Toshiba FPT-AG01U User manual

Owner’s Manual
3D Glasses
(FPT-AG01U)
Contents
Safety Precautions........................ 2
Accessories .................................. 6
Each part's name and function..... 6
Precautions for daily use .............. 7
Enjoying 3D images ...................... 8
Replacing the battery.................... 9
Care and Storage.......................... 9
Troubleshooting.......................... 10
Specifications ............................. 11
Thank you for purchasing a Toshiba product.
• Please read this manual carefully, and use this product safely and correctly.
Before use, be sure to read " Safety Precautions " (-pages 2–4).
• Retain this manual for future reference.
© 2010 TOSHIBA CORPORATION
TD/O

2
Safety Precautions
Warning
About handling the 3D Glasses
• Do not leave the 3D Glasses, the battery or the accessories within the
reach of small children.
Inhaling or swallowing them may cause suffocation or lesions in the
stomach wall.
If swallowed, consult a doctor immediately.
• Do not repair, modify, or disassemble the 3D Glasses by yourself.
Doing so may cause a fire or cause you to become indisposed while
watching 3D images.
Contact the Toshiba Call Center for repair of your 3D Glasses.
• Do not expose the battery to excessive heat such as sunshine, fire, or
the like.
Caution
About handling the 3D Glasses
• Do not use the 3D Glasses if they are not working properly or broken.
Continuing to use them in such a state may cause injury, eye strain, or
indisposition.
Do not use the 3D Glasses if they are broken or have any cracks.
• Do not stand or walk while wearing 3D Glasses.
You may lose your balance which could result in falls or other accidents.
• Do not wear the 3D Glasses for any purpose other than viewing 3D
programming.
3D Glasses do not function as sunglasses.
• Do not drop, exert pressure on, or step on the 3D Glasses.
Doing so may damage the glass section, which may result in injury.
Exposing the 3D Glasses to liquid or excessive heat may damage the liquid
crystal shutter function.
• If your nose or temple turns red, or you feel pain or discomfort, stop
using the 3D Glasses.
Such symptoms as above may occur if you keep wearing them for a long
time, which may also cause indisposition.

3
• Observe the following for the battery of the 3D Glasses:
– Do not use any battery other than the one specified.
– Do not use any battery with the polarity reversed.
– Do not charge, heat, disassemble, or short the battery.
Violation of the above may cause explosion or leakage of the battery, and a
burn or injury may result.
On watching the 3D images
• Some viewers may experience a seizure or blackout when exposed to
certain flashing images or lights contained in certain 3D television
pictures or video games.
Anyone who has had a seizure, loss of awareness, or other symptom linked
to an epileptic condition, or has a family history of epilepsy, should contact
a health care provider before using the 3D function.
• Avoid use of the 3D function when under the influence of alcohol.
• If you are ill or feel ill, you should refrain when viewing 3D images, and
consult your health care provider as may be appropriate.
• If you experience any of the following symptoms from viewing 3D video
images, stop viewing and contact your health care provider:
Convulsions, Eye or muscle twitching, Loss of awareness, Altered vision,
Involuntary movements, Disorientation, Eye Strain, Nausea/Vomiting,
Dizziness, Headaches.
• If you feel eye fatigue or other discomfort from viewing 3D video
images, remove the 3D Glasses and discontinue use until the condition
is eliminated.
• Viewing in 3D may cause dizziness and/or disorientation for some
viewers.
Therefore, to avoid injury do not place your TV near open stairwells,
balconies, or wires.
Also do not sit near objects that could be broken if accidentally hit.
• When viewing 3D images, always wear 3D Glasses.
Watching 3D images without 3D Glasses may cause eye strain.
Use specified 3D glasses.
• When watching 3D images, do not wear 3D Glasses while tilted and do
not lie down.
If you watch while lying down or tilted, the 3D effect is lost and it may cause
eye strain.
• It is recommended that the viewer’s eyes and 3D Glasses are level with
the screen.

4
• If you have prescription eye glasses or contact lenses, wear the 3D
glasses over them.
Watching 3D images without appropriate eyewear may cause eye strain.
• If 3D images often appear in double or if you cannot see the images in
3D, stop viewing.
Continuous viewing may cause eye strain.
• Due to the possible impact on vision development, viewers of 3D video
images should be age 6 or above.
Children and teenagers may be more susceptible to health issues
associated with viewing in 3D and should be closely supervised to avoid
prolonged viewing without rest.
• Watching TV while sitting too close to the screen for an extended
period of time may cause eye strain.
The ideal viewing distance should be at least 3 times the screen height.
About lithium battery
• Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type.
screen height

5
FCC STARTMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the Toshiba Service Center or an experienced radio/TV technician
for help.
FCC Caution:
To assure continued compliance, follow the attached installation instructions.
Any changes or modifications not expressly approved by Toshiba Corp. of
North America could void the user’s authority to operate this device. Service
Center or an experienced radio/TV technician for help.
CANADIAN NOTICE:
For Model FPT-AG01U
This Class B digital apparatus complies with Canadian ICES-003.
California state law
Perchlorate Material – special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.

6
Accessories
* [1]= the quantity.
Each part's name and function
3D Glasses
case [1]*
For the storage
of the 3D
Glasses.
Screwdriver
[1]*
For replacing
the battery.
Specialized
band [1]*
For securing the
3D Glasses.
Lense wipe [1]*
For wiping the
3D Glasses.
Lens (liquid-crystal
shutter)
A right and left liquid-
crystal shutter opens and
closes alternately with the
images for the left eye and
for the right eye
alternately projected on
the television screen. In
this way, 3D images are
reproduced.
Infrared
reception part
Receives the
infrared signal
for the liquid-
crystal shutter
control sent from
the television.
Power button and power light
Turns on or off the power of 3D
Glasses by keeping pressing the
power button for about 1 second.
---When the power is turned on,
the power light lights up for
about 2 seconds.
---When the power is turned off,
the power light blinks 3 times.
Insulation sheet
This is put for the consumption
prevention of the battery.
Pull this out before beginning use.
Battery cover
When replacing the batteries, remove this.
Power
button
Power
light

7
Precautions for daily use
Notes on handling the 3D Glasses’ liquid crystal shutter lenses
• Do not put excessive force on the lenses.
• Do not scratch the surface of the lenses with sharp objects.
• Do not drop or bend the 3D Glasses.
Notes on IR communication
• Do not block the IR sensor for 3D Glasses on the TV by placing objects in
front of it.
• Do not cover the IR sensor on the 3D Glasses with stickers or labels.
• Keep the IR sensor on the 3D Glasses clean.
• If the 3D Glasses interfere with any other IR communication device or 3D
TV, the 3D Glasses may not work correctly.
Notes on watching the TV
• If you use any device, such as a mobile phone or mobile wireless device,
near the 3D Glasses, the 3D Glasses may not work correctly.
• Use the product in the following temperature range; otherwise, the quality
of the 3D image or the reliability of the product cannot be guaranteed.
3D Glasses: 32ºF - 104ºF (0ºC - 40ºC)
TV: 32ºF - 95ºF (0ºC - 35ºC)
• If you use a fluorescent light, it may flicker depending on the frequency of
the light. In this case, reduce the brightness of the fluorescent light, or use
another light. (It is not recommended to watch the TV in a dark room,
especially for children.)
• Wear the 3D Glasses properly, otherwise you may not see the correct 3D
image.
• When not viewing 3D images, take off the 3D Glasses; otherwise, it may be
difficult to see the display on other products such as PC, digital clock or
calculator, etc.

8
Enjoying 3D images
Note:
Compatible with Toshiba 3D TVs only.
In addition to Compatible Toshiba 3D TV, viewing 3D programming may require
the following (Please refer to the Toshiba 3D TV):
•Compatible 3D Playback Device and compatible 3D content or other 3D Source.
•3D Capable HDMI Cable.
1Setting television so that 3D images will be shown properly.
• See the television owner’s manual.
2Using the 3D Glasses.
• When you use for the first time, pull out the insulation sheet inserted in
the battery cover part.
1) Hold down the 3D Glasses power button for about 1 second.
•The power light lights up for about 2 seconds, and then the 3D Glasses
are turned on.
2) Wear the 3D Glasses.
•If the 3D Glasses shift, adjust length by using the provided restraint
band.
3When 3D images’ display is something wrong, adjust the TV
settings.
• See the television owner’s manual.
After finishing watching 3D images.
• Hold down the 3D Glasses power button for about 1 second. The power
light blinks 3 times, and then the 3D Glasses are turned off.
• Store the 3D Glasses in the supplied glasses case.
Note: If the infrared data communication between the television and 3D Glasses
is lost for 5 minutes, the power of 3D Glasses is turned off to prevent the battery
being consumed.
Pull out
Stopper
Move the stopper to
adjust the length of
the band.
Put in
Put in

9
Replacing the battery
• If the power of 3D Glasses is turned on when the battery residual quantity
is a little, the power light will blink 5 times. (When the battery died, the
power light does not blink or light up.)
• The battery for replacement must use the coin type lithium battery CR2032.
Note: Dispose of batteries in a designated disposal area and in accordance with
applicable laws and regulations.
Care and Storage
• When cleaning the 3D Glasses, gently wipe with a dry, soft cloth.
– First remove any dirt or dust from the the 3D Glasses.
– Harsh rubbing or use of a dirty or stiff cloth will scratch the 3D Glasses.
• Do not use benzene, thinner, alcohol, water, or abrasive cleaners, which may
damage the 3D Glasses.
• When not using the 3D Glasses, put it in the provided glasses case and store
it avoiding high temperature and humidity.
• It is recommended to remove the battery from the 3D Glasses if the 3D
Glasses are not to be used for an extended period of time. This will prevent
the consumption of the battery and the leak of the battery liquid. Store the
removed battery in the plastic bag etc. not to short-circuit.
Warning
• Do not leave the 3D Glasses, the battery or the accessories within the
reach of small children.
Inhaling or swallowing them may cause suffocation or lesions in the
stomach wall.
If swallowed, consult a doctor immediately.
1Loosen the screw using the
provided driver, and remove the
battery cover.
2Replace the battery, and screw the
battery cover.
Battery cover
Put the display of "+"
to the upper side.
Battery
Battery cover

10
Troubleshooting
Images are not displayed
as 3D.
• Ensure the setting is for 3D images. For
details, refer to the television owner's
manual.
• Check there is no object blocking infrared
signals in the infrared reception part of
television and 3D Glasses. If the infrared
data communication between the television
and 3D Glasses is lost for 5 minutes, the
power of 3D Glasses is turned off.
• Ensure you wear the appropriate glasses or
contact lenses if necessary.
3D images are not
correct.
• The left and right of the 3D images might be
reversed or the signal system of 3D images
might be different.
Refer to the television owner's manual to
switch the left and right.
The power of 3D Glasses
does not turn on.
• Check the insulation sheet is pulled out.
• The battery might be weak. Try to replace a
battery.

11
Specifications
• The included battery is for testing purpose only, and its life may be shorter
than the above-mentioned time.
• The specification may change without notice.
Disposal Instructions
Follow local regulations for disposal of this product.
3D method Liquid Crystal Shutter
Dimensions Width: 7-1/8 inches (181 mm)
Height: 1-25/32 inches (46 mm)
Depth: 6-3/4 inches (171 mm)
Operating
temperature
32ºF - 104ºF (0ºC - 40ºC)
Mass (weight) 0.13 lbs (61 g) * Included the battery
Material Frame: Resin
Lens: Liquid crystal glass
Battery Coin type lithium battery CR2032
Battery life About 75 hours in a row
* The battery operating time may become
shorter depending on the usage condition or
environment.
This symbol is only applicable in European Union countries.
This symbol is only applicable in China.

Corporate Headquarters: 82 TOTOWA ROAD, WAYNE, NJ 07470, U.S.A.
NATIONAL SERVICE DIVISION: 1420-B TOSHIBA DRIVE, LEBANON, TN 37087, U.S.A.
PRINTED IN CHINA
(10-07)
HEAD OFFICE: 191 McNABB STREET, MARKHAM, ONTARIO, L3R 8H2,
CANADA – TEL: [phone]
SERVICE CENTERS:
TORONTO: 191 McNABB STREET, MARKHAM, ONTARIO L3R 8H2,
CANADA – TEL: [phone]
