T19014
Electric Spiralizer
Safety and Instruction Manual With Recipes
PLEASE READ CAREFULLY
*Subject to registering Your Extended Guarantee online at www.towerhousewares.co.uk.

2
1912 Midland Metal
Spinners was founded by
George Cadman, who was
then 65 years old, as a metal
holloware manufacturing
company, in St. Mark’s Street,
Wolverhampton. They later
moved into the Tower and
Fort Works in Pelham Street,
which ultimately gave rise
to the famous Tower brand
name.
1937 Tower exhibited some
of their latest holloware
designs at the British
Industries Fair. As you can
see from the original poster,
their stand No. A410 must
have been a great sight as
it promoted their “Beautiful,
inexpensive, untarnishable
Plate, at prices all can afford
to pay”.
1961 Tower became one of
the largest manufacturers
of aluminium holloware,
electric kettles, tea pots and
other household articles
with over 1,000 employees.
1974 Russell Hobbs took
ownership of the expanding
Tower brand.
Tower presents the new
Electric Spiralizer, an
innovative design that
creates spirals and ribbons
effortlessly at the push
of the button. Spiralizing
may seem like a new craze,
but spiralizers have been
around for quite some time.
A staple in many American
restaurants, spiralizers
create beautiful garnishes
and vegetable based dishes
as fast as any chef knife.
Although similar to a
julienne peeler or mandolin,
spiralizers are quickly
become a new must-have
classic. The volume of
veggie spirals and noodles
created from one vegetable
is one of many great benets
of using a spiralizer.
Building from classic
spiralizer elements, the
Electric Spiralizer adds an
extra level of ease to the
spiralizing process. Unlike
manual or hand-crank
spiralizers, the Electric
Spiralizer requires no manual
turning; it’s never been
easier to create beautiful
spirals and ribbons. Simple
assembly and a one button
operation mean you’ll be
creating courgetti and
voodles (veggie noodles) in
no time.

3
Contents:
Please read this Manual carefully BEFORE using the Electric
Spiralizer for your own safety.
Thank you for purchasing the Tower Electric Spiralizer from
the Tower range of products.
It has been designed to provide many years of trouble-free
preparation.
There are many benets to using a Tower Electric
Spiralizer:
• Create colourful vegetable spirals and ribbons.
• Motorised holder for ease of access.
• 3 interchangeable blades: wide ribbons, long spirals
and shredded spirals.
• The hand-held spiralizing motor means no height.
restrictions for the size of your fruit and veg.
• Versatile and large food storage container.
• Non-slip feet.
1. Specications
Components and
structure
2. Technical data
3. Important Safety
Information
4. Setting Up
5. Using your Appliance
6. Tips
7. Weights & Measures
8. Troubleshooting
9. Cleaning & Care
10. Recycling
11. Wiring Safety
12. Warranty Information
13. Your Receipt
14. Recipes
Courgetti with Pesto
and Tomatoes
Shoestring Curly Fries
Thai Papaya Salad
Mason Jar Salad
Cucumber and
Strawberry Salad
Asian Side Salad
Parmesan Carrot and
Parsnip Crisps
Carrot and Courgette
‘Pancakes’
Spiced Apple and
Pear Chips
See back page for
Customer Service
Information.

4
1. Power button
2. Motor
3. Lid
4. Bowl
5. Wide Ribbon Blade
6. Large Spiral Blade
7. Shredded Spiral Blade
8. Lid cover
9. Food guide
10. Food holder
1 - Specications:
Structure of your appliance:
4
1
2
3
5
6
7
8
9
10

5
Description: Electric Spiralizer
Model: T19014
Rated Voltage: 220-240V
Frequency: ~ 50/60Hz
Power Consumption: 100W
Lock Max Power: 200W
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food
(LFGB section 30 & 31).
RKW Quality Assurance, United Kingdom.
2 - Technical Data:
Guarantee:
All accessories are covered
by the warranty.
The main body and housing
are guaranteed for the
extended free warranty
subject to registration.
If any defect arises due
to faulty materials of
workmanship, the faulty
products must be returned
to the place of purchase.
Refund or replacement is at
the discretion of the retailer.
Should you encounter problems or require a
replacement part, contact The Tower Customer Service
Department on: [phone].
Any necessary spare parts may be ordered from the
Tower website.
Your warranty becomes void should you decide to use
non Tower spare parts. Spare parts can be purchased
from www.towerhousewares.co.uk

6
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer, its
service agent or a similarly
qualied person.
• Do not let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• Do not carry the appliance
by the power cord.
• Do not use any extension
cord with this appliance.
• Do not pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch off at the wall socket
then remove the plug from
the socket when not in use
or before cleaning.
• Switch off and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play
with the appliance.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near pets.
• Do not use this product
for anything other than its
intended use.
• This appliance is for
household use only.
Please read these notes carefully BEFORE using your
Tower appliance
3 - Important Safety Information:

7
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• Do not immerse cords, plugs
or any part of the appliance
in water or any other liquid.
• Do not use this product
for anything other than its
intended use.
• CAUTION: The blades are
ultra-sharp. Handle with
care.
• CAUTION: Keep ngers
clear of the blade at all
times. Never push the
product with your hands
in line of the blade when
slicing. Always use the hand
guard.
• Never touch the blade when
handling or cleaning a blade
insert; touch only the plastic
side grips. Use a brush to
clean the blades.
• Do not attempt to slice
foods by hand.
• Operate the spiralizer on a
sturdy, dry surface.
• Do not leave spiralizer
unattended while it is
operating.
• Avoid contacting with
moving parts.
• The use of accessories
not recommended by the
manufacturer may cause
injuries to persons.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
service department:
[phone]

8
Before rst use:
• Remove all parts.
• Clean the cutting blade and peeling blade in warm, soapy water and dry thoroughly.
• Dispose of packaging and retain these instructions for future use.
Assembly:
• Place the bowl on a at, dry surface.
• Select your required blade and place it in the lid.
• Carefully twist the blade so that it locks into place.
• Put the lid onto the bowl.
• Fit the food guide in position by placing it on top of the
blade and turning it clockwise, so that it is secure.
Three blades:
Wide Ribbon Blade
For salad garnishes,
vegetables crisps.
Long Spiral Blade
For vegetable noodles,
spaghetti.
Shredded Spiral Blade
For coleslaw, hash browns,
garnishes.
4 - Setting Up

9
1. Assemble the spiralizer.
2. Prep the vegetable (or fruit) to be spiralized, as per the
preparation guide.
3. Insert the food holder into the at top of the vegetable
(g.1).
4. If using the long spiral or shredded spiral blade, push
the vegetable onto the centre spikes of the blade. If you
are using the wide ribbon blade, place the vegetable in
the cone of the blade.
5. Join the motor and the food holder together and plug
in (g.2).
6. Press the button on the motor to begin spiralizing,
using gentle downwards pressure to push the vegetable
against the blade.
Preparation Guide:
Produce Preparation Raw or Cooked
Apple Remove stem Both
Beetroot Peel and cut off ends Both
Broccoli Slice off orets and
use stem only
Cooked
Butternut Squash Slice off the bulbous
seeded end of the
squash, peel and
chop in half if large
Cooked
Cabbage Remove outer layers,
cut to t
Both
5 - Using Your Appliance
g.1
g.2

10
5 - Using Your Appliance
Carrot Slice ends off
atly and evenly if
required. Cut to t
Both
Celeriac Chop off ends, peel,
cut to t
Cooked
Courgette Slice end off atly
and evenly. Cut to t
Both
Cucumber Slice off ends, cut
to t
Raw
Daikon Radish Peel, slice off ends,
cut to t.
Both
Onion Peel outer skin. Both
Parsnip Peel, slice off ends
and cut to t.
Cooked
Potato Cut to t Cooked

11
Pear Cut off ends Both
Papaya Slice lengthways,
de-seed, peel off
dark skin
Raw
Sweet potato Peel, slice off ends
and chop in half if
large
Cooked
Turnip Chop off ends, peel Cooked
1. For best results, choose fruits and vegetables that are rm and symmetrical.
2. When you use the thin spiralizing option, the spiralizer and peeler will yield one very long
noodle. Use scissors to cut noodles into easier lengths before cooking or dressing.
3. For shorter peels, try scoring the fruit or veg in quarters.
6 - Tips

12
Check these charts for basic imperial to metric conversions
of weights.
Metric Imperial US cups
250ml 8 oz 1 cup
180ml 6  oz 3/4 cup
150ml 5 oz 2/3 cup
120ml 4 oz 1/2 cup
75ml 2 1/2 oz 1/3 cup
60ml 2 oz 1/4 cup
30ml 1 oz 1/8 cup
15ml 1/2 oz 1 tablespoon
Imperial Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
15 oz 425g
1 lb 450g
Food Allergies
Important Note: Some of the recipes contained in this document may contain nuts and/
or other allergens. Please be careful when making any of our sample recipes that you ARE
NOT allergic to any of the ingredients. For more information on allergies, please visit the
Food Standards Agency’s website at: www.food.gov.uk
7 - Weights & Measures

13
Questions Answers
The food holder is not
sticking into the food.
Ensure the ends of the food have been sliced off evenly, and that the food
holder is inserted into the centre of the sliced area.
The spiralizer is not
working.
Make sure the spiralizer is plugged in and the power button is properly
depressed.
There is a small core
left over.
This is a normal part of spiralizing. The centre part of the fruit or vegetable
will not be spiralized. However, this doesn’t mean it has to go to waste. You
can chop up or cook this part of the fruit or vegetable in the same way that
you cook the spiralized produce.
8 - Troubleshooting

14
10 RECYCLING
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
CAUTION:
the blades are sharp, please handle with care.
Always clean your mandolin immediately following each use.
Hand wash recommended.
Clean the bowl, lids and blades in warm soapy water.
Unplug the motor and wipe clean with a damp cloth
IMPORTANT!
Allow to dry fully after cleaning before using again.
Do not use the appliance if damp. Ensure the appliance is completely clean and dry before
storing.
Storage
Store in a cool, dry place out of reach of children.
Store the blades in the bowl with the lid secured.
9 - Cleaning & Care
10 - Recycling

15
WARNING:
This appliance is double insulated.
Do not connect any wire to the earth terminal.
11 - Wiring Safety for UK Use Only
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the
terminals in your plug,
please proceed as
follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and
must be connected to the terminal marked
[N] or coloured black.
The wire coloured brown is the live wire and
must be connected to the terminal marked
[L] or coloured red.
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the
same rating already tted and conforming to
BS 1362 and be ASTA approved.
If in doubt consult a qualied electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must
use an ASTA approved one (conforming to
BS 1362 of the same rating).
If in doubt, consult a qualied electrician
who will be pleased to do this for you.
If you need to remove the plug - disconnect
it from the mains - and then cut it off the
mains lead and immediately dispose of its
safely. Never attempt to reuse the plug or
insert it into a socket outlet as there is a
danger of an electric shock.

16
This product is guaranteed for 12 months from
the date of original purchase.
If any defect arises due to faulty materials of
workmanship, the faulty products must be
returned to the place of purchase.
Refund or replacement is at the discretion of the
retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase.
• The product must be installed and
used in accordance with the instructions
contained in this instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear, damage,
misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire Only.
The standard one year guarantee is only
extended to the maximum available for each
particular product upon registration of the
product within 28 days of purchase. If you
do not register the product with us within the
28 day period, your product is guaranteed for 1
year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and register
with us online. Alternatively, call our customer
registration line on [phone].
Please note that length of extended warranty
offered is dependent on product type and that
each qualifying product needs to be registered
individually in order to extend its warranty past
the standard 1 year.
Extended warranty is only valid with proof of
purchase.
We hope that you will enjoy
your Electric Spiralizer
for many years.
As a thank you for purchasing
one of our fantastic products,
we are giving you 3 years
peace of mind.
To receive your 3 year
guarantee, simply register your
appliance online by visiting
www.towerhousewares.co.uk
12 - Warranty

17
Afx your store receipt to
this page for safe keeping.
13 - Your Receipt

18
NOTES

19
NOTES

20
NOTES
