Introduction
Thistrimmerisintendedtobeusedbyresidential
homeownerstotrimgrassasneededoutdoors.It
isdesignedtouselithium-ionbatterypackModels
88620(providedwithModel51831),88625,Model
88640,Model88650,Model88660,orModel88675.
Thesebatterypacksaredesignedtobechargedonly
bybatterychargerModel88602,Model88605,or
Model88610(providedwithModel51831).Usingthis
productforpurposesotherthanitsintendedusecould
provedangeroustoyouandbystanders.
Model51831Tdoesnotincludeabatteryora
charger.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.Toro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuinethe
manufacturerparts,oradditionalinformation,contact
anAuthorizedServiceDealerorthemanufacturer
CustomerServiceandhavethemodelandserial
numbersofyourproductready.Figure1identies
thelocationofthemodelandserialnumbersonthe
product.Writethenumbersinthespaceprovided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.
g360584
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedinChina
AllRightsReserved

Safety
WARNING—Whenusingelectricgardening
appliances,alwaysreadandfollowbasicsafety
warningsandinstructionstoreducetheriskofre,
electricshock,andpersonalinjury,includingthe
following:
IMPORTANTSAFETY
INSTRUCTIONS
I.Training
1.Theoperatoroftheapplianceisresponsiblefor
anyaccidentsorhazardsoccurringtoothersor
theirproperty.
2.Donotallowchildrentouseorplaywiththe
appliance,batterypack,orthebatterycharger;
localregulationsmayrestricttheageofthe
operator.
3.Donotallowchildrenoruntrainedpeopleto
operateorservicethisdevice.Allowonlypeople
whoareresponsible,trained,familiarwiththe
instructions,andphysicallycapabletooperate
orservicethedevice.
4.Beforeusingtheappliance,batterypack,and
batterycharger,readalltheinstructionsand
cautionarymarkingsontheseproducts.
5.Becomefamiliarwiththecontrolsandproper
useoftheappliance,batterypack,andbattery
charger.
II.Preparation
1.Keepbystandersandchildrenawayfromthe
operatingarea.
2.UseonlythebatterypackspeciedbyToro.
Usingotheraccessoriesandattachmentsmay
increasetheriskofinjuryandre.
3.Pluggingthebatterychargerintoanoutletthatis
not120Vcancauseareorelectricshock.Do
notplugthebatterychargerintoanoutletother
than120V.Foradifferentstyleofconnection,
useanattachmentplugadapteroftheproper
congurationforthepoweroutletifneeded.
4.Donotuseadamagedormodiedbattery
packorbatterycharger,whichmayexhibit
unpredictablebehaviorthatresultsinre,
explosion,orriskofinjury.
5.Ifthesupplycordtothebatterychargeris
damaged,contactanAuthorizedServiceDealer
toreplaceit.
6.Donotusenon-rechargeablebatteries.
7.Chargethebatterypackwithonlythebattery
chargerspeciedbyToro.Achargersuitablefor
1typeofbatterypackmaycreateariskofre
whenusedwithanotherbatterypack.
8.Chargethebatterypackinawell-ventilatedarea
only.
9.Donotexposeabatterypackorbatterycharger
toreortotemperatureshigherthan68°C
(154°F).
10.Followallcharginginstructionsanddo
notchargethebatterypackoutsideofthe
temperaturerangespeciedintheinstructions.
Otherwise,youmaydamagethebatterypack
andincreasetheriskofre.
11.Donotoperatetheappliancewithoutallguards
andothersafetyprotectivedevicesinplaceand
functioningproperlyontheappliance.
12.Dressproperly—Wearappropriateclothing,
includingeyeprotection;longpants;substantial,
slip-resistantfootwear;rubbergloves;and
hearingprotection.Tiebacklonghairanddo
notwearlooseclothingorloosejewelrythatcan
getcaughtinmovingparts.Wearadustmaskin
dustyoperatingconditions.
III.Operation
1.Avoiddangerousenvironments—Donotusethe
applianceinrainorindamporwetlocations.
2.Usetheproperapplianceforyour
application—Usingtheappliancefor
purposesotheranitsintendedusecouldprove
dangeroustoyouandbystanders.
3.Preventunintentionalstarting—Ensurethatthe
switchisintheOFFpositionbeforeconnecting
tothebatterypackandhandlingtheappliance.
Donotcarrytheappliancewithyourngeron
theswitchorenergizetheappliancewiththe
switchintheONposition.
4.Operatetheapplianceonlyindaylightorgood
articiallight.
5.Removethebatterypackfromtheappliance
beforeadjustingitorchangingaccessories.
6.Keepyourhandsandfeetawayfromthecutting
areaandallmovingparts.
7.Stoptheappliance,removethebatterypack
fromtheappliance,andwaitforallmovement
tostopbeforeadjusting,servicing,cleaning,or
storingtheappliance.
8.Removethebatterypackfromtheappliance
wheneveryouleaveitunattended.
9.Donotforcetheappliance—Allowtheappliance
todothejobbetterandsaferattheratefor
whichitwasdesigned.
10.Donotoverreach—Keepproperfootingand
balanceatalltimes,especiallyonslopes.Walk,
neverrunwiththeappliance.
3

11.Stayalert—Watchwhatyouaredoinganduse
commonsensewhenoperatingtheappliance.
Donotusetheappliancewhileill,tired,orunder
theinuenceofalcoholordrugs.
12.Ensurethattheventilationopeningsarekept
clearofdebris.
13.Underabusiveconditions,thebatterypackmay
ejectliquid;avoidcontact.Ifyouaccidently
comeintocontactwiththeliquid,ushwith
water.Iftheliquidcontactsyoureyes,seek
medicalhelp.Liquidejectedfromthebattery
packmaycauseirritationorburns.
14.CAUTION—Amistreatedbatterypackmay
presentariskofreorchemicalburn.Donot
disassemblethebatterypack.Donotheatthe
batterypackabove68°C(154°F)orincinerate
it.ReplacethebatterypackwithagenuineToro
batterypackonly;usinganothertypeofbattery
packmaycauseareorexplosion.Keep
batterypacksoutofthereachofchildrenand
intheoriginalpackaginguntilyouarereadyto
usethem.
IV.MaintenanceandStorage
1.Maintaintheappliancewithcare—Keepitclean
andingoodrepairforbestperformanceandto
reducetheriskofinjury.Followtheinstructions
forlubricatingandchangingaccessories.Keep
handlesdry,clean,andfreefromoilandgrease.
2.Whenthebatterypackisnotinuse,keepit
awayfrommetalobjectssuchaspaperclips,
coins,keys,nails,andscrewsthatcanmakea
connectionfrom1terminaltoanother.Shorting
thebatteryterminalsmaycauseburnsorare.
3.Keepyourhandsandfeetawayfrommoving
parts.
4.Stoptheappliance,removethebatterypack
fromtheappliance,andwaitforallmovement
tostopbeforeadjusting,servicing,cleaning,or
storingtheappliance.
5.Checktheappliancefordamagedparts—Ifthere
aredamagedguardsorotherparts,determine
whetheritwilloperateproperly.Checkfor
misalignedandbindingmovingparts,broken
parts,mounting,andanyotherconditionthat
mayaffectitsoperation.Unlessindicatedinthe
instructions,haveanAuthorizedServiceDealer
repairorreplaceadamagedguardorpart.
6.Donotreplacetheexistingnon-metalliccutting
meansontheappliancewithametalliccutting
means.
7.Donotattempttoserviceorrepairtheappliance,
batterypack,orbatterychargerexceptas
indicatedintheinstructions.HaveanAuthorized
ServiceDealerperformserviceusingidentical
replacementpartstoensurethattheproductis
safelymaintained.
8.Storeanidleapplianceindoorsinaplacethatis
dry,secure,andoutofthereachofchildren.
9.Donotdisposeofthebatteryinare.The
cellmayexplode.Checkwithlocalcodesfor
possiblespecialdisposalinstructions.
SAVETHESE
INSTRUCTIONS
4

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal144-3094
144-3094
1.Thebatterypackis
charging.
3.Thebatterypackisover
orundertheappropriate
temperaturerange.
2.Thebatterypackisfully
charged.
4.Batterypackchargingfault
decal144-3098
144-3098
decal144-3096
144-3096
decal144-3088
144-3088
decal144-3084
144-3084
5

decal144-3085
144-3085
decal140-8475
140-8475
1.ReadtheOperator’s
Manual.
3.Keepawayfromopenre
orames.
2.Call2Recycle®battery
recyclingprogram
4.Donotexposetorain.
decal137-9461
137-9461
1.Batterychargestatus
decal139-5210
139-5210
1.Warning—readtheOperator’sManual;stayawayfrom
movingparts;keepallguardsinplace;weareyeprotection;
donotoperateinwetconditions.
6

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Allenwrench1Unfoldthehandle.
Auxiliaryhandleassembly1
2Screwdriver(notincluded)–Installtheauxiliaryhandle.
Guard1
3Screwdriver(notincluded)–Installtheguard.
Important:Thebatterypackisnotfullycharged
whenyoupurchaseit.Beforeusingthetoolfor
thersttime,refertoChargingtheBatteryPack
(page13).
7

1
UnfoldingtheHandle
Partsneededforthisprocedure:
1Allenwrench
Procedure
1.Unfoldthehandle(AofFigure3).
2.Alignthelockingbuttononthelowershaftwiththeslottedholeontheuppershaftandslidethe2shafts
together(BandCofFigure3).
Note:Thelockingbuttonclicksintotheslottedholewhentheshaftsaresecured(DofFigure3).
3.UsingtheprovidedAllenwrench,tightenthescrewontheshaftconnectoruntilitissecure(EofFigure3).
g330189
Figure3
8

2
InstallingtheAuxiliaryHandle
Partsneededforthisprocedure:
1Auxiliaryhandleassembly
–Screwdriver(notincluded)
Procedure
1.UsingaPhillipsheadscrewdriver,separatetheauxiliaryhandlefromthehandleplatebyremoving
the2screws(AofFigure4).
2.Lineuptheauxiliaryhandlewithauxiliaryhandleplateonthetrimmerhandle(BofFigure4).
3.Securetheauxiliaryhandletothehandleplatewiththe2previouslyremovedscrews(CofFigure4).
g331072
Figure4
9

3
InstallingtheGuard
Partsneededforthisprocedure:
1Guard
–Screwdriver(notincluded)
Procedure
1.UsingaPhillipsheadscrewdriver,removethe2screws,2washers,and2spacersfromthetrimmer
base(AofFigure5).
2.Aligntheguardontothetrimmerbase(BofFigure5).
3.Securetheguardontothebaseofthetrimmerwiththe2screws,2washers,and2spacerspreviously
removed(CofFigure4).
g330190
Figure5
10

ProductOverview
g335846
Figure6
1.Batterylatch4.Runtrigger
2.Lockouttrigger5.Guard
3.Auxiliaryhandle6.String
g330065
Figure7
1.BatterychargerModel
88610(includedwith
Model51831)
2.BatterypackModel88620
(includedwithModel
51831)
Specications
Model51831/T
Rated
Voltage
60VDCmaximum,54VDCnominalusage
Charger
Type
88602,88605,or88610(includedwith51831)
BatteryType88620(includedwith51831),88625,88640,
88650,88660,or88675
AppropriateTemperatureRanges
Charge/storethebatterypack
at
5°C(41°F)to40°C(104°F)*
Usethebatterypackat-30°C(-22°F)to49°C(120°F)
Usethetrimmerat0°C(32°F)to49°C(120°F)
Storethetrimmerat0°C(32°F)to49°C(120°F)*
*Chargingtimewillincreaseifyoudonotchargethe
batterywithinthisrange.
Storethetool,batterypack,andbatterychargerinan
enclosedclean,dryarea.
11

Operation
StartingtheTrimmer
1.Makesurethattheventsonthetrimmerare
clearofanydustanddebris.
g330191
Figure8
1.Trimmerventingareas
2.Alignthecavityinthebatterypackwiththe
tongueonthehandlehousing(Figure9).
3.Pushthebatterypackintothehandleuntilthe
batterylocksintothelatch(Figure9).
g330417
Figure9
1.Batterylatch
4.Tostartthetrimmer,squeezethelockouttrigger,
thensqueezetheruntrigger(Figure10).
g330416
Figure10
1.Lockouttrigger2.Runtrigger
ShuttingOfftheTrimmer
Toshutoffthetrimmer,releasebothtriggers.
Wheneveryouarenotusingthetrimmerorare
transportingthetrimmertoorfromtheworkarea,
removethebatterypack.
RemovingtheBatteryPack
fromtheTrimmer
Pressthebatterylatchonthemachinetoreleasethe
batterypackandslidethebatterypackoutofthe
machine(Figure11).
g331067
Figure11
1.Batterylatch
12

ChargingtheBatteryPack
Important:Thebatterypackisnotfullycharged
whenyoupurchaseit.Beforeusingthetoolfor
thersttime,placethebatterypackinthecharger
andchargeituntiltheLEDdisplayindicatesthe
batterypackisfullycharged.Readallsafety
precautions.
Important:Chargethebatterypackonlyin
temperaturesthatarewithintheappropriate
range;refertoSpecications(page11).
Note:Atanytime,pressthebattery-charge-indicator
buttononthebatterypacktodisplaythecurrent
charge(LEDindicators).
1.Ensurethattheventsonthebatteryandcharger
areclearofanydustanddebris.
g330066
Figure12
1.Batterypackcavity5.LEDindicators(current
charge)
2.Batterypackventingareas6.Handle
3.Batterypackterminals7.Charger
4.Battery-charge-indicator
button
2.Lineupthechargerwiththecavityontheback
ofthebatterypack(Figure12).
3.Slidethechargerintothebatterypackuntilitis
fullyseated(Figure12).
4.Toremovethecharger,slidethecharger
backwardoutofthebattery.
5.RefertothefollowingtabletointerprettheLED
indicatorlightonthebatterycharger.
Indicator
light
Indicates
OffNobatterypackinserted
Green
blinking
Batterypackischarging
GreenBatterypackischarged
RedBatterypackand/orbatterychargerisoverorunder
theappropriatetemperaturerange
Red
blinking
Batterypackchargingfault*
*RefertoTroubleshooting(page18)formore
information.
Important:Thebatterycanbeleftonthecharger
forshortperiodsbetweenuses.
Ifthebatterywillnotbeusedforlongerperiods,
removethebatteryfromthecharger;referto
Storage(page17).
13

AdvancingtheLineUsing
theBumpFeed
1.Runthetoolatfullthrottle.
2.Tapthebumpbuttononthegroundtoadvance
theline.Thelineadvanceseachtimethebump
buttonistapped.Donotholdthebumpbutton
ontheground.
Note:Thelinetrimmingcut-offbladeonthe
grassdeectorcutsthelinetothecorrectlength.
Note:Ifthelineisworntooshort,youmaynot
beabletoadvancethelinebytappingitonthe
ground.Ifso,releasebothtriggersandreferto
AdvancingtheLineManually(page14).
g330186
Figure13
1.Bumpbutton
AdvancingtheLine
Manually
Removethebatterypackfromthetrimmer,thenpush
thebumpbuttonatthebaseofthespoolretainer
whilepullingonthetrimmerlinetomanuallyadvance
theline.
14

AdjustingtheCuttingSwath
Thetrimmercomesfromthefactorywithacuttingswathof33.0cm(13inches)asshowninAofFigure14.
Refertothefollowinginstructionstoadjusttheswathto38.1cm(15inches)asshowninDofFigure14.
1.Removetheswathbladefromthebottomoftheguardbyremovingthe2screwsholdingitinplaceusing
theprovidedAllenwrench(BofFigure14)androtatetheswathblade180°.
2.Oncetheswathbladeisrotated,installitontotheguardusingthe2screwspreviouslyremoved(Cof
Figure14).
g330415
Figure14
OperatingTips
•Keepthetrimmertiltedtowardtheareabeingcut;
thisisthebestcuttingarea.
•Thestringtrimmercutswhenyoumoveitfromleft
toright.Thispreventsthetrimmerfromthrowing
debrisatyou.
•Usethetipofthestringtodothecutting;donot
forcethestringheadintouncutgrass.
•Wireandpicketfencescancausethestringto
wearrapidlyandevenbreak.Stoneandbrick
walls,curbs,andwoodcanalsocausethestring
towearrapidly.
•Avoidtreesandshrubs.Thestringcaneasily
damagetreebark,woodmoldings,siding,and
fenceposts.
g330188
Figure15
1.Directionofrotation2.Stringpath
15

Maintenance
Aftereachuseofthetrimmer,completethefollowing:
1.Removethebatteryfromthetrimmer.
2.Wipethetrimmercleanwithadampcloth.Do
nothosethetrimmerdownorsubmergeitin
water.
CAUTION
Thelinecutoffbladeonthedeectoris
sharpandcancutyou.
Donotuseyourhandstocleanthe
deectorshieldandblade.
3.Wipeorscrapecleanthecuttingheadareaany
timethereisanaccumulationofdebris.
4.Checkandtightenallfasteners.Ifanypartis
damagedorlost,repairorreplaceit.
5.Brushdebrisawayfromairintakeventsand
exhaustonmotorhousingtopreventthemotor
fromoverheating.
ReplacingtheString
Important:Useonly2mm(0.080inch)
monolamentreplacementstring(the
manufacturerPartNo.88201),orpurchase
pre-woundspoolPartNo.88615orpre-wound
spool3-packPartNo.88616.
1.Removethebatterypackandcleananydebris
fromthetrimmerhead.
2.Pressthetabssimultaneouslyonthesideof
thetrimmerheadandremovecoverandspool
(Figure16).
g330429
Figure16
1.Coverandspool2.Covertabs
3.Removethespoolfromthecoverandremove
anyremainingstringfromthespool.
4.Cut1pieceof2mm(0.080inch)stringto
approximately3m(10ft).
Important:Donotuseanyothergauge
ortypeofstring,asthiscoulddamagethe
trimmer.
5.Bendthenewstringatthemidpointandinsert
thebendintothestarterslotinthecenterrimof
thespool(Figure17).
Note:Ensurethatthelinesnapsintoposition
intheslot.
6.Wrapthe2halvesofthestringevenlyandrmly
aroundthespoolasshowninFigure17.
Note:Ensurethatthestringiswrapped
clockwisearoundthespoolwhenlookingatthe
bottomofthespool.
16

g330440
Figure17
1.Guideslotforstringend
(oncefullywound)
3.Newstring
2.Centerrimspoolstarter
slot
7.Windthestring,leavingjustenoughextending
fromthespooltocontacttheswathblade,and
snaptheendsintotheguideslotsonthespool
(Figure17).
8.Installthespoolintothecoverandroutethe
endsofthestringthroughtheholesinthecover
asshowninFigure18.
g330442
Figure18
1.Stringexitholes
9.Installthespoolandcoverassemblytothe
trimmerhead,pushuntilthecovertabssnap
intoplace.
Storage
Important:Storethetool,batterypack,and
chargeronlyintemperaturesthatarewithinthe
appropriaterange;refertoSpecications(page
11).
Important:Ifyouarestoringthebatterypack
fortheoff-season,chargeituntil2or3LED
indicatorsturngreenonthebattery.Donotstore
afullychargedorfullydepletedbattery.When
youarereadytousethemachineagain,charge
thebatterypackuntiltheleftindicatorlightturns
greenonthechargerorall4LEDindicatorsturn
greenonthebattery.
•Disconnecttheproductfromthepowersupply
(i.e.,removetheplugfromthepowersupplyorthe
batterypack)andcheckfordamageafteruse.
•Donotstorethemachinewiththebatterypack
installed.
•Cleanallforeignmaterialfromtheproduct.
•Whennotinuse,storethetool,batterypack,and
batterychargeroutofthereachofchildren.
•Keepthetool,batterypack,andbatterycharger
awayfromcorrosiveagents,suchasgarden
chemicalsandde-icingsalts.
•T oreducetheriskofseriouspersonalinjury,do
notstorethebatterypackoutsideorinvehicles.
•Storethetool,batterypack,andbatterycharger
inanenclosedclean,dryarea.
PreparingtheBatteryPack
forRecycling
Important:Uponremoval,covertheterminalsof
thebatterypackwithheavy-dutyadhesivetape.
Donotattempttodestroyordisassemblethe
batterypackorremoveanyofitscomponents.
Lithium-ionbatterypackslabeledwiththe
Call2Recyclesealcanberecycledatany
participatingretailerorbatteryrecycling
facilityintheCall2Recycleprogram(US
andCanadaonly).Tolocateaparticipating
retailerorfacilityclosesttoyou,pleasecall
1-800-822-8837orvisitwww.call2recycle.org.
Ifyoucannotlocateaparticipatingretaileror
facilitynearby,orifyourrechargeablebattery
isnotlabeledwiththeCall2Recycleseal,
pleasecontactyourlocalmunicipalityformore
informationonhowtoresponsiblyrecyclethe
battery.IfyouarelocatedoutsideoftheUS
andCanada,pleasecontactyourauthorized
Torodistributor.
17

Troubleshooting
Performonlythestepsdescribedintheseinstructions.Allfurtherinspection,maintenance,andrepairwork
mustbeperformedbyanauthorizedservicecenterorasimilarlyqualiedspecialistifyoucannotsolvethe
problemyourself.
ProblemPossibleCauseCorrectiveAction
1.Thebatteryisnotfullyinstalledinthe
tool.
1.Removeandthenreplacethebattery
intothetool,makingsurethatitisfully
installedandlatched.
2.Thebatterypackisnotcharged.2.Removethebatterypackfromthetool
andchargeit.
3.Thebatterypackisdamaged.3.Replacethebatterypack.
Thetooldoesnotstart.
4.Thereisanotherelectricalproblem
withthetool.
4.ContactanAuthorizedServiceDealer.
1.Thebatterypackchargecapacityis
toolow.
1.Removethebatterypackfromthetool
andfullychargethebatterypack.
Thetooldoesnotreachfullpower.
2.Theairventsareblocked.2.Cleantheairvents.
1.Thereisdebrisonthedrumareaon
thetrimmer.
1.Cleananydebrisoffofthedrumarea.
Thetoolisproducingexcessivevibration
ornoise.
2.Thespoolisnotproperlywound.2.Advancethelineusingthetrigger
switchand/orremovethelineonthe
spoolandwindthespoolagain.
Thebatterypackloseschargequickly.1.Thebatterypackisoverorunderthe
appropriatetemperaturerange.
1.Movethebatterypacktoaplace
whereitisdryandthetemperatureis
between5°C(41°F)and40°C(104°F).
1.Thebatterychargerisoverorunder
theappropriatetemperaturerange.
1.Unplugthebatterychargerandmove
ittoaplacewhereitisdryandthe
temperatureisbetween5°C(41°F)
and40°C(104°F).
Thebatterychargerisnotworking.
2.Theoutletthatthebatterychargeris
pluggedintodoesnothavepower.
2.Contactyourlicensedelectricianto
repairtheoutlet.
TheLEDindicatorlightonthebattery
chargerisred.
1.Thebatterychargerand/orbattery
packisoverorundertheappropriate
temperaturerange.
1.Unplugthebatterychargerandmove
thebatterychargerandbatterypack
toaplacewhereitisdryandthe
temperatureisbetween5°C(41°F)
and40°C(104°F).
1.Thereisanerrorinthecommunication
betweenthebatterypackandthe
charger.
1.Removethebatterypackfromthe
batterycharger,unplugthebattery
chargerfromtheoutlet,andwait10
seconds.Plugthebatterychargerinto
theoutletagainandplacethebattery
packonthebatterycharger.IftheLED
indicatorlightonthebatterychargeris
stillblinkingred,repeatthisprocedure
again.IftheLEDindicatorlighton
thebatterychargerisstillblinkingred
after2attempts,properlydisposeof
thebatterypackatabatteryrecycling
facility.
TheLEDindicatorlightonthebattery
chargerisblinkingred.
2.Thebatterypackisweak.2.Properlydisposeofthebatterypackat
abatteryrecyclingfacility.
1.Thereismoistureontheleadsofthe
batterypack.
1.Allowthebatterypacktodryorwipeit
dry.
Thetooldoesnotrunorruncontinuously.
2.Thebatteryisnotfullyinstalledintothe
tool.
2.Removeandthenreplacethebattery
intothetoolmakingsurethatitisfully
installedandlatched.
18
