Toto TRANSITIONAL A Series Installation instructions

Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
[phone] or [phone] when calling from outside of U.S.A.
Installation and Owner’s Manual
Manual de Instrucciones y del Propietrario
Manuel D’Installation et D’Utilisation
Showerhead and Arm
Ducha Fija y Brazo
Pomme de Douche et Bras
TRANSITIONAL COLLECTION
SERIES A
TRADITIONAL COLLECTION
SERIES A
TS200N6 TS300N6
TS200A(L)51
TS200A(L)55
TS200A(L)61
TS200A(L)65
TS300A(L)51
TS300A(L)55
TS300A(L)61
TS300A(L)65

3
ENGLISH
TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO! .............................................................................. 3
Care & Cleaning ................................................................................................... 3
Warnings ............................................................................................................... 3
Common Tools Needed ...................................................................................... 3
Before Installation ................................................................................................ 4
Installation Procedure .......................................................................................... 4
Warranty................................................................................................................ 5
Rough-In Dimensions ..................................................................................12-13
Replacement Parts ............................................................................................. 15
WARNINGS
For safe operation, please observe the following:
Recommended operating pressure:
Minimum pressure.........20 psi (0.14 MPa), dynamic
Maximum pressure........80 psi (0.55 MPa), static
Hot water supply temperature must not exceed 160°F (71°C).
Do not use steam for hot water supply.
Do not use the product at an ambient temperature below 32°F (0°C).
CARE & CLEANING
Your new showerhead is designed for years of trouble-free performance. Keep
it looking new by cleaning it periodically with mild soap, rinsing thoroughly
with warm water and drying with a clean, soft cloth. Do not use abrasive
cleaners, steel wool or harsh chemicals, as these will dull the finish. Failure
to follow these instructions may void your warranty. If any nozzles become
clogged with mineral build up, rub gently with finger tips to clean.
COMMON TOOLS NEEDED
Adjustable Wrench
Pipe Tape

4
ENGLISH
INSTALLATION PROCEDURE
NO TE: Thoroughly clean and remove debris from the water supply pipe
before installation to prevent clogging the spray outlet.
NOTE: Do NOT twist showerhead to install shower arm.
• Slide escutcheon onto the shower arm.
• Wrap the shower arm threads with pipe tape. Screw the shower arm into
the supply elbow.
• Ensure the gasket/sieve is in the pivot ball before installation.
• Thread the showerhead onto the shower arm by hand.
• Use an adjustable wrench to tighten the showerhead to the shower arm
firmly enough to seat the gasket and prevent leaking.
BEFORE INSTALLATION
Observe all local plumbing codes.
Make sure the water supply is shut off.
Read these instructions carefully to ensure proper installation.
TOTO reserves the right to update product design without notice.
Showerhead
Assembly
Gasket / Sieve
Escutcheon
Pipe Tape
Finished wall
Shower Arm

12
ROUGH-IN DIMENSIONS / DIMENSIONES PRELIMINARES /
DIMENSIONS BRUTE
Transitional
TS200N6
Traditional
TS300N6
2-1/4" 58mm
5-7/8" 150mm
3-1/8" 80mm
1/2” NPT
1/2” NPT
2-1/4" 58mm
5-7/8" 150mm
3-1/8" 80mm
1/2” NPT
1/2” NPT

13
ROUGH-IN DIMENSIONS / DIMENSIONES PRELIMINARES /
DIMENSIONS BRUTE
4-7/16" 112mm
3-5/16" 84mm
G 1/2"
5-3/8" 136mm
3-3/8" 85mm
G 1/2"
4-3/8" 111mm
3-3/8" 85mm
G 1/2"
3-3/8" 85mm
5-5/16" 135mm
G 1/2"
Transitional 4.5”
TS200A(L)51
TS200A(L)55
Traditional 4.5”
TS300A(L)51
TS300A(L)55
Traditional 5.5”
TS300A(L)61
TS300A(L)65
Transitional 5.5”
TS200A(L)61
TS200A(L)65

15
REPLACEMENT PARTS / PIEZAS DE REPUESTO /
PIÈCES DE RECHANGE
No. Description Descripción Description
1 Gasket / Sieve Junta / Colador Joint / Passoire
1
