Hettich Rotolavit II User manual

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 1
Operating Instructions
Cell Washer Centrifuge Hettich Rotolavit II and Rotolavit II-S

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 2
manufactured by
Hettich AG
Seestrasse 204a
CH-8806 Baech / Switzerland
phone [phone]
[email protected]
www.hettich.ch
© 2020 by Hettich AG
All rights reserved. No part of this publication may be reproduced without the prior written permission of the
copyright owner.
Modifications reserved!

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 3
EG-KONFORMITÄTSERKLÄRUNG / EC-DECLARATION OF CONFORMITY
DECLARATION DE CONFORMITE CE/ DICHIARAZIONE DI CONFORMITA CE
DECLARACIÓN DE CONFORMIDAD CE / DECLARAÇÃO DE CONFORMIDADE CE
Name und Adresse des Herstellers Hettich AG, Seestrasse 204a,
Name and address of the manufacturer CH-8806 Baech, Switzerland
Nom et adresse du fabricant Tel. [phone], Fax. [phone]
Nome e indirizzo del produttore [email protected]
Nombre y dirección del fabricante
Nome e endereço do fabricante
Wir erklären in alleiniger Verantwortung, dass das Medizinprodukt für die In-vitro-Diagnostik
We declare, with sole responsibility, that the medical product for in-vitro diagnostics
Nous déclarons, sous notre seule responsabilité, que le produit médical pour le diagnostic in-vitro
Dichiariamo sotto la nostra unica responsabilità che il dispositivo medico-diagnostico in vitro
Declaramos bajo nuestra exclusiva responsabilidad que el dispositivo médico es para uso diagnóstico in vitro
Declaramos, sob a nossa inteira responsabilidade, que o dispositivo médico para diagnósticos in vitro
Rotolavit II, Rotolavit II-S
und / and / et / e / y / e
UltraCW II
ab Seriennummer / from serial-number / dès le numéro de série / a partire dal numero di serie /
desde el número de serie / a partir do número de série
0000030
gefertigt in der Schweiz / manufactured in Switzerland / fabriqué en Suisse / prodotto in Svizzera /
fabricado en Suiza / fabricado na Suíça
mit folgender Klassifizierung nach der Richtlinie über In-vitro-Diagnostika 98/79/EG, Anhang III
classified as follows according to the directive on in vitro diagnostic medical devices 98/79/EC, annex III
avec la classification selon la directive relative aux dispositifs médicaux de diagnostic in vitro 98/79/CE, appendice III
con la classificazione secondo la direttiva relativa ai dispositivi medico-diagnostici in vitro 98/79/CE, appendice III
con la siguiente clasificación según la directiva sobre dispositivos médicos de diagnóstico in vitro 98/79/CE, anexo III
com a seguinte classificação segundo a diretiva relativa aos dispositivos médicos de diagnóstico in vitro 98/79/CE, anexo III
X Sonstiges Produkt / Other device / Autre dispositif / Altro dispositivo / Otro producto / Outro produto

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 4
allen Forderungen der Richtlinie über In-vitro-Diagnostika 98/79/EG, Anhang III entspricht, die anwendbar sind.
meets all the provisions of the directive on in vitro diagnostic medical devices 98/79/EC, annex III which apply to it.
remplit toutes les exigences de la directive relative aux dispositifs médicaux de diagnostic in vitro 98/79, appendice III CE qui
le concernent.
soddisfa tutte le disposizioni della direttiva relativa ai dispositivi medico-diagnostici in vitro 98/79/CE, appendice III che lo
riguardano.
cumplir con todos los requisitos de la directiva sovre dispositivos médicos de diagnóstico in vitro 98/79/CE, anexo III que
sean aplicables.
está em conformidade com todos os requisitos da diretiva relativa aos dispositivos médicos de diagnóstico in vitro
98/79/CE, anexo III aplicáveis.
Baech, 30. September 2019
Doris Friedlos Geschäftsleiterin / CEO /
Directrice général / Gerente
Ort, Datum / Place, date /
Lieu, date / Luogo, data / Lugar, fecha / Local, data
Name und Funktion / Name and function /
Nom et fonction / Nome e funzione / Nombre y función /
Nome e função
Angewandte gemeinsame technischen Spezifikationen, harmonisierte
Normen, nationale Normen oder andere normative Dokumente
Applied common technical specifications, harmonised standards, national
standards or other normative documents
Spécifications techniques communes, normes harmonisées, normes
nationales et autres documents normatifs appliqués
Specifiche tecniche comuni, norme Armonizzate o nazionali applicate,
altri Documenti normativi applicati
Especificaciones técnicas comunes aplicadas, normas armonizadas,
normas nacionales o otros documentos normativos
Especificações técnicas comuns aplicadas, normas harmonizadas,
normas nacionais ou outros documentos normativos
EN 61010-1
EN 61010-2-020
EN 61326-1
RoHS II Directive 2011/65/EU
WEEE Directive 2002/96/EU

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 5
Contents
1 Used terms and signs 8
1.1 Explanation of the terms 8
1.2 Explanation of signs 8
2 Use according to the specifications 9
2.1 Versions 9
2.2 Storage and forwarding the operator-manual 9
2.3 Responsibility of the owner 10
2.4 Requirements of the operating personnel 10
2.5 Changes and alterations 10
2.6 Warranty 11
3 Notes on safety 11
4 Behaviour in case of malfunctions and irregularities 13
4.1 Remaining risks 13
4.2 Switching off the device in an emergency 13
4.3 Emergency release 13
5 Technical specifications 14
6 Unpacking the centrifuge 15
6.1 Storage after delivery 15
6.2 Installation after storage 15
6.3 Delivery checklist 16
6.4 Disposing of packaging material 16
6.5 Transportation 16
7 Installing the wash centrifuge 17
7.1 Connections 17
7.2 Accessory 18
7.3 First steps 19
7.4 Starting the wash centrifuge 21
7.5 Install and remove the rotor 21
8 Operation settings 22
8.1 Overview 22
8.1.1 Password protection 23
8.2 Start screen 23
8.3 Select program 24
8.4 Add a new program 24
8.5 System settings 24
8.5.1 History 25

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 6
8.5.2 Language, date and time settings 25
8.5.3 Edit password 25
8.6 Service menu 26
8.6.1 Calibration 26
8.6.2 User settings 27
8.6.3 Device settings 27
8.6.4 Network settings 28
9 Programs 28
9.1 Starting the program 28
9.2 Stop a running program 30
9.3 Pre-installed programs 31
9.3.1 flush 31
9.3.2 refill pump 31
9.3.3 wash redcells 3 5ml 3x (wash erythrocytes, 3.5 ml, 3 x) 32
9.3.4 agit and spin 32
9.3.5 decant 32
9.3.6 spin 20sec 3500rpm 32
9.3.7 susp 3 5ml spin 20sec (centrifuge 3.5ml suspension for 20sec) 32
9.3.8 wash 3 5ml 3x and anti (wash 3.5 ml, 3 x, plus antihuman globulin test) 33
9.3.9 wash white cells Tspot (wash leukocytes, Tspot) 33
9.3.10 cell recovery (only device type 1008-00S) 33
9.2.11 immunophenotyping (only device type 1008-00S) 33
9.4 Process descriptions 34
9.4.1 Principle 34
9.4.2 FILL 1 process 34
9.4.3 FILL 2 process 34
9.4.4 DOWN process 35
9.4.5 SPIN process 35
9.4.6 DECANT process 36
9.4.7 AGIT process 36
9.4.8 LOOP process 37
9.4.9 CHECK process 37
9.5 Add a new program 38
10 Adjusting 40
10.1 Entering the rotor type 40
10.2 Calibrating the filling volume 40
10.3 Audible signal 41

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 7
10.4 Relative centrifugal force (RCF) 41
10.5 Querying operating hours 41
11 Centrifugation of materials or mixtures of materials with a density higher than 1.2 kg / dm3 42
12 Maintenance and servicing 42
12.1 Centrifuge 43
12.2 Rotor 44
12.3 Autoclaving 44
12.4 Removal of the splash guard receiver and cap 45
12.5 Flushing the system with deionized or distilled water 45
12.6 Cleaning the system with cleaning solution 45
12.7 Glas breakage 46
12.8 Repairs 46
12.9 Rotor crash 46
12.10 Maintenance schedule 47
13 Faults and errors 48
13.1 Operator faults 48
13.2 Software error codes 49
13.3 Changing the fuse 51
14 Returning the device / parts of it 51
15 Storage 51
15.1 Disposal 52
16 Appendix 53
16.1 Rotors and accessories 53
16.2 Spare parts 55
16.3 Document history 56

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 8
1 Used terms and signs
In this manual and on the device, certain common terms and signs are used to warn you of possible dangers
or to give you hints that are important in avoiding injury or damage. Observe and follow these hints and
regulations to avoid accidents and damage. These terms and signs are explained below.
1.1 Explanation of the terms
Warning is used whenever you or somebody else could be injured if you do not observe the
accompanying safety regulation.
Caution is used for information that is important for avoiding damage.
1.2 Explanation of signs
Caution is used for information that is important for avoiding damage.
Symbol on the device:
Attention, general hazard area.
Before using the device, make sure you read the operating instructions and observe the safety
information!
Symbol in this document:
Attention, general hazard area.
This symbol refers to safety relevant warnings and indicates possibly dangerous situations.
The non-adherence to these warnings can lead to material damage and injury to personnel.
Symbol in this document:
This symbol refers to important circumstances.
Symbol on the device and in this document:
Beware of biohazard.
Symbol on the device and in this document:
Symbol for the separate collection of electric and electronic devices according to the guideline
2002/96/EG (WEEE). The device belongs to Group 8 (medical devices).
Applies in the countries of the European Union, as well as in Norway and Switzerland.
Symbol in this document:
Disconnect the mains plug
Symbol in this document:
Wear protective gloves
Symbol in this document:
Important or useful additional information

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 9
2 Use according to the specifications
The present device is a wash centrifuge intended for in-vitro diagnostic applications, in accordance with
“Directive 98/79 EC”. The sample processing with the use of the device and the corresponding inserts is realised
by the filling with a washing liquid and subsequent shaking, centrifuging and decanting. The device itself is used
for sample processing and not for sample analysis.
The following device types are available for this device:
Rotolavit II, Type 1008-00 and 1008-03
These device types are used to wash respectively to clean erythrocytes for carrying out quick anti-human globulin
tests (direct and indirect Coombs tests) in crossmatch, antibody screening and differentiation.
Leukocytes can be washed in the same way to prepare samples for tuberculosis or tumour testing. The device
is intended exclusively for the applications mentioned and is only allowed to be used in closed clinical
laboratories by medically trained specialists.
Rotolavit II-S, Type 1008-00S
This device type is used to wash respectively to clean blood or other cell-containing samples to prepare the flow
cytometric analysis on a sample preparation system and flow cytometer. The process steps can be individually
configured by the user and stored in the device. The configured process steps are processed automatically by
the device. A wash-cycle may consist of several processes in which the samples are centrifuged, the
supernatant decanted, and then each sample tube is filled with a physiological saline solution and mixed.
The device should only be used by trained medical personnel in clinical laboratories and used only for the stated
purpose.
The life cycle of the device specified by the manufacturer is seven years. The lifetime of some parts of the
accessories is divergent and is specified in chapter 12.10 of this manual.
Any other use beyond this purpose, as well as non-observance of the intended use (see instructions in the
operating instructions regarding transport, storage and execution of cleaning, inspection and maintenance
work) is considered to be improper use. The company Hettich AG accepts no liability for any damage arising
from this.
2.1 Versions
The device is available in different configurations. If specific equipment features or functions are available only for
certain configurations, this is indicated at the relevant points in this manual. The functions described in this manual
refer to the latest software version. This manual was written in accordance with the software-version 1.01.421.
2.2 Storage and forwarding the operator-manual
This instruction manual belongs with the device and should always be stored where persons working on the
device have access to it. It is the responsibility of the owner to ensure that persons who are working or will work
on the device are informed as to the whereabouts of this operator manual. We recommend that it is always stored
in a protected location close to the device. Make sure that the instruction manual is not damaged by fluid or
humidity. If the device is sold on or transported and then set up again at a different location, the operator manual
must go with it.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 10
2.3 Responsibility of the owner
The owner of the device:
is responsible for the flawless condition of the device and for its proper operation in accordance with the
specifications.
is responsible for ensuring that persons who are to operate or service the device are qualified to do this,
have been instructed accordingly and are familiar with the operating manual at hand.
must know about the applicable guidelines, requirements and operational safety regulations, and train
staff accordingly.
is responsible for ensuring that unauthorized persons have no access to the device.
is responsible for ensuring that the maintenance plan is adhered to and that maintenance work is carried
out properly (see chapter 12).
must ensure that the device and its surroundings are kept clean and tidy, for example through
corresponding instructions and inspections.
is responsible for ensuring that personal protective clothing is worn by operating personnel, e.g. work-
clothes, protective gloves.
is responsible for ensuring that before starting work with this device all qualifications are released, the IQ
(Installation-Qualification), the OQ (Operational-Qualification) and PQ (Process-Qualification).
is responsible for periodic routine to flush, clean and disinfect the device as well, described in chapter 12,
and take care of controlling the used fluid for the needed quality.
is responsible for the use of the password-protection, user-settings (cha.8.6.2).
2.4 Requirements of the operating personnel
The device may only be operated and maintained by persons who are of legal age and have been instructed
accordingly. Personnel who are to be trained, instructed or who are undergoing general training may only work
with the appliance under the continuous supervision of an experienced person.
Repairs may only be performed by qualified electricians who are authorised to do so by the manufacturer. The
regulations in the separate service manual must be observed.
2.5 Changes and alterations
No unauthorized changes or alterations may be made to the device. No parts may be added or inserted which
have not been approved by the manufacturer.
Unauthorized modifications or changes result in the CE declaration of conformity losing its validity and the
device should no longer be operated.
The manufacturer is not liable for any damage, danger or injuries that result from unauthorized changes or
alterations, or from non-observance of the regulations in this manual.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 11
2.6 Warranty
No claim of warranty will be considered by the manufacturer unless ALL instructions in this manual have been
followed. Especially the flow-sensor and the magnetic-valve are excluded from a warranty exchange if they are
enriched with salt-crystals and this happens if the information in chapter 12 are not followed.
No claim of warranty will be considered by the manufacturer when an unauthorized modification is implemented
or non-authorized parts are installed.
3 Notes on safety
No claim of warranty will be considered by the manufacturer unless ALL instructions in this manual
have been followed.
The centrifuge should be installed on a good, stable base. We suggest that no other critical device, like
a balance, microscope or HPLC, is placed onto the same base.
The centrifuge should be set up so that no containers with e. g. liquids can fall down onto the
centrifuge
When the centrifuge is running, according to EN / IEC 61010-2-020, no persons, dangerous
substances or objects may be within the safety margin of 300 mm around the centrifuge.
Rotors, suspensions and accessories that possess traces of corrosion or mechanical damage or if their
term of use has expired may not be used any longer.
The centrifuge may no longer be put into operation when the centrifuging chamber has safety-related
damage.
For centrifuges without temperature control, when the room temperature is increased and/or if the device is
frequently used, the centrifuging chamber could be heated up. Therefore, it can't be ruled out that the sample
material might be changed due to the temperature.
Before the initial operation of your centrifuge you should read and pay attention to the operating instructions. Only
personnel that has read and understood the operating instructions are allowed to operate the device.
The centrifuge may not be operated in explosion-endangered areas.
The centrifuge should not be used with:
inflammable or explosive materials
materials that react with one another producing a lot of energy
Along with the operating instructions and the legal regulations on accident prevention, you should also follow the
recognised professional regulations for working in a safe and professional manner. These operating instructions
should be read in conjunction with any other instructions concerning accident prevention and environmental
protection based on the national regulations of the country where the device is to be used.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 12
This centrifuge is a state-of-the-art piece of equipment which is extremely safe to operate. However, it may pose
a risk to the user or third parties if it is not used by trained personnel, improperly or in accordance with its intended
purpose.
The centrifuge should not be moved or knocked during operation.
In case of fault or emergency release, never touch the rotor before it has stopped turning.
To avoid damage due to condensate, when changing from a cold to a warm room the centrifuge must either heat
up for at least 24 hours in the warm room before being connected to the mains.
Only the rotors and accessories approved by the manufacturer for this device may be used, see chapter “rotor
and accessories”. Before centrifuge tube-holders, reducers, which are not listed in the chapter “rotors and
accessories”, the user should make sure they can be used by asking the manufacturer of the device.
When centrifuging with maxim revolutions per minute the density of the materials or the material mixtures may not
exceed 1.2 kg/dm3.
The centrifuge may only be operated when the balance is within the bounds of acceptability
≤ 5g = pass and ≥10g = stop
If users centrifuge hazardous materials or compounds contaminated with toxic, radioactive or pathogenic micro-
organisms, they must take appropriate work-instruction measures.
Repairs must only be carried out by personnel authorised to do so by the manufacturer.
Only original spare parts and original accessories licensed by the manufacturer can be utilised.
Components contaminated with blood (e.g. rotor, centrifugation area, waste-tube and conectors) must, following
replacement, be disposed of in the special waste for materials contaminated with blood.
The following safety regulations apply:
EN / IEC 61010-1 and EN / IEC 61010-2-020 as well as their national deviations.
The safe operation and reliability of the centrifuge can only be guaranteed if:
the centrifuge is operated in accordance with the operating instructions
the electrical installation on the site where the centrifuge is installed conforms to the demands of
EN / IEC stipulations
the tests for device safety required in the respective countries, e.g. in Germany in accordance with
“DGUV Vorschrift 3”, are carried out by an expert.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 13
4 Behaviour in case of malfunctions and irregularities
The device may only be used in a flawless condition. If you as the operator notice irregularities, malfunctions or
damage, immediately take the device out of work and inform your superior.
You can find on correcting malfunctions in chapter 13.
4.1 Remaining risks
The device is built according to the state-of-the-art and the recognized safety regulations. If used and handled
improperly, there could be life-threatening danger to the user or third parties, the device could be impaired or
there could be other property damage. The device is only to be used for its intended purpose and only when it is
in safe working condition. Malfunctions which could affect safety must be corrected immediately.
4.2 Switching off the device in an emergency
Push the on / off switch on the rear-panel to its off-position and disconnect the power plug. This
disconnects the device from the power supply at all poles.
4.3 Emergency release
The lid cannot be opened during power failure. An emergency release has to be executed by hand.
For emergency release disconnect the centrifuge from the mains.
Open the lid only during rotor standstill.
Only the plastic release pin provided may be used for emergency release.
Switch off the mains switch (switch position "0").
Look through the window in the lid to be sure that the rotor has come to a standstill.
Insert the release pin horizontally into the hole. Push the unlocking pin in until the handle can be lifted when
the pin is pressed in.
Open the lid.
An error appears on the display after switching on the centrifuge.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 14
5 Technical specifications
Modell
Rotolavit II
Rotolavit II-S
Part-Nr.
1008-00
1008-03
1008-00S
Ext. power-supply
100–240 V~
Mains frequency
50–60 Hz
Protection class
class I
Connected load
144 VA
Current consumption
0,7 A (230 V~) or 6 A (24 V=)
Power
150 W
Fuse
10 A / 250 V F
Optional car-battery DC-
input
no
11–30 VDC
no
Width
330 mm / 13inch
Depth
480 mm / 18,9inch
Height, closed lid
280 mm / 11inch
Height, open lid
580 mm / 22,9inch
Weight kg / lb
24,4 / 53,8
24,7 / 54,5
24,4 / 53,8
Capacity, standard
12 x 5 ml
Capacity (optional)
24 x 5 ml
Speed / Radius
3500 RPM / 105 mm
force
1438 RCF
Kinetic energy, max.
250 Nm
Max. allowed density
1,2 kg / dm3
Obligatory inspection
(BGR 500)
no
EMC
IEC61326-3-2 / FCC CFR47, part 15, ed 2015, class b
Noise level
62dB
62dB
62dB
Ambient conditions
EN / IEC61010-1
Altitude ambient
Not suitable for use in explosion endangered areas
indoors only
up to 2000m above sea level
Ambient temperature
18 °C to 30 °C
Humidity
20 %rF to 80 %rF / nicht kondensierend
Storage temperature
5 °C to 50 °C / max. 60%rF
tab. 1.0

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 15
6 Unpacking the centrifuge
If packaging arrives damaged, it must be confirmed by the carrier and the centrifuge must be specially
inspected.
To avoid damage, do not unpack the appliance until you reach the installation site.
Check the delivery note to ensure that the delivery is complete. Check the appliance for damage.
Take care, you could injure your skin on the edge of the cardboard packaging carton.
Lift the centrifuge on both sides and not on the frontpanel. Take it out of the box with an adequate
amount of people to help you.
According to the laboratory instrument standards EN / IEC 61010-2-020 an emergency switch to
disconnect the power supply in the event of a failure must be installed in the building electrical system.
This switch has to be placed remote from the centrifuge, preferably outside of the room in which the
centrifuge is installed or near by the exit of this room.
Before the centrifuge is connected to the power or the lid is opened using the emergency opening,
place the centrifuge carefully on one side so that the three transport locking screws on the underside
of the centrifuge can be removed with the help of the enclosed hexagon L-key wrench. Carefully place
the centrifuge back on its feet, connect the power correctly, and operate the centrifuge and open the
lid, so that the transport foam of the supplied rotor, or the additional transport lock on delivery without
rotor, can be removed.
Position the centrifuge in a stable and level manner in a suitable place. During set-up, the required
safety margin of 300 mm around the centrifuge is to be kept according to EN / IEC 61010-2-020.1
When the centrifuge is running, according to EN / IEC 61010-2-020, no persons, dangerous
substances or objects may be within the safety margin of 300 mm around the centrifuge.
If you notice deviations from the delivery note, damage or irregularities, do not put the appliance
into operation, but inform the haulage company and your supplier.
If possible, keep the transportation material and the transportation safety device in a safe and dry place.
6.1 Storage after delivery
If the device must first be stored after delivery, then check the box from outside for damage and if it is so,
inform the haulage company and your supplier immediately. For the storage conditions, refer to tab. 1.0
technical specifications.
6.2 Installation after storage
If the storage environment was outside the working environment, then you must allow the device to acclimatise
to the new environment for 24 hours without connecting to the power.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 16
6.3 Delivery checklist
1 power-supply, fig. 7.2.4
1 drainage hose (14,3 mm) with connector, E4374, fig. 7.2.3
1 fill hose (7,1 mm) with connector, E4373, Inlet 1, with intake pipe; for the physiological saline solution,
E4373
1 fill hose (7,1 mm) with connector, Inlet 2 (Fluid 2), with intake pipe for a secondary solution *1
1 angle piece (plastic), for the drainage hose (for free-running drain), E4394, fig. 7.2.1
1 power-cord
1 battery-cord (with open wires) *
2
1 release-pin, E2287, fig. 7.2.1
1 hex L-key, fig. 7.2.1
The rotor(s) and associated accessories are included in the delivery in the quantity ordered.
*1would be delivered only for devices with the optional secondary pump (p/n 1008-02 and
1008-04)
*2would be delivered only for devices with the optional car battery DC-input (p/n 1008-03
and 1008-04)
6.4 Disposing of packaging material
Dispose of the packaging material (cardboard, polyurethane foam, tie and plastic bag) in accordance with the
applicable disposal regulations for the respective material in your country. If you have any questions, please
contact your local supplier. We recommend to keep at least one set of the original packaging for transporting
(Chap. 6.5).
6.5 Transportation
Please store the original packaging and use it for transportation. If you have to transport the device and you do
not have the original packaging material anymore, please contact your local supplier. The device and its motor
and rotor must be protected during transportation.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 17
7 Installing the wash centrifuge
7.1 Connections
1 solution tube to the lid
2 mounting bracket for the power-supply
3 ON / OFF main switch
4 ethernet interface 1
5 DC power input *
6 fuse, fuse holder
7 inlet1, saline
8 inlet 2, solution 2*
9outlet, drain 2
* Refer to the technical specifications comparing to
The part number from your device, tab 1.0
3
4 5 6 7 8 9
9 Emergency release hole
(Refer to chapter 4.3)
If you use the device connected to a car- or truck-battery without the option, then the device could
become damaged.
Refer to the technical specifications comparing to the part number from your device, tab 1.0
Allow the option to be installed only from an authorised distributor.
If you install the device in a car, truck, ship or another mobile environment, then you must protect
the device with the transportation foam during transportation and you must ensure that the ambient
conditions are conform to the tec. Specifications.
fig. 7.1
Fig. 7.2

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 18
7.2 Accessory
E4394, angle piece E4373, fill-hose,
Inlet 1, complete
E2287, emergency- E4261, plug,
release pin anschluss, input 1
hex L-Key E4258, weight for
suction tube (separate
Fig. 7.2.1 Fig. 7.2.2
E4374, drain hose, complete
E4259, plug, for waste tube
Fig. 7.2.3
E4251 / E4502, power-supply
Fig. 7.2.4
The Angle piece is for the drain hose. This ensures that the liquid runs off and no siphon is created.
If liquid back into the device and fills the bowl, your device (motor) will be damaged.
Fig. 7.2.5 Fig. 7.2.6

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 19
7.3 First steps
Please check chapter 3 before starting the installation.
Install the power supply in its mounting bracket on the rear side (see Fig. 7.1, Pos. 2) and plug the connector to
the DC input (Fig. 7.1, Pos. 5). Plug the provided main power cable into the power supply and the other side to
the power source.
Check the country-specific regulations when making connections (e.g. in Germany with
residual current circuit breaker). Observe the connection and power ratings, see on the label
and the technical specification. Make sure to establish a safe PE conductor connection.
Lay the power cable so that
it is always accessible and within reach, so it can be disconnected in the event of
a failure
no one can trip over it
it does not have contact with a solution, e.g. water or saline, mechanical parts, e.g.
shakers or mixers, or hot parts, e.g. ovens or torches
Plug the connector from the fill hose to the inlet 1 on the rear side (Fig. 7.1, Pos. 7) and dip
the other side with the suction-tube into the container with the saline solution.
If the fill hose is too short for your installation and it is not possible to move the can with the
solution closer and you need an oversized fill hose (from your local distributor), then you must
validate the flush- and the refill pump programs for correct operation.
If your device has the optional inlet 2, plug the connector from the fill hose 2 to the inlet 2 on
the rear side, see on fig. 7.1, Pos. 8 afterwards dip the other side with the suction tube into
the container with the fluid 2 solution.
Ensure that it is not possible to interchange the ends from the tubes and the cans or
containers, otherwise all probes will be disturbed!
Plug the connector from the drainage hose to the outlet on the rear side, see on fig. 7.1 pos.
9, and put the other side into the waste.
Ensure that the drainage hose lies flat onto the base, if not and it is like figure 7.2.6, the
device will become damaged.
Clean and disinfect the device before first use.

Hettich AG, Seestrasse 204a, 8806 Baech, Switzerland Operator_Manual_Rotolavit II_und_Rotolavit II-S_en_rev2.5
Seite 20
fig. 7.4 fig. 7.3
seal
splash guard receiver
splash guard cap
centrifugation area
bowl
inscription (just on fig. in red)
lid lock access hole
fig. 7.5
handle to lift the rotor
marking for positioning the rotor
fig. 7.6
