TORREY PINES SCIENTIFIC EchoTherm RT10 User manual

OPERATING INSTRUCTIONS
EchoTherm J
Model RT10 Variable Speed, Rotating Mixer
Document Number RT10-01

I. Introduction
Congratulations on your purchase of a Torrey Pines Scientific Model RT10 Variable Speed, Rotating
Mixer. You will find it easy to use and to maintain. Please read the instructions to insure that you receive
the maximum benefit from it.
II. Warranty
Torrey Pines Scientific warrants this unit to be free from defects in material and workmanship for a period
of one year from the date of purchase. If repair or adjustment is necessary within the one year period, and
has not been the result of abuse or misuse, please return the unit, freight prepaid to us or the dealer from
whom you purchased the unit, and correction will be made without charge. Out of warranty products will
be repaired on a charge basis. Be sure to fill in and return the warranty registration card.
III. Return of Items
Authorization must be obtained before returning items for any reason. When applying for
authorization, please include data regarding the reason the items are to be returned. For your protection,
items must be carefully packed to prevent damage in shipment and insured against possible damage or
loss. Torrey Pines Scientific will not be liable for damage resulting from careless or insufficient packing. A
15% restocking charge will be made on all unauthorized returns. Note: Torrey Pines Scientific reserves
the right to make improvements in design, construction and appearance without notice.
IV. Labels and Symbols
There are various labels on the body of these units. Listed below are the labels and their meanings.
This symbol means: Attention. The instruction manual is to be consulted for further
information.
V. Cautions
Mixing
The RT10 is a variable speed, rotating mixer. It can vary speeds from about 4 to about 50 rpm. The
speed control is open loop without a speed control feedback system. Be sure to monitor the speed setting
from time to time to be sure your samples are mixed correctly. The speed control has an off detent fully
counterclockwise. When turned on, the rotating speed will increase as the control is turned clockwise.
Electrical
These units operate on 12 volts dc from an external power supply provided. There are two power supplies
for this unit. One takes inputs of 115VAC, 60Hz, and the other 230 volts AC, 50Hz . Be certain that your
voltage matches the unit. Check the voltage on the bottom label for the voltage setting on the unit. Take
the normal care and precautions one would use with any electrical appliance. The units are supplied with
an external power supply for the country of use.

VI. Set Up Parameters and Instructions
These units are very simple to use. Follow the instructions below for installation.
Note: The IPX (Index of Protection) rating for this unit is 0 as specified by the manufacturer.
Set Up Parameters
1. Ambient operating temperature range is from 5EC to 40EC.
2. Maximum altitude of operation should not exceed 2000 meters.
3. Maximum ambient operating relative humidity should not exceed 80% at 31EC decreasing linearly to
50% relative humidity at 40EC.
Set Up Instructions
1. Place the unit on a level, dry bench or surface.
2. Plug the unit into an outlet of proper voltage.
3. The power is supplied to the mixer motor when the knob is turned clockwise.
Note: Do not use this equipment in any manner not specified by the manufacturer. Note: Ne pas
utiliser cet équipement si vous ne pouves pas respecter les conditions d = utilisation spécifiées par
le fabricant.
Environmental Information
1. This unit is for installation category II.
2. This unit is rated pollution degree 2.
3. For pollution category for decommissioning, check local code requirements.
VII. Installing the Tube Racks
The RT10 is supplied with a 4-sided rack for holding 50-0.5ml centrifuge tubes and 48-1.5ml or 2.0ml
centrifuge tubes. The rack has 4 covers, one for each side of the rack. They are provided with stainless
steel pins in them to couple the cover to the magnets in the rack which keeps the tubes from falling from
the racks as they rotate. The covers should be placed with the pin flush-mounted side down when using
tubes with snap-on caps. For screw down caps on tubes, flip the cover over. Additionally, there are 2
accessory racks available. One for 16-15ml centrifuge tubes (RT10-100), and the other for 6-50ml
centrifuge tubes (RT10-101).
To mount the rack provided, or either of the accessory racks, open the thumb screw on the rod holding
the rack so that the hole in the end of the rod is clear. Then be certain the screw at the end of the metal
chassis is backed-out to be flush with the chassis. Carefully lower the rack into the chassis and place the
hole on the end of the rod with the screw onto the motor shaft sticking out of the motor housing. Lower
the other end of the rod to align it with the screw on the other end of the chassis. Turn the screw opposite
the motor housing until it is fully into the hole on the rod. Next, align the thumbscrew with the flat side of
the motor shaft and tighten the thumbscrew on the rod to the shaft of the motor. Do not over-tighten. It
need only be snug. The mounting is complete.

VIII. Cleaning and Maintenance
This unit is subject to spills. They should be wiped off quickly to prevent discoloration of the plastic tube
rack. Wipe spills with a soft cloth or paper towel. If a cleaning solution is necessary, use a mild soap or
detergent solution and a soft cloth. Be sure not to use solvents. They could damage the plastic.
Maintenance
There is no preventative maintenance required on these units other than to keep them clean. All
components are solid state and will work until they fail. If they fail, they can be replaced easily. A simple
inspection should be done whenever the unit is to be used. This simple inspection should include:
1. Checking that the AC cord is not frayed or burned.
2. Checking that the unit is not dirty to a point where proper performance is impaired.
3. Be certain to store the unit properly, when not in use, in an area that will not have items placed on top of
the unit, and covered in a way that will keep dirt and other foreign bodies out of the unit..
Spare and Consumable Parts
There are very few spare or consumable parts necessary. A simple list is below.
Part number Description
870-0006 Power Supply, 115VAC, 60Hz
870-0007 Power Supply, 90-230VAC, 50/60Hz
IX. ADDITIONAL SYMBOLS
The following are additional symbols found on the labels of the instrument.
Symbol Description
V Voltage
~ Alternating Current
A Current
Hz Frequency
W Power in Watts
