Slim Duct Type Owner’s Manual
Contents
1 PRECAUTIONS FOR SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 PARTS NAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 PARTS NAME OF REMOTE CONTROLLER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 CORRECT USAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 TIMER OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 HOW TO ENABLE POWER SAVING MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 ADVANCED SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8 HINTS FOR ECONOMICAL OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
9 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10 AIR CONDITIONER OPERATIONS AND PERFORMANCE . . . . . . . . . . . . . . . . . . . . 16
11 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
12 TROUBLES AND CAUSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Thank you very much for purchasing TOSHIBA Air Conditioner.
Please read this owner’s manual carefully before using your Air Conditioner.
• Be sure to obtain the “Owner’s manual” and “Installation manual” from constructor (or dealer).
Request to constructor or dealer
• Please clearly explain the contents of the Owner’s manual and hand over it.
ADOPTION OF NEW REFRIGERANT
This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional
refrigerant R22 in order to prevent destruction of the ozone layer.
1-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 1 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–2–
Slim Duct Type Owner’s Manual
EN
1PRECAUTIONS FOR SAFETY
WARNING
WARNINGS ABOUT INSTALLATION
• Make sure to ask the qualified installation professional in electric work to
install the air conditioner.
If the air conditioner is inappropriate installed by yourself, it may cause
water leak, electric shock, fire, and so on.
• Be sure to connect earth wire. (grounding work)
Incomplete grounding cause an electric shock.
Do not connect ground wires to gas pipes, water pipes, lightning rods or
ground wires for telephone wires.
• If you install the indoor unit in a small room, take appropriate measures to
prevent the refrigerant from exceeding the limit concentration even if it
leaks.
Consult the dealer from whom you purchased the air conditioner when you
implement the measures. Accumulation of highly-concentrated refrigerant
may cause an oxygen deficiency accident.
• Check whether the piping work has been properly completed.
When existing pipes are used and if they are not constructed properly, the
refrigerant gas may leak. Contact the installation company and confirm that
the piping work has been properly completed. For details of installation of
the air conditioner, refer to the Installation Manual. Use tools and piping
materials for R410 only. Failure to do so or improper installation may cause
a burst of pipe, resulting in injury.
WARNINGS ABOUT OPERATION
• Cleaning of the air filter and other parts of the air filter involves dangerous work in high places, so be sure to
have a service person do it. Do not attempt it yourself.
• Avoid cooling the room too strong or exposing the human body to cool breeze for a long time as it is bad
for the health.
• When you notice something abnormal with the air conditioner (smells like something scorching, poor
cooling, etc.), immediately turn off the main switch, the circuit breaker, from the mains to stop the air
conditioner, and contact the dealer.
If the air conditioner is continuously operated with something abnormal, it may cause machine failure,
electric shock, fire, and so on.
WARNINGS ABOUT REPAIR AND MOVEMENT
• When the air conditioner cannot cool or heat a room well, contact the dealer from whom you purchased the
air conditioner as refrigerant leakage is considered as the cause. In the case of repair that requires refill of
refrigerant, ask service personnel about details of the repair.
The refrigerant used in the air conditioner is harmless.
Generally, the refrigerant does not leak. However, if the refrigerant leaks in a room and a heater or stove
burner in the room catches fire, it may generate toxic gas.
When you ask service personnel for repairing refrigerant leakage, confirm that the leakage portion has
been completely repaired.
• Do not move or repair any unit by yourself.
Since there is high voltage inside the unit, you may get electric shock when removing the cover and main
unit.
• Whenever the air conditioner needs repair, make sure to ask the dealer to do it.
If it is repaired imperfectly, it may cause electric shock or fire.
• When moving the air conditioner for re-installing at another place, ask the dealer to do it. If it is imperfectly
installed, it may cause electric shock or fire.
2-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 2 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–3–
Slim Duct Type Owner’s Manual
CAUTION
TO DISCONNECT THE APPLIANCE FROM THE MAINS SUPPLY
• This appliance must be connected to the mains by means of a switch with a contact separation of at least
3 mm.
•The installation fuse 25A or 16A must be used for the power supply line of this air conditioner.
CAUTIONS ABOUT INSTALLATION (Be sure to confirm the following cautions.)
• Certainly lay the drain hose for perfect draining.
Bad drainage may cause flooding in the house and getting furniture wet.
• Make sure to connect the air conditioner to an exclusive power supply of the
rated voltage, otherwise the unit may break down or cause a fire.
• Do not install the unit in a place where inflammable gas may leak.
If inflammable gas accumulates around the unit, it may cause a fire.
CAUTIONS ABOUT OPERATION
• Carefully read this manual before starting the air conditioner.
There are many important things to keep in mind for daily operation.
• Do not use this air conditioner for special purpose such as preserving food,
precision instruments, art objects, breeding animals, car, vessel, etc.
• When the air conditioner is operated with a combustion appliance in the same
place, be careful of ventilation to let fresh air enter the room.
Poor ventilation causes oxygen shortage.
• Do not place any combustion appliance in a place where it is directly exposed
to the wind of air conditioner, otherwise it may cause imperfect combustion.
• When the air conditioner is used in a closed room, be careful of sufficient ventilation of the room.
Poor ventilation causes oxygen shortage.
• Do not touch any switches with wet finger, otherwise you may get an electric shock.
• If the air conditioner won’t be used for a considerably long time, turn off the main switch or the circuit
breaker, for safety.
• Do not put anything on the outdoor unit nor step onto it.
If you do so, it may not only topple over the unit but also injure yourself.
• To make the air conditioner operate in its original performance, operate it within the range of the operating
temperature specified in the instructions.
Otherwise it may cause a malfunction, or water leak from the unit.
• Prevent any liquid from falling into the remote controller.
Do not spill juice, water or any kind of liquid.
3-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 3 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–4–
Slim Duct Type Owner’s Manual
EN
2PARTS NAME
Indoor unit
Outdoor unit
Provided in the electric parts box.
Earth screw
Air filter
Removes dust or trash.
(Provided on the suction port.)
Discharge duct flange is connected.
Air outlet
SET
TIME
TIMER SET
TEST
FILTER
RESET CL
FAN
SAVE
SWING/FIX
VENT
MODE
UNIT LOUVER
Remote controller
Separate sold part
Air inlet
Air inlet (Side and rear)
Air outlet
Refrigerant connecting
pipe and electric wires
4-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 4 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–5–
Slim Duct Type Owner’s Manual
3PARTS NAME OF REMOTE CONTROLLER
This remote controller can control the operation of up to 8 indoor units.
Display section
In the display example, all indicators are displayed for the
explanation.
In reality only, the selected contents are indicated.
• When turning on the leak breaker at the first time, flashes
on the display part of the remote controller.
• While this display is flashing, the model is being automatically
confirmed.
Accordingly, wait for a while after display has
disappeared, and then use the remote controller.
1SETTING display
Displayed during setup of the timer etc..
2Operation mode select display
The selected operation mode is displayed.
3CHECK display
Displayed while the protective device works
or a trouble occurs.
4Timer time display
Time of the timer is displayed.
(When a trouble occurs, the check code is
displayed.)
5Timer SET IN setup display
When pushing the Timer SET IN button, the
display of the timer is selected in order of
[OFF] →[OFF] repeat OFF timer
→[ON] →No display.
6Filter display
If “FILTER ” is displayed, clean the air
filter.
7TEST run display
Displayed during a test run.
8Set up temperature display
The selected set up temp. is displayed.
9Remote controller sensor display
Displayed while the sensor of the remote
controller is used.
10 PRE-HEAT display
Displayed when the heating operation starts
or defrost operation is carried out.
While this indication is displayed, the indoor
fan stops.
11 No function display
Displayed if there is no function even if the
button is pushed.
SET
TIME
TIMER SET
TEST
FILTER
RESET
TEMP.
CL
FAN
SAVE
SWING/FIX
VENT
MODE
ON / OFF
UNIT LOUVER
Display
section
Operation
section
2
12
5
7
3
1
4
6
9
11 10
8
15 14 13
5-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 5 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–6–
Slim Duct Type Owner’s Manual
EN
12 Air volume select display
The selected air volume mode is displayed.
13 Power saving mode display
Displayed during capacity saving mode by
temporary peak-cut limiting the power current
level of the outdoor unit.
14 Unit Number display
Unit number of the indoor unit selected with
the unit select button or abnormal indicate the
indoor/outdoor unit.
15 Central control display
Displayed when the air conditioner is used
under the central control in combination with
a central control remote controller.
In case the remote controller is disabled by
the central control system, flashes.
The button operation is not accepted.
Even when you push ON/OFF, MODE, or
TEMP. button, and the button operation is not
accepted.
(Settings made by the remote controller vary
with the central control mode. For details,
refer to the Owner’s Manual of the central
control remote controller.)
2
5
7
3
1
4
6
9
11 10
8
15 14 13
12
(AUTO)
(HIGH)
(MED.)
(LOW)
6-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 6 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–7–
Slim Duct Type Owner’s Manual
Operation section
Push each button to select a desired operation.
• The details of the operation needs to be set up once, afterward, the air conditioner can be used by
pushing button only.
1button (Air volume select button)
Selects the desired air volume mode.
2button (Timer set button)
TIMER SET button is used when the timer is
set up.
3button (Check button)
The CHECK button is used for the check
operation. During normal operation, do not
use this button.
4button (Ventilation button)
Ventilation button is used when a fan which is
sold on the market is connected.
• If “No function ” is displayed on the
remote controller when pushing the
Ventilation button, a fan is not connected.
5button (Filter reset button)
Resets (Erases) “FILTER ” display.
6button (Power save operation)
SAVE button is used for power save
operation.
7button (Swing/Wind direction
button)
No Function.
8Operation lamp
Lamp is lit during the operation. Lamp is off
when stopped.
Although it flashes when operating the
protection device or abnormal time.
9button
When the button is pushed, the operation
starts, and it stops by pushing the button again.
When the operation has stopped, the
operation lamp and all the displays disappear.
10 button (Operation select button)
Selects desired operation mode.
11 button (Unit/ Louver select button)
Selects a unit number (left) and louver
number (right).
UNIT:
Selects an indoor unit when adjusting wind
direction when multiple indoor units are
controlled with one remote controller.
LOUVER:
No Function.
12 button (Set up temperature button)
Adjusts the room temperature.
Set the desired set temperature by pushing
TEMP. or TEMP. .
OPTION :
Remote controller sensor
Usually the TEMP. sensor of the indoor unit
senses the temperature. The temperature on the
surrounding of the remote controller can also be
sensed.
For details, contact the dealer from which you
have purchased the air conditioner.
18
3
5
2
9
10
67
12
4
11
7-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 7 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–8–
Slim Duct Type Owner’s Manual
EN
4CORRECT USAGE
• When you use the air conditioner for the first time or when you change the SET DATA value, follow the
procedure below. From the next time, the operation displayed on the remote controller will start by
pushing the button only.
Preparation
Turn on the main power switch and/or the leakage breaker.
• When the power supply is turned on, a partition line is displayed on the display part of the remote
controller.
• After the power supply is turned on, the remote controller does not accept an operation for approx.
1 minute, but it is not a failure.
REQUIREMENT
• While using the air conditioner, operate it only with button without turning off the main power
switch and the leak breaker.
• When you use the air conditioner after it has not been used for a long period, turn on the leakage
breaker at least 12 hours before starting operation.
Start
1Push button.
The operation lamp goes on, and the
operation starts.
2Select an operation mode with the
“MODE ” button.
One push of the button, and the display
changes in the order shown as follows.
3Select air volume with “ ” button.
One push of the button, and the display
changes in the order shown as follows.
• When air volume is “ AUTO”, air
volume differs according to the room
temperature.
• In heating operation, if the room
temperature is not heated sufficiently with
VOLUME “ LOW” operation, select
“ MED.” or “ HIGH” operation.
• The temperature sensor senses
temperature near the suction air port of the
indoor unit, which differs from the room
temperature depending on the installation
condition.
A value of setting temperature is the
measure of room temperature.
(“AUTO ” is not selectable in the FAN
mode.)
4Determine the set up temperature by
pushing the “TEMP. ” or “TEMP.
” button.
Stop
Push button.
The operation lamp goes off, and the operation
stops.
SET
TIME
TIMER SET
TEST
FILTER
RESET
TEMP.
CL
FAN
SAVE
SWING/FIX
VENT
MODE
ON / OFF
UNIT LOUVER
1
3 2
4
AUTO HEAT DRY COOL FAN
LOWMED.HIGH AUTO
8-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 8 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–9–
Slim Duct Type Owner’s Manual
In case of autmatic operation (Auto Changeover)
• Because of some settings change, it will automatically select either cooling, heating, or fan only
operation depending on the indoor temperature.
• If the Auto mode is uncomfortable, you can select the desired conditions manually.
In case of cooling
• Start the cooling operation after approx. 1 minute.
In case of heating
• The heating operation mode is selected in accordance with the room temperature and operation starts
after approximately 3 to 5 minutes.
• After the heating operation has stopped, FAN operation may continue for approx. 30 seconds.
• When the room temperature reaches the set temperature and the outdoor unit stops, the super low
wind is discharged and the air volume decreases excessively.
During defrost operation, the fan stops so that cool air is not discharged. (“HEAT READY ” is displayed.)
• When the room temperature has reached the set temperature while the outdoor unit is stopping, the
indoor unit discharges wind with a very small air volume.
NOTE
When restarting the operation after stop
• When restarting the operation immediately after stop, the air conditioner does not operate for approx.
3 minutes to protect the machine.
 8°C OPERATION (For object pre-heating) (SM40 and SM45 types only)
The air conditioner can control the heating temperature to about 8°C in the heating mode.
The 8°C heating operation requires settings with the wired remote controller. Ask the installer or
dealer for the settings according to the installation manual of the indoor unit.
Start
Stop
NOTE
• The discharged air temperature is lower than that in the normal heating operation.
• The room temperature may not be heated evenly depending on the remote controller installation location.
• The room temperature may not reach 8°C depending on the room size or the installation conditions.
• The air volume setting is available during the 8°C heating operation.
The 8°C heating operation is cancelled in the following cases.
• When operation is stopped with button
• When another operation mode is selected with button
• When temperature setting or operation mode is changed or operation is started/stopped by the
wireless remote controller or the central control remote controller.
• If one or more models other than the 4-way air discharge cassette type (4 series), slim duct are
connected in the same control group, the 8°C heating operation is not available.
• This function is not available for SM56 that has 2-series outdoor unit.
• When you use this operation mode, observe proper operating hours and we recommend that you ask
service staff for periodic maintenance of the air conditioner.
1. Set the displayed temperature to 18°C in the heating mode by pushing TEMP. button.
2. Set the displayed temperature to 8°C by pushing TEMP. button for at least four seconds.
1. Set the displayed temperature to 18°C by pushing TEMP. button.
• The air conditioner returns to the normal HEAT mode. Select a desired temperature and operation mode.
9-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 9 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–10–
Slim Duct Type Owner’s Manual
EN
5TIMER OPERATION
• A type of timer operation can be selected from the following three types. (Setting of up to 168 hours is enabled.)
Timer operation
Set
1Push TIMER SET button.
The timer display (type) changes for every
push of the button.
• and timer time displays flash.
2Push to select “SET TIME”.
• For every push of button, the set time
increases in the unit of 0.5 hr (30 minutes).
When setting a time more than 24 hours for
timer operation, timer time can be set in the
unit of 1 hr.
The maximum set time is 168hr (7 days).
The remote controller displays the set time
with time (between 0.5 and 23.5 hours) (*1)
or number of days and time (24 hours or
more) (*2) as shown below.
• For every push of button, the set time
decreases in the unit of 0.5 hr (30 minutes)
(0.5 to 23.5 hours) or 1 hr (24 to
168 hours).
Example of remote controller display
• In the case of 23.5 hours (*1)
• In the case of 34 hours (*2)
3Push SET button.
• display disappears and timer time
display goes on, and or
display flashes.
(When ON timer is activated, timer time,
ON timer are displayed and other
displays disappear.)
4Cancel of timer operation
Push button.
TIMER display disappears.
NOTE
• When the operation stops after the timer
reached the preset time, the Repeat OFF timer
resumes the operation by pushing
button and stops the operation after the time of
the timer has reached the set time.
• When you push while the OFF timer
function of the air conditioner is active, the
indication of the timer function disappears and
then appears again after about 5 seconds.
This is due to normal processing of the remote
controller.
OFF timer : The operation stops when the time of timer has reached the set time.
Repeat OFF timer : Every time, the operation stops after the set time has passed.
ON timer : The operation starts when the time of timer has reached the set time.
1
3
2
4
OFF OFF ON
(OFF timer) (ON timer)(Repeat OFF timer)
Not display
shows 1 day (24 hours).
shows 10 hours. (Total 34 hours)
Number of days Time
10-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 10 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–11–
Slim Duct Type Owner’s Manual
6HOW TO ENABLE POWER SAVING MODE
Push button during operation.
• The air conditioner enters power saving mode.
•appears on the display.
To cancel the power saving operation, push button again.
•disappears.
NOTE
• When other electric appliances are used at the same time, to avoid triggering the circuit breaker,
power saving mode is recommended. Of course you can use power saving mode to save energy as
well.
• Power saving mode consumes less energy, but may not heat/cool the room as much as normal mode.
(The maximum current is limited of the normal mode.)
• To adjust the power-save settings, see “How to set up power saving mode” in ADVANCED
SETTINGS.
• Even when operation start/stop, operation mode change, or power reset is performed during the
power saving mode, the power saving mode is retained until the next operation.
11-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 11 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–12–
Slim Duct Type Owner’s Manual
EN
7ADVANCED SETTINGS
How to set up power saving mode
1Push button for at least four
seconds when the air conditioner is not
working.
• , symbol, and numbers flash.
2Select an indoor unit to be set by
pushing (left side of the button).
• Each time you push the button, unit
numbers change as follows:
The fan of the selected unit runs.
3Adjust the power-save setting by
pushing TIME buttons.
• Each push of the button changes the power
level by 1% within the range from 100% to
50%.
• The factory setting is 75%.
• This indication may not be true for types
other than 4-series outdoor unit.
4Push button.
5Push button to complete the setting.
4
3
1
52
UnitNo.
1-1 UnitNo. 1-2 UnitNo. 1-3
UnitNo.
1-4
Setting of power level in
power saving mode
12-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 12 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–13–
Slim Duct Type Owner’s Manual
8HINTS FOR ECONOMICAL OPERATION
Maintain room temperature at comfortable level
Clean air filters
The clogged air filter impairs the performance of the air conditioner.
Never open doors and windows more often than
necessary
To keep cool or warm air in the room, never open doors and
windows more often than necessary.
Window curtains
In cooling, close the curtains to avoid direct sunlight.
In heating, close the curtains to keep the heat in.
Get uniform circulation of room air
Adjust the air flow direction for the even circulation of room air.
Checks before operating
• Check whether the ground wires are properly connected.
• Check whether the air filters are installed.
• Turn on the leakage breaker at least 12 hours before operating.
Protective device
• The protective device stops operation when the air conditioner is
overloaded.
• When the protective device is activated, the current operation
stops and the operation lamp and on the remote controller
flash.
When the protective device is activated
• When the protective device has been activated and stopped operation, turn off the leakage breaker
immediately, and ask the installer to find the cause.
If the air conditioner is operated without fixing the problem, the air conditioner may malfunction.
• Check whether the air filters are installed.
If the air filters are not installed, the air heat exchanger may be clogged with dust, which may result in
water leakage.
For cooling (COOL)
• When the air inlet and/or outlet of the outdoor unit are blocked
• When the air outlet of the outdoor unit is continuously exposed to strong wind
For heating (HEAT)
• When the air filters are clogged with too much dust or dirt
• When the suction port and/or discharge port of the indoor unit are blocked
Do not turn off the leakage breaker
• Do not turn off the leakage breaker during a test run of the air conditioner. Use the ON/OFF button on
the air conditioner instead to control the power.
Clean, please.
Blows upward
Air flow adjustment
Blows downward
13-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 13 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–14–
Slim Duct Type Owner’s Manual
EN
9MAINTENANCE
WARNING
Cleaning of the air filter and other parts of the air filter involves dangerous work in high
places, so be sure to have a service person do it.
Do not attempt it yourself.
Cleaning of air filters
Clogging of air filters will reduce the cooling and heating performance.
(1) When “FILTER ” appears on the remote controller, clean the air filters.
(2) When the cleaning of air filters has been completed, push button.
“FILTER ” disappears.
CAUTION
Cleaning of remote controller
• Use a dry cloth to wipe the remote controller.
• Never use a damp cloth on the remote controller.
• Do not use a chemically-treated duster for wiping or leave such materials on the unit for long.
It may damage or fade the surface of the unit.
• Do not use benzine, thinner, polishing powder, or similar solvents for
cleaning. These may cause the plastic surface to crack or deform.
Periodic check
Long-period use of the air conditioner may cause deterioration or failure of
parts due to heat, humidity, dust, and operating conditions, or may cause poor
drainage of dehumidified water.
If you do not plan to use the unit for more than 1 month
(1) In addition to the self cleaning, operate the fan for 1 or 2 hours to dry inside
the unit.
• Operate “FAN” mode.
(2)
Stop the air conditioner and turn off the main power switch or the circuit breaker .
Checks before operation
(1) Check that the air filters are installed.
(2) Check that the air outlet or inlet is not blocked.
(3) Turn on the main power switch or the circuit breaker for the main power
supply to the air conditioner.
(1)
(2)
14-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 14 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–15–
Slim Duct Type Owner’s Manual
NOTE
• For environmental conservation, it is strongly recommended that the indoor and outdoor units of the
air conditioner in use be cleaned and maintained regularly to ensure efficient operation of the air
conditioner.
When the air conditioner is operated for a long time, periodic maintenance (once a year) is
recommended.
Furthermore, regularly check the outdoor unit for rust and scratches, and remove them or apply
rustproof treatment, if necessary.
As a general rule, when an indoor unit is operated for 8 hours or more daily, clean the indoor unit and
outdoor unit at least once every 3 months. Ask a professional for this cleaning/maintenance work.
Such maintenance can extend the life of the product though it involves the owner’s expense.
Failure to clean the indoor and outdoor units regularly will result in poor performance, freezing, water
leakage, and even compressor failure.
• This product incorporates a drain pump.
If it is used in a place full of dust or oil mist, the pump will be clogged and proper drainage is disabled.
Clean the drain pump periodically. For how to clean the drain pump, contact the dealer.
Maintenance List
Part Unit Check (visual/auditory) Maintenance
Hear exchanger Indoor/outdoor • Dust/dirt clogging, scratches • Wash the heat exchanger when it is
clogged.
Fan motor Indoor/outdoor • Sound • Take appropriate measures when
abnormal sound is generated.
Filter Indoor • Dust/dirt, breakage • Wash the filter with water when it is
contaminated.
• Replace it when it is damaged.
Fan Indoor
• Vibration, balance
• Dust/dirt, appearance
• Replace the fan when vibration or
balance is terrible.
• Brush or wash the fan when it is
contaminated.
Air inlet/outlet grilles Indoor/outdoor • Dust/dirt, scratches • Fix or replace them when they are
deformed or damaged.
Drain pan Indoor • Dust/dirt clogging, drain contamination • Clean the drain pan and check the downward slope for smooth
drainage.
Ornamental panel,
louvers Indoor • Dust/dirt, scratches • Wash them when they are
contaminated or apply repair
coating.
Exterior Outdoor • Rust, peeling of insulator
• Peeling/lift of coat
• Apply repair coating.
15-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 15 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–16–
Slim Duct Type Owner’s Manual
EN
10AIR CONDITIONER OPERATIONS AND
PERFORMANCE
3 minutes protection function
3-minutes protection function prevents the air conditioner from starting for initial 3 minutes after the main
power switch/circuit breaker is turned on for re-starting the air conditioner.
Power failure
Power failure during operation will stop the unit completely.
• To restart the operation, push the START/STOP button on the remote controller.
• Lightning or a wireless car telephone operating nearby may cause the unit to malfunction. Turn off the
main power switch or circuit breaker and then turn them on again. Push the START/STOP button on
the remote controller to restart.
Heating characteristics
Preheating operation
The air conditioner will not deliver warm air immediately after it is turned on. Warm air will start to flow out
after approximately 5 minutes when the indoor heat exchanger warmed up.
Warm air control (In heating operation)
When the room temperature reaches the set temperature, the fan speed is automatically reduced to
prevent to blow cold draft. At this time, the outdoor unit will stop.
Defrosting operation
If the outdoor unit is frosted during the heating operation, defrosting starts automatically (for
approximately 2 to 10 minutes) to maintain the heating capacity.
• The fans in both indoor and outdoor units will stop during the defrosting operation.
• During the defrosting operation, the defrosted water will be drained from the bottom plate of the outdoor unit.
Heating capacity
In the heating operation, the heat is absorbed from the outside and brought into the room. This way of
heating is called heat pump system. When the outside temperature is too low, it is recommended to use
another heating apparatus in combination with the air conditioner.
Attention to snowfall and freeze on the outdoor unit
• In snowy areas, the air inlet and air outlet of the outdoor unit are often covered with snow or frozen up.
If snow or freeze on the outdoor unit is left as it is, it may cause machine failure or poor warming.
• In cold areas, pay attention to the drain hose so that it perfectly drains water without water remaining
inside for freeze prevention. If water freezes in the drain hose or inside the outdoor unit, it may cause
machine failure or poor warming.
Air conditioner operating conditions
For proper performance, operate the air conditioner under the following temperature conditions:
If air conditioner is used outside of the above conditions, safety protection may work.
Cooling operation
Outdoor temperature : –15°C to 43°C
Room temperature : 21°C to 32°C (Dry valve temp.), 15°C to 24°C (Wet valve temp.)
[CAUTION] Room relative humidity – less than 80 %. If the air conditioner operates in
excess of this figure, the surface of the air conditioner may cause dewing.
Dry operation Outdoor temperature : 15°C to 43°C
Room temperature : 17°C to 32°C
Heating operation Outdoor temperature : –15°C to 15°C (Wet valve temp.)
Room temperature : 15°C to 28°C (Dry valve temp.)
16-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 16 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–17–
Slim Duct Type Owner’s Manual
11INSTALLATION
Installation place
CAUTION
•Check that the air conditioner is not installed in a place subject to combustible gas leak.
Accumulation of combustible gas around the unit may cause a fire.
• Drain the dehumidified water from the indoor unit and outdoor unit to a well-drained place.
• Do not put any obstacle near the air inlets and air outlet of the outdoor unit. Doing so may hinder the
radiation, which may reduce the performance or activate the protective device.
Electrical wiring
WARNING
• Be sure to connect earth wire. (grounding work)
Incomplete grounding cause an electric shock.
Do not connect ground wires to gas pipes, water pipes, lightning rods or ground wires for telephone wires.
CAUTION
•Make sure that a leakage breaker is connected.
Using the air conditioner without leakage breaker may cause electric shock.
•Use a leakage breaker with an appropriate capacity.
Be sure to use the rated voltage and an exclusive circuit for power supply of the air conditioner.
Do not install the air conditioner in the following places
• Do not install the air conditioner in any place within 1 m from a TV, stereo, or radio set. If the unit is
installed in such place, noise transmitted from the air conditioner affects the operation of these
appliances.
• Do not install the air conditioner near a high frequency appliance (sewing machine or massager for
business use, etc.), otherwise the air conditioner may malfunction.
• Do not install the air conditioner in a humid or oily place, or in a place where steam, soot, or corrosive
gas is generated.
• Do not install the air conditioner in a salty place such as seaside area.
• Do not install the air conditioner in a place where a great deal of machine oil is used.
• Do not install the air conditioner in a place where it is usually exposed to strong wind such as in seaside area.
• Do not install the air conditioner in a place where sulfureous gas generated such as in a spa.
• Do not install the air conditioner in a vessel or mobile crane.
• Do not install the air conditioner in an acidic or alkaline atmosphere (in a hot-spring area or near a
chemicals factory, or in a place subject to combustion emissions). Corrosion may be generated on the
aluminum fin and copper pipe of the heat exchanger.
• Do not install the air conditioner near an obstacle (air vent, lighting equipment, etc.) that disturbs
discharge air. (Turbulent airflow may reduce the performance or disable devices.)
• Do not use the air conditioner for special purposes such as preserving food, precision instruments, or
art objects, or where breeding animals or growing plants are kept.
(This may degrade the quality of preserved materials.)
• Do not install the air conditioner over an object that must not get wet. (Condensation may drop from
the indoor unit at a humidity of 80% or more or when the drain port is clogged.)
• Do not install the air conditioner in a place where an organic solvent is used.
• Do not install the air conditioner near a door or window subject to humid outside air.
Condensation may form on the air conditioner.
• Do not install the air conditioner in a place where special spray is used frequently.
17-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 17 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–18–
Slim Duct Type Owner’s Manual
EN
Be careful with noise or vibrations
• Do not install the air conditioner in a place where noise by outdoor unit or hot air from its air outlet
annoys your neighbors.
• Install the air conditioner on a solid and stable foundation so that it prevents transmission of resonating,
operation noise and vibration.
• If one indoor unit is operating, some sound may be audible from other indoor units that are not
operating.
WARNING
Re-Installation
Ask the dealer or an installation professional to re-install the air conditioner to a new place or move it to
another place and to observe the following items.
If the air conditioner is inappropriately installed by yourself, it may cause electric shock or fire.
12TROUBLES AND CAUSES
CAUTION
If any of the following conditions occur, turn off the main power supply switch and immediately contact the dealer :
• Switch operation does not work properly.
• The main power fuse often blows out, or the circuit breaker is often activated.
• A foreign matter or water fall inside the air conditioner.
• When the air conditioner does not operate even after the cause of the protective device activation has been
removed. (The operation lamp and on the remote controller are flashing.)
• Any other unusual conditions are observed.
Before you ask for servicing or repairs, check the following points.
▼Recheck
Inoperative
• The main power switch is turned off.
• The circuit breaker is activated to cut off power supply.
• The main power fuse has blown out.
Does not cool well or heat well
• The air inlet and/or outlet of the outdoor unit is blocked.
• Doors or windows are opened.
• The fan speed is set to low.
• The air conditioner is set in the DRY mode in cooling.
• The set temperature is too high (In cooling) or low (In heating).
18-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 18 Friday, March 7, 2008 2:47 PM

Toshiba XXXXXXX(X/X)
–19–
Slim Duct Type Owner’s Manual
▼These are not failures.
Indoor unit or outdoor unit makes a strange noise.
• When the temperature suddenly changes, the indoor or outdoor unit occasionally makes a strange
noise because of expansion/ contraction of parts or change of refrigerant flow.
• A “busyu” sound is heard occasionally.
It is generated by the solenoid valve when it is actuated.
• A clattering sound is heard when the power is turned on.
It is generated by the outdoor unit during preparation for operation.
The room air is smelly or a bad odor comes from the air conditioner.
• Smells impregnated in the walls‚ carpets, furniture, clothing, or furs, come out.
Outdoor unit is frosted in heating operation.
Water drains from outdoor unit.
• The outdoor unit is sometimes frosted in heating operation.
In that case, the unit automatically performs defrosting (for 2 to 10 minutes) for increasing the heating
efficiency.
• In defrosting operation, both the indoor and outdoor units stop air flow.
• Hiss sound is heard when flow of the refrigerant is changed for defrosting.
• Resultant water of automatic defrosting in heating operation drains from outdoor unit.
Air flow changes though the FAN button is not set to the AUTO mode.
• When the temperature of blown air drops in heating operation, the air conditioner automatically
changes or stops air flow from the indoor unit not to make persons in the room feel chilly.
• Air flow from the indoor unit is occasionally changed in the cooling operation.
A white mist of chilled air or water is generated from the outdoor unit.
• When the indoor unit in cooling operation or the outdoor unit in defrosting operation occasionally
steams.
Check these items. If any of these problems still remains, stop the operation, turn off the leakage breaker,
and then notifies the dealer of the serial number and details of the error. Never repair any part by yourself
as it is dangerous. When and a combination of , , , , or and a number are displayed on
the remote controller, also inform the dealer of the display content.
19-EN
+00EH99932001_ALL_SlimDuct_OM.book Page 19 Friday, March 7, 2008 2:47 PM
