Toyota CQ-ES0470K User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 13.2V
Negative Ground
Current Consumption Less than 3.0A
Power Output 17W×4
AM Radio
Frequency Range 531 - 1,602 kHz
Usable Sensitivity Less than 32dB/µV (S/N 20dB)
FM Stereo Radio
Frequency Range 87.5 - 108.0MHz
Usable Sensitivity Less than 14dB/µV (S/N 30dB)
Cassette Player (YGFD04737)
Reproduction System 4-Track, 2-Program Stereo
Tape Speed 4.76cm/sec.
Wow and Flutter 0.2% (WRMS)
Signal to Noise Ratio More than 42dB
CQ-ES0470K
AM/FM MPX Electronic Tuning Radio
with Stereo Cassette Tape Player and 6-
Disc CD Changer
PART No. : 86120-0K110
ID CODE : 57808
VEHICLE : IMV3,4
DESTINATION : Latin America
PRODUCED AFTER : Jan., 2005
CD Player (YGFD13301)
Signal to Noise Ratio More than 70dB (IHF-A)
Total Harmonic Distortion Less than 0.2%
Channel Separation 70+10dB (IHF-A)
Dimensions** (W×H×D) 178×100×156mm
Weight** 2585g
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“Dolby” and the double-D symbol are trade marks of Dolby
Laboratories Licensing Corporation.
Specifications*

1 FEATURES 2
2 SYSTEM BLOCK DIAGRAM 2
3 VIEWS AND FUNCTIONS 3
4 WIRING CONNECTION 4
5 BLOCK DIAGRAM 5
6 TERMINALS DESCRIPTION 6
• • •
• Multi-discs supported (CD-R,CD-RW, MP3)
• • •
• PLL (Phase Locked Loop) synthesized tuning.
• • •
• 12-station preset (6-AM, 6-FM).
• • •
• Anti-shock memory
• • •
• Scan tuning function
7 IC BLOCK DIAGRAM 8
8 REPLACEMENT PARTS LIST 11
9 EXPLODED VIEW (Unit) 16
10 WIRING DIAGRAM 17
11 SCHEMATIC DIAGRAM 21
12 MEMO 23
• • •
• Dolby noise reduction.
• • •
• Electronic volume control.
• • •
• CD changer control function.
• • •
• Illumination color : Greenish-White
CONTENTS
Page Page
1 FEATURES
2 SYSTEM BLOCK DIAGRAM
2
CQ-ES0470K

3 VIEWS AND FUNCTIONS
3
CQ-ES0470K

4 WIRING CONNECTION
4
CQ-ES0470K

5 BLOCK DIAGRAM
5
CQ-ES0470K

6.1. Main Block
IC601 : C2CBKH000100
Pin
No. Port Description I/O Volts (V)
FM AM CD TA
PE
1 BEEP Beep output O 0 0 0 0
2 BIT3 NCA1 rotary switch 3 I 4.9 4.9 4.8 0
3 BIT2 NCA1 rotary switch 2 I 4.9 4.9 4.8 4.9
4 BIT1 NCA1 rotary switch 1 I 0 0 0 4.9
5 FAN ON
(NC) Not used - - - - -
6CD-ON H: CD (IDC) deck
microcomputer
communication is possible
L: CD (IDC) deck micro
computer communication is
not possible
O 0 0 4.8 0
7 CD-
RESET H: Normal L: Reset O 4.9 4.9 4.9 4.9
8 CD-
SCKM CD (IDC) deck serial communication clock output O 0 0 4.8 0
9CD-SOM CD (IDC) deck serial
communication input I 4.9 4.9 2 4.9
10 CD-SIM CD (IDC) deck serial
communication output
terminal
O 4.9 4.9 3.7 0
11 RESET H: Normal L: Reset I 4.9 4.9 4.9 4.9
12 XT2 (NC) Not Used - - - - -
13 XT1 Connecting to GND I 0 0 0 0
14 GND Ground - 0 0 0 0
15 X2 Oscillation Terminal (Main)
12.396875MHz O 1.6 1.6 1.6 1.6
16 X1 Oscillation Terminal
(Main)12.396875MHz I 1.5 1.5 1.5 1.5
17 REGOFF Connecting to GND - 0 0 0 0
18 REGCPU Regulator output stable
capacity connection. - 3.6 3.6 3.6 3.6
19 VDD0 Positive power supply - 4.9 4.9 4.9 4.9
20 NC Not used O - - - -
21 NC Not used O - - - -
22 NC Not used O - - - -
23 SHIYOU4 H: Left handle L: Right handle I 0 0 0 0
24 ADIM H: Tail cancel off notice
L: Tail cancel on notice I 4.8 4.8 4.8 4.8
25 NC Not used O - - - -
26 DSP-
CNT H: When receiving FM 76.0- 78.9MHz
L: Other than the above
O 4.9 0 0 0
27 DSP-
BUSY H: Data in the DSP receiving buffer
L: No data in the DSP
receiving buffer
I 0.5 0.5 0.5 0.5
28 DSP-
RSTB DSP reset output O 4.9 4.9 4.9 4.9
29 DSP-CE Enabled chip output for
combined power IC, DSP O 0 0 0 0
30 DSP-CL Clock output for combined
power IC, DSP O 4.9 4.9 4.9 4.9
31 DSP-DO Not used (However it is
connected to DSP IC and
thus considered as an input)
I 0.6 0.5 0.6 0.5
32 DSP-DI Data output for combined
power IC, DSP O 0 0 0 0
33 PW/STB
YSTBY output for power IC O 4.9 4.9 4.9 4.9
34 LCD-SCK LCD data clock output O 0 0 0 0
35 LCD-
DATA LCD data input/output I/O 4.9 4.9 4.9 4.8
36 LCD-STB LCD data STB output O 0 0 0 0
Pin
No. Port Description I/O Volts (V)
FM AM CD TA
PE
37 LCD-
KEYREQ H: Key input data
L: No key data I 0 0 0 0
38 LCD-OFF H: Normal L: Displays off O 4.9 4.9 4.9 4.9
39 LCD-
RESET H: Normal L: Reset O 4.9 4.9 4.9 4.9
40 GND Ground Terminal - 0 0 0 0
41 VDD Positive power supply - 4.9 4.9 4.9 4.9
42 CD-EJ H: CD eject off L: CD eject on I 4.9 4.9 4.9 4.9
43 CST-EJ H: CST-EJ off L: CST-EJ on I 4.9 4.9 4.9 4.9
44 MODE-A Mode encoder input A I 4.9 4.9 4.9 4.9
45 MODE-B Mode encoder input B I 4.9 4.9 4.9 4.9
46 VOL-A Volume encoder input A I 4.9 4.9 4.9 4.9
47 VOL-B Volume encoder input B I 0.5 0.5 0.5 0.5
48 SHIYOU1 H: IDC L: CDP I 0 0 0 0
49 SHIYOU2 Ground pull down I 0 0 0 0
50 SHIYOU3 Ground pull down I 0 0 0 0
51 AMNC-
ON/OFF H: AMNC off L: AMNC on O 4.9 0 4.9 4.9
52 MUTE H: Mute on L: Mute off O 0 0 0 0
53 SD H: No electric field
L: With electic field I 4.9 4.9 3.3 3.3
54 PLL-SCL PLL data communication
clock output O 4.9 4.9 4.9 4.9
55 PLL-SDA PLL data communication
output I/O 4.9 4.9 4.9 4.9
56 ST H: No stereo input
L: With stereo input I 4.9 4.9 3.1 3.1
57 MSOUT H: No sounds L: With sounds I 4.8 4.8 4.8 0
58 NC Not used - - - - -
59 R-IN2 (F-IN1) : L (R-IN2) : -> eject
(F-IN1) : H (R-IN2) : -> brake O 0 0 0 0
60 F-IN1 (F-IN1) : L (R-IN2) : -> brake
(F-IN1) : H (R-IN2) : -> loads O 0 0 0 0
61 MSPL/FF H: FF/REW L: Play O 0 0 0 0
62 DOLBY H: Dolby off L: Dolby on O 0 0 0 4.9
63 EQ H: Metal tape L: Normal tape I 4.9 4.9 4.8 0
64 NC Not used - - - - -
65 NC Not used - - - - -
66 NC Not used - - - - -
67 NC Not used - - - - -
68 WP H: In E2PROM write protect
(input)
L: E2PROM is writing (output)
I/O 4.9 4.9 4.9 4.9
69 T-LOAD H: Cassette holder emitance
L: Normal operation and
cassette holder pushes in
I 4.9 4.9 4.9 0
70 F/R H: Sounds from side B
L: Sounds from side A O 0 0 0 4.9
71 NC Not used - - - - -
72 NC Not used - - - - -
73 TEST
(VPP) Connecting to ground - 0 0 0 0
74 NC(MP) Not used O - - - -
75 Vcont Analog input of electric field
strength I 0.5 0.8 0 0
76 AMNC-IN AM noise cancel decision
analog input using the A/D
input
I 0 1 0 0
77 NC Not used - - - - -
78 ST-SW1 Key input for steering
switch(1) I 4.9 4.9 4.8 4.9
79 ST-SW2 Key input for steering
switch(2) I 4.9 4.9 4.9 4.9
80 MTL H: Normal tape L: Metal tape O 0 0 0 4.9
81 MSM H: 1 Speed L: 3 Speeds O 0 0 0 4.9
6 TERMINALS DESCRIPTION
6
CQ-ES0470K

Pin
No. Port Description I/O Volts (V)
FM AM CD TA
PE
82 VDD Analog voltage input for the
A/D converter I 4.9 4.9 4.9 4.9
83 AVDD Standard Voltage for the
A/Dconverter I 4.9 4.9 4.9 4.9
84 GND
(AVSS) Ground for the A/D converter - 0 0 0 0
85 LANIN AVC-LAN data input I 0 0 0 0
86 LANOUT AVC-LAN data output O 0 0 0 0
87 GND Connecting to ground I 0 0 0 0
88 CAM-A/B H: Side B L: Side A I 0 0 0 4.9
89 ILL-DET H: Illumi off L: Illumi on I 4.9 4.9 4.9 4.9
90 SW1
<DQSY> Activates same period signals with H->L->H (Due to an
inverted circuit) (Interrupted
when normal)
I 4.9 4.9 0 4.9
91 +B DET H: +B on L: +B off I 4.9 4.9 4.9 4.9
92 ACC-
DET H: ACC off L: ACC on I 0 0 0 0
93 SW3
<NC> H: SW3 off L: SW3 on I 4.9 4.9 4.9 4.9
94 NC Not used I - - - -
95 FLASH
SO Flash rom data input (Independent of the
microcomputer)
I 0 0 0 0
96 FLASH
SI Flash rom data output (Independent of the
microcomputer)
O 4.9 0 0 0
97 NC Not used O 0 0 0 0
98 T-IN H: No tape L: With Tape I 4.9 4.9 4.9 0
99 END-B Tape end detector B I 0 0 0 1.5
100 END-A Tape end detector A I 0 0 0 1.5
6.2. Display Block
IC901 : YEAMPD32B015
Pin
No. Port Description I/O Volts (V)
1LED1 Led Output (green) O1.8
2LED2 Led Output (red) O1.5
3LED3 Led Output (brightness) O 0
4LED4(NC) - - -
5VSS Connecting to ground - 0
6VLC5 LCD Control Voltage 5 - 0
7VLC4 LCD Control Voltage 4 -1.5
8VLC3 LCD Control Voltage 3 -3.0
9VLC2 LCD Control Voltage 2 -3.0
10 VLC1 LCD Control Voltage 1 -4.5
11 VLCD LCD Control Voltage 0 -6.1
12 VDD Connecting to 5 volts -5.0
13 SYNC Synchronized input -5.0
14 LCD OFF LCD Control(When the LCD
is down) I5.0
15 RESET Reset I5.0
16 KEY REQ Key request output O 0
17 SCK Control clock input I 0
18 DATA Data input/output I/O 5.0
19 STB Strobe input I 0
20 OSC IN Oscillation Input I2.4
21 OSC OUT Oscillation Output O2.5
22 KEY 1 Key scan input I0.9
23 KEY 2 Key scan input I0.9
24 KEY 3 Key scan input I1.0
25 KEY 4 Key scan input I1.0
26-
33 SEG1/KS1 - SEG8/KS8 Segment/Key-scan input O3.0
34-
85 SEG9 - SEG60 Segment output O3.0
86-
89 SEG61/COM14 - SEG64/COM11 Segment / common output O3.0
90-
92 (NC) - - -
Pin
No. Port Description I/O Volts (V)
93-
100 COM7 - COM0 Common 7-0 O3.1
7
CQ-ES0470K
