Toto Connelly TL221DD12 Installation instructions

Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
[phone] or [phone] when calling from outside of U.S.A.
Installation and Owner’s Manual
Manual de Instrucciones y del Propietario
Manuel d’Installation et d’Utilisation
Widespread Lavatory Faucet
Grifo Mezclador Ensamble 8” para Lavabo
Robinet Mélangeur de Lavabo
Connelly™
TL221DD
TL221DD12

2
ENGLISH
TABLE OF CONTENTS
WARNINGS
THANK YOU FOR CHOOSING TOTO!
CARE & CLEANING
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thank You for Choosing TOTO! ........................................................................ 2
Care And Cleaning .............................................................................................. 2
Warnings............................................................................................................... 2
Common Tools Needed...................................................................................... 3
Before Installation................................................................................................ 3
Included Parts ...................................................................................................... 3
Installation Procedure.......................................................................................4-6
Warranty................................................................................................................ 7
Rough-In Dimensions ....................................................................................... 20
Your new faucet is designed for years of trouble-free performance. Keep it
looking new by cleaning it periodically with mild soap, rinsing thoroughly with
warm water and drying with a clean, soft cloth. Do not use abrasive cleaners,
steel wool or harsh chemicals, as these will dull the finish. Failure to follow
these instructions may void your warranty.
For safe operation of the faucet, please observe the following:
Operating Pressure:
Minimum Pressure ……………..20 psi (0.14 MPa), dynamic
Maximum Pressure …………….80 psi (0.55 MPa), static
Do not use the product at an ambient temperature below 32 ºF (0 ºC).

3
ENGLISH
COMMON TOOLS NEEDED
BEFORE INSTALLATION
INCLUDED PARTS
Adjustable Wrench Screwdriver
Drain Assembly Spout Assembly Handle Lever
(2X)
Spout Mounting
Hardware
Valve Hardware Set
(2X)
2.5mm Hex Key Valve Assembly
(2X)
Drain Lift Rod
Observe all local plumbing codes.
Make sure the water supply is shut off.
Read these instructions carefully to ensure proper installation.
TOTO reserves the right to update product design without notice.
Check to make sure you have the following parts indicated below:

4
ENGLISH
INSTALLATION PROCEDURE - Valves
2. Pass the valve up through the
installation hole.
Secure with mount collar until hand
tight, ensure O-ring is seated in
groove under collar.
3. Fixate the valve by threading the
mounting nut up the valve until hand
tight. Tighten the retaining screws
equally to secure.
Do not overtighten!
4. Repeat steps 1-3 for remaining valve.
NOTE: Hoses to connect valve inlets to water supply lines not included.
INSTALLATION PROCEDURE - Spout
5. Ensure O-ring is seated in groove
under sprout.
Pass the supply hoses and
mounting stud through the
mounting hole until the spout
comes to rest.
Spout
O-ring
Collar
Mounting
Screws
O-ring
Washer
(Metal)
Mounting
Nut
Gasket
(Rubber)
Collar
Gasket
Mounting
Screws
1. Thread a mounting nut to the bottom
of the valve. Place a washer and gasket
as shown.
NOTE: the hot water valve has a red
marking on side of body.
Gasket
(Rubber)
Washer
(Metal)
Mounting
Nut

5
ENGLISH
6. Orient the spout as needed. From
below the mounting surface, place
the crescent shaped gasket and
washer over the mounting stud as
shown.
Fasten the mounting nut to the
stud to secure the spout.
Tighten with wrench as needed.
7. Connect each hose to the side port
of each valve. Tighten with wrench.
NOTE: If wrapping the hose(s) in
a loop is needed, be careful not to
crimp the hose at any point as this
could restrict the water flow.
INSTALLATION PROCEDURE - Handles
8. Orient handle assembly and lower
onto the exposed portion of valve
until engaged. Secure with set screw.
Overtightening set screw will cause
handle to bind.
Repeat for other handle assembly.
NOTE: If handles do not line up exactly
as desired, remove handle from valve
and reinstall one (1) notch over (on valve).
Fine adjustment may be done by slightly
rotating valve from underneath installed
surface.
9. Insert the drain lift rod through the
opening in the spout. Drain Lift Rod
Valve
Handle Assembly*
Hex
Key
Set Screws
INSTALLATION PROCEDURE - Spout
Washer (Metal)
Gasket (Rubber)
Mounting Nut
Mounting Stud
Mounting Stud
Gasket (rubber)
Washer (metal)
Mounting Nut
