Tower Hobbies RHH11 Operator's manual

SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.
T127003BLG
RHH11 Cordless
11.1V Wet & Dry
Handheld Vac

2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been designing,
developing and manufacturing housewares and small
appliances used by millions of households throughout the
UK and beyond. During the 1960s, the rise in popularity
of pressure cooking saw Tower become the UK’s largest
producer of pressure cookers, right through into the late
1980s. In recent years the Tower brand has been reborn with
an exciting and varied range of housewares and electrical
appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.

3
Contents:
Thank you for purchasing this appliance from the
Tower range.
Please read this manual carefully BEFORE using the
appliance for your own safety.
It has been designed to provide many years of
trouble-free use.
There are many benefits to using a Tower Handheld
vacuum:
• 11.1V cordless rechargeable handheld vacuum.
• Powerful 65W motor giving 2.5KPA suction.
• 25 minute runtime from a single charge.
• Portable cordless operation - perfect for picking
up crumbs and dirt.
• Easy-empty 100ml dust compartment.
• Includes crevice nozzle and round brush.
1. Specifications
Components and
structure
2. Technical Data
3. Important Safety
Information
4. Before First Use
5. Using your Appliance
6. Troubleshooting
7. Recycling
8. Cleaning & Care
9. Wiring Safety
10. Warranty Information
11. Your Receipt
See back page for Customer
Service Information.

4
This box contains:
Instruction Manual
Handheld Vacuum Cleaner
AC Adaptor
Filter
Wet nozzle
Crevice nozzle
Brush
1. Long nozzle
2. Charger
3. Wet nozzle
4. Brush attachment
5. Dust container
6. Filter
7. Dust container release button
8. On/Off switch
9. Handle
1 - Specifications:
Structure of your appliance:
5 6 7 8 9
2 3
4
1

5
Description: RHH11 Cordless 11.1V Wet & Dry Handheld Vac
Model: T127003BLG
Voltage: 11.1V
Product Power: 65W
Charger Input: 100-240V
Charger Frequency: ~50/60Hz
Charger Output: DC13.5V/400mA
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom.
2 - Technical Data:
Should you encounter problems or require a replacement part, contact the Tower
Customer Support Team: [phone].
Some spare parts may be ordered from the Tower website.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Guarantee for spare parts:
The spares and accessories are guaranteed for 1 year from date of purchase.
The main body and housing are guaranteed for the extended free warranty subject
to registration.
If any defect arises due to faulty materials of workmanship, the faulty products must
be returned to the place of purchase within 12 months from the date of purchase.
Refund or replacement is at the discretion of the retailer.

6
Please read these notes carefully BEFORE using your
Tower appliance.
3 - Important Safety Information:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualied person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use any
extension cord with this
appliance.
• DO NOT pull the plug out
by the cord as this may
damage the plug and/or
the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or before
cleaning.
• Switch off and unplug
before tting or removing
tools/ attachments, after
use and before cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near
pets.

7
• Not suitable for carpets
with long bres as the
bristles will damage the
bres.
• Keep the vacuum cleaner
moving over the carpet
surface at all times to
avoid damaging the
carpet bres.
• DO NOT use this product
for anything other than its
intended use.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• This appliance is for
household use only.
• DO NOT use the
appliance outdoors.
• Keep hair, loose clothing,
ngers and all body parts
away from moving parts.
• DO NOT use to pick up
ammable liquids such
as gasoline or use in an
area where they might be
present.
• DO NOT use the
appliance without the dust
container lter in place.
• DO NOT pick up anything
that is burning or smoking
such as cigarettes,
matches or hot ashes.
• Use extra care when
cleaning on stairs.
• Use only manufacturer’s
recommended
accessories.
• DO NOT pull cord, use
cord as a handle, close a
door on cord, or pull cord
around sharp edges or
corners.
• DO NOT run vacuum
cleaner over the cord.
Keep cord away from
heated surfaces.
• This product is tted with
a thermal cut-out, which
will activate if the motor
overheats due to blocked
air inlets. If the appliance
cuts out, allow it to cool
for 1 hour, then empty the
dust container and clean
all of the lters.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
[phone]

8
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and counted all the parts
and the contents against the parts list.
4. Dispose of the packaging in a responsible manner.
Charging the Appliance:
5. This unit can be charged directly from the mains using the included mains
adaptor.
6. To charge the vacuum, connect the mains adaptor to the corresponding jack
at the back of the unit and plug the other end into an active mains socket,
ensuring the socket switch is turned to the ON position.
7. The LED indicator on the body of the charger will light up green to show the
charger has been plugged into the mains, red to show the unit is charging, and
go out when the unit is fully charged.
Note: The average charging time for this unit is 16 hours on first use, and 8 hours for
subsequent uses.
Turning the Appliance On and Off:
1. Push the On/Off switch on the body of the unit to the ON position to turn the
unit on. Air will begin emitting from the unit to indicate it has been powered
up.
2. Release the On/Off switch when the unit is in operation to turn it off. Air will
stop emitting from the unit to indicate it has been powered down.
Using the Accessories:
1. This unit comes complete with a full range of accessories, including:
• Long nozzle, to vacuum hard-to-reach areas.
• Wet nozzle, for vacuuming up liquids.
• Brush attachment, for cleaning upholstery or delicate fabrics.
2. To use any of the included accessories, attach them to the suction end of the
vacuum, ensuring they sit flush within the opening.
3. To remove an attached accessory, pull it firmly away from the main body of the
unit until it detaches.
4 - Before First Use
5 - Using Your Appliance

9
6 - Troubleshooting
Problem Solution
The vacuum will not work
• Ensure the vacuum cleaner is fully charged. To charge the
unit, plug the AC adaptor into it, connect it to a mains socket
and wait until the LED indicator on the charger goes out.
• Check that there are no blockages to the dust tank or filter
and remove as necessary.
The vacuum will not pick-up or the
suction power is weak
• The dust container may be full, or the filters may require
cleaning. Empty the dust container and clean the filters.
• There may be blockages in the filters or dust tank. Check for
blockages and clean the filters and dust tank as detailed in
the ‘Cleaning and Care’ section.
Dust is escaping from the vacuum
• The filter may not be installed correctly, or the dust container
may be full. Empty the dust container and reassemble the
filter system.
The vacuum is making an unusual
sound or hissing.
• The airflow may be restricted or blocked. Check for blockages
and clean the filters and hose as detailed in the ‘Cleaning and
Care’ section.

10
Emptying the Dust Tank:
Note: Ensure the vacuum cleaner is turned off and unplugged from the mains
before emptying the dust tank.
1. To remove the dust tank from the vacuum cleaner, press the release button on
the main body of the unit, then pull the tank firmly towards you and away from
the main body of the vacuum.
2. Once the dust tank has been removed, pull out the filter from inside. To do
this, grip the small tab marked ‘Pull’ on the lip of the filter and pull it firmly
upwards and away from the dust tank.
3. Once the filter has been removed, tap it over a rubbish bin or similar surface to
remove any dust residue, rinse it under running water and leave it to dry.
Note: Ensure the unit is thoroughly clean and the filter is completely dry before
attempting to use or store it.
4. Ensure the filter is inserted back into the unit before attempting to use it again.
Clearing Blockages:
If the dust tank is overfilled, the filter is clogged up, or the vacuum picks up a larger
piece of debris, the vacuum may become clogged.
Should this occur, carry out the following steps to unclog the vacuum:
1. Check the dust tank and empty it if necessary.
2. Check the filter for any debris and rinse it under running water if necessary, as
detailed in the sections above.
3. Detach any attachments from the unit and check for blockages.
8 - Cleaning & Care
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to
information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.
7 - Recycling

11
Storing the Appliance:
Note: Before storing the vacuum, unplug it from the mains and remove any
attachments from the front of the unit.
• Store the appliance in a cool, dry place, preferably inside its original packaging,
and out of the reach of children.
WARNING:
Do not immerse any electrical part of the appliance in water
such as motor units or plugs.
Please see cleaning section for further instructions.

12
WARNING:
This appliance is double insulated.
Do not connect any wire to the earth terminal.
9 - Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with
the coloured markings identifying the
terminals in your plug, please proceed
as follows:
The wires in the mains lead are
coloured in accordance with the
following code:
Blue neutral [N] Brown
live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral
and must be connected to the
terminal marked [N] or coloured black.
The wire coloured brown is the live
wire and must be connected to the
terminal marked [L] or coloured red.
On no account must either the brown
or the blue wire be connected to the
[EARTH] terminal .
Always ensure that the cord grip is
fastened correctly.
The plug must be fitted with a fuse
of the same rating already fitted and
conforming to BS 1362 and be ASTA
approved.
If in doubt consult a qualified
electrician who will be pleased to do
this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a
non-rewireable plug fitted to the
mains lead and should the fuse need
replacing, you must use an ASTA
approved one (conforming to BS 1362
of the same rating).
If in doubt, consult a qualified
electrician who will be pleased to do
this for you.
If you need to remove the plug –
disconnect it from the mains – and
then cut it off of the mains lead and
immediately dispose of it in a safe
manner. Never attempt to reuse the
plug or insert it into a socket outlet as
there is a danger of an electric shock.
Fuse
Neutral
(Blue)
Live
(Brown)

13
This product is guaranteed for 12 months
from the date of original purchase.
If any defect arises due to faulty materials
of workmanship, the faulty products must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase or a
receipt.
• The product must be installed and
used in accordance with the
instructions contained in this
instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear,
cosmetic damage, misuse or
consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire
only.
The standard one year guarantee is only
extended to the maximum available for
each particular product upon registration
of the product within 28 days of purchase.
If you do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and
register with us online.
Please note that length of extended
warranty offered is dependent on product
type and that each qualifying product
needs to be registered individually in order
to extend its warranty past the standard
1 year.
Extended warranty is only valid with proof
of purchase or receipt.
As a thank you for purchasing
one of our fantastic products,
we are offering you an extra
2 years peace of mind in
addition to your 1 year
guarantee.
To receive your extra 2 year
guarantee, register your
appliance online within 28
days of purchase by visiting
www.towerhousewares.co.uk
10 - Warranty

14
Affix your store receipt to this page for safe keeping.
11 - Your Receipt

15
Notes

thank you!
We hope you enjoy your appliance for many years. As a thank you for
purchasing one of our fantastic products, we are offering you an extra
2 years peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team:
[phone]
0120.V2
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
