Torrey LPC HS Series User manual

REV 1 CODIGO: 13100875
OWNER’S MANUAL
PRICE COMPUTING SCALE
LPC HS Series
BEFORE OPERATING THIS SCALE, PLEASE READ THIS MANUAL THOROUGHLY.

2LPC HS Series
Important warnings
Introduction
Installation guide
Name and location of general parts
Keyboard
LCD display screen
Description of operations
How to weigh a product
How to enter prices
”Fixed price” function
How to use "TARE" function
How to use “Reference ZERO” function
Price ADD-UP
How to store prices in the scale's memory
How to load prices from the scale's memory
Recharge battery
Serial connection with PC
Important messages displayed
Maintenance and cleaning
Troubleshooting guide
Technical specifications
Additional data
3
5
5
6
7
9
10
10
10
11
11
12
12
12
12
13
14
15
17
18
19
19
INDEX

IMPORTANT WARNINGS
Price Computing Scale
1. In case you have any problem with the
scale, read the warranty conditions.
2. Do not open the scale on your own. Your
warranty will be canceled.
3. Do not press the keyboard with any
sharp and/or pointed objects.
4. Use a VAC outlet exclusive for the scale,
avoiding overloads or voltage variations.
5. Do not wash the scale using flow of
water. This can damage the electronic
components. For more information read
“Maintenance and cleaning” section
6. Protect the scale from insects; they can
damage the electronic components. Use
online solid products against insects.
7. Do not drop or hit the scale with the
product to be weighted, this will damage
the weight sensor.
3

8. Do not use solvents or detergents for
cleaning, use only a damp towel.
9. Do not place any fans or heaters towards
the scale.
10. Do not place the scale where there is excess
of moisture or dust.
11. Only authorized and qualified staff should
check and repair the scale.
4
WARNING
Do not open the scale
Caution: to reduce the risk of short circuit in your
scale, do not remove the cover or sustitute any of
the parts for others that are not original only
authorized distributor..
Battery should be recharged for 10 hrs before
using the scale for the first time.
IMPORTANT
IMPORTANT WARNINGS
LPC HS Series

Dear customer:
We appreciate that you have chosen this product. We assure you that
you will get the maximum satisfaction of the new acquisition for your
business. We suggest you to read carefully this manual and make sure
to keep it at hand for later consultations.
INSTALLATION GUIDE
INTRODUCTION
IMPORTANT NOTE:By performing the steps described above, the scale
shows the word "HELP" it means that it was mistreated and / or hit
during transport, which caused irreversible damage. If so, contact your
authorized distributor. It is also possible that the scale shows "HELP"
when it is lit with a product on the plate, in this case, remove the
weight from the scale, turn it off and then on again.
1. Unpack the scale and check that it is in good
condition. If you find any damage, notify your
authorized dealer immediately.
2. Set the scale in a free movement and
vibrations place. Verify that it is right levelled.
3. Connect the source adapter to VAC outlet of
110/220VAC, (if it is necessary).
4. Turn on the scale and the viewer / screen will
show:
5
Price Computing Scale

NAME AND LOCATION OF GENERAL PARTS
1. CABINET: Stainless steel
resistant to corrosion.
2. PLATE: Food grade, stainless
steel with bent and rounded
borders.
3. PLATE HOLDER: Manufactured
in aluminum, resistant to
corrosion.
4. KEYBOARD: Fast response,
legible and easy to handle
keyboard
5. DISPLAY: Liquid cristal display.
6. ADJUSTABLE LEVELING BASES:
Loose or tight up them to
adjust the scale.
7. INPUT ADAPTER: DC power
supply connection, located at
the base of the scale.
8. LEVEL INDICATOR: Used as a
scale’s leveling reference.
9. POWER SUPPLY:110/220 VAC
to 6VDC Switching adapter
(included).
10. SERIAL CONNECTOR: Connect
the scale with a PC or printer
using a RS232 cable
6
2
1
8
4
7
5
3
6
10
9
LPC HS Series

KEYBOARD
7
Press to turn the scale ON
Press to turn the scale OFF
Press to set the scale to zero weight.
Press to eliminate any container’s weight that you do not
want to consider during a trade.
Is used to store prices data on the 99 scale’s memory.
Press to load a price previously saved in the 99 scale’s memory.
Press to activate the fixed price function.
Press to add total amounts per transaction onto your scale.
Price Computing Scale

Enter prices.
Press to clear the price.
In Add up mode, erase the total transaction.
Used to multiply the price by ½ or ¼
Read directly price values previously saved from 1 to 4
Save directly price values previously set from 1 to 4
8
Use to enter a double 0 to the price
KEYBOARD
LPC HS Series

LCD DISPLAY SCREEN
9
6
4
3
12
5
7
8
1. WEIGHT INDICATOR: Shows product's weight.
2. PRICE INDICATOR: Indicates the product's price per pounds.
3. “FIXED PRICE” INDICATOR: Shows that the product's price would not be
deleted when the product is removed from the scale. Do not allow to
modify the price, only de-activating the fixed price function.
4. AC/DC POWER SUPPLY INDICATOR: Shows the scale is connected to the
power outlet.
5. TOTAL INDICATOR: Shows the total amount to charge per product
during a sale. (Weight x price).
6. BATTERY INDICATOR: Shows charge level of the battery.
7. “ZERO”: Shows when scale is in zeros and ready to weight. It disappears
when a product is placed on the plate.
8. “TARE": Indicates the “TARE" function is active. Goes off when the
function is de-activated.
Price Computing Scale

DESCRIPTION OF OPERATIONS
How to weight a product
Turn the scale on, wait for the screen to display zero. Place the product to
be weighted on the scale and the “lb”weight will be displayed on the
“WEIGHT” indicator.
To enter a price per pound for a product, type the product's price on the
keypad. It will appear on the “PRICE" indicator and the total sale will be
shown at the “TOTAL" indicator. When the product is weighted, the scale
will show the result automatically (Weight x Cost per lb = Total sale)
Deleting an assigned price can be done manually or automatically.
•Manually: To modify the assigned price, press the "C" key and assign the
new value.
•Automatically: The price would be automatically deleted when the product
is removed from the scale. (Except if the "Fixed Price" function is active).
10
How to enter prices
LPC HS Series

Press the “->T<-”key to get the scale to zeros, eliminating the weight of
any container. To deactivate the function remove the container and
press the “->T<-”key again. To sum up follow the next sequence:
1. Place the empty container on the scale.
2. Press the “->T<-”key to set the scale back to zero. Scale with
container on it ready to use.
3. If the container is removed a negative number (the container's
weight) will display. You can deactivate it by pressing ->T<- key
again.
1. 2. 3.
It is important to mention that this function is subtractive from the
scale's maximum capacity. For example if you have a container that
weights 7 lb The scale will only be able to weight up to 33 lb of product
to complete the maximum capacity.
11
The "Fixed price" function is used when a product requires to be constantly
weighted. When the function is active, the price will remain on the display
although the price is cleared from the scale. To fix a price, place the
product on the scale's plate, type the cost per lb of the product and press
the "P-PACK" key. The P-PACK indicator will be turned on.To deactivate it,
clear the price by pressing the "C" key or press “P-PACK” key again.
“Fixed price” function
How to use "TARE" function
Price Computing Scale

12
To add prices up follow the next steps:
1. Place a product to weight on the plate, type the price and press “M+”
key (for example: a price of $2.20 and a weight of 1.50 lb).
2. Remove the product.
3. Place another product followed by the unit price and press “M+” key
again.
4. To visualize the total sum without adding any price up press “M+” key
when in zero.
1. 2.
3. 4.
If the scale shows weight on display without having any product on it, it
might be due to a voltage variation, rough use, or another factor. Just
press the "->0<-" key and the display will return to zeros.
How to use the "Reference ZERO" function
Price ADD-UP
How to store prices in the scale's memory
1. Type the price to save
2. Press “STO” key
3. Type in the memory slot to save from (00-99) you can also press any
of the direct access keys “M1... M4”.
4. Once you complete last steps you will hear a confirmation alarm.
How to load prices from the scale's memory
Press the “RCL” key followed by the memory slot (00-99)to load or press
any of the direct access keys “M1... M4”.An example sequence below:
If you have saved $26.60 in the memory slot 4, follow these steps to load:
1. Press “RCL” key
2. Type 0, 4 or press M4, and the price stored in the memory, will be
displayed on the "PRICE" indicator, in this case $26.60
LPC HS Series

13
To change the price stored in a memory just type the new price and store
it in the memory space you want to change it to, following the procedure
mentioned previously. These keys are very useful to avoid typing the same
price constantly. To use these stored memories we suggest you have a
product list with the saved prices and each of their memory entry.
To delete all stored memory slots, turn the scale ON and during the
countdown press RCL, M+ ½ and all the stored memories will be deleted.
The scale can operate with a 4VDC built in battery or with an AC/DC power
supply.
To recharge the 4VDC battery (included), connect the AC/DC power supply
to the scale for 10 hours, making sure the scale is turned off. If after
charging the battery doesn't have enough charge to turn the scale on,
contact your authorized distributor.
RECHARGE BATTERY
Price Computing Scale

Use this information in case you need to send weight measurement from
your scale to your PC or laptop.
•Connect your scale to the computer using a RS232 cable.
•Send "P" letter (or equivalent on ASCII code) from the computer.
•Scale will send a weight measure "CC" (control character).
Format of the data sent to the PC: Usually, through the computer, the
data following are sent in ASCII and hexadecimal code (Control character
"CC" is equal to "OD" in all examples)
SERIAL CONNECTION WITH PC
14
ASCII
HEXADECIMAL
You are able to use SCALE v2.x software to show weight measurement on
your PC or laptop screen.
*Installing: Please download the scale software from our web site
http://www.torrey-cloud.com/downloads/ (identify the “PPT Torrey
Software” section and proceed to download).
*System requirements: Windows XP service pack 2 or superior
LPC HS Series

OVER LOAD
This message indicates that a weight that exceeds the maximum capacity
has been placed on the scale. To correct it, simply remove the overweight .
HELP
This message appears in two different situations:
1. When the scale is turned on with an excess weight on the plate near
half the scale’s capacity. To correct this situation remove the weight
on the scale, turn the scale off, and then back on again.
2. When the scale has been handled roughly and/or hit.
NEGATIVE WEIGHT
This message indicates a negative weight to fix this place back in its plate
and press the "->0<-" key, or turn the scale off and then turn it on again.
PLS UNLOAD
This message appears when the scale was turned on with a weight on the
plate. To quit this message remove the weight, turn off the scale and then
turn it on again.
15
IMPORTANT MESSAGES DISPLAYED
Price Computing Scale

16
TOTAL “- - - - - - - -”
This message indicates that the limit has been exceeded when the
multiplication price per weight exceeds the 9999.99,if this happens, lines
at "TOTAL" indicator will appear.
LOW BATT
If this message appears in intervals on display, it indicates that the scale
needs to be recharged. Even with this advice the scale can continue
working for 30 minutes. If it appears and after a few seconds the scale
turns on, it means that the scale is completely discharged. At this point the
scale will not work and all of the operations being performed at the time
will be lost.
To solve the problem connect the AC/DC power supply for a period of time
of 10 hours, keeping the scale on.In case the scale needs to be used while
charging, this will not cause any issues, but it will only take longer to fully
charge.
IMPORTANT MESSAGES DISPLAYED
LPC HS Series

17
One of the greatest advantages of purchasing this scale model is that it
requires minimum maintenance and it is very simple to keep it in favorable
conditions.
•Do not use a flow of water to clean tour scale. use a damp rag and clean
each of these components daily: plate and keyboard.
•To remove oil and greasy substances, use a dry and clean rag, rubbing
dirty area several times.
•Do not use detergents or corrosive liquid while cleaning.
•Do not place the scale where is a lot of moisture and/or dust.
•When you clean de scale make sure that there are not aby papers, pieces
of meat or any other kind or material under the plate or under the plate-
holder that could obstruct the adequate operation of your scale.
•Periodically check the jack (where the AC/DC power supply in inserted) to
make sure it is in good condition. that is, check there are not sings of
strokes or detachments.
•Periodically check the AC/DC power supply to make sure the ends are in
good condition. and that the cable is not twisted or tangled.
•Regular check the scale to assure it is correctly leveled with its four
leveling bases well supported.
•Do not expose your scale to temperatures below 14°F (-10°C) or for above
104°F (40°C).
•Never press the keyboard with objects such pencils, pens knives, etc.
•Do not drop hard the product to be weighted on the plate or the scale
because with the time it could damage the load cell.
MAINTENANCE AND CLEANING
Price Computing Scale

18
Before you call for service to your authorized distributor, check this manual
again to avoid a misunderstanding.
PROBLEM POSSIBLE CAUSE SOLUTION
The scale does
not turn on
There is not electric
current.
With a multimeter check
the current outlets.
AC/DC power supply
cable
has an unconnected wire
or defectous voltage
outlet.
Check the AC/DC power
supply terminals, if it is
possible, check with
another AC/DC power
supply.
Low battery.
Connect the AC/DC power
supply and verify that the
battery is been recharged
.
If not replace the battery
The scale shows
different weights
with the same
product
Material under the plate.
Check if exists materials
under the platform. If so,
remove them and check
the operation again.
The word “HELP”
appears in the
display
The scale was turned on
with a weight over the
plate.
Remove the weight, turn
off the scale and then
turn it on again.
TROUBLESHOOTING GUIDE
LPC HS Series

19
TECHNICAL SPECIFICATIONS
L-PC 40L-HS L-PC 80L-HS
MAX. 40 lb
MIN. DIV. 0.01 lb
MAX TARE 40 lb
MAX PRICE / lb $ 999.99
MAX IMPORT $ 9999.99
OPER. TEMP. -14°F to 104 °F
MAX. 80 lb
MIN. DIV. 0.02 lb
MAX TARE 80 lb
MAX PRICE / lb $ 999.99
MAX IMPORT $ 9999.99
OPER. TEMP. -14°F to 104 °F
MAX = MAXIMUM CAPACITY.
MIN. = MINIMUM CAPACITY.
MAX TARE = MAXIMUM TARE.
MAX PRICE / lb = MAXIMUM PRICE PER lb
OPER TEMP = OPERATING TEMPERATURE.
POWER SUPPLY INPUT: 110/220VAC
POWER SUPPLY OUTPUT: 6VDC 500mA
BATTERY: 4VDC 2.5A/h
The serial number of this product can be found in the identification
information which is located at the top of the scale’s cabinet. We suggest
you that write the serial number and the scale model in the following
spaces and hold them as proof of your acquisition and as identification in
case of loss or to future request.
Distributor_______________________________________________
Address ________________________________________________
Telephone number _______________________________________
Purchase date __________________________________________
Purchase date __________________________________________
Serial number ___________________________________________
We reserve the right to change any specification contained in this text
without prior notice.
ADDITIONAL DATA
4.724’’
12.204” 11.417’’
Price Computing Scale

ELECTRONIC
SCALE
www.torrey.net
