Thank you for purchasing a Toshiba TOSVERT VF-S15 series inverter.
This instruction manual explains additional information about VFS15-400PL1 to 4037PL1.
This instruction manual gives a supplementary explanation of some items referred to in the instruction manual
E6581928(Quick Start) and E6581611(Detailed).
Please read this manual carefully along with the instruction manual E6581928 and E6581611.
3-phase 500V class 0.4 to 4.0 kW
- NOTICE -
1. Make sure that this instruction manual is delivered to the end user of the inverter unit.
2. Read this manual before installing or operating the inverter unit, and store it in a safe place for reference.
3. Please see to it that this manual is supplied to the inverter’s end user, along with the instruction manual
E6581928(Quick Start).
Instruction Manual (Supplementary)
TOSVERT VF-S15

E6582185
2
■Safety precautions
Please read “I. Safety precautions” and text in the manual E6581611 in CD-ROM.
Following chapter numbers are same as the manual E6581611.
1.2 Contents of the product
Explanation of the name plate label
1.3.2 Opening terminal cover and terminal block
Use the following procedure to open the terminal cover and pull the power terminal block.
Inverter type Procedure Reference number
VFS15-4004PL1-W1 to 4037PL1-W1 In the beginning, remove the outside terminal
block cover. (1)
Next, remove the inside terminal block cover. (2)
Model name
TOSVERT
VF-S15 series
Modified number
Applicable motor
capacity
004 : 0.4kW
007 : 0.75kW
015 : 1.5kW
022 : 2.2kW
037 : 4.0kW
Additional functions I
L : Built-in high-attenuation
EMC filter
Operation panel
P: Provided
Input (AC) voltage
4 : 380V to 500V
Additional functions II
W1 : World model
None: Japanese model
V F S 1 5 - 4 0 0 7 P L 1 - W 1
Type Form

E6582185
3
1.3.2(3)外側端子台カバーはずし方
s2frev0101.eps
1.3.2(3)外側端子台カバーはずし方
s2frev0103.eps
1.3.2(4)内側端子台カバーのはずし方
s2frev0101.eps
EASY
R/L1 S/L2 T/L3
MODE
RUN
RUN
STATUS
PRG
MON
STOP
%
Hz
1.3.2(4)内側端子台カバーのはずし方
s2frev0102.eps
EASY
R/L1 S/L2 T/L3
MODE
RUN
RUN
STATUS
PRG
MON
STOP
%
Hz
(1) Removing the outside terminal block cover (VFS15-4004PL1-W1 to 4037PL1-W1)
(2) Removing the inside terminal block cover (VFS15-4004PL1-W1 to 4037PL1-W1)
●After wiring is complete, be sure to restore the terminal cover to its original position.
1) 2)
Insert a screwdriver or other thin object
into the hole indicated with the mark.
While pressing on the screwdriver, sidles
the terminal cover downward to remove it.
1) 2)
The finger is put on to the tab part of the
terminal block cover. While pressing on the finger,
rotate the
terminal cover downward to remove it.

E6582185
4
1.3.2 Power circuit and control circuit terminal blocks
1) Power circuit terminal
Note1) Bend the clips on the wiring port of the terminal cover to connect the PB, PO, PA/+, and PC/- terminals.
Note2) Be careful to insert all wires into the cage of terminal block.
Grounding capacitor
switch position B
(
)
VFS15-4004PL1-W1 to 4015PL1-W1
M4 screw
Shorting-bar
Grounding capacitor
switch position A ( )
Grounding terminal
(M4 screw)
Grounding terminal
(
M5
screw)
For EMC plate
VFS15-4022PL1-W1 to 4037PL1-W1
Shorting
-
bar
M4
screw
For EMC plate
Grounding terminal
(M5
screw)
M3 screw
M3 screw
Grounding capacitor
switch position B ( )
Grounding capacitor
switch position A ( )

E6582185
5
2) Grounding capacitor switch
Three-phase 500V model have a built-in high-attenuation noise filter and is grounded via a capacitor.
A switch screw makes for easy switching to reduce leakage current from the inverter and the load on the
capacitor. However, be careful, as reducing the load means non-conformity with the EMC standard on
the inverter itself. Always do switching with the power off.
Note 1) Figure is VFS15-4022PL1-W1 to 4037PL1-W1.
1.4.4 Installation
Calorific values of the inverter and the required ventilation
About 5% of the rated power of the inverter will be lost as a result of conversion from AC to DC or from DC
to AC. In order to suppress the rise in temperature inside the cabinet when this loss becomes heat loss, the
interior of the cabinet must be ventilated and cooled.
The amount of forcible air-cooling ventilation required and the necessary heat discharge surface quantity
when operating in a sealed cabinet according to motor capacity are as follows.
Voltage class Inverter type Calorific values (W)
Note 1)
Amount of forcible air
cooling ventilation
required (m
3
/min)
Heat discharge
surface area
required for sealed
storage cabinet (m
3
)
Standby
power
requirement
(W)
Note 2)
4kHz 12kHz 4kHz 12kHz 4kHz 12kHz
Three-phase
500V class VFS15-
4004PL1-W1 29 39 0.17 0.22 0.59 0.79 17
4007PL1-W1 40 54 0.23 0.30 0.79 1.07 17
4015PL1-W1 62 88 0.35 0.50 1.24 1.76 17
4022PL1-W1 77 108 0.44 0.61 1.54 2.16 19
4037PL1-W1 113 169 0.64 0.96 2.26 3.38 19
Note 1) Case of 100% Load Continuation operation. The heat loss for the optional external devices
(input AC reactor, radio noise reduction filters, etc.) is not included in the calorific values in the table
Note 2) It is power consumption when power is on but is not output (0Hz), and cooling fan is activated (model
with cooling fan).
Install the screw at grounding capacitor switch position A ( ), th
e
grounding capacitor's capacity from small to large. (Default setting)
Tightening torque：0.5 Nm (4.4 lbin)
Move the screw to grounding capacitor switch position B ( ),
the
grounding capacitor's capacity from large to small. This reduce
s the
leakage current.
When this inverter is connected
to the IT system (insulated ground
of power supply or the system has Impedance), the screw
has to be
move
d as the figure shows.
Grounding
capacitor
switch
position
A ( )
Grounding
capacitor
switch
position
B ( )

E6582185
6
6.18 PWM carrier frequency
Load reduction (current reduction) by carrier frequency, ambient temperature and input voltage
VFS15- Ambient
temperature
Input voltage 480V or less Input voltage above 480V
PWM carrier frequency [kHz] PWM carrier frequency [kHz]
2.0~4.0 4.1~12.0 12.1~16.0 2.0~4.0 4.1~12.0 12.1~16.0
4004PL1-W1
40
°
C or less 1.5 A 1.5 A 1.5 A 1.5A 1.5A 1.2A
Above 40
∼
50
°
C
1.5 A 1.5 A 1.5 A 1.5A 1.5A 1.2A
Above 50
∼
60
°
C
1.4 A 1.2 A 1.2 A 1.4A 1.2A 1.0A
4007PL1-W1
40
°
C or less 2.3 A 2.1 A 2.1 A 2.1A 1.9A 1.9A
Above 40
∼
50
°
C
2.3 A 2.1 A 2.1 A 2.1A 1.9A 1.9A
Above 50
∼
60
°
C
2.2 A 1.7 A 1.7 A 2.0A 1.5A 1.5A
4015PL1-W1
40
°
C or less 4.1 A 3.7 A 3.3 A 3.8A 3.4A 3.1A
Above 40
∼
50
°
C
4.1 A 3.7 A 3.3 A 3.8A 3.4A 2.6A
Above 50
∼
60
°
C
3.9 A 3.0 A 2.6 A 3.6A 2.5A 1.5A
4022PL1-W1
40
°
C or less 5.5 A 5.0 A 4.5 A 5.1A 4.6A 4.2A
Above 40
∼
50
°
C
5.5 A 5.0 A 4.5 A 5.1A 4.6A 4.2A
Above 50
∼
60
°
C
5.2 A 4.0 A 3.6 A 4.8A 3.7A 3.4A
4037PL1-W1
40
°
C or less 9.5 A 8.6 A 7.5 A 8.7A 7.9A 6.9A
Above 40
∼
50
°
C
9.5 A 8.6 A 7.5 A 8.7A 7.9A 5.5A
Above 50
∼
60
°
C
9.0 A 6.9 A 6.0 A 8.3A 5.6A 3.3A
9.1.2 Measures to satisfy the EMC Directive
Combination of inverter and filter
Inverter type Conducted noise IEC61800-3, category C2
(Motor wiring length of 5m or less)
Conducted noise
IEC61800-3, category C1
(Motor wiring length of 20m
or less)
Conducted noise
IEC61800-3, category C2
(
Motor wiring length of 50m
or less)
VF S15-4004PL1-W1
Built-in filter
EMFS11-4015BZ
VF S15-4007PL1-W1 EMFS11-4015BZ
VF S15-4015PL1-W1 EMFS11-4015BZ
VF S15-4022PL1-W1 EMFS11-4025CZ
VF S15-4037PL1-W1 EMFS11-4025CZ
11.4 Default settings by inverter rating
■Default settings
The default setting of motor parameters are adapted to Toshiba IE3 motor.
In case of using Toshiba standard IE1 motor, the parameters values should be adjusted according to Table 4
(VFS15-4004PL to 4037PL) in E6582165 (VF-S15 motor control parameter default setting update information).
Inverter type
Torque
boost
value
Dynamic
braking
resistance
Dynamic
braking
resistor
capacity
Automatic
torque
boost
value
Motor
rated
capacity
*1
Motor
rated
current
Motor
no-load
current
Over-
voltage
stall
protection
level
Integrating
wattmeter
display unit
selection
／













 
VFS15- (%) (Ω) (kW) (%) (kW) (A) (%) (%) －
4004PL1-W1 6.0 200.0 0.12 6.2 0.40 1.0 65 141 0
4007PL1-W1 4.8 200.0 0.12 4.3 0.75 1.7 55 141 0
4015PL1-W1 4.8 200.0 0.12 4.4 1.50 3.2 42 141 0
4022PL1-W1 3.1 200.0 0.12 2.9 2.20 4.7 50 141 0
4037PL1-W1 3.1 160.0 0.12 2.8 4.00 7.3 38 141 1
*1: When region setting is JP,  is set to 3.7(kW).
If the parameters and the adjustment range, which are not shown in the manuals (E6581611 and additional
sheet), are displayed in the inverter, those parameters and adjustment range are “the factory specific
coefficient parameters”. Do not change or set the value of these parameters and adjustment range.

E6582185
7
12.2 Outside dimensions and mass
Outside dimensions and mass
Voltage
class
Applicable
motor
(kW) Inverter type Dimensions (mm) Drawing
Approx.
weight
(kg)
W H D W1 H1 H2 D2 A1 A2
3-phase
500V
0.4 VFS15-4004PL1-W1 105
130 150 93 121.5 12
7.5
6 6 B1 1.2 0.75 VFS15-4007PL1-W1 1.2
1.5 VFS15-4015PL1-W1 1.3
2.2 VFS15-4022PL1-W1 140
170 150 126 157 14 7 7 C1 2.1
3.7 VFS15-4037PL1-W1 2.2
Outline drawing
VF-S15
EMC plate
(Option)
Note 2
)
Fig. B1
Φ5
A1 A2
W
93 (Mounting dimension)
130
121.5 (Mounting dimension)
12
D
46
58
7.5 5

E6582185
8
Note 1 To make it easier to grasp the dimensions of each inverter, dimensions common to all inverters in these
figures are shown with numeric values but not with symbols.
Here are the meanings of the symbols used.
W: Width, H: Height, D: Depth
W1: Mounting dimension (horizontal)
H1: Mounting dimension (vertical)
H2: Height of EMC plate mounting area
D2: Depth of setting dial
A1: Mounting dimension (horizontal) from left side
A2: Mounting dimension (horizontal) from right side
Note 2. Here are the available EMC plates.
Fig.B1 : EMP008Z
Fig.C1 : EMP009Z
Note 3. The models shown in Fig. B1 are fixed at two points: in the upper left and lower right corners.
Note 4. The cooling fan of shown in Fig. B1 model are on the upper side of the inverter.
Fig. C1
VF-S15
EMC plate
(Option)
Note 2
)
2-Φ5
2-R2.5
D
44
58
126 (Mounting dimension) A2A1
5
14
7.5 157 (Mounting dimension)
170
W

E6582185
9
■ UL standard and CSA standard
The VF-S15 models that conform to the UL Standard and CSA Standard have the UL/CSA mark on the
nameplate.
This additional sheet is correction and additional information of as appendix for section 9.2 in E6581611.
2. Compliance with Installation
A UL certificate was granted on the assumption that the inverter would be installed in an enclosure. Therefore,
install the inverter in an enclosure and if necessary, take measures to maintain the inverter ambient
temperature (temperature in the enclosure) within the specified temperature range.
Current reduction
According to the carrier frequency f300 setting, you may need to reduce the inverter’s continuous
output current.
Reduction rates vary depending on the capacity of the inverter.
[Three-phase 400V class]
VFS15- Ambient
temperature
Input voltage 380V to 480V
PWM carrier frequency
2.0k to 4.0kHz 4.1k to 12.0kHz
4004 PL1 40
°
C or less 1.5 A 1.5 A
Above 40 to 50
°
C
1.5 A
4007 PL1 40
°
C or less 2.3 A 2.1 A
Above 40 to 50
°
C
2.3 A
4015 PL1 40
°
C or less 4.1 A 3.7 A
Above 40 to 50
°
C
4.1 A
4022 PL1 40
°
C or less 5.5 A 5.0 A
Above 40 to 50
°
C
5.5 A
4037 PL1 40
°
C or less 9.5 A 8.6 A
Above 40 to 50
°
C
9.5 A
3. Compliance with Connection
The opening of the branch circuit protective device may be an indication that a fault current has been
interrupted.
To reduce the risk of fire or electrical shock, current-carrying parts and other components of the controller
should be examined and replaced if damaged.
If burnout of the current element of an overload relay occurs, the complete overload relay must be replaced.

E6582185
10
AIC, Fuse and Wire sizes
Use the UL listed fuses at connecting to power supply.
Short circuit test is performed under the condition of the power supply short-circuit currents in below.
These interrupting capacities and fuse rating currents depend on the applicable motor capacities.
Table 3 AIC, Fuses and Wire sizes
Inverter model Voltage
(V)
Input
withstand
rating (kA)
Output
Interrupt
rating (kA)
Branch circuit
protection
Rating
(A)
Cable sizes of
power circuit
Earth Cable
Marking Y (1) X (2) Z1 Z2 - -
VFS15-4004PL1 480 5 5 Class CC 6 AWG 14 AWG 14
VFS15-4007PL1 480 5 5 Class CC 6 AWG 14 AWG 14
VFS15-4015PL1 480 5 5 Class CC 12 AWG 14 AWG 14
VFS15-4022PL1 480 5 5 Class J 15 AWG 14 AWG 14
VFS15-4037PL1 480 5 5 Class J 25 AWG 12 AWG 14
Suitable for use on a circuit capable of delivering not more than___X___rms symmetrical kilo
Amperes,___Y___Volts maximum, when protected by___Z1___with a maximum rating of___Z2___.
(1) Input withstand rating is that for which the product has been designed thermally. Installation on a
supply greater than this level will require additional inductance to satisfy this level.
(2) Output interrupt rating relies on Integral solid state short circuit protection. This does not provide
branch circuit protection. Branch circuit protection must be provided in accordance with the National
Electrical Code and any additional local codes. This is dependant on the type of installation.
In case of using with a higher AIC capability up to 100kA(*1), the Short Circuit Current Ratings (SCCR)
become 100kA(*1) by installing with the circuit breakers(GV•P) or the fuses listed in Table 4.
Table 4 AIC 100kA, Fuses, Circuit breakers and Wire sizes
Inverter model Voltage
(V)
Branch circuit protection Cable sizes of
power circuit
Earth Cable
With Fuses With circuit breakers
Class (*2)
Rating
(A) Type-
Form
(*3) Setting (A)
VFS15-4004PL1 480 Class J 6 GV2P07 9 AWG 14 AWG 14
VFS15-4007PL1 480 Class J 6 GV2P08 9 AWG 14 AWG 14
VFS15-4015PL1 480 Class J 15 GV2P10 9 AWG 14 AWG 14
VFS15-4022PL1 480 Class J 15 GV2P14 10 AWG 14 AWG 14
VFS15-4037PL1 480 Class J 25 GV3P13 13 AWG 12 AWG 14
(*1) In case with the circuit breaker, the Short Circuit Current Ratings (SCCR) is 65kA.
(*2) The manufacturer of the fuses should be "Cooper Bussmann" or "Mersen" (formerly, "Ferraz
Shawmut") for the compliance of UL standard.
(*3) The manufacturer of the listed circuit breaker is "Schneider Electric".

E6582185
11
Control circuit terminals
The control circuit terminal block is common to all equipment.
Terminal
symbol Input / output Function
Electrical
specifications
Note 4)
FLA
FLB
FLC
Note 3)
Output
Multifunction programmable relay contact output.
Detects the operation of the inverter's protection
function.
Contact across FLA-FLC is closed and FLB-FLC is
opened during protection function operation.
Max. switching capacity
250Vac (OVC II) -2A,
30Vdc-2A
(cosφ=1)
: at resistive load
250Vac (OVC II) -1A
(cosφ=0.4)
30Vdc-1A
(L/R=7ms)
Min. permissible load
5Vdc-100mA
24Vdc-5mA
RY
RC
Note 3)
Output
Multifunction programmable relay contact output.
Default settings detect and output low-speed signal
output frequencies.
Multifunction output terminals to which two different
functions can be assigned.
Note 3) A chattering (momentary ON/OFF of contact) is generated by external factors of the vibration and
the impact, etc. In particular, please set the filter of 10ms or more, or timer for measures when connecting
it directly with input unit terminal of programmable controller. Please use the OUT terminal as much as
possible when the programmable controller is connected.
Note 4) OVC II: Overvoltage category II

E6582185
12
■ Manufacturer’s Declaration of Conformity

E6582185
13

E6582185
14

E6582185
15
© Toshiba Schneider Inverter Corporation 2017
