Touchstone WLGN8740 User manual

RECESSED ELECTRIC FIREPLACE HEATER
Model # : WLGN8740, 86274
OWNER’S MANUAL
50” / 60”
Recessed Electric Fireplace
AC 110-120V 60Hz 1500W
WARNING
Read and understand this entire owner’s manual, including all safety
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
CAUTION
Keep this owner’s manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.

Recessed Electric Fireplace
rev: 20220427
2

Recessed Electric Fireplace
rev: 20220427
3
Table of Contents
Table of Contents
General Information................................................................................................................................................... 4
Fireplace Specifications............................................................................................................................................ 5
ETL Approval Listing Information ........................................................................................................................... 5
Dimensional Drawing............................................................................................................................................... 6
WLGN8740 –50” Recessed Electric Fireplace.................................................................................................... 6
86274 –60” Recessed Electric Fireplace.............................................................................................................. 7
Unpacking Your Fireplace......................................................................................................................................... 8
Parts and Hardware ................................................................................................................................................. 8
Tools Required...................................................................................................................................................... 8
What’s in the Box ................................................................................................................................................. 8
Unpacking and Setup................................................................................................................................................ 8
Unpacking Instructions:........................................................................................................................................ 8
Wiring ....................................................................................................................................................................... 9
Testing the Fireplace Prior to Installation............................................................................................................. 9
3-prong Outlet Installation.................................................................................................................................... 9
Hard Wire Connection........................................................................................................................................ 10
Installation................................................................................................................................................................. 11
WARNINGS....................................................................................................................................................... 11
Choosing Installation Location............................................................................................................................... 11
Removing The Glass Panel..................................................................................................................................... 12
Recessed Installation .............................................................................................................................................. 13
a. Crystal Ember Installation............................................................................................................................... 14
b. Fire log Installation......................................................................................................................................... 15
Wall Mounted Installation ...................................................................................................................................... 16
Operating Fireplace.................................................................................................................................................. 19
Power...................................................................................................................................................................... 19
Methods of Operation............................................................................................................................................. 19
Remote Control Operation...................................................................................................................................... 19
Remote Control and Touch Panel Functions.......................................................................................................... 20
Troubleshooting ........................................................................................................................................................ 21
Temperature Limiting Control................................................................................................................................ 21
Care and Maintenance ............................................................................................................................................. 22
Cleaning.................................................................................................................................................................. 22
Maintenance............................................................................................................................................................ 22
Warranty ................................................................................................................................................................... 23

Recessed Electric Fireplace
rev: 20220427
4
General Information
IMPORTANT SAFETY INFORMATION
WARNING!
•THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS
•Do not operate fireplace before reading and understanding operating instructions. Failure to operate
fireplace according to operating instructions could cause fire or injury.
•Risk of burns. This fireplace is HOT when in operation and heating element is ON. Power to the fireplace
should be turned off and the fireplace allowed to cool before servicing. To disconnect power to the
fireplace, turn controls to off, then remove plug from outlet.
•Do not install damaged, incomplete, or substitute components.
•Young children should be carefully supervised when they are in same room with fireplace. Toddlers,
young children and others may be susceptible to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the house. To restrict access to the fireplace, install an
adjustable safety gate to keep toddlers, young children and other at risk individuals away from the fireplace
and hot surfaces. Ensure that you have incorporated adequate safety measures to protect infants/toddlers
from touching hot surfaces.
•Clothing and other flammable material should not be placed on or near the fireplace.
•Due to high temperatures, the fireplace should be located out of traffic and away from furniture and
draperies.
•It is imperative that that the control compartments, circulating blower, and its passageway is the fireplace is
kept clean.
•Under no circumstances should this fireplace be modified.
•Do not use the fireplace if any part has been under water.
•Do not operate the fireplace with the glass panel removed, cracked or broken.
•Keep the packaging material out of the reach of children. As with all plastic bags, these are not toys and
should be kept away from children and infants.
•Servicing should only be done while the fireplace is disconnected from the power outlet.
•Unplug fireplace if not being used for an extended period of time.
•Do not operate this fireplace with a damaged cord or plug after the fireplace malfunctions, has been
dropped, or damaged in any manner.
•INDOOR USE ONLY! Do not use outdoors.
•Never locate fireplace where it may fall into a bathtub or other water container.
•Do not run the cord under carpeting. Do not cover cord with throw rugs, runners, or the like. Arrange cord
away from traffic area and where it will not be tripped over.
•Connect to properly grounded outlets only.
•Do not insert foreign objects into any ventilation or exhaust opening as this may cause and electric shock,
fire, or damage to the fireplace.
•To prevent a possible fire, do not block the air intakes or exhaust in any manner. Do not use on soft
surfaces, like a carpet, where openings may be blocked.
•Ensure clearances to combustibles are maintained when building a mantel or shelves above the fireplace.
Elevated temperatures on the wall or in the air above the fireplace can cause melting, discoloration or
damage to the decorations, a TV or other electronic components.

Recessed Electric Fireplace
rev: 20220427
5
Fireplace Specifications
Model Number
WLGN8740
86274
Description
Recessed 50”
Recessed 60”
Voltage
120v AC
120v AC
Watts
Max 1500W
Max 1500W
Amps
15 AMP
15 AMP
Fireplace Width
50 3/8”
60”
Fireplace Height
21 ½”
21 ½”
Fireplace Depth
5 ½”
5 ½”
Net Weight
60 lbs
68 lbs
Gross Weight
65 lbs
73 lbs
ETL Approval Listing Information
This fireplace has been tested in accordance with the ETL Intertek Standards for fixed and location-dedicated
electric room appliances in the United States and Canada. If you need assistance during installation, please contact
our technical support department at 800-215-1990 option 2.
Note: This fireplace must be electrically wired and grounded in accordance with local codes or, in the
absence of local codes, with National Electric Code ANSI/NFPA 70-latest edition in the United States or the
Canadian Electric Code, CSA C22.1 in Canada.

Recessed Electric Fireplace
rev: 20220427
6
Dimensional Drawing
WLGN8740 –50”Recessed Electric Fireplace

Recessed Electric Fireplace
rev: 20220427
7
86274 –60”Recessed Electric Fireplace

Recessed Electric Fireplace
rev: 20220427
8
Unpacking Your Fireplace
Parts and Hardware
Tools Required
•Phillips screwdriver
•Stud finder
•Level
•Tape measure
•Electric drill
•1/4”wood drill bit
What’s in the Box
Unpacking and Setup
Unpacking Instructions:
•Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Check the parts
list to make sure no parts are missing. If parts are missing, please contact technical support at 800-215-1990
option 3 for replacement.
NOTE: Dispose of plastic bag, as it may cause choking hazard with young children. Do not let children play
with plastic bag.

Recessed Electric Fireplace
rev: 20220427
9
Wiring
The WLGN8740/86274 series recessed fireplace can either be plugged into a grounded 3-prong outlet or hard wire
connection.
Testing the Fireplace Prior to Installation
•Before installing the fireplace, test the fireplace to make sure that it operates properly.
•Plug fireplace into approved outlet and power on fireplace. Once fireplace is tested, continue with
installation.
•If you have any problems, please contact technical support at 800-215-1990
3-prong Outlet Installation
•Only use this fireplace on a 120V AC, 15-Amp grounded circuit. Never overload the circuit. If this
fireplace trips the circuit breaker, unplug all other appliances on the same circuit before the next use. Avoid
plugging other appliances into the same circuit as this fireplace.
•Always check the fireplace plug and connections before each use.
•Never plug this fireplace into an outlet that is cracked or has any loose wires or connections. Plugging this
fireplace into a faulty outlet could result in the outlet overheating or catching fire.
•Make sure this plug fits securely into the outlet. Faulty wall outlet connections or loose plugs can cause the
outlet to overheat. If the outlet or faceplate is hot, discontinue use immediately and have a qualified
electrician inspect and/or replace the faulty outlet.
•The power cord supplied with the heater has three prongs: two flat blades (live and neutral) and one round
pin (ground). If a 3-slot receptacle is not available, an adapter MUST be used. The adapter MUST be
properly grounded to the outlet box (see figure below).
NOTE: Adapter NOT INCLUDED.

Recessed Electric Fireplace
rev: 20220427
10
Hard Wire Connection
If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire
the appliance directly to the house hold wiring.
This appliance must be electrically connected and grounded in accordance with local codes, if hard wired. In
the absence of local codes, use the current ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United States
or the current CSA C22.1 CANADIAN ELECTRICAL CODE in Canada.
A. Remove the cover plate from the left side B. Remove the wire connectors from the power
bottom of the appliance by removing the three cord. Keep power cord, in case needed in future.
screws, as shown above. Save screws for
installation of new cover plate. (figure 1)
C. Take the new cover plate and punch a 7/8”. Thread your wiring through the hole in the cover plate for
connecting to the wires in the WLGN8740/86274 fireplace.
D. Using the wire connectors, connect the ground green wires (G), the common white wires (N)
together, then the hot black wires (L) and then the refer to Figure 3.
E. Reinstall the cover plate using the three screws, as shown in Figure 1.

Recessed Electric Fireplace
rev: 20220427
11
Installation
WARNINGS
•Due to high temperatures, keep the fireplace out of high traffic locations.
•Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 36”
away from the front of the fireplace.
•Never install the fireplace where it may fall into a bathtub or other body of water.
•Wear safety gloves and safety glasses for protection during installation. Broken glass may cause injury or
harm.
•Prevent contact with loose insulation. Do not install the fireplace against a vapor barrier or exposed
insulation.
•Do not expose the fireplace to the elements (rain, etc).
Choosing Installation Location
Choosing Wall Location
•Measure wall location to ensure that fireplace will fit on desired wall location.
•Minimum clearances (measurements taken from front of glass panel):
•Select a location that is not prone to moisture and is located at least 36” away from combustible materials
such as curtains, drapes, furniture, bedding, or other combustible materials.
•See Safety Information on page 3 for warnings about safe placement, safe installation, and proper use of this
product.
Bottom of Fireplace to Floor: 6”
Sides of Fireplace: 0”
Back of Fireplace: 0”
Top of Fireplace: 8” to mantel
Top of Fireplace: 8” to TV
Top of Fireplace: 8” to ceiling

Recessed Electric Fireplace
rev: 20220427
12
Removing The Glass Panel
Prior to installation, it is best to remove the glass panel. Please remove the glass panel as per instructions below:
Instructions
1. There are 4 screws securing the glass panel to the fireplace. Remove all 4 screws (2 on the left side and 2 on the
right side). These screws are for shipping purposes only and will not be reused after installation.
2. After removing screws, lift glass panel UP and STRAIGHT OUT toward you to remove from fireplace. Place
glass panel in a soft, dry place.
CAUTION: It is recommended that 2 people remove the glass panel to minimize change of breakage.

Recessed Electric Fireplace
rev: 20220427
13
Recessed Installation
•Due to many different finish materials use on walls, it is highly recommended that you consult your local
builder before you install this fireplace in the wall.
•Select a location that is not prone to moisture and is located at least 36” away from combustible materials
such as curtains, drapes, furniture, bedding, or other combustible materials.
•In order to avoid the possibility of exposed insulation or vapor barrier coming in contact with the fireplace,
it is recommended that the walls of the fireplace enclosure be “finished” (ie. Sheetrock, drywall, etc) as you
would finish any other outside wall of your home. This will ensure that clearance to combustibles is
maintained within the wall cavity.
•Never install fireplace into load-bearing walls. When recessing fireplace in a wall, recess into non-load
bearing walls ONLY!
Instructions:
1. Choose a location in the wall to install fireplace.
2. Create opening in the wall according to the rough opening dimensions listed in the chart below:
Rough Opening Dimension Chart
Model
A
(Width)
B
(Height)
C
(Depth)
WLGN8740
47 ¼”
20 ½”
5 ¾”
86274
57 ¼”
20 ½”
5 ¾”

Recessed Electric Fireplace
rev: 20220427
14
Recessed Installation –cont.
3. With the help of a second person, insert fireplace into wall opening and secure with mounting screws provided.
4. Once the fireplace is installed in the wall, place crystal embers or fire log in the fireplace.
a. Crystal Ember Installation
1. Place plastic tray strip in fireplace
above the LED lights as shown in the
diagram to the right.
2. Carefully, place crystal embers on
plastic strip as illustrated in the picture to
the right. Apply an even layer from side
to side.

Recessed Electric Fireplace
rev: 20220427
15
Recessed Installation –cont.
b. Fire log Installation
1. Place fire log in fireplace as illustrated below.
5. Once completed installing crystal embers or fire log, reinstall glass panel. The hooks on the back of the glass
panels fit into the slots on the side of the firebox. Once in the slots, the glass panel goes down and locks into place.

Recessed Electric Fireplace
rev: 20220427
16
Wall Mounted Installation
•Due to many different finish materials use on walls, it is highly recommended that you consult your local
builder before you install this fireplace on the wall.
•Select a location that is not prone to moisture and is located at least 36” away from combustible materials
such as curtains, drapes, furniture, bedding, or other combustible materials.
Instructions
1. With glass panel removed (see p.10 for instructions on removing glass panel), have two people hold the fireplace
against the wall to determine the final location.
2. Place the unit face down on a soft, non-abrasive surface. Remove the bracket from the back of the unit by
removing the screws holding the bracket to the back of the fireplace.

Recessed Electric Fireplace
rev: 20220427
17
Wall Mounted Installation –cont.
3. Mark location of bracket on wall and then mount the bracket to the wall using the supplied screws and dry wall
anchors. The hooks in the bracket MUST be pointed away from the wall, upward, and level.
Note: Mount bracket to at least 2 studs. If 2 studs cannot be used, ensure that the supplied dry wall anchors are
used to affix the bracket to the wall and the bracket is adequately secured before moving to the next step.

Recessed Electric Fireplace
rev: 20220427
18
Wall Mounted Installation –cont.
4. With the wall mounting bracket installed, have 2 people lift the fireplace up and insert the 2 hooks on the bracket
into the back of the fireplace. The 2 hooks on the mounting bracket will line up with the 2 holes on the back of the
fireplace. Once aligned, the hooks will insert into the holes in the back of the fireplace and lock in the down
position.
Mounting bracket installed on wall Hang fireplace on mounting bracket hooks
5. Check the fireplace for stability, ensuring that the bracket will not pull free from the wall. Once satisfied, install
crystal embers/fire log and reinstall glass panel. See instructions on 12-13 for installing the crystal embers/fire log
and front glass panel.

Recessed Electric Fireplace
rev: 20220427
19
Operating Fireplace
Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that
the house circuit breakers for the power supply are turned on.
Power
Plug the power cable into a 110v 15 amp grounded outlet. Make sure the outlet is in good condition and that the
plug is not loose. NEVER exceed the maximum amperage for the circuit. DO NOT plug other appliances into the
same circuit.
Methods of Operation
This electric fireplace can be operated by the TOUCH PANEL, located on the BOTTOM right side glass panel of
the fireplace, or by the battery-powered REMOTE CONTROL. The operation and functions of the two methods are
the same.
Remote Control Operation
•This remote control uses 2 AAA batteries (not included).
•Instructions for battery installation are located in the remote control battery compartment.
•To improve operation of the remote control, aim the remote control at the front of the fireplace. DO NOT
PRESS the buttons too quickly. Give the unit time to respond to each command.
•NOTICE: NEVER dispose of batteries in fire. Failure to observe this precaution may result in an
explosion. Dispose of batteries at your local hazardous material processing center.

Recessed Electric Fireplace
rev: 20220427
20
Remote Control and Touch Panel Functions
BUTTON
FUNCTION
ACTION & INDICATION
ON: Enables control panel functions and remote control. Turns
on the flame effect.
OFF: Disables control panel functions and remove control.
Turns off the flame effect.
1. Press once. Indicator light turns on.
Power turns on. All functions enabled.
2. Press again. Flame effect turns off. Unit goes
to standby. All functions turn off.
TIMER button: Control time settings to turn off fireplace at
selected time.
Settings range from 1 hour to 8 hours.
1. Press once. Increases the timer shut off time by
1 hour.
2. Press again until desired setting is reached.
Setting range from 1 to 8 hours.
FLAME button: Makes flame effects dimmer or brighter.
NOTE: Flame effect stays on until power button is turned off.
Flame effect must be on for heater to turn on.
1. Press once to change the flame brightness.
2. Press again until desired setting is reached.
COLOR button: Changes the color of the flame.
1. Press once to change the color of the flame.
2. Press again until desired flame color setting is
reached.
HEATER button:
On Fireplace Glass Panel: Turns heater on and off.
On Fireplace Remote Control: Turns heater on and off and sets
thermostat temperature.
NOTE: The heater only works when the flame effect is on.
NOTE: To prevent overheating, the heater fan will blow cool air
for 8-10 seconds before the heater turns on, and after the heater
turns off.
On Fireplace Glass Panel:
1. Press once. Indicator lights up. Fan blows
cool air for 10 seconds and 750W heater turns on
and blows warm air.
2. Press again: Indicator lights up. 1500W heater
turns on and blows hot air.
3. Press again. Heater turns off.
On Fireplace Remote Control:
1. Press once. Heater turns on low (LL)
2. Press again: Heater turns on high (HH)
3. Press again: Thermostat set to 62F.
4. Press again: Thermostat moves up 1 degree.
Max Thermostat temperature is 82F.
TEMPERATURE button (on fireplace glass panel):
Control temperature settings to choose temperature as desired.
Setting ranges from 62F to 82F.
1. Press once. LED display is turned on and
temperature is set to 62F by default.
2. Press again unit desired setting is reached.
Note: Heater will turn off when temperature
reaches desired setting.
