NETWORKCAMERA
Model: IK-WB70A
QuickStartGuideandImportantSafeguards
Thisguidedescribesthehardwareinstallation.
TheapplicationAdobeReaderisneededtoseePDFfiles.Ifyoudonothave
thisapplication,downloaditfromtheWebsiteofAdobeSystemsIncorporated.
Refer the user's manual (PDF file) contained in the CD-ROM for settings,
operationsandotherinformation.
For information on our latest products and peripheral devices, refer to the
followingWebsite:
■ http://www.toshibasecurity.com
IK-WB70AQuickGuideEN.indd1IK-WB70AQuickGuideEN.indd1 2009/04/1014:25:172009/04/1014:25:17

2
Introduction
FCC(USA)-INFORMATION
NOTE:Thisequipmenthasbeentestedandfoundtocomplywiththe
limitsforaClassAdigitaldevice,pursuanttoPart15oftheFCCRules.
Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferencewhentheequipmentisoperatedinacommercial
environment.Thisequipmentgenerates,uses,andcanradiateradio
frequencyenergyand,ifnotinstalledandusedinaccordancewith
theinstructionmanual,maycauseharmfulinterferencetoradio
communications.Operationofthisequipmentinaresidentialarea
islikelytocauseharmfulinterferenceinwhichcasetheuserwillbe
requiredtocorrecttheinterferenceathisownexpense.
USER-INSTALLERCAUTION:YourauthoritytooperatethisFCCverified
equipmentcouldbevoidedifyoumakechangesormodificationsnot
expresslyapprovedbytheparty.
ThisdevicecomplieswithPart15oftheFCCRules.
Operationissubjecttothefollowingtwoconditions:
(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevice
mustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
ThisClassAdigitalapparatuscomplieswithCanadianICES-003.
Cetappareilnumé
riquedelaclasseAestconformeàlanorme
NMB-003duCanada
IK-WB70AQuickGuideEN.indd2IK-WB70AQuickGuideEN.indd2 2009/04/1014:25:182009/04/1014:25:18

3
ThankyouforpurchasingtheIK-WB70ANetworkCamera.Beforeyou
startusingthecamera,readthisquickstartguidecarefullytoensure
correctusage.Onceyouhavefinishedreadingthisquickstartguide,
keepitinaconvenientplaceforfuturereference.
Thedesign,specifications,software,andquickstartguidecontentsare
subjecttochangewithoutpriornotice.
TermsandTrademarks
●Theterm"OS"isusedinthismanualtoindicateoperatingsystems
compatiblewiththisproduct.
−
Windows®XP:Microsoft®Windows®XPoperatingsystem
− WindowsVista®:Microsoft®WindowsVista®Businessoperatingsystem
●TheformalnameofWindows®isMicrosoft®Windows®Operating
System.
●Microsoft®,Windows®and
WindowsVista® aretrademarksorregistered
trademarksofMicrosoft®CorporationintheUnitedStatesandother
countries.
●AdobeisaregisteredtrademarkandAdobeReaderisatrademarkof
AdobeSystemsIncorporated.
●Otherproductnamesappearinginthisquickstartguidemaybe
trademarksorregisteredtrademarksoftheirrespectiveholders.
NOTE
●This network camera might not operate correctly depending on the network
environment.
IK-WB70AQuickGuideEN.indd3IK-WB70AQuickGuideEN.indd3 2009/04/1014:25:182009/04/1014:25:18

4
TableofContents
Introduction
● Introduction.............................................................................................................. 2
●TermsandTrademarks........................................................................................... 3
● TableofContents.................................................................................................. 4
● IMPORTANTSAFEGUARDS..............................................................................5
● NOTESONUSEANDINSTALLATION........................................................... 9
● SettingNetworkCameraEnvironment........................................................ 10
●Itemsneededfornetworkcameramonitoringsystem..............................10
QuickStartGuide
● Contents................................................................................................................ 11
● PhysicalDescription.......................................................................................... 12
● HardwareInstallation(1)................................................................................... 13
● NetworkDeployment......................................................................................... 14
● AssigningIPAddress........................................................................................ 16
● RetrievingImages............................................................................................... 17
● AdjustingtheLens............................................................................................. 18
● HardwareInstallation(2)................................................................................... 19
IK-WB70AQuickGuideEN.indd4IK-WB70AQuickGuideEN.indd4 2009/04/1014:25:192009/04/1014:25:19

5
IMPORTANTSAFEGUARDS
1.ReadInstructions
Read all the safety and operating instructions before operatingthe
product.
2.RetainInstructions
Retainthesafetyinstructionsanduser'smanualforfuturereference.
3.Warnings
Complywithallwarningsontheproductandintheuser'smanual.
4.FollowInstructions
Followalloperatinganduseinstructions.
5.Cleaning
Disconnectthisvideoproductfromthepowersupplybeforecleaning.
6.Attachments
Do not use attachments not recommended by the video product
manufacturerastheymaycausehazards.
7.Accessories
Do not place this video product on an unstable cart, stand, tripod,
bracket or table. The video product may fall, causing serious injury
toaperson,orseriousdamagetotheproduct.Useonlywithstand,
tripod, bracket, or table recommended by the manufacturer, or sold
withthevideoproduct.Anymountingoftheproductshouldfollowthe
manufacturer's instructions, and should use a mounting accessory
recommendedbythemanufacturer.
8.Ventilation
Thisvideoproductshouldneverbeplacednearor overaradiator or
heat register. If this product is placed in a built in installation verify
thatthereis properventilationso that thecamera temperature
operateswithintherecommendedtemperaturerange.
9.PowerSources
This video product should be operated only from the type of power
source indicated on the information label. If you are not sure of the
typeofpowersupplyatyourlocation,consultyourproductdealer.
IK-WB70AQuickGuideEN.indd5IK-WB70AQuickGuideEN.indd5 2009/04/1014:25:192009/04/1014:25:19

6
IMPORTANTSAFEGUARDS(Cont.)
10.Power-CordProtection
Powercordsshouldberoutedsothattheyarenotlikelytobewalked
on or pinched by items placed upon or against them. Pay particular
attentiontocordsatplugs,screwsandthepointwheretheyexitthe
product.
11.Installation
Install this video product on a secure part of the ceiling or wall. If
installed on an unsecured location, the camera could fall causing
injuryanddamage.
12.Lightning
For additional protection on this video product during a lightning
storm, or when it is left unattended and unused for long periods of
time,unplugitfromthewalloutletanddisconnectthepowersupply
andcablesystem.Thiswillpreventdamagetothevideoproductdue
to lightning and power-line surges. If lightning occurs, do not touch
theunitoranyconnectedcablesinordertoavoidelectricshock.
13.Overloading
Do not overload the power supply or extension cords as this can
resultinariskoffireorelectricshock.
14.ObjectandLiquidEntry
Neverpushobjectsofanykindintothisvideoproductthrough
openingsastheymaytouchdangerouselectricalpointsorshort-out
partsthatcouldresultinafireorelectricalshock.Neverspillliquidof
anykindonthevideoproduct.
15.Servicing
Donot attempttoservice thisvideo productyourselfas openingor
removing covers may expose you to dangerous electrical or other
hazards.Referallservicingtoqualifiedservicepersonnel.
IK-WB70AQuickGuideEN.indd6IK-WB70AQuickGuideEN.indd6 2009/04/1014:25:192009/04/1014:25:19

7
16.DamageRequiringservice
Disconnectthisvideoproductfromthepowersupplyandrefer
servicingtoqualifiedservicepersonnelunderthefollowingconditions.
a. Whenthepower-supplycordorplugisdamaged.
b. If liquid has been spilled, or objects have fallen into the video
product.
c. Ifthevideoproducthasbeensubmergedinwater.
d. If the video product does not operate normally by following the
operating instructions in the user's manual. Adjust only those
controls that are covered by the user's manual as an improper
adjustment of other controls may result in damage and will often
requireextensiveworkbyaqualifiedtechniciantorestorethevideo
producttoitsnormaloperation.
e. If the video product has been dropped or the cabinet has been
damaged.
f. Whenthevideoproductexhibitingadistinctchangeinperformance
whichindicatesaneedforservice.
17.ReplacementParts
When replacingpartsbesuretheservicetechnicianusesparts
specified by the manufacturer or have the same characteristics as
theoriginalpart.Unauthorizedsubstitutionsmayresultinfire,electric
shockorotherhazards.
18.SafetyCheck
Uponcompletion ofanyserviceorrepairs tothis videoproduct,ask
theservicetechniciantoperformsafetycheckstodeterminethatthe
videoproductisinproperoperatingcondition.
IK-WB70AQuickGuideEN.indd7IK-WB70AQuickGuideEN.indd7 2009/04/1014:25:192009/04/1014:25:19

8
CAUTIONTOREDUCETHERISKOFELECTRICSHOCK.
DONOTREMOVECOVER.NOUSERSERVICEABLEPARTSINSIDE.
REFERSERVICINGTOQUALIFIEDSERVICEPERSONNEL.
Thelightningflashwitharrowheadsymbol,withinan
equilateraltriangle,isintendedtoalerttheusertothepresence
ofuninsulated"dangerousvoltage"withintheproduct's
enclosurethatmaybeofsufficientmagnitudetoconstitutea
riskofelectricshocktopersons.
Theexclamationpointwithinanequilateraltriangleisintended
toalerttheusertothepresenceofimportantoperating
andmaintenance(servicing)instructionsintheliterature
accompanyingtheappliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT
SUBMERGE THIS CAMERA IN
WATER.
FIELD INSTALLATION MARKING:
WORDED：“THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED
SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.”
IMPORTANTSAFEGUARDS(Cont.)
IK-WB70AQuickGuideEN.indd8IK-WB70AQuickGuideEN.indd8 2009/04/1014:25:202009/04/1014:25:20

9
NOTESONUSEANDINSTALLATION
･ Donotaimthecameraatthesun
Neveraimthecameraatthesunevenwiththecamerapoweroff.
･ Donotshootintenselight
Intense light such as a spotlight may cause a bloom or smear. A
vertical stripe may appear on the screen. However, this is not a
malfunction.
･ Treatthecamerawithcare
Droppingorsubjectingthecameratointensevibrationmaycauseit
tomalfunction.
･ Nevertouchinternalparts
Do not touch the internal parts of the camera other than the parts
specified.
･ Donotsubmergeinwater
Thecamerahassomeprotectiontowater(seeIPrating),andcanbe
usedindoorsoroutdoors.
Ifthecamerawassubmergedinwater,turnoffthepowerandcontact
yourdealer.
･ Keepthecamerainstallationawayfromvideonoise
IfcablesarewirednearelectriclightingwiresoraTVset,noisemay
appearinimages.Inthiseventrelocatecablesorreinstallequipment.
･ Checktheambienttemperatureandhumidity
Avoid using the camera where the temperature is hotter or colder
thanthespecifiedoperatingrange.Doingsocouldaffecttheinternal
partsor causethe imagequality todeteriorate.Specialcareis
requiredtousethecameraathightemperatureandhumidity.
･ Shouldyounoticeanytrouble
If any trouble occurs while you are using the camera, turn off the
power and contact your dealer. If you continue to use the camera
whenthereissomethingwrongwithit,thetroublemaygetworseand
anunpredictableproblemmayoccur.
IK-WB70AQuickGuideEN.indd9IK-WB70AQuickGuideEN.indd9 2009/04/1014:25:202009/04/1014:25:20

10
SettingNetworkCameraEnvironment
Itemsneededfornetworkcameramonitoringsystem
●Administrator'spersonalcomputer
Thepersonalcomputerthatisgivenallauthoritiesforsetting,
operating,monitoringandotherfunctionswiththenetworkcamerais
calledthe"administrator'spersonalcomputer"inthisguide.
* Thepersonalcomputerforviewingmonitoredimagesiscalledthe
"user'spersonalcomputer"inthisquickstartguide.Thenetwork
cameracanbeviewedbymorethanonepersonalcomputeratthe
sametime.
Recommendedpersonalcomputersystemrequirements:
･ WindowsXPorVistaBusiness
･ InternetExplorerVer6.0or7.0
･ CPU:IntelPentium41.7GHzorhigher
･ Memory:XP=256MBormore,Vista=1GBormore
●ConnectionequipmentsuchasEthernetcables,andhuborrouter.
･ TheLANcabletypediffersdependingontheconnectionmethod.
●Camerasearchapplication"InstallationWizard"
･ InstallthisapplicationfromtheCD-ROMsuppliedasanaccessory.
 (Double-click"Setup.exe"intheCD-ROMandinstalltheapplication
byfollowingtheonscreeninstructions.)
IK-WB70AQuickGuideEN.indd10IK-WB70AQuickGuideEN.indd10 2009/04/1014:25:202009/04/1014:25:20

11
●IK-WB70A ●Shade
●Screws/RJ45female/female
coupler
●Mountingbracket
Unused
●ACadapter ●Silicagel/Wrench
●I/OConnectors ●QuickStartGuideand
ImportantSafeguards
●Warranty ●CD-ROM
IK-WB70A
Contents
TheaboveURLissubjecttochangewithoutpriornotice.
IftheURLchanges,refertotheToshibawebsite(http://www.toshiba.com).
NETWORKCAMERA
Model: IK-WB70A
QuickStartGuideandImportantSafeguards
Thisguidedescribesthehardwareinstallation.
TheapplicationAdobe Readeris neededtosee PDFfiles. Ifyoudo nothave
thisapplication,downloaditfromtheWebsiteofAdobeSystemsIncorporated.
Referthe user's manual (PDFfile) contained in the CD-ROM forsettings,
operationsandotherinformation.
Forinformation on our latest products and peripheral devices,refer to the
followingWebsite:
■ http://www.toshibasecurity.com
IK-WB70AQuickGuideEN.indd11IK-WB70AQuickGuideEN.indd11 2009/04/1014:25:202009/04/1014:25:20

12
PhysicalDescription
● Frontpanel
IR LED
Lens
Reset button
Status LED
Illuminance sensor
● Connectors
Ethernet 10/100 RJ45 plug
Audio output (green) mini-jack
Microphone input (pink) mini-jack
Power cord socket (black)
General I/O terminal block
GND
Cablelength:approx.39inches(1000mm)
IK-WB70AQuickGuideEN.indd12IK-WB70AQuickGuideEN.indd12 2009/04/1014:25:222009/04/1014:25:22

13
HardwareInstallation(1)
FollowthestepsbelowtomounttheNetworkCamera:
1.Drillfourpilotholes(Φ0.31inchX1.5inches(D)(Φ8mmX38mm
(D)))tofitintheholesoftheMountingBracket.
●Hammerthesuppliedplasticanchorsintotheholes.
●AlignthefourholesoftheMountingBracketwiththefourplastic
anchors;insertthesuppliedscrewswithMountingBracketto
correspondingholes.
2.Removethelenscoverbyrotatingitcounterclockwise.Recordthe
MACnumberonthesideofthecameralensforuseinsettingupthe
networkcamera.
3.InstallthecameratotheMountingBracket,secureusingascrew
driver.
4.Runthecontrolcablethroughthewallorintothewaterproofjunction
box.
Note:
● Theattachedscrewsandanchorsareusedtoinstallthecamerato
asolidsurface.(e.g.concrete)Ifinstallingtolooseorthinmaterial
surfaces,usetheappropriateanchors(notincluded)withthescrews.
●Ifinstallingtotheceiling,usetheappropriatebracket(notsupplied).
●Ifinstallingtohighlocations,becarefulnottofallthecameracausing
injuryanddamage.

34
Mounting bracket
1
0.9 (23)
0.29 (7.3)
2.32 (59)
0.9 (23)
0.28 (7)
0.28 (7)
0.28 (7)
0.28 (7)
2
IK-WB70AQuickGuideEN.indd13IK-WB70AQuickGuideEN.indd13 2009/04/1014:25:222009/04/1014:25:22

14
GeneralConnection(withoutPoE)
1.Ifyouhaveexternaldevicessuchassensorsandalarms,make
connectionsfromgeneralI/OterminalblockbythesuppliedI/O
connectors.
 Inserttheexternalsensor'scablestotheconnectorandfastenthe
suppliedscrews.
2.UsethesuppliedRJ45female/femalecouplertoconnectthe
NetworkCameratoahub.
 UseCategory5CrossCablewhenNetworkCameraisdirectly
connectedtoPC.
3.ConnectthesuppliedACadapter.
Powerinput
ConnectthepoweradapterofthesuppliedACadapter,24VACUL
ListedClass2powersupply,orPoEhub.
ConnectthepoweradapterjacktotheNetworkCamerabefore
pluggingintothepowersocket.Thiswillreducetheriskof
accidentalelectricshock.
NetworkDeployment
POWER COLLISION
LINK
RECEIVE
PARTITION
12345
Ethernet hub
(not supplied)
RJ45 female/
female coupler
To AC outlet
Cable length:
approx. 39 inches (1000mm)
N.C. : No connection
485B : RS485-
485A : RS485+
AC24V : Power in 24 VAC
AC24V : Power in 24 VAC
GND :
DI :
DO :
Ground
Digital Input
Digital Output
+12V : 12 VDC Output
N.C.
485B
485A
AC24V
AC24V
GND
DI
DO
+12V
Therecommendedpower
suppliesforthiscameraare10
wattminimumfor24VACUL
ListedClass2powersupply.
Andtherecommendedpower
cordistwistedpairlinewitha
minimumwiresizeof18AWG.
IK-WB70AQuickGuideEN.indd14IK-WB70AQuickGuideEN.indd14 2009/04/1014:25:232009/04/1014:25:23

15
PoweroverEthernet(PoE)
●WhenusingaPoEhub
TheNetworkCameraisPoE-compliant,allowing
transmissionofpoweranddatatobothruninasingleEthernetcable.
SeethefollowingillustrationtoconnecttheNetwork
CameratoaPoEhubviaEthernetcable.
●Whenusinganon-PoEhub
UseaPoEpowerinjectortoconnectbetweentheNetworkCamera
andanon-PoEhub.
POWERCOLLISION
LINK
RECEIVE
PARTITION
12345
PoE hub
(not supplied)
POWERCOLLISION
LINK
RECEIVE
PARTITION
12345
non-PoE hub
PoE power injector
(not supplied) (not supplied)
IK-WB70AQuickGuideEN.indd15IK-WB70AQuickGuideEN.indd15 2009/04/1014:25:242009/04/1014:25:24

16
AssigningIPAddress
1.Installthe"InstallationWizard"undertheSoftwareUtilitydirectory
fromCD-ROM.
2.Theprogramwillconductanalysesonyournetworkenvironment.
Afteryournetworkisanalyzed,pleaseclickonthe"Next"buttonto
continuetheprogram.
3.TheprogramsearchesforotherNetworkCamerasonthesameLAN.
4.Aftersearching,themaininstallerwindowwillpopup.Clickonthe
MACthatmatchestheonelabeledonthesideofthecameralensto
connecttheInternetExplorertotheNetworkCamera.

0002D1714270
0002D1714270
Installation
Wizard
NOTE
● If"InstallationWizard"doesnotperformnormallyorthecameracannotbefound
during the search even though the camera and a PC are connected correctly,
pleaseswitchoffthewirelessLANofaPC.
● InstallationWizardcansearchthelocationoftheNetworkCameraeventhough
DHCPisnotusedonthenetwork.
 ReassignthestaticIPaddressbecauseIPaddressoftheNetworkCamerahas
beenset169.254.*.*bydefault.
IK-WB70AQuickGuideEN.indd16IK-WB70AQuickGuideEN.indd16 2009/04/1014:25:242009/04/1014:25:24

17
RetrievingImages
1.AccesstotheNetworkCamerafromtheLAN.
2.RetrievelivevideothroughInternetExplorer
®
.
Formoreinformationoncameraconfiguration,pleasereferto
user'smanualontheCD-ROM.
IK-WB70AQuickGuideEN.indd17IK-WB70AQuickGuideEN.indd17 2009/04/1014:25:262009/04/1014:25:26

18
AdjustingtheLens
UsetheliveimageretrievedfromtheNetworkCameratomakethelens
adjustments.
Toadjustthezoomfactorandfocusrange
1.Positionthecamerapanandtilttothedesireddirection.
2.Toadjustthezoomfactorloosenthezoomcontrollerscrewbyturning
itcounterclockwisetounlockthezoomring,rotatethezoomring
clockwiseorcounterclockwisetothedesiredposition.
 Turnthezoomcontrolscrewclockwisetolockthezoomring,take
CAUTIONnottoovertightenthecontrolscrew.
3.Toadjustthefocusrangeloosenthefocuscontrollerscrewby
turningitcounterclockwise,rotatethefocusringclockwiseor
counterclockwisetothedesiredposition.
 Turnthefocuscontrolscrewclockwisetolockthefocusring,take
CAUTIONnottoovertightenthecontrolscrew.

T
W
∞
W
∞
NT
Tighten Loosen
CAUTION:Donotovertightenthe
controlscrews.
Doingsocandamagethestructure
ofcameralens.
IK-WB70AQuickGuideEN.indd18IK-WB70AQuickGuideEN.indd18 2009/04/1014:25:262009/04/1014:25:26

19
1.Removethesilicagelfromthealuminumfoilbag.Attachthesilica
gelpackagetotheinsideofNetworkCamera.Refertoimage1.
2.ReinstalltheNetworkCameralensbyrotatingitclockwiseonthe
camera.Tightenthelensontothecameratoseattheseal.Referto
image2.

Treatsilicagelbagwithenoughcare.
Donottearthesilicagelpackage
whenreinstallingthelenscover.
Silica gel
12
3.Ifthecameraisplacedoutdoorsinstalltheshadefollowingthesteps
below:
3-1.Installtheshademountingscrewsonthecamerabody.Referto
image1.
3-2.AttachtheShadetotheNetworkCameraandlooselyinstallthe
twoshaderetainingscrewsandwashers.Refertoimage2.
3-3.MovetheShadetothedesiredlocationandtightentheshade
retainingscrews.Refertoimage3.
123
HardwareInstallation(2)
IK-WB70AQuickGuideEN.indd19IK-WB70AQuickGuideEN.indd19 2009/04/1014:25:282009/04/1014:25:28

TOSHIBA AMERICA INFORMATION SYSTEMS, INC.
Surveillance & IP Video Products
9740 Irvine Boulevard,
Irvine, CA 92618-1697
Phone Number: [phone]
IK-WB70AQuickGuideEN.indd20IK-WB70AQuickGuideEN.indd20 2009/04/1014:25:332009/04/1014:25:33
