UNINTERRUPTIBLE POWER SYSTEMS
Protection of Electronic Equipment from
Random Surges & High Amplitude Spikes
Comprehensive Power Management
via RS232 & Ethernet with Browser or SNMP
Remote Management Individual Output
Power Receptacles
Programmable Turn On/Off Based on
Specic Events
Event Notication through SNMP Trap &
Email Alerts
Detailed Data-Logging For Statistic Analysis
& Diagnostics
Double-Layer Security for Administrators &
Users
Optional Connectivity of Versatile Sensors
via Environmental Monitoring Device
Intelligent Power
Distribution Unit

MODEL Remote-D: 120 V Remote-D: 230 V
INPUT Voltage 120 V 230 V
Voltage Range 100 to 125 V 200 to 250 V
Load Capacity 15 A 20 A
Frequency 50/60 Hz Auto-Sensing
Input Line Cord (6 ft.) NEMA 5-15P IEC C14
OUTPUT Voltage 120 V 230 V
Frequency 50/60 Hz Auto-Sensing
Rated Current 15 A 10 A
Output Receptacles Eight NEMA 5-15R Eight IEC C13
COMMUNICATION Network Protocol SNMP Over UDP/IP, HTTP Over TCP/IP
Network Security SNMPv3, SSL, SSH & User Secure Password Protection
PHYSICAL Indication Input/Output Power Status Indicators
Network Port 10/100 Base-T RJ-45 Network Connectivity
Digital Contacts Two Set Event-Controlled Contacts
Dimensions (W x D x H) 17.2 x 10.6 x 1.73 in. (436 mm x 270 mm x 44 mm )
Weight 8.4 lb (3.8 kg)
OPTION Environmental Monitoring Device Part #: RMTI-EMD-HT
ENVIRONMENT Operating Ambient Temperature 32˚ to 104˚F (0˚ to 40˚C)
Recommended Temperature 59˚ to 77˚F (15˚ to 25˚C)
Humidity 10 to 80% Non-Condensed
CONFORMANCE Regulatory Approvals FCC Class A, UL, CUL, CE
WARRANTY One Year
Remote-D Intelligent Power Distribution Unit
*UPSRMTD090129*
UPS ADJUSTABLE SPEED DRIVES MOTORS CONTROLS INSTRUMENTATION PLC
INDUSTRIAL DIVISION
13131 West Little York Road, Houston, Texas 77041
Tel [phone] Fax [phone]
US [phone] Canada [phone] Mexico 01(800)527-1204
www.toshiba.com/ind
Copyright 1/2009
Available Through:
Remote-D 120 V (Rear)Remote-D 230 V (Rear)
Remote-D Status Screen Remote-D Log History ScreenRemote-D Management Screen
Visit http://RemoteD.tic.toshiba.com to view a live demo of the Remote-D interface.
