dynadock™
USB Docking Station with Video Port (DVI)
Connect to all your computer devices with one USB
cable quickly and easily!
The Toshiba dynadock USB Docking Station with Video Port is
an advanced docking solution with a high-performance video
controller. Virtually any brand of Windows-based computers
with a USB 2.0 port is compatible with this versatile port
replicator. Its upright slim docking station design provides
fast access to your desktop environment. Get one for your
home and office for simple expandability and connectivity!
Quick Connect
Easy Plug-and-Play connectivity; connects your desktop
devices to your computer with one USB cable.
Universal
Compatible with any brand of Windows-based computers,
including laptops and desktops, running XP or Vista™
operating systems.
Multimedia
Adds 7.1 channel surround sound via S/PDIF port and
provides high-resolution video output through the VGA or
DVI port on the dynadock.
Expandability
Provides six additional USB 2.0 ports--with the two front
“always on” ports providing power even when the PC is off.
View up to 3 displays1simultaneously.
Space-saving
Upright slim design takes up minimul desktop space and
reduces cable clutter. It also eliminates the
wear-and-tear on both the PC ports and the cable plugs
themselves.

Features
• Space-saving upright slim design reduces
cable clutter
• Provides 6 USB 2.0 ports with easy
Plug-and-Play connectivity
• Advanced docking station with high
performance video controller support:
- Available in either VGA or DVI video
support
- Supports viewing up to three displays
simultaneously
• Access all your computer devices through
one USB cable connectivity
• Front USB ports supply power even if the
PC is off
• Adds 7.1 channel surround sound though
S/PDIF port
Specifications
• Ports:
-Six USB (2.0)
-One S/PDIF (optical digital audio output)
-One Ethernet (RJ-45 LAN)
-One Serial
-One microphone (3.5 mm)
-One headphone or speaker (3.5 mm)
-One DVI-I (Digital 24-pin +Analog 5-pin
Female connector)
• Input ports
-One USB (2.0) port
-One DC-in plug
• Power
-AC 100-240V (input)
-DC 5V / 5A (output)
• Supported Video Modes
-Mirror mode
-Extended mode
-Primary Display2
• Resolution
-32-bit color depth up to 1600 x 1200
• Audio processor USB Audio Device Class
specifications v1.0 compliant 7+1 channel
audio processor
• Ethernet protocol
- IEEE 802.3
- IEEE 802.3u
• Serial connector
-RS232 DB9 Male connector
• Dimensions & Weight
-1.8” (W) x 3.1” (D) x 8.75” (H)
-1.13 lbs.3
• Agency approvals:
-Safety: UL/cUL, CE, PSE, SAA, CB Report
-EMC: FCC, IC, CE, VCCI, SMA
• One (1) Year Standard Limited Warranty
Minimum System Requirements
• PC with 1.2GHz or higher processor:
Intel® Pentium® /Celeron®family or AMD
K6/Athron/Duron family, or compatible
processor (Core™2 Duo 2.0GB PC
processor or higher recommend)
• Windows Vista™ or XP with SP1 (SP2
recommended)4
• 512MB of RAM or higher (1GB
recommended)
• USB 2.0 port
• 30MB of available disk space
• CD-ROM drive
1To view up to three displays: Notebook display; External
display connected to the notebook; External display connected
to the dynadock. 2Some built-in video adapters may prevent a
second monitor from being the primary display. 3Weight may vary.
See Weight Legal Footnote at www.info.toshiba.com . 4Windows
Vista supports mirror mode only; XP supports extended mode and
mirror mode. Visit dynadock.com for updated Windows XP and
Vista software driver support.
© 2007 Toshiba America Information Systems, Inc. dynadock is
a trademark of Toshiba America Information Systems, Inc. and
/or Toshiba Corporation. Windows and Vista are registered
trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. All other trademarks are
the property of their respective owners. All products and names
mentioned are the property of their respective owners. Product
specifications, configurations, prices, system/component/options
availability are all subject to change without notice. All Rights
Reserved.
dynadock™ USB Docking Station with Video Port (DVI)
Product Name dynadock USB Docking Station
with Video (DVI)
Part Number PA3542U-2PRP
UPC 032017782327
Product Category Expansion
Status In stock, Shipping
Operating System Windows®XP and Vista™4
Environmental RoHS Compliant
Country of Origin China
Replacement for New
Compatible with Computers with a USB 2.0 port
Color Mist Gray & Black
Product Dimensions 45mm x 78mm x 222mm
1.8” x 3.1” x 8.75”
Product Weight 500g / 1 lb, 2 oz. (with base
plate)3
Package Dimensions 289mm x 252mm x 70mm
11.4” x 9.9” x 2.75”
Package Weight 1306g / 2 lbs, 15 oz.
Master Carton Quantity 10
Master Carton Dimensions 523mm x 304mm x 378mm
20.6” x 12” x 14.9”
Master Carton Weight 15.6 kg / 34.4 lbs.
Packaging Retail box
Warranty One (1) Year Standard Limited
Package Contents USB docking station with DVI
port Base plate
Cable holder
USB 2.0 cable
AC power adapter
AC power cord/cable
CD (user manual, driver and util-
ity) Quick installation guide
DVI to VGA adapter
