Toshiba WTR-A25ASS User manual

INSTRUCTION MANUAL
TOASTER OVEN
WTR-A25ASS

BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
NOTE
CONTENTS
PRODUCT SAFETY
INSTRUCTION FOR USE
BEFORE FIRST USE ................................................................................................................... EN-5
NAME OF PARTS ........................................................................................................................ EN-6
OPERATION .................................................................................................................................. EN-7
CARE AND CLEANING .............................................................................................................. EN-1
IMPORTANT SAFEGUARDS .................................................................................................... EN-2
2
WARRANTY PAGE....................................................................................................................... EN-14
BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND
FOLLOW THESE INSTRUCTIONS.

EN-2
IMPORTANT SAFEGUARDS
BASIC SAFETY PRECAUTIONS
When using electrical appliance, basic safety precautions should
always be followed, including the following:
SAFETY WARNING
PRODUCT SAFETY
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs,
or any electrical parts in water or other liquid.
4. Close supervision is necessary when any appliance is used by or
near children.
5. Unplug from outlet when not in use and before cleaning. Allow
to cool before putting on or taking o parts.
6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions or has been damaged in any
manner. Return appliance to the nearest authorized service
facility for examination, repair, o r adjustment.
7. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot
surfaces.
10. Do not place on or near a hot gas or electric burner, or in a
heated oven.
11. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
disconnect, turn any control to " off ", then remove plug from
12. To
wall outlet.
13. Do not use appliance for other than intended use.

EN-3
SAFETY WARNING
14. Use extreme caution when removing tray or disposing of hot
grease.
15. Do not clean with metal scouring pads. Pieces can break o the
pad and touch electrical parts, creating parts, creating a risk of
electric shock.
16. Oversize foods or metal utensils must not be inserted in a
toaster oven as they may create a re or risk of electric shock.
17. A re may occur if the toaster oven is covered or touching
ammable material, including curtains, draperies, walls, and the
like, when in operation. Do not store any of the above materials
18. Extreme caution should be exercised when using containers
constructed of other than metal or glass.
19. Do not store any materials, other than manufacturers recom-
mended accessories, in this oven when not in use.
20. Do not place any of the following materials in the oven: paper,
cardboard, plastic and like.
21. Do not cover the crumb tray or any part of the oven with metal foil.
This will cause overheating of the oven.
22. Caution! To ensure continued protection against risk of electric
shock, connect to properly grounded outlets only.( If the appli-
ance is of the grounded type)
23. Remove plug from outlet when the appliance is not in use,
before putting on or taking o parts, and befor cleaning. Allow
to cool before handing.
24. Avoid contacting moving parts.
25. For household use only.
IMPORTANT SAFEGUARDS
on top of the appliance when in operation.
26. Hold " " for several seconds to shut down the oven.
Stop/Start

SAVE THESE INSTURCTIONS
HOUSEHOLD INDOOR USE ONLY
SAFETY WARNING
PRODUCT SAFETY
Do not insert your ngers into any gaps or holes;
it may cause injuries.
IMPORTANT SAFEGUARDS
CAUTION:
EN-4

EN-5
1. Remove all accessories and shipping materials packed inside the oven.
2. Wash the rack and pan in warm soapy water. Wipe the inside of the oven with
a damp cloth or sponge. Blot dry with paper towels to be sure the unit is dry
before using.
3. Place oven on a at counter or other stable surface DO NOT OPERATE ON THE
SAME CIRCUIT WITH ANOTHER APPLIANCE.
4. Make sure the crumb tray is properly installed before using.
For the rst time only: Set the temperature knob to MAX, the function setting on
toast and the timer to 15 minutes. This will burn o any oils still on the Oven.
BEFORE FIRST USE
NOTE The oven may smoke during this process.
This is normal for a new oven and will not last more than 10-15 minutes.

EN-6
PART NAMES
When using electrical appliances, basic safety precautions should always be followed,
including the following:
PRODUCT INSTRUCTION
Door handle
Housing
Function knob
Stop/Start button
Temperature knob
Timer knob
Crumb Tray
Rotisserie Kit Rack clamp
Baking RackBaking Pan
INSTRUCTION FOR USE
Rotisserie Forks
FONCTION
TEMP.
TEMPS
Arrêt/Démarrer

EN-7
HOW TO USE
CONTROL PANEL
OPERATION
1. Place the baking rack in position that will accommodate the height of the food to
be cooked.
2. Set the food on the rack. Make sure that you always use an ovenproof container in
the oven, never use plastic or cardboard containers in the oven.
3. Never use glass or ceramic pans or lids.
4. DO NOT let juices run to the bottom of the oven. Use the drip tray and crumb
ray when cooking.
5. Set the temperature as suggested by the recipe or as desired.
6. Securely shut the door and set the cooking time to begin operating the oven.
Bake level
(only Toast function)
Time / Slice
(only Toast function)
Temperature
Cooking Function
TOAST
BAKE
BROIL
PIZZA
COOKIES
DEFROST
REHEAT
ROTISSERIE
KEEP WARM
CONVECTION
LIGHT DARK
Stop/Start button
Temperature knob
Timer knob
2
3
4
Function knob
1
2
3
1
COOKING STEP
t
INSTRUCTIONS
When the oven is plugged in, the buzzer will ring once. The default function is toast.
In the process of cooking, selecting "Stop/Start" will stop the function.
CAUTION: THE OVEN SURFACES ARE HOT DURING AND AFTER USE
GENERAL
FONCTION
TEMP.
TEMPS
Arrêt/Démarrer

EN-8
FUNCTION INSTRUCTION
OVEN FUNCTION
COOKING
FUNCTION
Toast
Bake
Broil
Pizza 6 inch
Pizza 9 inch
Pizza 12 inch
Defrost
Reheat
Rotisserie
Keep warm
Convection
30 min
7 min30 seconds
30 min
1 hour30 min
30 min
1 hour
1 hour30 min
30 min
Fixed Temp Fixed Time
PRESET
TEMP TEMP RANGE PRESET TIME TIME RANGE
10 min
10 min30 seconds
450
350
450
350
180
350
180
450
150 450
100 ~180
150 450
100 ~180
150 450
150 350
150 450
150 350
TOAST BAKE
TOAST
LIGHT DARK
BAKE
Fixed temperature & time
Preset power level: 4
Power level range: 1-6 level
Preset toast quantity: 4
Toast quantity range: 1-6 slice
INSTRUCTION FOR USE
1 min~2 hours
1 min~2 hours
1 min~30 min
1 min~2 hours
Cookies

EN-9
FUNCTION INSTRUCTION
NOTE
NOTE
NOTE
The cooking time will be displayed and
countdown after pressing "Stop/Start"
to start cooking.
BROIL
COOKIES
KEEP WARM
CONVECTION
PIZZA
DEFROST
REHEAT
ROTISSERIE
Preset time : 1 hour
Do not preheat when using this function
Do not preheat when using this function
Do not preheat when using this function
BROIL PIZZA
COOKIES ROTISSERIS
DEFROST KEEP WARM
REHEAT CONVECTION
Preset temperature: 350
Temp range: 150
Preset time: 30 min
Preset temperature: 450
30min
Temp range: 150
Preset time: 10 min
Preset temperature: 350
Temp range: 150
Preset time: 30 min
Time range: 1 min~2 hours
Preset temperature: 350
Time range: 1 min~2 hours
Temp range: 150 -350-450
-350 -450
Time range: 1 min~2 hours Time range: 1min~
Preset temperature: 180
Temp range: 100 -180
Time range: 1 min~2 hours
Preset time: 1 hour 30 min
Preset temperature: 180
Temp range: 100 -180
Preset time: 1 hour 30 min
Time range: 1 min~2 hours
Preset temperature: 350
Temp range: 150 -450
Preset time: 30 min
Time range: 1 min~2 hours
Preset temperature: 450
Temp range: 150
Time range: 1 min~2 hours
-450
Preset time: 30 min

EN-10
FUNCTION INSTRUCTION
ROTISSERIE FUNCTION
1. Remove the Baking Rack from the oven and set aside.
2. Place the Baking Pan in the lowest level of the oven.
This will catch all the drippings from the food that is on the Rotisserie
Forks as it cooks. Do NOT attempt to use the Rotisserie Function without
placing the Baking Pan in the correct position of the oven.
4. Set the Function knob to " ROTIS".
5. Select the toast time you want to Rotisserie the food.
6. Rotate the Temperature knob clockwise to desired temperature.
ROTISSERIE FUNCTIONn USING THE ROTISSERIE FORKS
1. Secure the food with weight centered on the forks.
2. Slide the Holding Forks onto each of the forks and press rmly into the food,
piercing the food to hold in place on the forks. Insert the Holding Forks at
dierent angles to hold the food more rmly. Tighten the screws, turning
clockwise so that the holding forks will stay in place during the Rotisserie
cooking session.
3. Insert the pointed end of the Rotisserie forks into the Rotisserie Socket on the
inside right side of the oven.
4. Lift the Rotisserie Forks on the left side just a bit to allow the notch to t into
the Rotisserie Bracket on the left side of the oven.
5. Set the Temperature knob and the Time knob to begin operating the oven.
6. Once cooking is complete and you have checked the internal temperature of the
food to ensure that it has cooked properly, you can remove the Rotisserie Forks
with the Rotisserie Helper Handle.
7. Hold the handle in your right hand and support handle in your left hand.
INSTRUCTION FOR USE

EN-11
FUNCTION INSTRUCTION
10. Gently remove the right pointed side of the Rotisserie Forks from the
Rotisserie Socket and remove the food on the forks out of the oven.
11. Place the food on a heat safe plate or dish when you have removed from the
oven. Let it cool slightly before attempting to remove the holding forks and
Rotisserie Forks from the food.
12. To remove the Holding Forks, turn the screws counterclockwise and pull the
Holding.
CAUTION
Warning: Hot Surface!
Avertissement: Surface Chaude!
8. Place the hooks on the Helper Hander underneath the Rotisserie Forks.
9. Lift the left side of the Rotisserie Forks out of the Bracket rst and pull slightly
toward you.

EN-12
CARE AND CLEANING
1. Before cleaning unplug the toaster oven and allow it to cool completely.
2. Wash all the attachments with mild, soaped water including the rack and the
baking tray.
3. Do not use abrasive cleansers, scrubbing brushes and chemical cleaner as this will
cause damage to the non-stick coating of baking tray.
4. Using a wet cloth to wipe the interior of the oven.
5. Clean the door by using a wet cloth saturated with detergent or soap.
6. Never immerse the unit in water or other liquid.
7. Any other servicing should be performed by an authorized service representative.
INSTRUCTION FOR USE

EN-13
SPECIFICATION
MODEL
VOLTAGE
POWER
L*W*H
25L
60Hz
1500W
AC FREQUENCY
120V
18.9x15.6x10.8 inches(482x396x274 mm)
14. s( )
OVEN CAPACITY
NET WEIGHT
WTR-A25ASS
45lb 6.6 kg

ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid for
the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep your original sales receipt.
IMPORTANT:
1. This warranty does not cover damages resulting from accident, misuse or abuse, lack of
reasonable care, the axing of any attachments not provided with the product, loss of
parts, or subjecting the appliance to any but the specied voltage. ( Read directions
carefully. )
2. This warranty is void if this product is ever used for other than private household
3. This warranty is void if this product is ever used outside of United States .
If service is required during the warranty period, properly pack your unit. We recommend
using the original carton and packing materials.
If additional assistance is needed, please contact customer assistance at:
Midea America (Canada) Corp. expressly disclaims all responsibility for consequential damages
limitation of incidental or consequential losses so the foregoing disclaimer may not apply to
you. This warranty gives you specic legal rights, and you may also have other rights which
may vary from state to state.
The serial number can be found on the back cabinet. We suggest that you record the serial
number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
SAVE THIS FOR YOUR RECORDS
Made in China
purposes.
or incidental losses caused by use of the appliance. Some states do not allow this exclusion or
Midea America (Canada) Corp.
Markham, ON L3R 8V2
1-855-238-5607

Midea America (Canada) Corp.
Markham, ON L3R 8V2
Customer Assistance:1-855-238-5607

MODE D'EMPLOI
FOUR À PAIN
WTR-A25ASS
AVERTISSEMENT
DE SÉCURITÉ
SÉCURITÉ DES PRODUITS
AVERTISSEMENT
DE SÉCURITÉ
MODE D'EMPLOI
MODE D'EMPLOI
MODE D'EMPLOI

NOTE
CONTENU
SÉCURITÉ DES PRODUITS
MODE D'EMPLOI
AVANT LA PREMIÈRE UTILISATION........................................................................................FR-5
NOM DES PIÈCES..........................................................................................................................FR-6
OPÉRATION....................................................................................................................................FR-7
SOINS ET NETTOYAGE................................................................................................................FR-12
GARANTIES IMPORTANTES......................................................................................................FR-2
GARANTIE PAGE...........................................................................................................................FR-14
AVERTISSEMENT
DE SÉCURITÉ
SÉCURITÉ DES PRODUITS
AVERTISSEMENT
DE SÉCURITÉ
MODE D'EMPLOI
MODE D'EMPLOI
MODE D'EMPLOI
AVANT D'UTILISER CE PRODUIT, LISEZ, COMPRENEZ ET SUIVEZ CES
INSTRUCTIONS.
N'OUBLIEZ PAS DE CONSERVER CETTE LISTE DE LIVRES POUR
RÉFÉRENCE FUTURE

FR-2
DES GARANTIES IMPORTANTES
PRÉCAUTIONS DE SÉCURITÉ DE BASE
Lors de l'utilisation d'appareils électriques, des précautions de sécurité
de base doivent toujours être prises, notamment les suivantes :
AVERTISSEMENT
DE SÉCURITÉ
SÉCURITÉ DES PRODUITS
1. Lisez toutes les instructions.
2. Ne pas toucher les surfaces chaudes. Utilisez des poignées ou des
boutons.
3. Pour vous protéger contre les chocs électriques, n'immergez pas le
cordon, les prises ou tout autre élément électrique dans l'eau ou un
autre liquide.
4. Une surveillance étroite est nécessaire lorsqu'un appareil est utilisé
par des enfants ou à proximité.
5. Débranchez la prise lorsqu'elle n'est pas utilisée et avant de la nettoy-
er. Laissez refroidir avant de mettre ou d'enlever des pièces.
6. Ne faites pas fonctionner un appareil dont le cordon ou la che est
endommagé ou qui fonctionne mal ou a été endommagé de
quelque manière que ce soit. Renvoyez l'appareil au centre de
service agréé le plus proche pour examen, réparation ou réglage.
7. L'utilisation d'accessoires non recommandés par le fabricant de
l'appareil peut provoquer des blessures.
8. Ne pas utiliser à l'extérieur.
9. Ne laissez pas le cordon pendre au-dessus du bord de la table ou du
comptoir, ni toucher des surfaces chaudes.
10. Do not place on or near a hot gas or electric burner, or in a heated
oven.
11. Il faut faire preuve d'une extrême prudence lorsqu'on déplace un
appareil contenant de l'huile chaude ou d'autres liquides chauds
12. Pour vous déconnecter, mettez n'importe quelle commande sur
" ", puis retirez la che de la prise murale.
13. N'utilisez pas l'appareil pour une utilisation autre que celle prévue.
AVERTISSEMENT
DE SÉCURITÉ
SÉCURITÉ DES PRODUITS
AVERTISSEMENT
DE SÉCURITÉ
MODE D'EMPLOI
MODE D'EMPLOI
Arrêt

FR-3
GARANTIES IMPORTANTES
14. Faites preuve d'une extrême prudence lorsque vous retirez le plateau
ou que vous jetez de la graisse chaude.
15. Ne pas nettoyer avec des tampons à récurer métalliques. Des
morceaux peuvent se détacher du tampon et toucher des parties
électriques, créant ainsi des pièces, d'où un risque de choc électrique.
16. Les aliments ou les ustensiles en métal trop grands ne doivent pas être
insérés dans un four grille-pain car ils peuvent créer un incendie ou un
risque de choc électrique.
17. Un incendie peut se produire si le grille-pain-four est couvert ou
touche des matériaux inammables, notamment des rideaux, des
tentures, des murs et autres, lorsqu'il fonctionne. Ne les stockez pas
sur le dessus de l'appareil lorsqu'il fonctionne.
18. Il convient de faire preuve d'une extrême prudence lors de l'utilisation
de récipients autres qu'en métal ou en verre.
19. Ne stockez pas de matériaux, autres que les accessoires recommandés
par le fabricant, dans ce four lorsqu'il n'est pas utilisé.
20. Ne mettez pas les matériaux suivants dans le four : papier, carton,
plastique et autres.
21. Ne couvrez pas le plateau à miettes ni aucune partie du four avec une
feuille de métal. Cela entraînera une surchaue du four.
22. Attention : pour assurer une protection continue contre le risque de
choc électrique, ne branchez les appareils qu'à des prises correcte-
ment mises à la terre. (Si l'appareil est du type mis à la terre)
23. Retirez la che de la prise de courant lorsque l'appareil n'est pas
utilisé, avant de mettre ou de retirer des pièces, et avant le nettoyage.
Laisser refroidir avant de le remettre.
24. Évitez de contacter les pièces mobiles.
25. A usage domestique uniquement.
26. Appuyez longuement sur " "pour arrêter le
four.
AVERTISSEMENT
DE SÉCURITÉ
SÉCURITÉ DES PRODUITS
AVERTISSEMENT
DE SÉCURITÉ
MODE D'EMPLOI
MODE D'EMPLOI
Arrêt/Démarrer
fonctionnement du
