Toshiba AC25CEW-SS User manual

TOASTER OVEN
AC25CEW-SS
INSTRUCTION MANUAL

IMPORTANT SAFEGUARDS
BASIC SAFETY PRECAUTIONS.......................................................................................... EN-3
BEFORE FIRST USE............................................................................................................... EN-6
PRODUCT INSTRUCTION
NAMES OF PARTS..................................................................................................................EN-7
OPERATION
HOW TO USE...............................................................................................????????................????..??....??.....EN-8
FUNCTION INSTRUCTION..............................................................................................????....EN-9
CARE AND CLEANING........................................................................................................EN-13
BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND
FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
NOTE
CONTENTS
EN-2
SPECIFICATION.....................................................................................................................EN-13

BASIC SAFETY PRECAUTIONS
When using electrical appliance, basic safety precautions should
always be followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord,
plugs, or (state specific part or parts in question) in water or
other liquid.
4. Close supervision is necessary when any appliance is used by
or near children.
5. Unplug from outlet when not in use and before cleaning.
Allow to cool before putting on or taking off parts.
6. Do not operate any appliance with a damaged cord or plug
or after the appliance malfunctions or has been damaged in
any manner. Return appliance to the nearest authorized service
facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a
heated oven.
11. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
12. Always attach plug to appliance first, then plug cord into the
wall outlet. To disconnect, turn any control to “off” , then
remove plug from wall outlet.
SAFETY WARNING
IMPORTANT SAFEGUARDS
EN-3

BASIC SAFETY PRECAUTIONS
13. Do not use appliance for other than intended use.
14. Use extreme caution when removing tray or disposing of hot
grease.
15. Do not clean with metal scouring pads. Pieces can break off the
pad and touch electrical parts, creating parts, creating a risk of
electric shock.
16. Oversize foods or metal utensils must not be inserted in a
toaster-oven as they may create a fire or risk of electric shock.
17. A fire may occur if the toaster-oven is covered or touching
flammable material, including curtains, draperies, walls, and
the like, when in operation. Do not store any them on top of
the appliance when in operation.
18. Extreme caution should be exercised when using containers
constructed of other than metal or glass.
19. Do not store any materials, other than manufacturers
recommended accessories, in this oven when not in use.
20. Do not place any of the following materials in the oven: (that is,
paper, cardboard, plastic and like).
21. Do not cover crumb tray or any part of the oven with metal foil.
This will cause over heating of the oven.
22. This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to fit into a polarized outlet only one way. If the plug
does not fit fully into the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way. (for appliance provided two-wire
polarized plug).
SAFETY WARNING
EN-4

BASIC SAFETY PRECAUTIONS
23. Caution-To ensure continued protection against risk of electric
shock, connect to properly grounded outlets only. ( If the
appliance is of the grounded type).
24. Remove plug from outlet when the appliance is not in use, before
putting on or taking off parts, and befor cleaning. Allow to cool before
handing.
25. Avoid contacting moving parts.
26. For household use only.
CAUTION: Do not insert ngers into any gaps or holes; it may cause injuries.
SAVE THESE INSTURCTIONS
HOUSEHOLD INDOOR USE ONLY
SAFETY WARNING
EN-5
IMPORTANT SAFEGUARDS

BEFORE FIRST USE
1. Remove all accessories and shipping materials packed inside
the Oven.
2. Wash the Rack and Pan in warm soapy water. Wipe the inside
of the Oven with a damp cloth or sponge. Blot dry with paper
towels to be sure the unit is dry before using.
3. Place Oven on a flat counter or other stable surface DO NOT
OPERATE ON THE SAME CIRCUIT WITH ANOTHER APPLIANCE.
4. Make sure the Crumb Tray is properly installed before using.
For the first time only, Set the Temperature Knob to MAX, the
function setting on toast and the timer to 15 minutes. This will
burn off any oils still on the Oven.
• The oven may smoke during this process. This is normal
for a new
NOTA
EN-6

NAMES OF PARTS
PRODUCT INSTRUCTION
Door handle
Baking Pan Baking Rack Crumb Tray
Rotisserie Kit Rack clamp Rotisserie Kit
Housing
Function knob
Stop/Start button
Temperature knob
Timer knob
When using electrical appliance, basic safety precautions should always be followed,
including the following:
EN-7

HOW TO USE
1. Place the Baking Rack in position that will accommodate the height of the food to
be cooked.
2. The food must be put into the baking pan to avoid the fire danger that caused by
the accumulation of food chipping on the heating pipes.
Make sure that you always use an ovenproof container in the oven, never use plastic
or cardboard containers in the Oven.
3. Clean the heating pipe periodically.
4. Never use glass or ceramic pans or lids.
5. DO NOT let juices run to the bottom of the oven. Use the Crumb Tray when cooking.
6. Set the temperature as suggested by the recipe or as desired.
7. Securely shut the door and set the cooking time to begin operating the oven.
When the oven is electrified, the buzzer will ring once. The default function is TOAST.
In the process of cooking , pressing " Stop/Start " can stop cooking.
CONTROL PANEL
Stop/Start button
Temperature knob
Timer knob
2
3
4
Function knob
1
Bake level
(only Toast function)
Time / Slice
(only Toast function)
Temperature
Cooking Function
EN-8
TIME
TEMP.
2
3
4
1
TOAST
BAKE
BROIL
PIZZA
COOKIES
DEFROST
REHEAT
ROTISSERIE
KEEP WARM
CONVECTION
LIGHT DARK
COOKING STEP
THE OVEN SURFACES ARE HOT DURING AND AFTER USE GENERAL
INSTRUCTIONS
CAUTION

FUNCTION INSTRUCTION
OPERATION
OVEN FUNCTION
TOAST BAKE
COOKING
FUNCTION
Toast
Bake
Broil
Pizza 6 inch
Pizza 9 inch
Pizza 12 inch
Cookie
Defrost
Reheat
Rotisserie
Keep warm
Convection
30min
7min
8.5min
9min
30min
1hour30min
30min
1hour
1hour30min
30min
Fixed Temp Fixed Time
1min~30min
PRESET
TEMP TEMP RANGE PRESET TIME TIME RANGE
Fixed temperature & time
Preset power level : 4
Power level range : 1-6 level
Preset toast quantity : 4
Toast quantity range : 1-6 slice
Preset temperature : 450 °F
Temp range : 150 °F - 450 °F
Preset time : 30min
Time range : 0.01～2 Hour
150 °F~450 °F
100 °F~180 °F
350 °F
180 °F
350 °F
180 °F
450 °F
150 °F~450 °F
100 °F~180 °F
150 °F~450 °F
0.01~2Hour
0.01~2Hour
EN-9
TOAST
LIGHT DARK
BAKE
350 °F
450 °F
450 °F

FUNCTION INSTRUCTION
Preset temperature : 350 °F
Temp range : 150 °F - 450 °F
Preset time : 30min
Time range : 0.01～2 Hour
NOTE Do not preheat whenusing this fuction
NOTE Do not preheat whenusing this fuction
NOTE Do not preheat whenusing this fuction
Preset temperature : 350
°F
Temp range : 150 °F - 450 °F
Preset time : 30min
Time range : 0.01～2 Hour
Preset temperature : 350
°F
Temp range : 150 °F - 450 °F
Preset time : 30min
Time range : 0.01～2 Hour
Preset temperature : 350
°F
Temp range : 150 °F - 450 °F
Preset time : 30min
Time range : 0.01～2 Hour
Preset temperature : 350
°F
Temp range : 150 °F - 450 °F
Preset time : 1hour
Time range : 0.01～2 Hour
Preset temperature : 180
°F
Temp range : 100 °F - 180 °F
Preset time : 1hour 30min
Time range : 0.01～2 Hour
Preset temperature : 180
°F
Temp range : 100 °F - 180 °F
Preset time : 1hour 30min
Time range : 0.01～2 Hour
Preset temperature : 450
°F
Temp range : 150 °F - 450 °F
Preset time : 30min
Time range : 0.01～2 Hour
BROIL PIZZA
COOKIES ROTISSERIE
DEFROST KEEP WARM
REHEAT CONVECTION
EN-10
BROIL
COOKIES
KEEP WARM
CONVECTION
PIZZA
DEFROST
REHEAT
ROTISSERIE

FUNCTION INSTRUCTION
ROTISSERIE FUNCTION
1. Remove the Baking Rack from the oven and set aside.
2. Place the Baking Pan in the lowest level of the oven.
This will catch all the drippings from the food that is on the Rotisserie Forks as it
cooks.
Do Not attemp to use the Rotisserie Function without placing the Baking Pan in
the correct position of the oven.
3. Set the Function knob to "ROTIS".
4. Select the length of time you want to Rotisserie the food.
5. Rotate the Temperature knob clockwise to desired temperature.
ROTISSERIE FUNCTIO USING THE ROTISSERIE FORKS
1. Secure the food with weight centered on the forks.
2. Slide the Holding Forks onto each of the forks and press firmly into the food,
piercing the food to hold in place on the forks. Insert the Holding Forks at different
angles to hold the food more firmly. Tighten the screws, turning clockwise so that
the holding forks will stay in place during the Rotisserie cooking session.
3. Insert the pointed end of the Rotisserie forks into the Rotisserie Socket on the
inside right side of the oven.
4. Lift the Rotisserie Forks on the left side just a bit to allow the notch to fit into the
Rotisserie Bracket on the left side of the oven.
5. Set the Temperature knob and the Time knob to begin operating the oven.
6. Once the cooking time has been complete and you have checked the internal
temperature of the food to ensure that it has cooked properly, you can remove the
Rotisserie Forks with the Rotisserie Helper Handle.
7. Hold the handle in your right hand and support handle in your left hand.
8. Place the hooks on the Helper Hander underneath the Rotisserie Forks.
9. Lift the left side of the Rotisserie Forks out of the Bracket first and pull slightly
toward.
OPERATION
EN-11

FUNCTION INSTRUCTION
10. Gently remove the right pointed side of the Rotisserie Forks from the Rotisserie
Socket and remove the food on the forks out of the oven.
11. Place the food on a heat safe plate or dish when you have removed from the
oven. Let it cool slightly before attempting to remove the holding forks and
Rotisserie Forks from the food
12. To remove the Holding Forks, turn the screws counterclockwise and pull the
Holding.
Warning: Hot Surface!
Avertissement: Surface Chaude!
CAUTION
hot surface
EN-12

1. Before cleaning unplug the toaster oven and allow it to cool completely.
2. Wash all the attachments with mild, soaped water including the rack and the
baking tray.
3. Do not use abrasive cleansers, scrubbing brushes and chemical cleaner as this
will cause damage to the non-stick coating of baking tray.
4. Using a wet cloth to wipe the inner of the oven.
5. To clean the door by using a wet cloth saturated with detergent or soap.
6. Never immerse the unit in water or other liquid.
7. Any other servicing should be performed by an authorized service representative.
CARE AND CLEANING
SPECIFICATION
OPERATION
MODEL
CUBAGE
VOLTAGE
AC FREQUENCY
POWER
L*W*H
Rated Energy Consumption
AC25CEW-SS
25L
120V,1Ph
60Hz
1500W
18.9x15.6x10.8 inch
1.5KW/H
EN-13

ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in
material and workmanship for aperiod of one yearfrom the date of purchase.
This warranty is valid forthe original retail purchaser from the date of initial
retailpurchase and is not transferable. Keep your original salesreceipt.
IMPORTANT:
1. This warranty does not cover damages resulting from accident, misuse or
abuse, lack of reasonable care, the affixing of any attachments not provided
with the product, loss of parts, or subjecting the appliance to any but the
specified voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private
household purposes.
3. This warranty is void if this product is ever used outside of United State.
If service is required during the warranty period, properly pack your unit.
mend using the original carton and packing materials.
If additional assistance is needed, please contact customer assistance at:
Midea America Corp.expressly disclaims all responsibility for consequential
damages or incidental losses caused by use of the appliance. Some states do
not allow this exclusion or limitation of incidental orconsequential losses so
the foregoing disclaimer may not apply toyou. This warranty gives you
specific legal rights, and you may also have other rights which may vary from
state to state.
[e-mail]
855-204-5313
Midea America Corp
5 Sylvan Way,
Parsippany, NJ07054
Model Number:
Serial Number:
SAVE THIS FOR YOUR RECORDS
Made in China
We recom
EN-14
The serial number can be found on the back cabinet. We suggest that you
record the serial number of your unit in the space below for future reference

HORNO TOSTADOR
AC25CEW-SS
MANUAL DE INSTRUCCIONES

CONTENIDO
SP-2
SALVAGUARDIAS IMPORTANTES
MEDIDAS DE SEGURIDAD BÁSICAS.................................................................................SP-3
ANTES DEL PRIMER USO......................................................................................................SP-6
INSTRUCCIONES DEL PRODUCTO
NOMBRES DE PIEZAS............................................................................................................SP-7
FUNCIONAMIENTO
CÓMO UTILIZAR.....................................................................................................................SP-8
INSTRUCCIÓN DE LA FUNCIÓN.........................................................................................SP-9
CUIDADO Y LIMPIEZA.........................................................................................................SP-13
ESPECIFICACIONES...............................................................................................................SP-13
ANTES DE UTILIZAR ESTE PRODUCTO, LEA, ENTENDA Y SIGA ESTAS
INSTRUCCIONES. ASEGÚRESE DE GUARDAR ESTA LISTA DE LIBROS
PARA SU CONSUL-TA EN EL FUTURO
NOTA

MEDIDAS DE SEGURIDAD BÁSICAS
Cuando utilice aparatos eléctricos, siempre debe seguir las
precauciones básicas de seguridad, incluyendo las siguientes:
1. Leer instrucciones antes de usar.
2. Para protegerse de cualquier peligro eléctrico, NO coloque la
unidad o el cable en agua o en ningún otro líquido.
3. No toque las superficies calientes. Use los mangos o asas.
4. Desenchufe la unidad de la toma de corriente cuando no esté
en uso y antes de limpiarla. Deje enfriar siempre antes de fijar
o retirar cualquier pieza.
5. El uso de accesorios no recomendados por el fabricante del
aparato puede causar lesiones.
6. A continuación, enchufe el cable a la toma de corriente. Para
desconectar, gire cualquier control a "off", luego retire el
enchufe de la toma de corriente.
7. No deje que el cable cuelgue del borde de la mesa o mostrador,
ni toque la superfi- cie caliente.
8. No coloque el horno tostador dentro de un horno caliente o
cerca de un quemador de gas caliente o eléctrico.
9. No utilice al aire libre.
10.No opere ningún aparato con un cable o enchufe dañado o
después de que el aparato funcione mal o se haya dañado de
alguna manera. Devuelva el electro-doméstico al centro de
servicio autorizado más cercano para su examen, reparación
o ajuste. Guarde únicamente los accesorios suministrados con
esta unidad dentro del horno cuando no esté en uso.
SALVAGUARDIAS IMPORTANTES
SP-3
11.Se puede producir un incendio si el aparato está cubierto o
toca material inflam-able, incluyendo cortinas, telones,
paredes y similares, cuando está en funciona-miento.
No coloque ningún objeto encima del aparato cuando esté
en funciona-miento.
ADVERTENCIA DE
SEGURIDAD

MEDIDAS DE SEGURIDAD BÁSICAS
12.No coloque ningún cartón, papel o plástico dentro del horno.
13.Ningún recipiente colocado dentro del horno debe ser
hermético. Además, necesitan tener espacio suficiente para
permitir la expansión de los fluidos.
14.No limpie con almohadillas para fregar metales. Las piezas
pueden romper la almohadilla y tocar las partes eléctricas
que implican un riesgo de descarga eléctrica.
15.Los alimentos de gran tamaño o los utensilios de metal no se
deben insertar en un horno tostado, ya que pueden crear un
incendio o riesgo de descarga eléctrica.
16.No cubra la bandeja para migas ni ninguna parte del horno
con papel metálico.
17.Se debe tener extrema precaución al mover un aparato que
contenga aceite caliente u otros líquidos calientes. Tenga
mucho cuidado al retirar la bandeja o eliminar la grasa
caliente.
18.No almacene ningún objeto o material dentro del horno sin
uso, aparte de los accesorios recomendados por el fabricante.
19.No cubra la bandeja de migas ni ninguna otra parte del horno
con láminas de metal. Esto causará un sobrecalentamiento
del horno.
SP-4
20.Se necesita supervisión cuando cualquier aparato eléctrico
es utilizado por niños o cerca de ellos.
21.Se debe tener extrema precaución al mover un aparato que
contenga aceite caliente u otros líquidos calientes. Tenga
mucho cuidado al retirar la bandeja o eliminar la grasa caliente.
22.Este aparato tiene un enchufe polarizado (una pata es más
ancha que la otra). Para reducir riesgo de descarga eléctrica,
ADVERTENCIA DE
SEGURIDAD

MEDIDAS DE SEGURIDAD BÁSICAS
completo en el tomacorriente, inviértalo. Si aún así no encaja,
póngase en contacto con un electricista. No trate de
modificar el enchufe de manera alguna.
(Para aparatos equipados con un enchufe polarizado de
dos cables.).
23.Atención -Para asegurar una protección continua contra
descargas eléctricas, sólo conectar a tomacorrientes con
conexión a tierra adecuada. (Si el aparato es del tipo a tierra.)
24. Desconectar de la toma de corriente cuando no se use, antes
de poner o sacar partes, y antes de limpiar. Dejar enfriar
antes de tocar.
25.Evite el contacto con las partes móviles.
26.Solo para uso doméstico.
27.No utilice el aparato para otro uso que no sea el previsto.
SP-5
SALVAGUARDIAS IMPORTANTES
28.No limpie con almohadillas para fregar metales. Las piezas
pueden romper la almohadilla y tocar las partes eléctricas,
creando un riesgo de descarga eléctrica.
29.Se debe tener extrema precaución cuando se utilicen
recipientes con otros materiales que no sean de metal o
vidrio.
PRECAUCIÓN: No introduzca el dedo en las aberturas o agujeros,
podría causar el riesgo de lesiones.
GUARDE ESTAS INSTRUCCIONES
SOLO PARA USO DOMÉSTICO
polarizado de una sola manera. Si el enchufe no encaja por
el enchufe está diseñado para encajar en un tomacorriente
ADVERTENCIA DE
SEGURIDAD

ANTES DEL PRIMER USO
1. Retire todos los accesorios y materiales de envío embalados
dentro del horno.
2. Lave la rejilla y la bandeja en agua jabonosa tibia. Limpie el
interior del horno con un paño húmedo o una esponja. Seque
con toallas de papel para asegurarse de que la unidad esté seca
antes de usarla.
3. Coloque el Horno en un mostrador plano u otra superficie
estable. NO HAGA FUNCIONAR EN EL MISMO CIRCUITO CON
OTRO APARATO.
4. Asegúrese de que la bandeja de migas esté instalada
correctamente antes de usarla.
Sólo por primera vez, ajuste el mando de temperatura en MAX, la
configuración de la función en tostar y el temporizador a 15
minutos. Esto quemará cualquier aceite que quede en el horno.
• El horno puede echar humo durante este proceso.
Esto es normal en un horno nuevo.
NOTA
SP-6
