- 1 -
SERVICE MANUAL
LCD Color Television
23HLV85
FILE NO. 050-200532
Published in Japan, Sep. 2005 (YC)
TOSHIBA CORPORATION 2005
DOCUMENT CREATED IN JAPAN, Sept., 2005

- 2 -
TABLE OF CONTENTS
SERVICE SAFETY PRECAUTIONS ..........................................................................................................................................3
HANDLING THE LCD MODULE ................................................................................................................................................5
1. SERVICE MODE ....................................................................................................................................................................7
1-1. STARTING SERVICE MODE........................................................................................................................................... 7
2. ADJUSTMENT ....................................................................................................................................................................... 8
2-1. ADJUSTMENT TOOLS AND CONDITIONS ...................................................................................................................8
2-2. AUTO GAIN/OFFSET ADJUSTMENT .............................................................................................................................8
2-3. DDC EDID DATA READ & WRITE ...................................................................................................................................9
3. VCTI FIRMWARE INSTALLATIONS/UPGRADING ............................................................................................................. 19
3-1. VCTI FIRMWARE INSTALLATIONS ............................................................................................................................. 20
3-2. SCALER FIRMWARE INSTALLATIONS ....................................................................................................................... 26
4. TROUBLESHOOTING ......................................................................................................................................................... 33
5. EXPLODED VIEW ............................................................................................................................................................... 40
6. CHASSIS AND CABINET REPLACEMENT PARTS LIST .................................................................................................. 41
7. PC BOARDS TOP & BOTTOM VIEW .................................................................................................................................. 52
8. SCHEMATIC DIAGRAM ...................................................................................................................................................... 55
8-1. WIRING DIAGRAM ....................................................................................................................................................... 56
8-2. BLOCK DIAGRAM ........................................................................................................................................................ 57

- 3 -
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE SAFETY PRECAUTIONS
• The caution items shown here describe major safety issues and should always be observed.
• The meanings of the various indications are as follows.
WARNING
CAUTION
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users due to a product defect after the service operation is completed, could possibly be in
danger of injury or even death in the event of operational error.
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users after the service operation is completed, could possibly be in danger of injury, or
where there could be physical damage in the event of operational error.
* Physical damage means major damage to a home, furnishings and other possessions.
Examples of marks
SHOCK HAZARD
PROHIBIT DISASSEM-
BLING
UNPULUG
The " indicates caution (including danger and warning).
The actual meaning of this caution is indicated inside the
" or nearby illustrations or text.
The example shown to the left indicates the danger of "electrical shock".
The indicates a forbidden action.
The actual meaning of this caution is indicated inside the or nearby illustrations or text.
The example shown to the left indicates that disassembly is forbidden.
The
- indicates a forced action (an action that must be performed).
The actual meaning of this forced action is indicated by
- or nearby illustrations or text.
The example shown to the left indicates that the power plug must be disconnected.

- 4 -
WARNING
KEEP CHILDREN
AWAY
UNPULUG
SHOCK HAZARD
USE SPECIFIED
PARTS
CAUTION FOR
WIRING
CAUTION FOR
ASSEMBLING /
WIRING
CHECK INSULATION
RESISTANCE
PROHIBIT
REMODELING
• Always advise users to keep children away.
There is danger of injury to children from tools, disassembled products, etc.
• Always disconnect the power plug before starting work whenever power is not required.
Failure to disconnect the power plug before starting work can result in electrical shock.
• Depending on the model, use an insulation transformer or wear gloves when servicing with the
power on, and disconnect the power plug to avoid electrical shock when replacing parts.
In some cases, alternating current is also impressed in the chassis, so electrical shock is pos-
sible if the chassis is contacted with the power on.
• Always use the replacement parts specified for the particular model when making repairs.
The parts used in products have the necessary safety characteristics such as inflammability,
voltage resistance, etc.; therefore, use only replacement parts that have these same character-
istics.
Use only the specified parts when the mark is included in a circuit diagram or parts list.
• Parts mounting and routing of the wiring should be the same as that used originally.
For safety purposes, insulating materials such as tubing or tape is sometimes used and printed
circuit boards are sometimes mounted floating.
Also make sure that wiring is routed and clamped to avoid parts that generate heat and which
use high voltage.Always follow the original scheme.
• After a repair has been completed, reassemble all disassembled parts, and route and recon-
nect the wiring, in accordance with the original scheme.
Do not allow internal wiring to be pinched by cabinets, panels, etc.
Any error in reassembly or wiring can result in electrical leakage, flame, etc., and may be
hazardous.
• After completing the work, disconnect the power plug from the outlet, remove the antenna, turn
on the power switch.Then, use a 500V insulation resistance meter to check the insulation
resistance of the antenna terminal, other metallic parts and between the prongs of the power
plug to make sure that the insulation resistance is 1M 1or more.
The set will require inspection and repair if the insulation resistance is below this value.
• Never remodel the product in any way.
Remodeling can result in improper operation, malfunction, or electrical leakage and flame,
which may be hazardous

- 5 -
HANDLING THE LCD MODULE
Safety Precautions
In the event that the screen is damaged or the liquid crystal
(fluid) leaks, do not breathe in or drink this fluid.Also, never
touch this fluid.
Such actions could cause toxicity or skin irritation.If this fluid
should enter the mouth, rinse the mouth thoroughly with wa-
ter.If the fluid should contact the skin or clothing, wipe off
with alcohol, etc., and rinse thoroughly with water.If the fluid
should enter the eyes, immediately rinse the eyes thoroughly
with running water.
Precautions for Handling the LCD Module
The LCD module can easily be damaged during disassembly
or reassembly; therefore, always observe the following pre-
cautions when handling the module.
1.When attaching the LCD module to the LCD cover, posi-
tion it appropriately and fasten at the position where the
display can be viewed most conveniently.
2.Carefully align the holes at all four corners of the LCD
module with the corresponding holes in the LCD cover
and fasten with screws.Do not strongly push on the mod-
ule because any impact can adversely affect the perform-
ance.Also use caution when handling the polarized screen
because it can easily be damaged.
CAUTION
The metal edges of the LCD module
are sharp, handle it with care.
3.If the panel surface becomes soiled, wipe with cotton or
a
soft cloth.If this does not remove the soiling, breathe o
n
the surface and then wipe again.
If the panel surface is extremely solied, use a CRT cleane
r
as a cleaner.Wipe off the panel surface by drop the cleane
r
on the cloth.Do not drop the cleaner on the panel.Pa
y
attention not to scratch the panel surface.
4.Leaving water or other fluids on the panel screen for a
n
extended period of time can result in discoloration o
r
stripes.Immediately remove any type of fluid from th
e
screen.
5.Glass is used in the panel, so do not drop or strike wit
h
hard objects.Such actions can damage the panel.
6.CMOS-LSI circuitry is used in the LCD module, so avoi
d
damage due to static electricity.When handling the mod
-
ule, use a wrist ground or anchor ground.

- 6 -
7.Do not expose the LCD module to direct sunlight or strong
ultraviolet rays for an extended period of time.
8. Do not store the LCD module below the temperature con-
ditions described in the specifications.Failure to do so
could result in freezing of the liquid crystal due to cold air
or loss of resilience or other damage.
9. Do not disassemble the LCD module.Such actions could
result in improper operation.
10.When transporting the LCD module, do not use packing
containing epoxy resin (amine) or silicon resin (alcohol or
oxim).The gas generated by these materials can cause
loss of polarity.

- 7 -
1.Service Mode
1-1.Starting Service Mode
*Set LCD TV to the normal TV signal receive mode.
Note: In this "Service Mode" section, [ ] shows a button.
1-1-1.Press [MUTE] on the remote control once.
1-1-2.Press [MUTE] again, and press [ ] on LCD TV.
Service mode displayed on TV screen
VCTi version
Items other than those enclosed by are default
settings.
Item Default setting
3D Comb Filter 1
HDTV 1
PC Information 1
Speaker Outout 0
FLI2310 1
Country 2
Canadian Vchip 0
BS 0
Module Option 0
Scaler version

- 8 -
2.Adjustment
Note: In this "Adjustment" section, [ ] shows a button.
2-1.Adjustment Tools and Conditions
Tools: Pattern Generator (801GF, MSPG925F)
DDC Adjustment Tool
PC
Remote Control
Conditions: Heat Run 30 minutes or more
2-2.Auto Gain/Offset Adjustment
2-2-1.RF Mode Adjustment (normal TV receive mode)
No reguired
2-2-2.Component Mode Adjustment
Preparation
Carry out Heat Run for 30 minutes or more before adjustment
(with no RF signal).
1) Connect Y, Pb, and Pr output signals of Pattern Generator
to the component jack (Y, Pb, Pr) of LCD TV.
2) Connect Y, Pb, and Pr output signals of Pattern Generator
to the component jack (D Jack) of LCD TV.
3) Change the TV input mode to component mode.
4) Select 480p Mode (Y:100% Pb/Pr:75%) in Pattern Generator.Select Pattern 33 (Color Bar Pattern
signal) in Pattern Generator (MSPG925F).
5) Go into service mode, and Auto Gain menu appears, and then press VOL [+].
6) Press [OK] to store the adjustment data.
2-2-3.PC Mode Adjustment
Preparation
Carry out Heat Run for 30 minutes or more before adjustment (with no RF signal).
Connect Pattern Generator to the 15-pin D-Sub Jack of LCD TV.
1) Change the TV input mode to PC mode.
2) Set Pattern Generator to the following:
XGA (1024x768) 16-step or 11-step grayscale
3) Go into service mode, and Auto Gain menu appears, and then press VOL [+].
4) Press [ENTER] to store the adjustment data.
(Adjustment in component mode or PC mode)

- 33 -
No Power
(LED indicator off)
Check P51 Connector
No Power
(LED indicator off)
Change IC1000, IC1001
Change IC1105, IC1104 or
IC1106, IC1103
Check 15V or ST_5V
of Power B/D
Check Output of
IC1105, IC1104 or
IC1106,IC1103
Fail
Check LED Assy
Check Output of
IC1000, IC1001 Fail
Pass
Pass
Pass
Process A
Change LED Assy
Fail
Fail
Ref.1/1-1
ST_5V : P1000, #1Ref.115V : P1000, #14, 15Ref.1-1
4.TROUBLESHOOTING

- 34 -
No Raster on Component
signal
Check input source cable
and jack
Re-soldering or Change
the defect part Check
IC400
Repeat Process A
Fail
Check the signal of
R178, R179, R180
Check the input/ output
of IC400
Check the input/ output
of IC501
Fail
Pass
Pass
Re-soldering or Change
the defect part Check
IC501,X500, IC701
Change R178, R179, R180
Re-soldering or Change
the defect part Check
IC450,X450,IC451
Check the input/ output
of IC450 Fail
Fail
Pass
Pass
Ref.2/2-1
Component V signal Output :
IC400, #64
Ref.2Component H signal Output :
IC400, #66
Ref.2-1
Process C

- 35 -
No Raster on SIDE-AV
signal(SIDE-AV,VIDEO1)
Check P50,JA100
Check 5V,33V of
TU100, Re-soldering of
Change the defect part
Repeat Process A
Check the signal of
R13, R177 Fail
Pass Pass
Fail
Fail Fail
No Raster on TV(RF) signal
Re-soldering or change
defect part check
IC200,X200
Fail
Re-soldering or change
defect part check
IC300,3200
Check the output of
TU100
Check the input/output
IC200
Pass
Check the input/output
IC300
Pass
Check the input/output
IC200
Pass
Pass
Ref.3
Ref.4
ITU 656 Clock out :
IC200, #83
Ref.4
Y separated output :
IC300, #96
Ref.3
Process C

- 36 -
No Raster on DVD Signal No Raster on S-VIDEO
Signal
Re-soldering or change
defect part check
IC200,X200
Check P53,P1001 or P202
Repeat Process A Repeat Process A
Check the signal of R11, R12
Fail
Fail
Fail
Pass
Pass
Pass
Pass
Check the signal of
L214,L215,L216
Check the input/output
IC200
Ref.5 Ref.6
Y signal input : IC200, #62Ref.6Y signal input : IC200, #68Ref.5
Process C

- 37 -
No Raster on HDMI signal
Check input source cable
and jack
Re-soldering or change
defect part check IC600
Re-soldering or
change defect part
check IC501,X500,IC701
Repeat Process A
Check the input/output
IC600
Pass
Pass
Pass
No Raster on PC signal
Repeat Process A
Check the input/output
IC501
Pass
Ref.7/7-1
Ref.8/8-1
PC H Signal Input :
IC501, #181
Ref.7-1
HDMI H Signal output :
IC600, #2
Ref.7
PC V Signal input :
IC501, #182
Ref.8-1
HDMI V Signal output :
IC600, #3
Ref.8
Fail
Fail
Process C

- 38 -
No Sound (SIDE AV,DVD)
No Sound (RF)
Change source input
Check the speaker wire
Check the input
source
Pass
Pass
Fail
Fail
Fail
Re-soldering or Change
the defect part Check
IC901
Check the input/output
of IC901
Pass
Fail
Re-soldering or Change
the defect part Check
IC200,X200
Check the input/ output
of IC200
Pass
Fail
Re-soldering or Change
the defect part Check IC900
Check the input/ output
of IC900
Pass
Fail
Change the speaker
Check the speaker
Pass
Ref.9
Sound Input :
IC900, #3, 5
Ref.9
Process D

- 39 -
No Sound HDMI
No Sound Component & PC
Change source input
Re-soldering or
change the defect
part ic650
Check the input source Check the input source
Fail Fail
Fail
Fail Fail
Re-soldering or
change the defect
part IC800 & IC801
Check the input/output
IC650
Check the input/output
IC801
Check the input/output
IC800
Pass
Pass
Pass
Pass
Pass
Process D

- 40 -
5. EXPLODED VIEWS
23HLV85
010
140 100
170 150
040
020
080
090
130
120
030
050
110
Y151

- 41 -
6. CHASSIS AND CABINET REPLACEMENT PARTS LIST
Model : 23HLV85
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “SERVICE SAFETY PRECAUTIONS” ON PAGE 3 OF
THIS MANUAL.
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in
the original circuit or specified in the parts list.The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the SERVICE SAFETY PRECAUTIONS.Do not degrade
the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
• The PC board assembly with ∗ mark is no longer available after the end of the production.
Location Parts No. Reference Description
No.
CAPACITORS
C20 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C23 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C24 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C51 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C52 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C53 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C76 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C77 72796127 0CC150CK41A CERAMIC, 15PF 1608 50V 5% R/T
C80 72795161 0CH6331K416 CERAMIC CHIP, 330PF 50V J NP0 2012
C81 72795161 0CH6331K416 CERAMIC CHIP, 330PF 50V J NP0 2012
C82 72795183 0CK225DH94A CERAMIC, 2.2UF 2012 25V 80%, -
C83 72795197 0CE476WF6DC ELECTROLYTIC, 47UF MVK 16V 20% R/T
C84 72781845 0CH6030K116 CERAMIC, 3PF 2012 50V 0.5 PF
C85 72781845 0CH6030K116 CERAMIC, 3PF 2012 50V 0.5 PF
C100 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C101 72796122 0CE107EK638 ELECTROLYTIC, 100UF KMG 50V M FM5
C102 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C103 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C104 72795176 0CK103CK51A CERAMIC, 0.01UF 1608 50V 10%
C105 72795185 0CK273DK51A CERAMIC, 27000PF 2012 50V 10%
C106 727951690CC390DK41A CERAMIC, 39PF 2012 50V 5% NP0
C108 72795146 0CE108EF618 ELECTROLYTIC, 1000UF KMG 16V 20% F
C10972795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C110 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C111 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C150 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C173 72795168 0CC331CK41A CERAMIC, 330PF 1608 50V 5% R/
C175 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C200 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C201 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C202 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C205 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C206 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C207 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C208 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C20972795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C212 72795196 0CE475WJ6DC ELECTROLYTIC, 4.7UF MVK 35V 20% R/
C213 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C215 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C216 72796130 0CC390CK41A CERAMIC, 39PF 1608 50V 5% R/T
C218 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C221 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C222 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD

- 42 -
Location Parts No. Reference Description
No.
C223 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C224 72795173 0CH3822K516 CERAMIC, 8200PF 2012 50V 10%
C226 72795186 0CK334CF94A CERAMIC, 0.33UF 1608 16V 80%,
C22972795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C230 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C231 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C232 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C233 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C234 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C235 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C236 727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C237 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C240 727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C241 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C242 72795186 0CK334CF94A CERAMIC, 0.33UF 1608 16V 80%,
C245 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C246 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C247 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C248 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C250 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C251 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C252 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C253 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C254 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C255 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C256 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C257 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C258 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C25972795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C260 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C261 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C262 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C263 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C264 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C265 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C266 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C268 72796128 0CC220CK41A CERAMIC, 22PF 1608 50V 5% R/T
C270 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C271 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C272 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C273 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C275 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C276 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C278 72795176 0CK103CK51A CERAMIC, 0.01UF 1608 50V 10%
C27972795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C280 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C282 72795164 0CC221CK41A CERAMIC, 220PF 1608 50V 5% R/
C288 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C300 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C302 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C303 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C305 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C307 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C308 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C30972795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C311 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C312 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C313 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C314 72795178 0CK105CF94A CERAMIC, 1UF 1608 16V 80%, -20
C316 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C317 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C318 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C31972795176 0CK103CK51A CERAMIC, 0.01UF 1608 50V 10%
C320 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C321 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C322 72796133 0CK152CK51A CERAMIC, 1500PF 1608 50V 10%
C323 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C324 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C325 727961290CC270CK41A CERAMIC, 27PF 1608 50V 5% R/T
C326 72796131 0CC820CK41A CERAMIC, 82PF 1608 50V 5% NP0
C327 72795168 0CC331CK41A CERAMIC, 330PF 1608 50V 5% R/
C328 72795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7

- 43 -
Location Parts No. Reference Description
No.
C32972795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C333 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C334 72795187 0CK474CH94A CERAMIC, 0.47UF 1608 25V 80%,
C335 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C336 72795167 0CC330CK41A CERAMIC, 33PF 1608 50V 5% R/T
C337 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C33972795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C341 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C342 727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C343 72795188 0CK475DD57A CERAMIC, 4.7UF 2012 10V 10% X
C344 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C346 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C348 72796137 0CE226WF6DC ELECTROLYTIC, 22UF MVK 16V 20% R/T
C34972795180 0CK106EF56A CERAMIC, 10UF 3216 16V 10% X7
C350 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C351 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C352 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C353 72795178 0CK105CF94A CERAMIC, 1UF 1608 16V 80%, -20
C354 72795170 0CC471CK41A CERAMIC, 470PF 1608 50V 5% R/
C355 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C402 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C404 72796128 0CC220CK41A CERAMIC, 22PF 1608 50V 5% R/T
C405 72795160 0CH6220K416 CERAMIC, 22PF 2012 50V 5% NP0
C407 72796128 0CC220CK41A CERAMIC, 22PF 1608 50V 5% R/T
C408 72796134 0CK473CK56A CERAMIC, 47000PF 1608 50V 10%
C410 72795175 0CK102CK56A CERAMIC, 1000PF 1608 50V 0.1
C411 72796134 0CK473CK56A CERAMIC, 47000PF 1608 50V 10%
C412 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C417 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C418 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C421 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C422 72796136 0CK823CK56A CERAMIC, 82NF 1608 50V 10% R/
C423 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C424 72795173 0CH3822K516 CERAMIC, 8200PF 2012 50V 10%
C427 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C436 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C442 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C454 72796126 0CH6330K416 CERAMIC CHIP, 33PF 50V J NP0 2012
C456 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C460 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C461 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C462 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C463 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C464 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C484 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C486 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C495 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C496 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C501 72795161 0CH6331K416 CERAMIC CHIP, 330PF 50V J NP0 2012
C502 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C506 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C510 72795176 0CK103CK51A CERAMIC, 0.01UF 1608 50V 10%
C517 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C520 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C530 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C532 72795153 0CH6080K116 CERAMIC, 8PF 2012 50V 0.5 PF
C534 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C553 72795192 0CE107WH6DC ELECTROLYTIC, 100UF MVK 25V 20% R/
C554 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C602 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C604 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C60972796125 0CH6050K116 CERAMIC, 5PF 2012 50V 10% NP0
C610 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C611 72796125 0CH6050K116 CERAMIC, 5PF 2012 50V 10% NP0
C612 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C63972795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C640 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C647 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C648 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C650 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C651 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C653 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD

- 44 -
Location Parts No. Reference Description
No.
C654 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C658 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C65972796128 0CC220CK41A CERAMIC, 22PF 1608 50V 5% R/T
C662 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C670 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C671 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C673 72795197 0CE476WF6DC ELECTROLYTIC, 47UF MVK 16V 20% R/T
C674 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C676 72795197 0CE476WF6DC ELECTROLYTIC, 47UF MVK 16V 20% R/T
C678 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C67972795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C680 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C681 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C712 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C713 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C714 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C715 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C716 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C717 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C718 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C71972795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C720 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C721 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C722 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C723 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C724 72795157 0CH6471K416 CERAMIC CHIP, 470F 50V J NP0 2012
C72972795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C731 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C733 72795191 0CE107WF6DC ELECTROLYTIC, 100UF MVK 16V 20% R/
C750 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C755 72795154 0CH6101K416 CERAMIC, 100PF 50V 5% NP0 201
C757 72795157 0CH6471K416 CERAMIC CHIP, 470F 50V J NP0 2012
C75972795154 0CH6101K416 CERAMIC, 100PF 50V 5% NP0 201
C760 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C761 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C762 72795161 0CH6331K416 CERAMIC CHIP, 330PF 50V J NP0 2012
C763 72795155 0CH6102K406 CERAMIC CHIP, 1000PF 50V J SL 2012
C764 72795194 0CE226WJ6DC ELECTROLYTIC, 22UF MVK 35V 20% R/T
C800 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C801 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C802 72795196 0CE475WJ6DC ELECTROLYTIC, 4.7UF MVK 35V 20% R/
C806 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C807 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C808 72795196 0CE475WJ6DC ELECTROLYTIC, 4.7UF MVK 35V 20% R/
C810 72795196 0CE475WJ6DC ELECTROLYTIC, 4.7UF MVK 35V 20% R/
C812 72795148 0CH8106F691 ELECTROLYTIC, 10UF 16V 20% 105STD
C813 72795192 0CE107WH6DC ELECTROLYTIC, 100UF MVK 25V 20% R/
C900 727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C905 72795182 0CK224CF56A CERAMIC, 0.22UF 1608 16V 10%
C906 72795183 0CK225DH94A CERAMIC, 2.2UF 2012 25V 80%, -
C907 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C908 72795182 0CK224CF56A CERAMIC, 0.22UF 1608 16V 10%
C90972795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C910 72795183 0CK225DH94A CERAMIC, 2.2UF 2012 25V 80%, -
C911 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C912 72795183 0CK225DH94A CERAMIC, 2.2UF 2012 25V 80%, -
C914 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C915 72795182 0CK224CF56A CERAMIC, 0.22UF 1608 16V 10%
C916 72795192 0CE107WH6DC ELECTROLYTIC, 100UF MVK 25V 20% R/
C917 72795171 0CH3103K516 CERAMIC, 10000PF 50V 10% B(Y5
C918 72795172 0CH3104K566 CERAMIC, 0.1UF 50V 10% X7R 20
C919727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C920 72795182 0CK224CF56A CERAMIC, 0.22UF 1608 16V 10%
C921 727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C922 72795164 0CC221CK41A CERAMIC, 220PF 1608 50V 5% R/
C923 727951790CK105DK94A CERAMIC, 1UF 2012 50V 80%, -20
C924 72796135 0CK474DH56A CERAMIC, 0.47UF 2012 25V 10%
C930 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C931 72795183 0CK225DH94A CERAMIC, 2.2UF 2012 25V 80%, -
C932 72795199 0CH8106J691 ELECTROLYTIC, 10UF 35V 20% 105STD
C933 72795177 0CK104CK56A CERAMIC, 0.1UF 1608 50V 10% R
C934 72795196 0CE475WJ6DC ELECTROLYTIC, 4.7UF MVK 35V 20% R/
