IK-TF9C
3-MEGA PIXEL 3 CCD COLOR CAMERA
›3 Progressive Scan CCD Sensors
›Output Resolution of 2048 x 1536
›Video Output – Camera Link
›20 frames/sec (full frame)
›Partial Scan 30 frames/sec and 40 frames/sec
›Ultra Compact Size
›On-screen and RS-232 Setup
›Asynchronous Reset
›Pulse Width Trigger
›C-Mount Lens Mount
3-MMEGA PPIXEL
3CCCD
PROGRESSIVE SSCAN
COLOR CCAMERA

13 1
26 14
44±0.2
44±0.2
22±0.1
12
34
8.2
19.2 2-M2
26±0.1
5±0.1 4.8
2-M3 Depth 3
78 -0.3
+0.2 6.3
26±0.1
25
26±0.1
5±0.1 56±0.2
25±0.2 25±0.1
4-M3 Depth 3
4-M2 Depth 3
Scanning System Progressive Scan
Image Sensor 3 x 1/3” CCD
Effective Pixels 1034 x 779
Output Pixels 2048 x 1536 (by way of 1/2 pixel offset)
Frame Rate 20 frames per second (full frame)
Partial Scan 30 fps (972 lines); 40 fps (644 lines)
Pixel Size 4.65 µm (H) x 4.65 µm (V)
Clock 80.87 MHz
Output Interface Camera Link
Output Signal 8-bit RGB
Sync Signal Output FVAL/LVAL/DVAL
Gamma Correction Yes
White Balance AWB/Manual
Gain Manual, OFF (odB)
Input Power 12VDC +/- 10%
Minimum Illumination 10 Lux at F2.2
Lens Mount C-mount
Ambient Temp. 0ºC - 40ºC
Ambient Humidity Less than 90%
Weight 165g
Dimensions 44 mm x 44 mm x 78.3 mm
IK-TF9C
3 MEGA PIXEL 3CCD COLOR CAMERA
©2006 Toshiba America Information Systems, Inc. All rights reserved. All
products and names mentioned are the property of their respective owners.
While Toshiba has made every effort at the time of publication to ensure the
accuracy of the information provided herein, product specifications, configu-
rations, prices, system/component/options availability are all subject to
change without notice.
Toshiba America Information Systems, Inc.
Imaging Systems Division
9740 Irvine Boulevard, Irvine, California 92618
1-602-7967130 • www.cameras.toshiba.com
SPECIFICATIONS
DIMENSIONS
CONNECTOR PIN ASSIGNMENTS
DC IN 12V Terminal
DISP Button
MENU UP Button
DATA UP (AWB) Button
DATA DOWN Button
MENU DOWN Button
PAGE Button
DIGITAL Terminal
Prism Faceplate
1 GND
2 X0-
3 X1-
4 X2-
5 Xcllk-
6 X3-
7 SerTC+
8 SerTFG-
9 CC1-
10 CC2+
11 CC3-
12 CC4+
13 GND
14 GND
15 X0+
16 X1+
17 X2+
18 Xcllk+
19 X3+
20 SerTC-
21 SerTFG+
22 CC1+
23 CC2-
24 CC3+
25 CC4-
26 GND
-
O
O
O
O
O
I
O
I
I
-
-
-
1 +12V
2 +12V
3 GND
4 GND
Serial communication control (RXD)
Serial communication control (TXD)
Trigger pulse input
Partial scanning control
NC
NC
Connector used:
HR10A-7P-4PB
(HIROSE electronics
Co. Ltd.) or equivalent
Connector used:
12226-51000-00 (3M)
or equivalent
Measurements in Millimeters
12
3 4
DC IN 12V DIGITAL Function I/O
