Tosot GJC08BU-A6NRNJ2A User manual

User Manual
Window Air Conditioner
Before using your TOSOT Window Air Conditioner
please read this user manual in its entirety.
MO DEL NUMB ERS
8,000 BTU-GJC08BU-A6NRNJ2A

Welcome to the TOSOT Direct Family!
We’re extremely happy to welcome you as a new member of our family! Please read
the tips below before using your product for the first time.
1. Allow the unit to sit upright for at least 3-4 hours before powering on. Shipping
carriers may set the unit on its side, which causes the refrigerant to pool in certain
areas. Standing the unit upright for 3-4 hours allows the refrigerant to move freely
within the coils.
2. Run the unit continuously for 24 hours after letting the unit stand upright for 3-4
hours. This allows the unit to work out any “kinks’ that may have resulted during
shipping from our factory or to your doorstep.
3. For more details and quick start guide about installation, please contact
[email protected] .
4. If you have any other questions, please email us at [email protected]
before making a return request. Our support team typically replies within 24 hours,
usually sooner. If you haven’t received a reply, please check your spam or junk
folder as sometimes our replies get lost in customer’s inboxes!
Tips for First-Time Use
Warranty Information
1. All TOSOT products come with a 1-year warranty from the date of purchase.
2. You can get a 6-month warranty extension by registering your new product at
www.tosotdirect.com/extend .

Table of Contents
Safety and Instructions
Installation and Setup
Operation
Electrical Information
Parts
Control Panel
Remote Control
Replacing the Batteries
Changing the Wind Direction
Installation
Tools Required List
Window Requirements
Installation Procedure
Adding Foam to Accordion Panels
Proposition 65 Notice
Cleaning
Maintenance Checklists
Troubleshooting
Malfunction Codes
01
01
02
03
04
05
07
09
10
11
11
12
12
16
17
17
19
20
21
-------------------------------------
-------------------------------------
---------------------------------------------------
-------------------------------------
-----------------------------------------------------------
------------------------------
-----------------------------------------------
--------------------------------------------
-----------------------------------
----------------------------------------------------
-------------------------------------------------------
------------------------------------
----------------------------------------------
-------------------------------------------
----------------------------------------
------------------------------------
------------------------------------
---------------------
-------------------------------------

Safety and Instructions
01
Installation and Setup
Please read all instructions before use and save this user manual for future reference.
A digital version can be obtained by emailing us at
[email protected] .
Your safety and the safety of others are very important to us. We have provided many
important safety messages throughout this manual and on the appliance itself. Always
read and follow all posted safety messages. If you have any doubts, please contact
[email protected] with any questions.
To reduce the risk of fire, electric shock, injury, or death to persons using or near this
appliance, please follow some basic safety precautions. These precautions include,
but are not limited to, the following:
● This appliance is not intended for use by any persons (including children) with
reduced or restricted physical, mental, or sensory capabilities, or lack of experience
and knowledge, unless under direct supervision of a person responsible for their
safety.
● Please keep plastic bags and sheets out of the reach of children as they might be
mistakenly used for play. Packaging materials can become airtight chambers and
may pose a risk of suffocation if not disposed of properly.
● This product should be plugged directly into a power outlet. Power outlet should
be properly rated, protected, and sized in order to avoid electrical overload.
Do not use a multiple-outlet power strip or extension cord with this window
air conditioner.
Failure to do so may result in short-circuit or electrical shock.
● Do not cut or remove the third (ground) prong from the power cord under any
circumstances.
● When installing or moving the appliance, be careful not to punch, crush, or damage
the power cord.
● Never attempt to operate this appliance if it visibly damaged, malfunctioning,
disassembled, or has missing or broken parts. This includes exposed wiring on a
damaged cord or electrical plugin.
● Do not attempt to disassemble or repair and part of this appliance. All repairs and
services must be performed by qualified service personnel.

02
● Use caution when unpacking and installing as the sharp edges of the unit may
cause personal injury.
● It is recommended that two people install and setup the air conditioner to avoid the
unit falling out of window.
● Chemicals and other solvents which are dissolved in the air (e.g. cleaning products,
hair spray, air fresheners, perfumes, etc.) may cause the product to deform and
become damaged.
● Installation must be performed in accordance with national wiring standards by
authorized and trained personnel only.
● The outdoor operating temperature range for this unit is 64°F - 104°F (18°C-40°C).
Operating this air conditioner outside of this temperature range may cause damage
to your air conditioner.
Operation
● To avoid risk of electrical shock, do not grasp the power cord or the unit with wet
hands and avoid placing the product where it could be splashed with water.
● Avoid placing the unit itself or any other objects on top of the power cord, including
rugs or carpeting.
● Keep air inlet/outlets free from obstruction and clean the filter regularly to ensure
optimal and safe performance.
● Do not insert fingers or other objects into the air inlet our outlet. Not only is the
internal fan running at high speeds, there is also an increased risk of deadly
electrical shock.
● Remove the power plug from the wall outlet if the product will not be used for
extended periods.
● If the product makes a strange noise or emits a strange or smoky smell, immediately
remove the power plug and contact customer service for next steps.
● Turn off the product and remove the power plug before cleaning or maintenance.
Wait for the fan to stop moving.
● Do not attempt to accelerate the defrosting process other than using instructions
contained in this user manual, as this may damage your unit.

03
● No open fire (e.g. electrical heater or gas stove) should be used on or near the
appliance.
● Do not direct airflow directly at room occupants, pets, or plants, as this may
negatively impact health.
● Do not use the air conditioner for special use purposes; such as the preservation
of precision devices, food, plants, or other irreplaceable objects as it might cause
deterioration of quality.
● Always insert filters securely and clean filters every 2 weeks for optimal performance.
● Do not drink water drained from the air conditioner as this may contain contaminants
which will make you ill.
Electrical Information
The power supply cord with this air conditioner contains a current detection device
designed to reduce the risk of fire. In the event that the power supply cord is damaged,
it cannot be repaired. The power supply cord must be replaced with a replacement
cord received from the manufacturer by a trained service technician. Please contact
[email protected] for further details.
● Please ensure that the electrical service in your home is adequate for the model
you have chosen. This information can be found on the serial plate, which is located
on the side of the unit behind the air intake grille.
● Your air conditioner must be used in a properly grounded wall receptacle. If the
wall receptacle you intend to use is not adequately grounded or protected by a time
delay fuse or circuit breaker, have a qualified electrician install the proper wall power
receptacle before using this appliance.
● Be sure that the air conditioner is properly grounded. To minimize shock and fire
hazards, proper grounding is important. The power cord is equipped with a three-
prong grounding plug for protection against shock hazards.
● Do not run the air conditioner without the white plastic shell in place. This could
result in mechanical damage within the air conditioner.
● Do
not use an extension cord or adapter plug with this air conditioner under any
circumstances
.

04
To test your power supply cord please do the following:
1. Plug in the air conditioner.
2. The power supply cord will have two buttons
on the plug head. If you press the
TEST
button you should notice a clicking noise as
the
RESET button pops out.
3. Press the RESET button again, and you will
notice a clicking noise as the button engages.
4. The power supply cord is now supplying
electricity to the unit.
Parts
● Do not use the power supply cord to turn the unit on or off
● Always make sure the RESET button is pushed in for correct operation
● The power supply must be replaced if it fails to reset when either the TEST button
is pushed, or it cannot be reset. Please contact
[email protected] for
more information.
Air outlet
Air intake
Power cord
Fan direction
adjusting rod
Control panel

05
Control Panel
1
5 4 3 2 1
1On/Off button
2Fan button
3+ / -button
4Mode button
5Timer button
Cool mode Dual-8 display Fahrenheit unit
Dry mode
Energy Save
mode
mode
Filter cleaning
mode
Fan Only mode
Auto mode
Low speed
indicator Medium speed indicator High speed indicator Auto speed indicator
NOTICE: “ ” when fan has operated for 250h accumulatively, filter cleaning icon is on to remind user for
cleaning filter; when filter cleaning icon is on (fan has operated for 250h accumulatively), Press and
hold “Time” button and “-” button simultaneously for 3s to clear accumulative operation time of filter and
then filter cleaning icon is off.
Press to power the air conditioner ON or OFF . When turning the unit on via the
control panel, the unit will operate in
Energy Saving mode until you change the
operating mode using the
Mode button.
ON/OFF Button

06
2
Pressing this button will cycle the fan speed through one of 4 fan modes, as shown
below:
Fan Button
4
Pressing this button will cycle through one of the 5 function modes, as shown below:
Mode Button
5
When the unit is running, press this button to schedule when the unit will power off
by using the +/- button to adjust the length of time before powering off. When the
unit is not running, press this button to schedule when the unit will power on by using
the +/- button to adjust the length of time before powering on.
Timer Button
3
● Pressing this button will allow you to change the temperature setting. Holding
either button will increase or decrease automatically. It will take 3 seconds for the
temperature settings to be confirmed by the machine.
● After pressing the timer button, the +/- buttons will adjust the timer setting from
0.5-24 hours in 0.5-hour increments. After the 10-hour mark, the +/- button will
adjust the timer setting in 1-hour increments. It will take 5 seconds for the timer
settings to be confirmed by the machine.
+/- Button
AUTO LOW MED HIGH
Save
nergy DRY FAN
AUTO COOL E

07
1
Press to power the air conditioner ON or OFF . The unit will start in Energy Saving
mode after first being powered on. When the unit is powered off the set temperature
will be saved until the unit is powered back on. In the event of a power outage, the
unit will return to the last saved settings before the unit lost power.
ON/OFF Button
2
Press this button to cycle through the five operating modes. A corresponding logo
indicator on the left side of the remote will be shown.
Mode Button
Remote Control
This is a universal remote control for a variety of models. If your model does not
have a function listed on the remote control, there will be no changes in the operation
of your unit. The max range of the remote control is approx. 25 feet with no obstacles
or interference from other devices, such as wireless phones or fluorescent lamps.
Cool Dry Auto Energy
Saver
Fan
Only Heat
(Only for models
with heating function.)
● Auto mode: the air conditioner will operate according to ex-factory setting. The set
temperature cannot be adjusted.

08
● Cool mode: standard cooling mode. The set temperature and fan speed can both
be adjusted.
●Energy Saving mode: an automatic mode to save on energy costs. The set
temperature cannot be adjusted. The fan speed can be adjusted.
●Dry mode: the unit will run on low speed for dehumidification. The fan speed
cannot be adjusted.
●Fan Only mode: the air conditioner will not produce cool air, only blow air from the
outside. The fan speed can be adjusted, but you cannot use the “Auto” fan speed
setting.
6
Press this button to enter the sleep operation mode. While in sleep mode, you can
only use the Cool, Energy Saving, or Dry modes. When in sleep mode, the AC
temperature will automatically increase by 2°F per hour up to 86°F.
Sleep Button
3
● Pressing the “+” or “-” button will increase/decrease the set temperature by 1°F.
Release the button once your desired temperature is reached.
● After pressing the Timer button, each press of the +/- button will increase/decrease
the time by 0.5 hours. Release the button once your desired time setting has been
reached.
+/- Button
4
Press this button to turn the swing feature on or off. When on, the air flow will swing
back and forth vertically.
Note: Swing button is not available for this model.
Swing Button
5
Press this button to cycle through the Auto mode and 3 fan speeds (Low, Medium,
High)
Fan Button
Auto
Speed 1 Speed 2 Speed 3

09
7
When the unit is running, press this button to schedule when the unit will power off
by using the +/- button to adjust the length of time before powering off. When the unit
is not running, press this button to schedule when the unit will power on by using the
+/- button to adjust the length of time before powering on. Press the timer button a
second time to confirm the timer setting. If you have confirmed a time setting, you can
press this button again to cancel the timer mode.
Timer Button
8
Pressing this button will use a sensor located in the remote control to determine the
temperature setting of your air conditioner. The remote controller will send a
temperature update to the air conditioner every 10 minutes for better accuracy in
your room. If the air conditioner does not receive an update from the remote control
after 11 minutes, it will revert to using a sensor on the air conditioner itself to adjust
the temperature settings. In the case of a power outage, this setting will not be saved.
You will need to manually reset the I Feel mode after a power outage.
“I Feel” Button
9
Press this button to turn off the lights on the display panel of your air conditioner.
Press the button again to turn the light back on.
Notice: Change Between °F and °C
With the remote powered off, press the Mode and “-“ buttons simultaneously to switch
between Fahrenheit and Celsius displays.
Light Button
Replacing the Batteries
1. Press the back side of the remote
control battery cover and slide out
following the engraved arrow.
2. Replace with two new AAA (1.5V)
batteries of the same make and
model. Make sure the polarities
(+ & -) are aligned correctly.
3. Reinstall the battery cover box.

10
Changing the Wind Direction
Move the adjusting rod with your fingers to change the wind direction from left to right.
Move the adjusting air outlet frame to change the window direction from up to down.
Fan direction adjusting rod
Air outlet frame

11
Installation
Tools Required
Phillips-head screwdriver Flat-blade screwdriver
Level
Scissors or knife Pencil Ruler or tape measure
Spare parts list Tools
Air conditioner
Top mounting rail
Window sill and sash seal (2)
Accordion panel seal (2)
Left and right accordion panel
Foam top window gasket Top mounting rail seal strip
screws(4)
Window locking
bracket
Remote controller Batteries User Manual Type A
screws(6)
Type B Lock frame(2)
(For wooden windows)
Foam Insulation (2)
+
-

12
Window Requirements
The instructions outlined below are for standard, vertical-sliding windows. If you have
a different window type (e.g. horizontal-sliding window) you may need to choose a
different window or use a different installation procedure.
If you are installing this air conditioner in a smaller window, you may not need the
accordion subassembly. Please refer to the window size requirements for more details.
In some cases, you may need to put a small wooden block under the air conditioner
to ensure that the unit is not tilting towards the inside of your home. If the unit is tilted
towards the inside of your home, water may drain into your home and damage the
window frame, wall, or flooring. A slight angle of 5° is all it takes to ensure that water
does not drain into your home.
13.5”min
25”to 36”
8,000 BTU minimum width: 25’’
8,000 BTU maximum width: 36”
8,000 BTU minimum height: 13.5”
Installation Procedure
Step 1: Install the top mounting rail
1. Remove the adhesive from the top mounting rail seal strip. Align strip to the four (4)
holes and stick to the side of the mounting rail which attaches to your air conditioner.

13
2. Use four (4) included Type A screws to fix the top mounting rail to the outer case
of the air conditioner. The flat edge with a single hole in the middle should be
closest to you.
Step 2: Install accordion panels
1. Remove the accordion panel seal from the paper backing. With the LEFT and
RIGHT text visible, apply the panel seal as shown in the figure below.
2. With the LEFT and RIGHT text facing towards you, pull the accordion panel towards
the unit. Align the end of the accordion panel with plastic groove on the unit and
slide to bottom. Slide the plastic framing of the accordion panel into the top mounting
rail and the lower guide rail.
top mounting rail
lower guide rails
accordion panel

14
Step 3: Attach the window sill seal and sash seals
1. Cut the window sill and sash seal strips to proper length. Tear off the paper backing
and stick to the lowest part of the window sill. Repeat for the top of sliding window.
Window sill and sash seal
Step 4: Install the air conditioner unit
1. With two people, align the lower guide rail to the edge of the window sill. After
placing, close the window so that the top mounting rail is aligned with the inside
edge of the window.
Top mounting rail
Window
frame
Horizontal or inclined
about 3°
Lower
guide rail
2. Unfold the accordion panels from both sides. Use five (5) included Type B screws
to fix the frame of the accordion panel to the window frame and window sill. There
are three (3) pre-drilled holes on the top. Use the two (2) included frame locking
brackets to secure the bottom of the accordion panel to the window sill.

15
Window frame
windowsill
Step 5: Install the window locking bracket
1. To keep the unit from falling out the window, secure the window locking bracket
once the window is resting against the top mounting rail.
Plastic
window
window
Wooden
Step 6: Plug the gap of the top window with foam
1. Cut foam top window gasket to the proper length. Use this to plug the gap between
the windows to prevent rain or insects from getting into the room.
Foam top
window gasket

16
Adding Foam to Accordion Panels
1. After completing installation of your unit, measure the length between the air
conditioner and the edge of the window frame.
LL
2. Cut the included foam insulation to length.
LL
3. Place the foam insulation along the accordion panel. If there is any excess foam,
it can be tucked into the frame or trimmed off with scissors.

17
Cleaning
Proposition 65 Notice
California Safe Drinking Water and Toxic Enforcement Act of 1986 requires us to
notify customers that this product contains chemicals known to the State of California
to cause cancer and birth defects or other reproductive harm. Please wash your
hands after finishing installation of this product.
To avoid electric shock, turn off the air conditioner and disconnect from power before
cleaning. Do not wash or douse the air conditioner with water. Do not use volatile
liquids to clean the air conditioner.
Cleaning the filter
1. Open the front panel
Locate the groove on either side of the front panel and pull towards you as shown in
the figure on the right. Some force may be required.
