DVD VIDEO RECORDER
SERVICE MANUAL
FILE NO. 810-200413
D-R2SU
D-R2SC
D-KR2SU
DIGITAL VIDEO

PREPARATION OF SERVICING
Pickup Head consists of a laser diode that is very susceptible to external static electricity.
Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement,
its life might be shortened. When replacing, use a conductive mat, soldering iron with ground wire, etc. to
protect the laser diode from damage by static electricity.
And also, the LSI and IC are same as above.
1M W
Ground conductive
wrist strap for body.
Soldering iron
with ground wire
or ceramic type
Conductive mat The ground resistance
between the ground line
and the ground is less than 10 W .
LASER BEAM CAUTION LABEL
When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of a laser
may be received.

SAFETY NOTICE
SAFETY PRECAUTIONS
LEAKAGE CURRENT CHECK
Plug the AC line cord directly into a 120V AC outlet (do
not use an isolation transformer for this check). Use an
AC voltmeter, having 5000 Wper volt or more sensitivity.
Connect a 1500 W10 W resistor, paralleled by a 0.15 mF
150V AC capacitor between a known good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of
cabinet (antennas, handle bracket, metal cabinet
screwheads, metal overlays, control shafts, etc.).
Measure the AC voltage across the 1500 Wresistor.
The test must be conducted with the AC switch on and
then repeated with the AC switch off. The AC voltage
indicated by the meter may not exceed 0.3 V. A reading
exceeding 0.3 V indicates that a dangerous potential
exists, the fault must be located and corrected.
Repeat the above test with the DVD VIDEO RECORDER
power plug reversed.
NEVER RETURN A DVD VIDEO RECORDER TO
THE CUSTOMER WITHOUT TAKING NECESSARY
CORRECTIVE ACTION.
READING SHOULD NOT EXCEED 0.3V
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
DVD VIDEO RECORDER AC VOLTMETER
(5000 W per volt
or more sensitivity)
Good earth ground
such as a water pipe,
conduit, etc.
1500 W
10 W
0.15 m F 150V AC
AC OUTLET
Test all exposed metal.
Voltmeter Hook-up for Leakage Current Check

SECTION 2
PART REPLACEMENT AND ADJUSTMENT PROCEDURES
SECTION 3
SERVICING DIAGRAMS
1. CIRCUIT SYMBOLS AND
SUPPLEMENTARY EXPLANATION
1-1. Precautions for Part Replacement
1-2. Solid Resistor Indication
1-3. Capacitance Indication
1-4. Inductor Indication
1-5. Waveform and Voltage Measurement
1-6. Others
2. PRINTED WIRING BOARD AND
SCHEMATIC DIAGRAM
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram
4. CIRCUIT DIAGRAMS
4-1. Power Supply Circuit Diagram
4-2. Front Circuit Diagram
4-2-1. Front Jack Circuit Diagram
4-2-2. Front Circuit Diagram (L)
4-2-3. Front Circuit Diagram (R)
4-3. Digital Circuit Diagram
4-3-1. Digital 1 Circuit Diagram
4-3-2. Digital 2 Circuit Diagram
4-4. Mother Circuit Diagram
4-4-1. Tuner Circuit Diagram
4-4-2. Timer Circuit Diagram
4-4-3. Audio Circuit Diagram
4-4-4. Video Circuit Diagram
5. PC BOARDS
5-1. Front Jack PC Board
5-2. Front (L) PC Board
5-3. Front (R) PC Board
5-4. Digital PC Board
5-5. Mother PC Board
CONTENTS
SECTION 1
GENERAL DESCRIPTIONS
1. OPERATING INSTRUCTIONS
1. Replacement of Mechanical Parts
1-1. Cabinet Replacement
1-1-1. Top Cover
1-1-2. Front Panel
1-1-3. Tray Door
1-1-4. Operation Panel Door
1-1-5. RAM Diver
1-1-6. Fan
1-1-7. Rear Panel
1-2. PC Board Replacement
1-2-1. Digital PC Board
1-2-2. Mother PC Board
1-2-3. Power PC Board
1-2-4. Front (R), Front (L), Front (Jack) PC Board
2. LOCATION OF MAIN PARTS
2-1. Location of Main Parts
2-2. Location of PC Boards
SECTION 4
PARTS LIST
SAFETY PRECAUTION
NOTICE
ABBREVIATIONS
1. Integrated Circuit (IC)
2. Capacitor (Cap)
3. Resistor (Res)
4. EXPLODED VIEWS
4-1. Packing Assembly
4-2. Chassis Assembly
5. PARTS LIST

SECTION 1
GENERAL DESCRIPTIONS
1. OPERATING INSTRUCTIONS
Please refer to the owner's manual about the contents.
SECTION 1
GENERAL DESCRIPTIONS

2. LOCATION OF MAIN PARTS
2-1. Location of Main Parts
Fig. 1-2-1
2-2. Location of PC Boards
Fig. 1-2-2
ZG45 FAN
RAM1 RAM DRIVE
EU05 Mother PC board
EU01 Digital PC Board
EU0 Power PC board
EU03A Front (R) PC Board
EU55 Front (Jack) PC Board
EU03B Front (L)
PC Board

1-1. Cabinet Replacement
1-1-1. Top Cover
1. Remove seven screws (1), then remove the top cover (2).
Fig. 2-1-1
SECTION 2
PART REPLACEMENT AND
ADJUSTMENT PROCEDURES
Screws (1)
Screws (1)
Screws (1)
Top cover (2)
SECTION 2
PART REPLACEMENT AND
ADJUSTMENT PROCEDURES
CAUTIONS BEFORE STARTING PART REPLACEMENT
Electronic parts are susceptible to static electricity and may easily damaged, so do not forget to ground as required.
Many screws are used inside the unit. To prevent the screws from missing or dropping, etc. always use a magnetized
screwdriver in servicing. Several kinds of screws are used and some of them need special cautions. That is, take care of
the tapping screws securing molded parts and fine pitch screws used to secure metal parts. If they are used improperly,
the screw holes will be easily damaged and the parts can not be fixed.
1. REPLACEMENT OF MECHANICAL PARTS

1-1-2. Front Panel
1. Remove the top cover. (Refer to item 1-1-1.)
2. Peel off three tapes (1) and disconnect the flexible cable (2).
3. Disconnect the flexible cable (3) and two connectors (4).
4. Remove the screw (5).
5. Remove two screws (6).
6. Release four claws, then remove the front panel (7).
Fig. 2-1-2
Flexible cable (2)
Flexible
cable (3)
Tapes (1)
Connector (4)
Connector (4)
Screws (6)
Screw (5)
Front panel (7)
Claw
Claw
Claws
1-1-3. Tray Door
1. Remove the front (R) PC board and front (L) PC board. (Refer to item 1-2-4.)
2. Remove the spring (1).
3. Remove the tray door (2) while slightly bending it.
Fig. 2-1-3
Spring (1)
Tray oor (2)

1-1-5. RAM Drive
1. Peel off four tapes (1).
2. Disconnect two flexible cables (2).
3. Disconnect the connector (3).
4. Remove two screws (4) and acrylic board (5).
5. Remove four screws (6), then remove the RAM drive (7).
1-1-4. Operation Panel Door
1. Open the operation panel door (1).
2. Release two claws and unhinge the door (1).
Fig. 2-1-4
Front panel
Hinge
Claw
Claw
Hinge
Operation panel oor (1)
Flexible cable (2)
Flexible
cable (2)
Connector (3)
Tapes (1)
Tape (1)
Acrylic
boar (5)
Screws (6)
Screws (4)
RAM rive (7)
Connector
Claw
Flexible cable (2)
A
A
Remove the connector claw
in the irection in icate
by the arrows to release the
flexible cable.
Fig. 2-1-5

1-1-6. Fan
1. Peel off the tape (1).
2. Disconnnect the connector (2).
3. Remove four screws (3) and the fan (4).
Note:
• After replacing the fan (4), attatch the tape (1) as it was.
1-1-7. Rear Panel
1. Remove twelve screws (1), then remove the rear panel (2).
Fig. 2-1-7
Wire (5)
Wire (5)
Screws (3)
Connector (2)
Tape (1)
Fan (4)
Acrylic boar
Pass the wire (5)
un erneath the
fol e part.
Screws (1)
Rear panel (2)
Fig. 2-1-6

1-2. PC Board Replacement
1-2-1. Digital PC Board
1. Remove the RAM drive. (Refer to 1-1-5.)
2. Disconnect two connectors (1).
3. Peel off the tape (2), then disconnect the connector (3).
4. Disconnect the connector (4).
5. Remove four screws (5) and the digital PC board (6).
Connector (4) Screws (5)
Digital PC
boar (6)
Connector (3)
Tape (2)
Connectors (1)
Fig. 2-1-8

1-2-2. Mother PC Board
1. Remove the RAM drive. (Refer to item 1-1-5.)
2. Remove the rear panel. (Refer to item 1-1-7.)
3. Disconnect three connectors (1).
4. Disconnect the flexible cable (2).
5. Remove four screws (3), then remove the mother PC board (4).
Fig. 2-1-9
Screws (3)
Mother PC boar (4)
Connectors (1)
Flexible cable (2)
Connector (1)

1-2-3. Power PC Board
Cautions :
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type.
1. Disconnect three connectors (1).
2. Disconnect the connector (2).
3. Remove the screw (3), four screws (4) and the power PC board (5).
Fig. 2-1-10
Connectors (1)
Connector (1)
Connector (2)
Screw (3)
Power PC boar (5)
Screws (4)

1-2-4. Front (R), Front (L), Front (Jack) PC Board
1. Remove the front panel. (Refer to item 1-1-2.)
2. Disconnect the flexible cable (1), then peel off the tape (2).
3. Remove four screws (3), then remove the stay (4).
4. Remove eight screws (5) and the screw (6), then remove the front (R) PC board (7) and front (L) PC board (8).
5. Remove four screws (9), then remove the front (Jack) PC board (10).
Fig. 2-1-11
Screws (3)
Screws (5)
Screw (6)
Screws (9)
Stay (4)
Front (L) PC boar (8)
Front (R) PC boar (7)
Flexible cable (1)
Tape (2)
Front (Jack)
PC boar (10)

1. CIRCUIT SYMBOLS AND SUPPLEMENTARY EXPLANATION
1-1. Precautions for Part Replacement
• In the schematic diagram, parts marked (ex.
F801) are critical part to meet the safety regulations,
so always use the parts bearing specified part codes
(SN) when replacing them.
1-2. Solid Resistor Indication
Unit None ........... W
K ........... kW
M ........... MW
Tolerance None ........... ±5%
B ........... ±0.1%
C ........... ±0.25%
D ........... ±0.5%
F ........... ±1%
G ........... ±2%
K ........... ±10%
M ........... ±20%
Rated Wattage (1) Chip Parts
None ......... 1/16W
(2) Other Parts
None ......... 1/6W
Other than above, described in the Circuit Diagram.
Type None ........... Carbon film
S ........... Solid
R ........... Oxide metal film
M ........... Metal film
W ........... Cement
FR ........... Fusible
Symbol
+
........... Electrolytic, Special electrolytic
NP
........... Non polarity electrolytic
........... Ceramic, plastic
M........... Film
........... Trimmer
Unit None ........... F
m........... mF
p ........... pF
Rated voltage None ........... 50V
For other than 50V and electrolytic capacitors,
described in the Circuit Diagram.
Tolerance (1) Ceramic, plastic, and film capacitors of which
capacitance are more than 10 pF.
None ........... ±5% or more
B ........... ±0.1%
C ........... ±0.25%
D ........... ±0.5%
F ........... ±1%
G ........... ±2%
(2) Ceramic, plastic, and film capacitors of which
capacitance are 10 pF or less.
None ........... more than ±5 pF
B ........... ±0.1 pF
C ........... ±0.25 pF
(3) Electrolytic, Trimmer
Tolerance is not described.
Temperature characteristic None ........... SL
(Ceramic capacitor) For others, temperature characteristics are
described. (For capacitors of 0.01 mF and
no indications are described as F.)
Static electricity capacity Sometimes described with abbreviated letters as
(Ceramic capacitor) shown in Eg. 3.
1-3. Capacitance Indication
100k
Rated Wattage Type Tolerance
Eg. 1
104
10x104pF (0.1
m F)
Temperature characteristic
(or Temperature characteristic+
Static electricity capacity tolerance)
Eg. 3
100 m
Temperature
response Rated voltage Tolerance
Eg. 2
Fig. 3-1-1
Fig. 3-1-3
Fig. 3-1-2
• Using the parts other than those specified shall violate
the regulations, and may cause troubles such as
operation failures, fire etc.
SECTION 3
SERVICING DIAGRAMS
SECTION 3
SERVICING DIAGRAMS

1-4. Inductor Indication
Unit None ........... H
m........... mH
m ........... mH
Tolerance None ........... ±5%
B ........... ±0.1%
C ........... ±0.25%
D ........... ±0.5%
F ........... ±1%
G ........... ±2%
K ........... ±10%
M ........... ±20%
1-5. Waveform and Voltage Measurement
• The waveforms for CD/DVD and RF shown in the
circuit diagrams are obtained when a test disc is
played back.
• All voltage values except the waveforms are expressed
in DC and measured by a digital voltmeter.
1-6. Others
• The parts indicated with "NC" or "KETU" etc. are not
used in the circuits of this model.
Eg. 4
Eg. 5
Fig. 3-1-4
Fig. 3-1-5
Type name
10 m
Type Tolerance

2. PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM
Fig. 3-2-1
1 2 3 4 5 6 7 1 2 3 4 5
5
4
3
2
1
5
4
3
2
1
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
1 2 3 4 5 6 7 8 9
10 11
18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
10
9 8 7 6 5 4 3 2 1
11 10
9 8 7 6 5 4 3 2 1
723
622
521
420
319
218
117
16
17
18
19
20
21
22
23
16
15 15
14 14
13 13
12 12
11 11
10 10
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
13 12 11 10
9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8
23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
13 12 11 10
9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
10 10
11 11
12 12
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
1 2 3 4 1 2
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
1 2 3 4
GND
CN104
Driver_SCK
W100
FL(+)
FL(-)
Vkk
GND
EVER+5V
FL_5V
DASPX
GND
B_DASP
D_GND
CS0X
B_CS2 B_CS0 B_CS1 CS1X
DA1
PDIAGX
DA0 DA2
DMACKX
GND
INTRQ
IOCS16X
DIORX
GND
IORDY
SPSYNC
DMARQ
GND
DIOWX
GND
DATA0
DATA15
GND
RSV
DATA2
DATA13
DATA1
DATA14
DATA4
DATA11
DATA3
DATA12
DATA6 DATA9 DATA5
DATA10
RESETX
GND
DATA7 DATA8
B_DD6 B_DD9 B_DD5
B_DD10
DRESETB
D_GND
B_DD7 B_DD8 B_DD4
B_DD11
B_DD3
B_DD12
B_DD2
B_DD13
B_DD1
B_DD14
B_DD0
B_DD15
D_GND
NC
B_DMARQ
D_GND
BDIOW
NC
B_DIOR
D_GND
B_IORDY
NC
B_DMACK
D_GND
B_DINTRQ
NC
B_DA1
NC
B_DA0 B_DA2 B_CS0 B_CS1
B_DASP
D_GND
B_DD7
B_DD15
GND
CN703
B_DD1
B_DD14
B_DD4
B_DD11
B_DRESET
D_GND
RxD
CN508
GND
D5V
GND
V-GND
EE40
Eject_SW
LED_Scan2 LED_Scan1
GND
B_DD8 B_DD6 B_DD9 B_DD3 B_DD5
B_DD10 B_DD12
B_DD2
B_DD13
D_GND
B_DD0
NC
B_DMAREQ
D_GND
B_IORDY
B_DIOR
D_GND
NC
BDIOW
NC
B_DMACK
D_GND
B_DA0 B_DA1
NC
B_INTRQ
NC
CR-OUT CB-OUT
V-GND
CY-OUT
V-GND
Y-OUT
V-GND
CV-OUT
V-GND
C-OUT
A-GND
SPICS SPIDA SPICK
PB-LRCK PB-DATA
IEC958
A-GND
REC-ACK
PB-BCK
A-GND
PB-ACK
A-GND
REC_BCK
REC_DATA REC_LRCK
CN401
A_GND
C-IN
V_GND
CV/Y-IN
V_GND
RXD(R-T)
TXD(T-R) RTS(T-R) CTS(R-T)
EVER6V
GND
EVER6V
GND
ON/OFF15.3V
GND
ON/OFF37V
GND
A_GND
TPO+
TPO-
PowerGood
CPU5V
GND
ON/OFF5V
GND
ON/OFF3.0V
GND
A-GND
GND GND TPI+
TPI-
TpAon TpBop TpBon
CN506CNZ01
GND GND
DGND TpAop
CTS2
SPICK
PB-LRCK PB-DATA
PB-BCK
CN902
REC_DATA
CR-OUT CB-OUT
V-GND
CY-OUT
V-GND
Y-OUT
V-GND
CV-OUT
REC_LRCK
GND GND
REC_BCK
B-B
TPO-
GND
TXD(T-E) RTS(T-E) CTS(E-T)
CN706
C-IN
GND
CV/Y-IN
GND
RXD(E-T)
TPI-
GND GND
TPO+
GND TPI+
-
LNB_ON/OFF
REMOTE
GND
Power_SW
LED_Scan0
LED_Out3 LED_Out1 Driver_CS
Power_LED
CN704
Audio_R
GND
TxD
-
GND
WriteEnable
TimerReset
5vcpu
Audio_L
GND
Video_COMP
GND
PowerGood
CPU5V
GND
ON/OFF5V
GND
ON/OFF3.0V
GND
ON/OFF-9V
GND
ON/OFF+9V
GND
EVER6V
GND
EVER6V
GND
NC
GND
ON/OFF37V
GND
GND
D+5V
GND
D+3.3V
GND
D+1.5V
GND
D+1.5V
D+3.3V
GND
D+1.5V
GND
FL(+)
GND
CN105
GND
FL_5V
EVER_5V
Vkk NC
CN102
12V
GND GND
5V
MOTOR(+)
MOTOR(-)
CN106
FL(-)
CN201 CN501 CN500
RTS2
TXD2
RXD2
GND GND
D3.3V
FLSSHW-X
LED_Out2 LED_Out0
REMOTE
GND
Power_SW
Power_LED
Eject_SW
LED_Scan2 LED_Scan1 LED_Scan0
DATA4
DATA11
DATA3
DATA12
TPBon TPBop
B-B
CN170
GND
TPAop TPAon
CN102
LED_Out3 LED_Out1
CN101
PowerON0
PowerON1
FAN_CNT
D1.5V
PowerON0
PowerON1
FAN_CNT
Vkk
GND
ON/OFF+9V
GND
GND
D3.3V
DATA6 DATA9 DATA5
DATA10
RESETX
GND
DATA7 DATA8 DATA2
DATA13
DATA1
DATA14
DATA0
DATA15
GND
RSV
DMARQ
GND
DIOWX
GND
DIORX
GND
IORDY
SPSYNC
DMACKX
GND
INTRQ
IOCS16X
DA1
PDIAGX
DA0 DA2
CS0X CS1X
DASPX
GND
12V(YELLOW)
GND(BLACK) GND(BLACK)
5V(RED)
B-B
PB-ACK
CN701
GND
D1.5V
GND
D3.3V
D1.5V
GND
CNW01
CN702
A-GND
REC-ACK
A-GND
C-OUT
A-GND
SPICS SPIDA
IEC958
GND
Driver_In
Driver_Out
Driver_SCK
W100R W150
Power_SW
Power_LEDPower_LED
EVER+5V
REMOTE
GND
Power_SW
EVER+5V
REMOTE
GND
Driver_Out
GND
Video_Y
GND GND
Audio_L
GND
Video_COMP
Driver_CS
GND
LED_Out2 LED_Out0
GND
Driver_In
CN171
Video_C
GND
Line2_S
GND
Line2_S
Audio_R
Video_C
Video_Y
GND
W051 FFC
52559-4082
127301123K2
MOUNT
52806-1010
FAN
LEADS
CABLE
memo
W004 LEADS CABLE 05 120
W008 LEADS CABLE 04  250
W016 LEADS CABLE 12  260
W100 LEADS CABLE 07  140
W101 PARALLEL CABLE 05  58
W170 WIREAWG22M3L110 01  110
memo
W051 FFC 40 360
W051A ATAPI-FFC-UNT
W053 FFC 18  210
W058 FFC 11 410
52806-1110
LEADS
CABLE
FFC
1394 SHIELD
LEADS CABLE
LEADS
CABLE
RAM DRIVE
W051A
ATAPI-FFC-UNT
W004
W058 W170
FFC
W053
W100
W008
W101
PARALLEL
DV connector
no use
LEADS
CABLE
W016
EU03A
FRONT RIGHT EU03B
FRONT
LEFT
EU55
JACK
EU05
MOTHER
RAM1 RAM DRIVE
EU01
DIGITAL
EU02
POWER

FL_Tube
FRONT PANEL UNIT
AC 120 V
DC FAN
AC IN
Audio LPF
&Amplifier
ANALOG
CIRCUIT
Lch
Rch
R.S
POWER_UNIT
12.5MHz
32.768KHz
KEY
Y
PB
PR
VIDEO
ANALOG
CIRCUIT
OUT
SVideo
Audio OUT
INTERLACE/PROGRESSIVE /
COLOR DIFFERENCE
Video OUT
COMPOSITE
Video OUT
Video OUT
OPTICAL.
DIGITAL.OUT
DVDRAM/RWDrive
INPUT
Line Selector
V/U Tuner
ENG36501G
uPD72852
1394 PHY
uPD61171F1
FRAME SYNC
ENCODE
ENCRIPT
ATAPI DRV
DECRIPT
DECODE
GRAPIC
NTSC ENCODE
MAIN CPU
uPD72893
1394 AV LINK
DV
uPD64011B
3D Y/C_DNR+
ADC+Decoder
OSC
27MHz
Audio
AD Converter
AK5365
Audio
D/A Converter
PCM1751
NJM2115
16Mbit
SDRAM
12.288MHz
16Mbit
SDRAM
256Mbit
DDR-SDRAM
X4
64kbit
EEPROM
PLL
64Mbit
FLASH ROM
OUT_1
OUT_1
IN_3
IN_2
IN_1
VHF/UHF
Timer CPU
uPD784225Y
FL_Driver
BU2879AK
24.576MHz
24.576MHz
4.0MHz
S-in
S-in
S-in
C_Video-in
C_Video-in
C_Video-in
Audio-in L/R
Audio-in L/R
Audio-in L/R
MPN5216
Type: SD-W3002
IC512
IC504
IC502 IC503
IC901
IC515, IC516
IC520, IC521
IC101
IC301
IC302
ICA01
IC700
MB01
ICA19
--- Digital 1
--- Front
--- Audio
--- Timer
--- Tuner
--- Digital 2 (Audio/Video)
Fig. 3-3-1
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram

10134
A
B
C
D
E
G
2 5 6 7 89
F
Fig. 3-4-1
4.CIRCUIT DIAGRAMS
4-1. Power Supply Circuit Diagram

134
A
B
C
D
E
G
2 5
F
4-2. Front Circuit Diagram
4-2-1. Front Jack Circuit Diagram
Fig. 3-4-2
