthemaximumrecommendedslope,as
determinedinthefollowingtablesandthetraction
unit
Operator's Man ual .
StabilitywithaLoadedBucket
OrientationStabilityRating
FrontUphill
B
RearUphill
D
SideUphill
B
StabilitywithanUnloadedBucket
OrientationStabilityRating
FrontUphill
D
RearUphill
C
SideUphill
C
SafetyandInstructional
Decals
Safetydecalsandinstructionsareeasily
visibletotheoperatorandarelocatednear
anyareaofpotentialdanger.Replaceany
decalthatisdamagedorlost.
133-0221
1.Tippinghazard—readtheOperator'sManual;fortheTX
1000donotexceedloadsof600lb(417kg);forother
modelsdonotexceedloadsof380lb(172kg).
5

Operation
Note:Alwaysusethetractionunittoliftandmovethe
attachment.
Important:Beforeinstallingthebucket,ensurethatthe
mountplatesarefreeofanydirtordebrisandthatthe
pinsrotatefreely.Ifthepinsdonotrotatefreely,grease
them.
Beforeinstallingorremovingthebucket,positionthe
machineonalevelsurface.
RefertoyourtractionunitOperator’sManualformore
informationoninstallingandremovingthebucketfromyour
tractionunit.
Whenloadingmaterial,alwayshavethebucketleveltothe
ground,movingforwardintothematerialtobelifted.When
thebucketisfull,tiltitgentlyrearwardtodecreasethelifting
resistancewhenyoulifttheload.
Whentransportingaload,keepthebucketasclosetothe
groundaspossible.
OperationalSpecications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Width132cm(53.25inches)
Length74cm(29inches)
Height43cm(17inches)
Weight115kg(253lb)
Capacity(SAEstruck
capacity)
0.25m3(9.0ft3)
MaximumMaterialDensityat
Capacity
Thedensityofthematerialsmovedbythebucketvariesand,
therefore,sodoestheamountofmaterialthatthebucket
cancarrybeforereachingthemaximumloadrating.Table1
liststhedensityofmaterialthatcancarry,bothheapedand
struck(i.e.,leveledoff),inthebucket.Table2listscommon
materialsandtheirdensities.
TX1000
BucketCapacityMaximumDensity
Heapedbucket1404kg/m3(87lb/ft3)
Struck(leveled)bucket1641kg/m3(102lb/ft3)
Important:Thisattachmentisnotrecommendedfor
othermodelsduetothelow-ratedcapacity.
OtherModels
BucketCapacityMaximumDensity
Heapedbucket579kg/m3(36lb/ft3)
Struck(leveled)bucket677kg/m3(42lb/ft3)
MaterialDensity
MaterialDensity(Approximate)
Caliche1250kg/m3(78lb/ft3)
Clay:
Naturalbed
Dry
Wet
Withgravel,dry
Withgravel,wet
1600kg/m3(104lb/ft3)
1480kg/m3(93lb/ft3)
1660kg/m3(104lb/ft3)
1420kg/m3(89lb/ft3)
1540kg/m3(96lb/ft3)
Coal:
Anthracite,broken
Bituminous,broken
1100kg/m3(69lb/ft3)
830kg/m3(52lb/ft3)
Earth:
Dry,packed
Wet,packed
Loam
1510kg/m3(94lb/ft3)
1600kg/m3(100lb/ft3)
1250kg/m3(78lb/ft3)
Granite,brokenorlarge
crushed
1660kg/m3(104lb/ft3)
Gravel:
Dry
Pitrun(graveledsand)
Dry,13to51
mm(1/2to2inch)
Wet,13to51mm(1/2
to2inch)
1510kg/m3(94lb/ft3)
1930kg/m3(120lb/ft3)
1690kg/m3(106lb/ft3)
2020kg/m3(126lb/ft3)
Limestone,brokenorcrushed1540kg/m3(96lb/ft3)
Sand:
Dry
Wet
Withgravel,dry
Withgravel,wet
1420kg/m3(89lb/ft3)
1840kg/m3(115lb/ft3)
1720kg/m3(107lb/ft3)
2020kg/m3(126lb/ft3)
Sandstone,broken1510kg/m3(94lb/ft3)
Shale1250kg/m3(78lb/ft3)
Slag,broken1750kg/m3(109lb/ft3)
Stone,crushed1600kg/m3(100lb/ft3)
Topsoil950kg/m3(59lb/ft3)
6

Storage
1.Beforelong-termstorage,washtheattachmentwith
milddetergentandwatertoremovedirtandgrime.
2.Paintallscratchedorbaremetalsurfaces.
Note:PaintisavailablefromyourAuthorizedService
Dealer.
3.Storetheattachmentinaclean,drygarageorstorage
area.Coverittoprotectitandkeepitclean.
7

ToroCompactUtilityEquipmentWarranty
AOne-YearLimitedWarranty
CompactUtilityEquipment
(CUE)Products
ConditionsandProductsCovered
TheT oroCompanyanditsafliate,ToroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlywarrantyourToroCompactUtility
Equipment(“Product”)tobefreefromdefectsinmaterialsorworkmanship.
Thefollowingtimeperiodsapplyfromthedateofpurchase:
ProductsWarrantyPeriod
ProSneak
CompactUtilityLoaders,
Trenchers,StumpGrinders,
andAttachments
1yearor1000operatinghours,
whicheveroccursrst
KohlerEngines3years*
AllotherEngines2years*
Whereawarrantableconditionexists,wewillrepairtheProductatnocost
toyouincludingdiagnosis,labor,andparts.
*SomeenginesusedonT oroProductsarewarrantedbytheenginemanufacturer.
InstructionsforObtainingWarrantyService
IfyouthinkthatyourT oroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:
1.ContactanyAuthorizedT oroCompactUtilityEquipment(CUE)
ServiceDealertoarrangeserviceattheirdealership.Tolocatea
dealerconvenienttoyou,accessourwebsiteatwww.T oro.com.Y ou
mayalsocallourToroCustomerCareDepartmenttollfreeatthe
numberbelow.
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.
3.IfforanyreasonyouaredissatisedwiththeServiceDealer’s
analysisorwiththeassistanceprovided,contactusat:
SWSCustomerCareDepartment
ToroWarrantyCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
TollFree:888-384-9940
OwnerResponsibilities
YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator’sManual.Suchroutinemaintenance,
whetherperformedbyadealerorbyyou,isatyourexpense.Parts
scheduledforreplacementasrequiredmaintenance(“MaintenanceParts”),
arewarrantedfortheperiodoftimeuptothescheduledreplacementtime
forthatpart.Failuretoperformrequiredmaintenanceandadjustmentscan
begroundsfordisallowingawarrantyclaim.
ItemsandConditionsNotCovered
Notallproductfailuresormalfunctionsthatoccurduringthewarrantyperiod
aredefectsinmaterialsorworkmanship.Thisexpresswarrantydoesnot
coverthefollowing:
•Productfailureswhichresultfromtheuseofnon-T ororeplacement
parts,orfrominstallationanduseofadd-on,modied,orunapproved
accessories
•Productfailureswhichresultfromfailuretoperformrequired
maintenanceand/oradjustments
•ProductfailureswhichresultfromoperatingtheProductinanabusive,
negligentorrecklessmanner
•Partssubjecttoconsumptionthroughuseunlessfoundtobedefective.
Examplesofpartswhichareconsumed,orusedup,duringnormal
productoperationinclude,butarenotlimitedto,belts,wipers,spark
plugs,tires,lters,gaskets,wearplates,seals,O-rings,drivechains,
clutches.
•Failurescausedbyoutsideinuence.Itemsconsideredtobeoutside
inuenceinclude,butarenotlimitedto,weather,storagepractices,
contamination,useofunapprovedcoolants,lubricants,additives,or
chemicals,etc.
•Normal“wearandtear”items.Normal“wearandtear”includes,butis
notlimitedto,wornpaintedsurfaces,scratcheddecals,etc.
•Repairsnecessaryduetofailuretofollowrecommendedfuel
procedure(consultOperator'sManualformoredetails)
–Removingcontaminantsfromthefuelsystemisnotcovered
–Useofoldfuel(morethanonemonthold)orfuelwhichcontains
morethan10%ethanolormorethat15%MTBE
–Failuretodrainthefuelsystempriortoanyperiodofnon-use
overonemonth
•Anycomponentcoveredbyaseparatemanufacturer’swarranty
•Pickupanddeliverycharges
GeneralConditions
RepairbyanAuthorizedT oroCompactUtilityEquipment(CUE)Service
Dealerisyoursoleremedyunderthiswarranty.
NeitherTheToroCompanynorToroWarrantyCompanyisliablefor
indirect,incidentalorconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythiswarranty,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletionof
repairsunderthiswarranty.Allimpliedwarrantiesofmerchantability
andtnessforusearelimitedtothedurationofthisexpresswarranty.
Somestatesdonotallowexclusionsofincidentalorconsequential
damages,orlimitationsonhowlonganimpliedwarrantylasts,sothe
aboveexclusionsandlimitationsmaynotapplytoyou.
Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveother
rightswhichvaryfromstatetostate.
ExceptfortheenginewarrantycoverageandtheEmissionswarranty
referencedbelow,ifapplicable,thereisnootherexpresswarranty.The
EmissionsControlSystemonyourProductmaybecoveredbyaseparate
warrantymeetingrequirementsestablishedbytheU.S.Environmental
ProtectionAgency(EPA)ortheCaliforniaAirResourcesBoard(CARB).
ThehourlimitationssetforthabovedonotapplytotheEmissions
ControlSystemWarranty.RefertotheCaliforniaEmissionControl
WarrantyStatementsuppliedwithyourProductorcontainedintheengine
manufacturer’sdocumentationfordetails.
CountriesOtherthantheUnitedStatesorCanada
CustomerswhohavepurchasedT oroproductsoutsidetheUnitedStatesorCanadashouldcontacttheirT oroDistributor(Dealer)toobtainguarantee
policiesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtainingguarantee
information,contacttheToroimporter.Ifallotherremediesfail,youmaycontactusatT oroWarrantyCompany.
AustralianConsumerLaw:AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oro
Dealer.374-0261RevE
