Toshiba ML-EM23PSS User manual

Microwave Oven
INSTRUCTION MANUAL
Model:
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you
with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
ML-EM23P(SS)

Welcome to the world of
TOSHIBA
BEFORE OPERATING THIS PRODUCT,
READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
CONTENTS
OPERATION
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
IMPORTANT SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS
UTENSILS
SETTING UP YOUR OVEN
TROUBLE SHOOTIHG
2

(a) Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
Specifications
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
Model:
W-1250W
Approx. 13 Kg
ML-EM23P(SS)
3
230V-240V~ 50Hz
1200
750W-800W
23 L
270 mm
485X397X293 mm

To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.( For appliance with
type Y attachment)
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
4. If the supply cord is damaged, it must be replaced by
1. Read and follow the specific:"PRECAUTIONS TO
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children unless they are older than 8
2. This appliance can be used by children aged from 8
3. Keep the appliance and its cord out of reach of children
less than 8 years.
and supervised. Children less than 8 years of age shall be
kept away unless continuously supervised.
IMPORTANT SAFETY
INSTRUCTIONS WARNING
before replacing the lamp to avoid the possibility of
electric shock.
5. WARNING: Ensure that the appliance is switched off
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
6. WARNING: It is hazardous for anyone other than a
4

.ovens
and keep the door closed in order to stifle any flames.
delayed eruptive boiling, therefore care must be taken
when handling the container.
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
12.The contents of feeding bottles and baby food jars
13. Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
deposits removed.
14. The oven should be cleaned regularly and any food
11. Microwave heating of beverages can result in
keep an eye on the oven due to the possibility of ignition.
in sealed containers since they are liable to explode.
could lead to deterioration of the surface that could
15. Failure to maintain the oven in a clean condition
7. WARNING: Liquids and other foods must not be heated
10. If smoke is emitted, switch off or unplug the appliance
8. When heating food in plastic or paper containers,
9. Only use utensils that are suitable for use in microwave
IMPORTANT SAFETY
INSTRUCTIONS WARNING
adversely affect the life of the appliance and possibly
result in a hazardous situation.
16. The appliance must not be installed behind a
applicable for appliances with decorative door.)
decorative door in order to avoid overheating. (This is not
this oven.(for ovens provided with a facility to use a
17.Only use the temperature probe recommended for
temperature-sensing probe.)
5

-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
21.The microwave oven is intended for heating food and
and similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
decorative door open. (for ovens with a decorative door.)
18.The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
allowed during microwave cooking.
cleaner.
19.The microwave oven must be operated with the
22. Metallic containers for food and beverages are not
23. The appliance shall not be cleaned with a steam
24.The appliance is intended to be used freestanding.
20.This appliance is intended to be used in household
IMPORTANT SAFETY
INSTRUCTIONS WARNING
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
a wall.
25.The rear surface of appliances shall be placed against
6

TO REDUCE THE RISK OF
INJURY TO PERSONS
GROUNDING INSTALLATION
DANGER
Electric Shock Hazard
Touching some of the
internal components can
cause serious personal injury or death. Do not
disassemble this appliance.
WARNING
Electric Shock Hazard
Improper
use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly
installed and grounded.
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of electric
for the electric current.
This appliance is equipped with a cord having a
plug must be plugged into
an outlet that is properly installed and grounded.
shock by providing an escape wire grounding
wire with a grounding plug. The
Consult a qualified electrician or serviceman
instructions are not completely understood or if doubt exists
as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire
extension cord.
if the gronuding
7

TO REDUCE THE RISK OF
INJURY TO PERSONS
GROUNDING INSTALLATION
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
2. If a long cord set or extension cord is used:
1)The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the a[[ppliance.
2)The extension cord must be a grounding-type 3-wire cord.
3)The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over unintentionally.
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
8

TO REDUCE THE RISK OF
INJURY TO PERSONS
GROUNDING INSTALLATION
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a competent person to carry out any
service or repair operation that involves the removal of
a cover which gives protection against exposure to
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do
4. Do not exceed 1 minute cooking time.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
microwave energy.
not use it for microwave cooking.
9

MATERIALS YOU CAN USE IN MICROWAVE OVEN
UTENSILS REMARKS
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
10

Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
UTENSILS REMARKS
11

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable shaft
SETTING UP YOUR OVEN
NAMES OFOVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the ca rton and oven cavity. Your
oven comes with the following accessories:
TURNTABLE INSTALLATION
12

Installation
1.Select a level surface that provide enough open space
for the intake and/or outlet vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of appliance shall be placed against a wall.
Leave a minimum clearance of 30cm above the oven, a
minimum clearance of 20cm is required between the oven
and any adjacent walls.
(3) Do not remove the legs from the bottom of the oven.
(4) Blocking the intake and/ or outlet openings can damage
the oven.
(5) Place the oven as far away from radios and TV as
possible. Operation of microwave oven may cause
interference to your radio or TV reception.
20cm
30cm
20cm
min85cm
0cm
SETTINGUP YOUR OVEN
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the
install if oven is damaged.
Cabinet: Remove any protective film found on the microwave
cover that is attached to the oven cavity to protect the magnetron.
oven for any damage such as dents or broken door. DO not
oven cabinet surface. Do not remove the light brown Mica
13

SETTINGUP YOUR OVEN
INSTALLATION
2.Plug your oven into a standard household outlet. Be sure
WARNING
Do not install oven over a range cooktop or other heat-
the oven could be damaged and the warranty would be avoid.
The accessible surface may
be hot during operation
and the frequecy on the rating label.
the voltage and the frequency is the same as the voltage
producing appliance. If installed near or over a heat source,
14

OPERATION
CONTROL PANEL AND FEATURES
(1)
(7)
(8)
(9)
(11)
(2)
(12)
Auto Menu (Popcorn,Potato,Pizza,Frozen Vegetable,Beverage amd Dinner Plate)
Number Pads
START/ +30 SEC.
Time Defrost
STOP Cancel Hold 3 sec: Before cooking starts, press to clear all
previous settings. During cooking, press once to stop oven; press twice
to stop oven and clear all settings.
Display
Time Cook
Memory
(3) Power Level
(4) Clock and Settings
(5) Weight Defrost
(6) Kitchen Timer
(10)
Stop/Cancel:
15
(4)
(1)
(2)
(3)
(7)
(8)
(9)
(11)
(10)
(12)
(5)
(6)

OPERATION
1.POWER LEVELS
2.CLOCK SETTING
(1)
(2)
(3)
Press "Clock" once, "00:00" will appear in the display.
Press the number pads to enter the current clock time. For example, if the time is
now 10:12, press " 1, 0, 1, 2 " in order.
Press "Clock to finish clock setting, " : " will flash and the numbers will
appear as a clock time in the display.
NOTE:
If the numbers entered are not within the range between 1:00 to 12:59, the setting
will not be accepted until valid numbers are entered.
In the process of setting clock, if the pad is pressed or if there is no operation
within 1 minute, the display will automatically return to the previous clock setting.
Press "Kitchen Timer" once, "00:00" will appear in the display.
Press the number pads to enter the time amount. The maximum amount of time
that can be entered is 99 minutes, 99 seconds.
When the time amount elapses, the oven will beep 5 times.
3. KITCHEN TIMER
(1)
(2)
(3)
(4)
Press to confirm setting, and the timer will start to count down.
Note:
During the Kitchen Timer function, no cooking function can be set into operation.
Kitchen Timer amount cannot be increased by pressing .
Pressing will cancel the Timer countdown.
The Kitchen Timer setting is different from the Clock setting; it is simply a timer.
16
11 power levels are available.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
0
0%
PL0
"

OPERATION
Press "Time Cook" , "00:00" will appear in the display.
Press number pads to enter the cooking time. The maximum cooking time is 99
minutes,99 seconds.
Press "Power" , PL10 will flash. Press number pads 0 through 9 to select a
different power level if desired. Seethe POWER LEVEL table
above.
Press to start cooking. The remaining cooking time will display.
a.
b.
c.
d.
Press "Time Cook" , "00:00" will display.
Press "1, 5, 0, 0" in order for 15:00 to appear in the display.
Press "Power" , then press "5" to select 50% microwave power.
Press to start cooking. Buzzer sounds once. The remaining cooking
time will display.
4.MICROWAVE COOK
(1)
(2)
(3)
(4)
Example : To cook the food with 50% microwave power for 15 minutes.
NOTE:
In the process of setting, if the pad is pressed or if there is no operation within
1 minute, the oven will automatically return to display the clock.
Instant cooking at 100% power level and 1 to 6 minutes cooking time can be
started by pressing number pads 1 to 6. Press to increase the cooking
time by 30 seconds with each press. The maximum cooking time is 99 minutes,
99 seconds.
Instant cooking at 100% power level and 30 seconds cooking time can be
started by pressing . Each repeated press will increase cooking time by 30
seconds. The maximum cooking time is 99 minutes, 99 seconds.
NOTE:
Time can also be added in 30 second increments by pressing during Micro-
wave Cooking, Time Defrost and Multi-stage Cooking.
Time cannot be added by pressing during Weight Defrost and Kitchen Timer
functions.
(1)
(2)
5.ONE TOUCH START
17

OPERATION
Press "Time Defrost" , "dEF2" will appear in the display.
Press the number pads to input the defrost time.
Press to start defrost cooking. And the remaining defrost time will display.
(1)
(2)
(4)
6.TIME DEFROST
(3) The default microwave power is power level 3. If you want to change the power level,
level, press
the desired power level.
(2) Press number pads to input weight to be defrosted.
disp
(1) Press
Input the
(4) Press to start defrosting and the cooking time remaining will be
(3)If the weight input is not between 100 to 2000 g, the input will be invalid. A beep
weight range between 100 to 2000 g.
layed.
once,"dEF1" will display.
will sound and the unit will notwork until valid numbers are entered.
Press "Popcorn" , "50" will appear in the display.
Press "Popcorn" one more times to choose the weight, "100" will
display in order.
(1)
(2)
8. POPCORN
repeatedly until the number you wish appears in the display
Press 3 Times: 3 po
"1",
Press nce : 1 potato (approx. 8.0 oz)
Press Twice: 2 potatoes ( approx. 16.0 oz)
"2", "3" will display in order.
tatoes (approx. 24.0 oz)
O
Oven beeps 5 times when
9. POTATO
(1) Press
Press to cook. The remaining time will display.
(2)
cooking finish.
7. WEIGHT DEFROST FUNCTION
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
18
"Power" once, and PL3 will display; then press the number pad for
"Weight Defrost"
"Potato"

OPERATION
10. FROZEN VEGETABLE
Press "Frozen Vegetable" , "150" will appear in the display.
Press "Frozen Vegetable" two more times to choose the weight, "350" and "500" will
display in order.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
11. BEVERAGE
Press "Beverage" , "1" will appear in the display.
Press "Beverage" two more times to choose the weight, "2" and "3" will
display in order. One cup is about 4.0 Oz.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
12. DINNER PLATE
Press "Dinner Plate" , "250" will appear in the display.
Press "Dinner Plate" two more times to choose the weight, "350" and "500" will
display in order.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
Press "Pizza" , "100" will appear in the display.
Press "Pizza" two more times to choose the weight, "200" and "400" will
display in order.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
13. PIZZA
19
